Asus Z87-C User manual

Motherboard
Z87-C

ii
E7869
First Edition
April 2013
Copyright©2013 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
Offer to Provide Source Code of Certain Software
This product contains copyrighted software that is licensed under the General Public License (“GPL”),
under the Lesser General Public License Version (“LGPL”) and/or other Free Open Source Software
Licenses. Such software in this product is distributed without any warranty to the extent permitted by the
applicable law. Copies of these licenses are included in this product.
Where the applicable license entitles you to the source code of such software and/or other additional data,
you may obtain it for a period of three years after our last shipment of the product, either
(1) for free by downloading it from http://support.asus.com/download
or
(2) for the cost of reproduction and shipment, which is dependent on the preferred carrier and the location
where you want to have it shipped to, by sending a request to:
ASUSTeK Computer Inc.
Legal Compliance Dept.
15 Li Te Rd.,
Beitou, Taipei 112
Taiwan
In your request please provide the name, model number and version, as stated in the About Box of the
product for which you wish to obtain the corresponding source code and your contact details so that we
can coordinate the terms and cost of shipment with you.
The source code will be distributed WITHOUT ANY WARRANTY and licensed under the same license as
the corresponding binary/object code.
This offer is valid to anyone in receipt of this information.
ASUSTeK is eager to duly provide complete source code as required under various Free Open Source
Software licenses. If however you encounter any problems in obtaining the full corresponding source
code we would be much obliged if you give us a notication to the email address [email protected], stating
the product and describing the problem (please DO NOT send large attachments such as source code
archives, etc. to this email address).

iii
Contents
Safety information...................................................................................................... iv
About this guide......................................................................................................... iv
Z87-C specications summary ................................................................................. vi
Chapter 1: Product introduction
1.1 Before you proceed ................................................................................... 1-1
1.2 Motherboard overview............................................................................... 1-2
1.3 Central Processing Unit (CPU) ................................................................. 1-4
1.4 System memory ......................................................................................... 1-8
1.5 Expansion slots........................................................................................ 1-23
1.6 Onboard buttons ...................................................................................... 1-25
1.7 Onboard LEDs .......................................................................................... 1-26
1.8 Jumpers ....................................................................................................1-27
1.9 Connectors ............................................................................................... 1-28
1.10 Software support...................................................................................... 1-37
Chapter 2: BIOS information
2.1 Managing and updating your BIOS .......................................................... 2-1
2.2 BIOS setup program .................................................................................. 2-6
2.3 My Favorites ............................................................................................. 2-10
2.4 Main menu ................................................................................................ 2-11
2.5 Ai Tweaker menu...................................................................................... 2-13
2.6 Advanced menu ....................................................................................... 2-25
2.7 Monitor menu ........................................................................................... 2-35
2.8 Boot menu ................................................................................................2-38
2.9 Tools menu ............................................................................................... 2-44
2.10 Exit menu.................................................................................................. 2-46
Appendices
Notices .................................................................................................................... A-1

iv
Safety information
Electrical safety
To prevent electrical shock hazard, disconnect the power cable from the electrical outlet
before relocating the system.
When adding or removing devices to or from the system, ensure that the power cables
for the devices are unplugged before the signal cables are connected. If possible,
disconnect all power cables from the existing system before you add a device.
Before connecting or removing signal cables from the motherboard, ensure that all
power cables are unplugged.
Seek professional assistance before using an adapter or extension cord. These devices
could interrupt the grounding circuit.
Ensure that your power supply is set to the correct voltage in your area. If you are not
sure about the voltage of the electrical outlet you are using, contact your local power
company.
If the power supply is broken, do not try to x it by yourself. Contact a qualied service
technician or your retailer.
Operation safety
Before installing the motherboard and adding devices on it, carefully read all the manuals
that came with the package.
Before using the product, ensure all cables are correctly connected and the power
cables are not damaged. If you detect any damage, contact your dealer immediately.
To avoid short circuits, keep paper clips, screws, and staples away from connectors,
slots, sockets and circuitry.
Avoid dust, humidity, and temperature extremes. Do not place the product in any area
where it may become wet.
Place the product on a stable surface.
If you encounter technical problems with the product, contact a qualied service
technician or your retailer.
About this guide
This user guide contains the information you need when installing and conguring the
motherboard.
How this guide is organized
This guide contains the following parts:
• Chapter 1: Product introduction
This chapter describes the features of the motherboard and the new technology it
supports.
• Chapter 2: BIOS information
This chapter tells how to change system settings through the BIOS Setup menus.
Detailed descriptions of the BIOS parameters are also provided.
•
•
•
•
•
•
•
•
•
•
•
•

v
Where to nd more information
Refer to the following sources for additional information and for product and software
updates.
1. ASUS websites
The ASUS website provides updated information on ASUS hardware and software
products. Refer to the ASUS contact information.
2. Optional documentation
Your product package may include optional documentation, such as warranty yers,
that may have been added by your dealer. These documents are not part of the
standard package.
Conventions used in this guide
To ensure that you perform certain tasks properly, take note of the following symbols used
throughout this manual.
DANGER/WARNING: Information to prevent injury to yourself when trying to
complete a task.
CAUTION: Information to prevent damage to the components when trying to
complete a task
IMPORTANT: Instructions that you MUST follow to complete a task..
NOTE: Tips and additional information to help you complete a task.
Typography
Bold text Indicates a menu or an item to select.
Italics Used to emphasize a word or a phrase.
<Key> Keys enclosed in the less-than and greater-than sign
means that you must press the enclosed key.
Example: <Enter> means that you must press the Enter or
Return key.
<Key1> + <Key2> + <Key3> If you must press two or more keys simultaneously, the key
names are linked with a plus sign (+).

vi
Z87-C specications summary
CPU LGA1150 socket for the 4th Generation Intel®Core™ i7/Intel®Core™i5/
Intel®Core™ i3, Pentium®and Celeron®processors
Supports 22nm CPU
Supports Intel®Turbo Boost Technology 2.0*
*The Intel®Turbo Boost Technology 2.0 support depends on the CPU types.
Chipset Intel®Z87 Express Chipset
Memory 4 x DIMM, max. 32GB, DDR3 2800 (O.C.)* / 2666 (O.C.)* / 2600 (O.C.)*
/ 2500 (O.C.)* / 2400 (O.C.)* / 2200 (O.C.)* / 2133 (O.C.)* / 2000 (O.C.)*
/ 1866 (O.C.)* / 1800 (O.C.)* / 1600 / 1333 MHz, non-ECC, un-buffered
memory
Dual channel memory architecture
Supports Intel® Extreme Memory Prole (XMP)
*Hyper DIMM support is subject to the physical characteristics of individual
CPUs. Please refer to Memory QVL (Qualied Vendors List) for details.
Expansion slots 1 x PCI Express 3.0 x16 slot
1 x PCI Express 2.0 x16 slot* (max. at x4 mode, compatible with PCIe x1
and x4 devices)
2 x PCI Express 2.0 x1 slots
3 x PCI slots
*The PCIe 2.0 x16 slot shares bandwidth with PCIe 2.0 x1_1 slot and PCIe 2.0
x1_2 slot. The PCIe 2.0 x16 slot default setting is in x2 mode.
VGA Integrated Graphics Processor - Intel®HD Graphics support
Multi-VGA output support: D-Sub port/DVI port/HDMI port
Supports HDMI with max. resolution of 4096 x 2304 @24Hz and 2560 x
1600 @60Hz
Supports Intel®InTru™ 3D, Intel® Quick Sync Video, Intel® Clear Video HD
Technology and Intel® Insider™
Supports up to three displays simultaneously
Maximum shared memory 1024MB
Multi-GPU support Supports AMD®Quad-GPU CrossFireX™ Technology
Storage Intel®Z87 Express Chipset with RAID 0, 1, 5, 10 and Intel®
Rapid Storage Technology 12.0 support
- 6 x SATA 6.0 Gb/s ports (yellow)
- Supports Intel®Smart Response Technology, Intel®Rapid Start
Technology, Intel®Smart Connect Technology*
* These functions will work depending on the CPU installed.
LAN Realtek®8111GR Gigabit LAN controller
Audio Realtek® ALC892 8-channel high denition audio CODEC
- Supports jack-detection, multi-streaming and front panel jack-retasking
- Absolute pitch 192khz/24bit true BD lossless sound
- BD audio layer content protection
(continued on the next page)

vii
Z87-C specications summary
USB Intel®Z87 Express Chipset - supports ASUS USB 3.0 Boost
Turbo Mode
- 2 x USB 3.0/2.0 ports at mid-board for front panel support
- 4 x USB 3.0/2.0 ports at rear panel (blue)
- 8 x USB 2.0/1.1 ports (6 ports at mid-board, 2 ports at rear panel)
ASUS Unique
features
ASUS Dual Intelligent Processors 2 with DIGI+ VRM
ASUS DIGI+ VRM
- Industry-leading digital 4-phase power design
- ASUS DIGI+VRM utility
ASUS EPU
- EPU
ASUS TPU
- Auto Tuning, TurboV, GPU Boost
ASUS Exclusive Features:
- Network iControl
- USB 3.0 Boost featuring speedy USB 3.0 transmission
- Disk Unlocker
- AI Suite 3
- Anti Surge
ASUS Quiet Thermal Solution:
- ASUS Fan Xpert 2
- ASUS Fanless Design: Heat-sink solution
ASUS EZ DIY
- ASUS UEFI BIOS EZ Mode
- ASUS O.C. Tuner
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
ASUS Q-Design
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- ASUS Q-Slot
ASUS Exclusive
Overclocking
Features
Precision Tweaker 2
- vCore: Adjustable CPU Core voltage at 0.001V increment
- iGPU: Adjustable CPU Graphics voltage at 0.001V increment
- vCCIO: Adjustable Analog and Digital I/O voltage at 0.001V increment
- vCCIN: Adjustable CPU Input voltage at 0.01V increment
- vCCSA: Adjustable CPU System Agent voltage at 0.001V increment
- vDRAM Bus: Memory voltage control at 0.01V increment
- vPCH: Chipset voltage control at 0.0125V increment
SFS (Stepless Frequency Selection)
- BCLK/PCIE frequency tuning from 80MHz up to 300MHz at 0.1MHz
increment
Overclocking Protection
- ASUS C.P.R. (CPU Parameter Recall)
(continued on the next page)

viii
Z87-C specications summary
Rear Panel I/O Ports 1 x HDMI port
1 x D-Sub port
1 x DVI-D port
1 x LAN (RJ45) port
4 x USB 3.0/2.0 ports (blue)
2 x USB 2.0/1.1 ports
8-channel Audio I/O ports
Internal I/O
connectors
1 x 19-pin USB 3.0/2.0 connector supports additional 2 USB ports
3 x USB 2.0/1.1 connectors support additional 6 USB ports
6 x SATA 6.0 Gb/s connectors (yellow)
1 x 4-pin CPU Fan connector supports both 3-pin (DC mode) and 4-pin
(PWM mode) CPU coolers control
1 x 4-pin CPU Optional Fan connector (CPU_OPT)
3 x 4-pin Chassis Fan connectors
1 x Front panel audio connector (AAFP)
1 x S/PDIF out header
1 x TPM connector
1 x 24-pin EATX Power connector
1 x 8-pin EATX 12V Power connector
System Panel
1 x Clear CMOS jumper
1 x DirectKey button
1 x DirectKey (DRCT) connector
1 x COM port connector
BIOS features 64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 2.7, WfM 2.0, SM BIOS 2.7,
ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS
3, My Favorites, Quick Note, Last Modied Log, F12 PrintScreen function,
F3 Shortcut functions, and ASUS DRAM SPD (Serial Presence Detect)
memory information
Manageability WfM 2.0, DMI 2.7, WOL by PME, PXE
Accessories 2 x Serial ATA 6.0Gb/s cables
ASUS I/O shield
User’s manual
Support DVD
contents
Drivers
ASUS Utilities
EZ Update
Anti-virus software (OEM version)
Form factor ATX form factor: 12 in. x 8.4 in. (30.5 cm x 21.4 cm)
Specications are subject to change without notice.

1-1
Chapter 1: Product introduction
Chapter 1
Product introduction
If any of the items is damaged or missing, contact your retailer.
Thank you for buying an ASUS®Z87-C motherboard!
Before you start installing the motherboard, and hardware devices on it, check the items
in your motherboard package. Refer to the specication list on page viii for the list of
accessories.
1.1 Before you proceed
Take note of the following precautions before you install motherboard components or change
any motherboard settings.
• Unplug the power cord from the wall socket before touching any component.
• Before handling components, use a grounded wrist strap or touch a safely grounded
object or a metal object, such as the power supply case, to avoid damaging them due
to static electricity.
• Hold components by the edges to avoid touching the ICs on them.
• Whenever you uninstall any component, place it on a grounded antistatic pad or in the
bag that came with the component.
• Before you install or remove any component, ensure that the ATX power supply is
switched off or the power cord is detached from the power supply. Failure to do so
may cause severe damage to the motherboard, peripherals, or components.
Chapter 1: Product introduction

ASUS Z87-C
1-2
1.2 Motherboard overview
Before you install the motherboard, study the conguration of your chassis to ensure that the
motherboard ts into it.
Ensure that you unplug the power cord before installing or removing the motherboard.
Failure to do so can cause you physical injury and damage motherboard components.
1.2.1 Placement direction
When installing the motherboard, ensure that you place it into the chassis in the correct
orientation. The edge with external ports goes to the rear part of the chassis as indicated in
the image below.
1.2.2 Screw holes
Place eight screws into the holes indicated by circles to secure the motherboard to the
chassis.
Do not overtighten the screws! Doing so can damage the motherboard.
Place this side towards the
rear of the chassis

1-3
Chapter 1: Product introduction
1.2.3 Motherboard layout

ASUS Z87-C
1-4
1.3 Central Processing Unit (CPU)
The motherboard comes with a surface mount LGA1150 socket designed for the 4th
generation Intel®Core™ i7 / Intel®Core™ i5 / Intel®Core™ i3, Pentium®and Celeron®
processors.
Ensure that all power cables are unplugged before installing the CPU.
Connectors/Jumpers/Slots Page
1. ATX power connectors (24-pin EATXPWR, 8-pin EATX12V) 1-30
2. LGA1150 CPU socket 1-4
3. CPU, CPU optional, and chassis fan connectors (4-pin CPU_FAN,
4-pin CPU_OPT, 4-pin CHA_FAN1-3)
1-32
4. DDR3 DIMM slots 1-8
5. USB 3.0 connector (20-1 pin USB3_12) 1-33
6. Clear RTC RAM jumper 1-27
7. Intel®Z87 Serial ATA 6.0 Gb/s connectors (7-pin SATA6G_1-6 [yellow]) 1-31
8. DRCT (DirectKey) connector (2-pin DRCT) 1-35
9. System panel connector (20-8 pin PANEL) 1-36
10. USB 2.0 connectors (10-1 pin USB910, USB1112, USB1314) 1-34
11. TPM connector (20-1 pin TPM) 1-31
12. DirectKey button 1-25
13. Serial port connector (10-1 pin COM) 1-33
14. Front panel audio connector (10-1 pin AAFP) 1-35
15. Digital audio connector (4-1 pin SPDIF_OUT) 1-29
1.2.4 Layout contents

1-5
Chapter 1: Product introduction
1.3.1 Installing the CPU
• Ensure that you install the correct CPU designed for LGA1150 only. DO NOT install a
CPU designed for LGA1155 and LGA1156 sockets on the LGA1150 socket.
• Upon purchase of the motherboard, ensure that the PnP cap is on the socket and
the socket contacts are not bent. Contact your retailer immediately if the PnP cap
is missing, or if you see any damage to the PnP cap/socket contacts/motherboard
components. ASUS will shoulder the cost of repair only if the damage is shipment/
transit-related.
• Keep the cap after installing the motherboard. ASUS will process Return Merchandise
Authorization (RMA) requests only if the motherboard comes with the cap on the
LGA1150 socket.
• The product warranty does not cover damage to the socket contacts resulting from
incorrect CPU installation/removal, or misplacement/loss/incorrect removal of the PnP
cap.
Ensure that you install the correct CPU designed for LGA1150 socket only. DO NOT install
a CPU designed for LGA1555 and LGA1156 sockets on the LGA1150 socket.

ASUS Z87-C
1-6

1-7
Chapter 1: Product introduction
1.3.2 Installing the CPU heatsink and fan
To install the CPU heatsink and fan assembly
To uninstall the CPU heatsink and fan assembly

ASUS Z87-C
1-8
1.4 System memory
1.4.1 Overview
The motherboard comes with four Double Data Rate 3 (DDR3) Dual In-line Memory Modules
(DIMM) slots.
A DDR3 module is notched differently from a DDR or DDR2 module. DO NOT install a DDR
or DDR2 memory module to the DDR3 slot.
Install one memory module in slot A2 rst as a single-channel operation.
Recommended memory congurations

1-9
Chapter 1: Product introduction
1.4.2 Memory congurations
You may install 2GB, 4GB and 8GB unbuffered and non-ECC DDR3 DIMMs into the DIMM
sockets.
• The default memory operation frequency is dependent on its Serial Presence Detect
(SPD), which is the standard way of accessing information from a memory module.
Under the default state, some memory modules for overclocking may operate at a
lower frequency than the vendor-marked value. To operate at the vendor-marked
or at a higher frequency, refer to section 2.5 Ai Tweaker menu for manual memory
frequency adjustment.
• For system stability, use a more efcient memory cooling system to support a full
memory load (4 DIMMs) or overclocking condition.
• You may install varying memory sizes in Channel A and Channel B. The system maps
the total size of the lower-sized channel for the dual-channel conguration. Any excess
memory from the higher-sized channel is then mapped for single-channel operation.
• According to Intel®CPU spec, DIMM voltage below 1.65V is recommended to protect
the CPU.
• Always install DIMMs with the same CAS latency. For optimum compatibility, we
recommend that you obtain memory modules from the same vendor.
• Due to the memory address limitation on 32-bit Windows®OS, when you install 4GB
or more memory on the motherboard, the actual usable memory for the OS can be
about 3GB or less. For effective use of memory, we recommend that you do any of the
following:
a) Use a maximum of 3GB system memory if you are using a 32-bit Windows® OS.
b) Install a 64-bit Windows®OS when you want to install 4GB or more on the
motherboard.
c) For more details, refer to the Microsoft®support site at http://support.microsoft.
com/kb/929605/en-us.
• This motherboard does not support DIMMs made up of 512Mb (64MB) chips or less
(Memory chip capacity counts in Megabit, 8 Megabit/Mb = 1 Megabyte/MB).

ASUS Z87-C
1-10
DDR3 2666(O.C.) MHz capability
Z87-C Motherboard Qualied Vendors Lists (QVL)
DDR3 2800(O.C.) MHz capability
Vendors Part No. Size SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage DIMM socket
support
(Optional)
1 2 4
ADATA AX3U2600GW8G11-DG2 16GB (2x4GB) DS - - 11-13-13-35 1.65V • • •
DDR3 2600(O.C.) MHz capability
Vendors Part No. Size SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage DIMM socket
support
(Optional)
1 2 4
G.SKILL F3-20000CL10Q-16GBZHD(XMP) 16GB (4x4GB) DS - - 10-11-11-31 1.65 • • •
DDR3 2500(O.C.) MHz capability
Vendors Part No. Size SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage DIMM socket
support (Optional)
1 2 4
G.SKILL F3-2800C11Q-16GTXD(XMP) 16GB (4x4GB) DS - - 11-13-13-35 1.65 • • •
G.SKILL F3-2800C12Q-32GTXD(XMP) 32GB (4x8GB) DS - - 12-13-13-35 1.65 • • •
G.SKILL F3-2800C12Q-32GTXDG(XMP) 32GB (4x8GB) DS - - 12-14-14-35 1.65 • • •
APACER 78.BAGH5.AFD0C 8GB (2x4GB) DS - - 12-14-14-35 1.65 • •
APACER 78.CAGH6.AFD0C 16GB (2x8GB) DS - - 12-14-14-35 1.65 • •
CORSAIR CMD16GX3M4A2800C11 16GB (4x4GB) DS - - 11-14-14-35 1.65 • • •
CORSAIR CMD16GX3M4A2800C12 16GB (4x4GB) DS - - 12-14-14-36 1.65 • • •
Vendors Part No. Size SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage DIMM socket
support (Optional)
1 2 4
APACER 78.BAGFF.AFC0C 16GB (4x4GB) SS - - 12-13-13-35 1.65 • • •
APACER 78.CAGFF.AFD0C 32GB (4x8GB) DS - - 12-13-13-35 1.65 • • •
CORSAIR CMD16GX3M4A2666C11 16GB (4x4GB) DS - - 11-13-13-35 1.65 • • •
G.SKILL F3-2666C11Q-16GTXD(XMP) 16GB (4x4GB) DS - - 11-13-13-35 1.65 • • •
G.SKILL F3-2666C10Q-16GTXD(XMP) 16GB (4x4GB) DS - - 10-12-12-31 1.65 • • •
GEIL GOC332GB2666C11QC(XMP) 32GB (4x8GB) DS - - 11-13-13-35 1.65 • • •
TEAM TXD34G2666HC11CBK 8GB (2x4GB) SS - - 11-13-13-35 1.65 • • •
TEAM TXD38G2666HC11CBK 16GB (2x8GB) DS - - 11-13-13-35 1.65 • •
G.SKILL F3-2666CL10Q-16GBZHD(XMP) 16GB (4x4GB) DS - - 9-11-9-27 1.65 • •

1-11
Chapter 1: Product introduction
DDR3 2400(O.C.) MHz capability
DDR3 2200(O.C.) MHz capability
Vendors Part No. Size SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage DIMM socket
support
(Optional)
1 2 4
G.SKILL F3-17600CL7D-4GBFLS(XMP) 4GB (2x2GB) DS - - 7-10-10-28 1.65 • •
GEIL GET34GB2200C9DC(XMP) 4GB (2x2GB) DS - - 9-10-9-28 1.65 • • •
GEIL GET38GB2200C9ADC(XMP) 8GB (2x4GB) DS - - 9-11-9-28 1.65 • • •
Vendors Part No. Size SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage DIMM socket
support (Optional)
1 2 4
A-DATA AX3U2400GC4G10(XMP) 4GB DS - - 10-12-12-31 1.65 • • •
Apacer 78.BAGFL.AFD0C(XMP) 8GB (2x4GB) DS - - 11-12-12-30 - • • •
Apacer 783BAGF3.AFD0C(XMP) 8GB (2x4GB) DS - - 11-11-11-30 - • • •
CORSAIR CMGTX8(XMP) 8GB (4x2GB) SS - - 10-12-10-30 1.65 • • •
CORSAIR CMZ16GX3M2A2400C10
(Ver4.21)
16GB (2x8GB) DS - - 10-12-12-31 1.65 • • •
CORSAIR CMZ16GX3M4A2400C9R
(Ver4.13)(XMP)
16GB (4x4GB) DS - - 2400 9-11-11-31 1.65 • • •
G.SKILL F3-19200CL10Q-
32GBZHD(XMP)
32GB (4x8GB) DS - - 10-12-12-31 1.65 • • •
G.SKILL F3-19200CL11Q-
16GBZHD(XMP)
16GB (4x4GB) DS - - 11-11-11-31 1.65 • • •
G.SKILL F3-19200CL11Q-
16GBZHD(XMP)
16GB (4x4GB) DS - - 11-11-11-31 1.65 • • •
G.SKILL F3-19200CL9D-
4GBPIS(XMP)
4G (2x2GB) DS - - 9-11-9-28 1.65 • •
G.SKILL F3-19200CL9Q-
16GBZMD(XMP)
16GB (4x4GB) DS - - 9-11-11-31 1.65 • • •
GEIL GOC316GB2400
C10QC(XMP)
16GB (4x4GB) DS - - 10-11-11-30 1.65 • • •
GEIL GOC316GB2400
C11QC(XMP)
16GB (4x4GB) DS - - 11-11-11-30 1.65 • • •
Kingston KHX2400C11D3
K4/8GX(XMP)
8GB (4x2GB) SS - - 11-13-11-30 1.65 • • •
KINGSTON KHX24C11K4/16X(XMP) 16GB (4x4GB) DS - - 11-13-13-30 1.65 • • •
KINGSTON KHX24C11T2K2/8X(XMP) 8GB (2x4GB) DS - - - 1.65 • • •
KINGSTON KHX24C11T3K4/32X(XMP) 32GB (4x8GB) DS - - 9-9-9-24 1.65 • • •
Patriot PVV34G2400C 9K(XMP) 4GB (2x2GB) DS - - 9-11-9-27 1.66 • •
Patriot PXD38G2400C 11K(XMP) 8GB (2x4GB) DS - - 11-11-11-30 1.65 • • •
Patriot PXD38G2400C 11K(XMP) 8GB (2x4GB) DS - - 2400 11-11-11-30 1.65 • • •
Team TXD38G2400HC
10QBK(XMP)
8GB DS - - 10-12-12-31 1.65 • • •

ASUS Z87-C
1-12
DDR3 2133(O.C.) MHz capability
Vendors Part No. Size SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage DIMM socket
support
(Optional)
1 2 4
A-DATA AX3U2133XC4G10(XMP) 4GB DS - - 10-11-11-30 1.65 • • •
A-DATA AX3U2133XW8G10(XMP) 8GB DS - - 10-11-11-30 1.65 • • •
Apacer 78.BAGE4.AFD0C(XMP) 8GB (2x4GB) DS - - 9-9-9-24 - • • •
Apacer AHU04GFB33CAQ3R(XMP) 4GB DS - - 11-13-13-31 - • • •
CORSAIR CMD8GX3M2A2133C9
(Ver1.5)(XMP)
8GB (2x4GB) DS - - 9-11-10-27 1.5 • • •
CORSAIR CMT4GX3M2B2133C9(Ver
7.1)(XMP)
4GB (2x2GB) DS - - 9-10-9-27 1.5 • • •
CORSAIR CMT4GX3M2B2133C9(XMP) 4GB (2x2GB) DS - - 9-10-9-27 1.5 • • •
G.SKILL F3-17000CL11Q2-
64GBZLD(XMP)
64GB (8x8GB) DS - - 11-11-11-30 1.5 • • •
G.SKILL F3-17000CL9Q-
16GBXLD(XMP)
16GB (4x4GB) DS - - 9-11-9-28 1.65 • • •
G.SKILL F3-17000CL9Q-
16GBZH(XMP)
16GB (4x4GB) DS - - 9-11-10-28 1.65 • • •
G.SKILL F3-17066CL9D-
8GBPID(XMP)
8GB (2x4GB) DS - - 9-9-9-24 1.65 • • •
G.SKILL F3-17066CL9Q-
16GBTDD(XMP)
16GB (4x4GB) DS - - 9-9-9-24 1.65 • •
G.SKILL F3-2133C11Q-32GZL(XMP) 32GB (4x8GB) DS - - 11-11-11-31 1.5 • • •
KINGSTON KHX2133C11D3K4/
16GX(XMP)
16GB (4x4GB) DS - - 11-12-11-30 1.65 • • •
KINGSTON KHX2133C11D3T1K2/
16GX(XMP)
16GB (2x8GB) DS - - 9-9-9-24 1.6 • • •
KINGSTON KHX21C11T3FK8/64X(XMP) 64GB (8x8GB) DS - - 9-9-9-24 1.5 • • •
OCZ OCZ3XTEP2133C 9LV4GK 2GB DS - - 7-7-7-20 1.65 • •
Patriot PV316G213C1K (XMP) 16GB (2x8GB) DS - - 11-11-11-30 1.5 • • •
Patriot PVV34G2133C9 K(XMP) 4GB (2x2GB) DS - - 9-11-9-27 1.66 • • •
Patriot PXD38G2133C1 1K(XMP) 8GB (2x4GB) DS - - 9-9-9-24 1.65 • • •
Patriot PXD38G2133C11 K(XMP) 8GB (2x4GB) DS - - 2133 11-11-11-27 1.5 • • •
Team TLD38G2133HC11A BK(XMP) 8GB DS - - 11-11-11-31 1.65 • • •
Team TXD34096M2133HC11A-
V(XMP)
4GB DS - - 11-11-11-31 1.65 • • •
