Asus Asmb2 User manual

ASMB2

Server Management Board

iiii

E2244E2244

E2244

First edition V1First edition V1

First edition V1

November 2005November 2005

November 2005

No part of this manual, including the products and software described in it, may be reproduced,

transmitted, transcribed, stored in a retrieval system, or translated into any language in any form

or by any means, except documentation kept by the purchaser for backup purposes, without the

express written permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modified or

altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the

serial number of the product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR

IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS

DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS

OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS

HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR

ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR

INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND

SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY

OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL,

INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered

trademarks or copyrights of their respective companies, and are used only for identification or

explanation and to the owners’ benefit, without intent to infringe.

iiiiii

iii

Contents

Notices ................................................................................................. v

Safety information .............................................................................. vi

About this guide ................................................................................ vii

ASMB2 specifications summary .......................................................... ix

Chapter 1:Chapter 1:

Chapter 1: Product introductionProduct introduction

Product introductionProduct introduction

Product introduction

1.1 Welcome! .............................................................................. 1-2

1.2 Package contents ................................................................. 1-2

1.3 Board layout ......................................................................... 1-3

1.4 System requirements ........................................................... 1-3

1.5 Network setup ...................................................................... 1-4

Chapter 2: InstallationChapter 2: Installation

Chapter 2: Installation

2.1 Before you proceed .............................................................. 2-2

2.2 Hardware installation ............................................................ 2-2

2.3 Firmware update................................................................... 2-5

2.3.1 For motherboards without ASF function support ... 2-5

2.3.2 For motherboards with ASF function support ........ 2-5

2.4 BIOS remote console ............................................................ 2-6

2.5 ASMB2 configuration ............................................................ 2-7

2.5.1 Running the BIOS IPMI configuration ....................... 2-7

2.5.2 Running the ASMC utility ...................................... 2-10

2.5.3 Configuring the LAN controller ............................. 2-11

2.5.4 Using ASWM to update the ASMB2 firmware ....... 2-13

2.6 Software installation .......................................................... 2-14

2.6.1 Installing the ARC ................................................. 2-14

2.6.2 Launching ARC ...................................................... 2-15

iviv

Contents

Chapter 3: Software supportChapter 3: Software support

Chapter 3: Software support

3.1 ASUS Remote Console (ARC) ............................................... 3-2

3.1.1 ARC sections .......................................................... 3-3

3.1.2 Connecting to the remote server ........................... 3-6

3.1.3 Retrieving sensor information ................................. 3-8

3.1.4 Displaying FRU information ................................... 3-10

3.1.5 Displaying system event logs ............................... 3-11

3.1.6 Using Remote Console .......................................... 3-12

3.1.7 Displaying all remote server sensors .................... 3-13

3.1.8 Adjusting the monitoring settings ........................ 3-14

3.1.9 Updating the remote server BIOS file ................... 3-16

3.1.10 Controlling the remote server power ................... 3-17

3.1.11 Viewing PET information ....................................... 3-18

3.2 ASUS Host Management Controller Setup .......................... 3-21

3.2.1 Installing and launching the ASUS Host

Management Controller Setup utility .................... 3-21

3.2.2 Command fields .................................................... 3-22

3.2.3 Initial ..................................................................... 3-22

3.2.4 View ...................................................................... 3-22

3.2.5 Set ........................................................................ 3-25

3.2.6 Monitor ................................................................. 3-26

3.2.7 Help ...................................................................... 3-26

Appendix:Appendix:

Appendix: Reference informationReference information

Reference informationReference information

Reference information

A.1 LAN port for server management ........................................ A-2

A.2 BMC socket ........................................................................... A-3

A.3 Troubleshooting ................................................................... A-5

Notices

Federal Communications Commission StatementFederal Communications Commission Statement

Federal Communications Commission Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to

the following two conditions:

•

This device may not cause harmful interference, and

•

This device must accept any interference received including interference

that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with

manufacturer’s instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment to an outlet on a circuit different from that to

which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

Canadian Department of Communications StatementCanadian Department of Communications Statement

Canadian Department of Communications Statement

This digital apparatus does not exceed the Class B limits for radio noise

emissions from digital apparatus set out in the Radio Interference

Regulations of the Canadian Department of Communications.

This class B digital apparatus complies with CanadianThis class B digital apparatus complies with Canadian

This class B digital apparatus complies with Canadian

ICES-003.ICES-003.

ICES-003.

The use of shielded cables for connection of the monitor to the graphics

card is required to assure compliance with FCC regulations. Changes or

modifications to this unit not expressly approved by the party

responsible for compliance could void the user’s authority to operate

this equipment.

vivi

Safety information

Electrical safetyElectrical safety

Electrical safety

•

To prevent electrical shock hazard, disconnect the power cable from

the electrical outlet before relocating the server.

•

When adding or removing devices to or from the server, ensure that

the power cables for the devices are unplugged before the signal cables

are connected. If possible, disconnect all power cables from the existing

server before you add a device.

•

Before connecting or removing signal cables from the server, ensure

that all power cables are unplugged.

•

Seek professional assistance before using an adapter or extension cord.

These devices could interrupt the grounding circuit.

•

Make sure that your power supply is set to the correct voltage in your

area. If you are not sure about the voltage of the electrical outlet you

are using, contact your local power company.

•

If the power supply is broken, do not try to fix it by yourself. Contact a

qualified service technician or your retailer.

Operation safetyOperation safety

Operation safety

•

Before installing any component to the server, carefully read all the

manuals that came with the package.

•

Before using the product, make sure all cables are correctly connected

and the power cables are not damaged. If you detect any damage,

contact your dealer immediately.

•

To avoid short circuits, keep paper clips, screws, and staples away from

connectors, slots, sockets and circuitry.

•

Avoid dust, humidity, and temperature extremes. Do not place the

product in any area where it may become wet.

•

Place the product on a stable surface.

•

If you encounter technical problems with the product, contact a qualified

service technician or your retailer.

viivii

vii

About this guide

This user guide contains the information you need when installing and

configuring the server management board.

How this guide is organizedHow this guide is organized

How this guide is organized

This guide contains the following parts:

••

•Chapter 1: Product introductionChapter 1: Product introduction

Chapter 1: Product introductionChapter 1: Product introduction

Chapter 1: Product introduction

This chapter describes the server management board features and the

new technologies it supports.

••

•Chapter 2: InstallationChapter 2: Installation

Chapter 2: InstallationChapter 2: Installation

Chapter 2: Installation

This chapter provides instructions on how to install the board to the

server system and install the utilities that the board supports.

••

•Chapter 3: Software supportChapter 3: Software support

Chapter 3: Software supportChapter 3: Software support

Chapter 3: Software support

This chapter tells you how to use the software applications that the

server management board supports.

••

•Appendix: TroubleshootingAppendix: Troubleshooting

Appendix: TroubleshootingAppendix: Troubleshooting

Appendix: Troubleshooting

The Appendix shows the location of the LAN port for server

management and BMC socket on several motherboards. This section

also presents common problems that you may encounter when

installing or using the server management board.

Where to find more informationWhere to find more information

Where to find more information

Refer to the following sources for additional information and for product

and software updates.

1.1.

1. ASUS websitesASUS websites

ASUS websitesASUS websites

ASUS websites

The ASUS website provides updated information on ASUS hardware

and software products. Refer to the ASUS contact information.

2.2.

2. Optional documentationOptional documentation

Optional documentationOptional documentation

Optional documentation

Your product package may include optional documentation, such as

warranty flyers, that may have been added by your dealer. These

documents are not part of the standard package.

viiiviii

viii

TypographyTypography

Typography

Bold textBold text

Bold text Indicates a menu or an item to select.

Italics

Used to emphasize a word or a phrase.

<Key> Keys enclosed in the less-than and greater-than sign means

that you must press the enclosed key.

Example: <Enter> means that you must press the Enter or

Return key.

<Key1+Key2+Key3> If you must press two or more keys simultaneously, the

key names are linked with a plus sign (+).

Example: <Ctrl+Alt+D>

Command Means that you must type the command exactly as shown,

then supply the required item or value enclosed in

brackets.

Example: At the DOS prompt, type the command line:

format a:

DANGER/WARNING:DANGER/WARNING:

DANGER/WARNING: Information to prevent injury to yourself

when trying to complete a task.

CAUTION:CAUTION:

CAUTION: Information to prevent damage to the components

when trying to complete a task.

NOTE:NOTE:

NOTE: Tips and additional information to help you complete a

task.

IMPORTANT:IMPORTANT:

IMPORTANT: Instructions that you MUST follow to complete a

task.

Conventions used in this guideConventions used in this guide

Conventions used in this guide

To make sure that you perform certain tasks properly, take note of the

following symbols used throughout this manual.

ixix

ASMB2 specifications summary

Specifications are subject to change without notice.

IPMIIPMI

IPMI

featuresfeatures

features

CPUCPU

CPU

ChipsetChipset

Chipset

Internal RAMInternal RAM

Internal RAM

Internal ROMInternal ROM

Internal ROM

InterruptInterrupt

Interrupt

TimersTimers

Timers

SystemSystem

System

InterfaceInterface

Interface

Serial/ModemSerial/Modem

Serial/Modem

InterfaceInterface

Interface

LAN InterfaceLAN Interface

LAN Interface

LEDLED

LED

BusBus

Bus

FeaturesFeatures

Features

SoftwareSoftware

Software

supportsupport

support

IPMI 2.0-compliant and supports:

- Auto monitoring sensor and event logging

- IPMI Host I/O interface

- Receiving and logging of event messages

- IPMB/I

C system interface

- System Watchdog Timer (ASR)

16-bit H8S/2000 core 33 MHz

Renesas H8S/2168

40 KB

256 KB

C, Timer, UART, LPC

16-bit system timer

Watchdog timer

Low Pin Count

Supports Keyboard Controller Style (KCS)

Basic Mode

IPMI 2.0 Shared LAN

BMC heartbeat

Two I

C bus

One IPMB bus

Two UART bus

Remote power on/off

Remote BIOS update

Short Message Service (SMS)

Remote Console Redirection (text mode)

Serial-Over-LAN (SOL)

Remote reboot

Upgradeable firmware

Platform Event Trap (PET)

ASUS Remote Console (ARC)

ASUS Host Management Controller Utility (DOS-based)

Product

introduction

This chapter describes the server

management board features and the new

technologies it supports.

1-21-2

1-2 Chapter 1: Product introductionChapter 1: Product introduction

Chapter 1: Product introductionChapter 1: Product introduction

Chapter 1: Product introduction

1.1 Welcome!

Thank you for buying an ASUSThank you for buying an ASUS

Thank you for buying an ASUS

®®

ASMB2 server managementASMB2 server management

ASMB2 server management

board!board!

board!

The ASUS ASMB2 is an Intelligent Platform Management Interface (IPMI)

2.0-compliant board that allows you to monitor, control, and manage a

remote server from the local or central server in your local area network

(LAN).

The ASMB2 comes with the proprietary ASUS Remote Console (ARC)

application that offers round-the-clock remote server monitoring through

the component sensors. With ARC, you can monitor the remote server

CPU(s) temperature(s), system temperature, fan rotations, and power

supply voltages. The ASMB2 records each remote server system event for

accurate and efficient troubleshooting.

ARC allows you to update the remote server system BIOS file when it gets

outdated or corrupted. It also lets you move through the BIOS file menus

using the Remote Console Redirection feature. To keep you always

informed of the remote server system status, ARC is also capable of

sending Short Message Service (SMS) or text message to your mobile or

PDA phone.

The ASMB2 comes with a power management feature that allows you to

power on/off or reset the remote server giving you full control during

power-critical situations. The server management board also comes with a

Field Replaceable Unit (FRU) information feature that gathers information

on replaceable system components or modules such as the motherboard or

backplane model name, serial number, manufacturer, etc. You can use the

FRU information when reporting and/or replacing server system

components.

Before you start installing the server management board check the items in

your package with the list below.

If any of the above items is damaged or missing, contact your retailer.

1.2 Package contents

Check your server management board package for the following items.

ASUS ASMB2 board

Support CD

User guide

ASUS ASMB2ASUS ASMB2

ASUS ASMB2 1-31-3

1-31-3

1-3

1.3 Board layout

The ASUS ASMB2 comes in a BMC package. The illustration below shows

the major components of the server management board.

LED indicatorsLED indicators

LED indicators

The ASMB2 board comes with a BMC heartbeat LED. Refer to the table

below for the LED indications.

1.4 System requirements

Before you install the ASMB2 board, check if the remote server system

meets the following requirements:

• ASUS server motherboard with Baseboard Management Controller

(BMC) socket*

• LAN (RJ-45) port for server management**

• Microsoft

Internet Explorer 5.5 or later

* Visit the ASUS website (www.asus.com) for an updated list of server

motherboards that support the ASMB2.

** See the Appendix for details.

LEDLED

LED NameName

NameName

Name StatusStatus

StatusStatus

Status DescriptionDescription

DescriptionDescription

Description

LED1LED1

LED1 BMCBMC

BMCBMC

B M C Blinking ASMB2 firmware is in execution.

HeartbeatHeartbeat

Heartbeat Off The ASMB2 firmware is corrupted or the

server system standby-power is off.

Board connectorsBoard connectors

Board connectors

ServerServer

Server

managementmanagement

management

chipchip

chip

BMC heartbeatBMC heartbeat

BMC heartbeat

LEDLED

LED

1-41-4

1-4 Chapter 1: Product introductionChapter 1: Product introduction

Chapter 1: Product introductionChapter 1: Product introduction

Chapter 1: Product introduction

1.5 Network and smart phone setup

The ASMB2 server management board installed on the remote server

connects to a local/central server via direct LAN connection or through a

network hub. Below are the supported server management configurations.

Remote hostRemote host

Remote host

with ASMB2with ASMB2

with ASMB2

Local host withLocal host with

Local host with

ASUS RemoteASUS Remote

ASUS Remote

Controller (ARC)Controller (ARC)

Controller (ARC)

Hub or routerHub or router

Hub or router

Direct LAN connectionDirect LAN connection

Direct LAN connection

LAN connection through a network hubLAN connection through a network hub

LAN connection through a network hub

Remote hostRemote host

Remote host

with ASMB2with ASMB2

with ASMB2

RJ-45 cableRJ-45 cable

RJ-45 cable

Local host withLocal host with

Local host with

ASUS RemoteASUS Remote

ASUS Remote

Controller (ARC)Controller (ARC)

Controller (ARC)

USBUSB

USB

cablecable

cable

USBUSB

USB

cablecable

cable

ASUS ASMB2ASUS ASMB2

ASUS ASMB2 2-12-1

2-12-1

2-1

Installation

This chapter provides instructions on

how to install the board to the server

system and install the utilities that the

board supports.

2-22-2

2-2 Chapter 2: InstallationChapter 2: Installation

Chapter 2: InstallationChapter 2: Installation

Chapter 2: Installation

2.2 Hardware installation

To install the server management board:

1. Remove the remote server

system cover, then locate the

Baseboard Management

Controller (BMC) socket on the

motherboard.

2.1 Before you proceed

Take note of the following precautions before you install the server

management board to the remote server system.

• Unplug the server system power cord from the wall socket before

touching any component.

• Use a grounded wrist strap or touch a safely grounded object or to

a metal object, such as the power supply case, before handling

components to avoid damaging them due to static electricity.

• Hold components by the edges to avoid touching the ICs on them.

• Whenever you uninstall any component, place it on a grounded

antistatic pad or in the bag that came with the component.

•Before you install or remove any component, ensureBefore you install or remove any component, ensure

Before you install or remove any component, ensureBefore you install or remove any component, ensure

Before you install or remove any component, ensure

that the power supply is switched off or the powerthat the power supply is switched off or the power

that the power supply is switched off or the power

cord is detached from the power supply.cord is detached from the power supply.

cord is detached from the power supply. Failure to do so

may cause severe damage to the motherboard, peripherals, and/or

components.

2. Position the board at a 30º-45º

angle, then match the notch on

the board with the break on the

socket.

3. Carefully push the board to the

socket until its connectors

(golden fingers) are

fully-inserted to the socket.

Refer to the Appendix

section for the location of

the BMC socket on supported

motherboards.

ASUS ASMB2ASUS ASMB2

ASUS ASMB2 2-32-3

2-32-3

2-3

4. Press the board firmly until the

BMC socket retaining clips snap

back and secure the board in

place.

When installed, the board

appears as shown.

5. Reinstall the server system cover, then connect the power plug to a

grounded wall socket.

6. Insert the LAN cable plug to the LAN port for server management.

Refer to the Appendix for the location of the LAN port for server

management on various server motherboards.

7. For direct LAN configuration, connect the other end of the LAN cable

to the local/central server LAN port.

For connection to a network hub or router, connect the other end of

the LAN cable to the network hub or router.

2-42-4

2-4 Chapter 2: InstallationChapter 2: Installation

Chapter 2: InstallationChapter 2: Installation

Chapter 2: Installation

To uninstall the board:

1. Simultaneously push the BMC

socket retaining clips outward

until the board tilts up.

2. Carefully pull the board out

from the BMC socket, then set

aside.

ASUS ASMB2ASUS ASMB2

ASUS ASMB2 2-52-5

2-52-5

2-5

2.3 Firmware update

You need to update the Broadcom

IPMI and ASMB2 firmware before you

start using the ASMB2 board.

2.3.12.3.1

2.3.1 For motherboards without ASF functionFor motherboards without ASF function

For motherboards without ASF functionFor motherboards without ASF function

For motherboards without ASF function

supportsupport

support

To update the firmware:

1. Insert the support CD into the optical drive.

2. Restart the remote server, then press <Del> during POST to enter the

BIOS setup.

3. Go to BootBoot

BootBoot

Boot menu and set the Boot Device Priority item to [CD-ROM].

4. When finished, press <F10> to save your changes and exit the BIOS

setup.

5. On reboot, the main menu appears. Type bb

a> FreeDOS command prompt

b> Broadcom IPMI Firmware Update

c> ASMB2 Firmware Update

Please choose a to c:

6. A screen confirming whether or not you want to update the firmware

appears. Press <Y> to update; otherwise, press <N>.

7. After the update, the screen goes back to the main menu. Type cc

8. A screen confirming whether or not you want to update the firmware

appears. Press <Y> to update; otherwise, press <N>.

9. When the update is complete, turn off the system and unplug the AC

power cord.

2.3.22.3.2

2.3.2 For motherboards with ASF function supportFor motherboards with ASF function support

For motherboards with ASF function supportFor motherboards with ASF function support

For motherboards with ASF function support

To update the firmware:

1. Follow steps 1 ~ 4 of the previous section.

2. On reboot, the main menu appears. Type cc

a> FreeDOS command prompt

b> Broadcom ASF Firmware Update

c> Broadcom IPMI Firmware Update

d> ASMB2 Firmware Update

Please choose a to d:

3. A screen confirming whether or not you want to update the firmware

appears. Press <Y> to update; otherwise, press <N>.

4. After the update, the screen goes back to the main menu. Type dd

5. A screen confirming whether or not you want to update the firmware

appears. Press <Y> to update; otherwise, press <N>.

6. When the update is complete, turn off the system and unplug the AC

power cord.

2-62-6

2-6 Chapter 2: InstallationChapter 2: Installation

Chapter 2: InstallationChapter 2: Installation

Chapter 2: Installation

2.4 BIOS remote console

You need to adjust the Remote AccessRemote Access

Remote AccessRemote Access

Remote Access settings in the BIOS setup of the

remote server for correct configuration and connection to the cental server.

Update the remote server BIOS file following the instructions in the

motherboard/system user guide. Visit the ASUS website

(www.asus.com) to download the latest BIOS file for the motherboard.

To adjust the Remote Access settings:

1. Restart the remote server, then press <Del> during POST to access

the BIOS setup.

2. Go to the ServerServer

ServerServer

Server menu, select the Remote Access Configuration sub-

menu, then press <Enter>.

3. Enable Remote AccessRemote Access

Remote AccessRemote Access

Remote Access, then set the following sub-menu items:

•Serial Port NumberSerial Port Number

Serial Port NumberSerial Port Number

Serial Port Number to [COM2]

•BaudrateBaudrate

BaudrateBaudrate

Baudrate to [57600]

•Terminal TypeTerminal Type

Terminal TypeTerminal Type

Terminal Type to [VT-UTF8]

•Media TypeMedia Type

Media TypeMedia Type

Media Type to [Serial]

Select Screen

Select Item

+- Change Option

F1 General Help

F10 Save and Exit

ESC Exit

BIOS SETUP UTILITY

Server

Select Remote Access

type.

Configure Remote Access type and parameters

Remote Access [Enabled]

Serial Port Number [COM2]

Baudrate [57600]

Flow Control [None]

Redirection After BIOS POST [Always]

Terminal Type [VT-UTF8]

Media Type [Serial]

4. Press <Esc>, then select IPMI ConfigurationIPMI Configuration

IPMI ConfigurationIPMI Configuration

IPMI Configuration sub-menu from the

ServerServer

Server menu.

5. Use this sub-menu to adjust the remote server LAN settings or view

the System Event Log (SEL).

6. When finished, press <F10> to save your changes and exit the BIOS

setup.
