AT&T Smart Trac 05000 User manual

Power LED
Volume keys
Pair button
Reset button
USB Charging port
Talkback microphone
Power LED
Speaker
User Guide
Smart Trac™
Digital Audio Monitor
Sound and Volume
Indicator Lights
Power and
Screen On/Off
On back:
• Stand
•Belt Clip
Select
Navigation
Speaker
Pair button
Microphone
On back:
•AC port
Power On/Off switch
Model Number: 05000
1

mhealth
What’s mHealth?
mHealth, or mobile health, is the use of mobile
devices to aid in health and wellness.
Whether you want to keep track of feedings and
diapers or monitor medicines and sleep patterns,
withAT&T mHealth, you can quickly and easily keep all
these data in the palm of your hand.
AT&T’s line of mHealth monitors are designed to keep
you and your baby connected and collect their key
milestones and events.
Welcome to your Smart Trac Monitor
What’s Included?
Parent
Monitor (1x) Baby Unit (1x)
USB power
adapter for
rechargeable
battery (1x)
AC power
adapter (1x)
Cord Clips (6x)
Using your Audio Monitor
Placement 3 ft.
Place Baby Unit on a flat surface and use cord clips.
To prevent entanglement, any cord must be 3 feet
away from children’s reach.
WARNING!
Strangulation Hazard: Children
have STRANGLED in cords.
Keep this cord out of the reach
of children (more than 3 ft.
(0.9 m) away).
Connecting Parent and Baby Unit
1. Connect Baby Unit to power outlet using AC
power adapter provided.
2. Turn on Baby Unit by sliding Power switch to right;
Power LED illuminates. To turn off, slide Power
switch to left; Power LED is off.
3. Charge Parent Monitor before first use or when
Parent Monitor indicates that battery is low.
4. Turn on Parent Monitor by holding Power button
for 3 seconds, Power LED illuminates. The Parent
Monitor will link to Baby Unit and signal bars will
display on screen. To turn off, hold Power button
for 3 seconds. Power LED is off.
5. Audio Monitor is now ready to use.
2

Using your Audio Monitor
Screen On/Off
This feature allows you to turn the monitor screen off
while still hearing audio from the Baby Unit. Simply
press the Screen On/Off button for one second to
turn the screen on or off.
Important: When the monitor is in battery mode, the
screen will automatically turn off after 8 minutes; this
helps to conserve battery power. To turn screen back
on, press the Screen On/Off button for one second.
Charging the Battery
The Parent Monitor has an internal, non-replaceable,
Li-ion rechargeable battery. Charge the battery by
connecting the Parent Monitor to a power outlet using
the USB power adapter provided. Battery Indicator:
Flashes when battery is low; needs to be charged
1/4 3/4
Battery charge Battery charge
1/2 Full
Battery charge Battery charge
Bars animate; battery charging
Stand
The back of Parent Monitor features a flip-out stand
that keeps monitor at ideal viewing angle on flat
surfaces.
Talk Back
With both units on, push and hold the Talk button on
the Parent Monitor. Your baby will hear what you are
saying until you release the Talk button.
Sound Indicator Lights and Volume
The Sound Indicator Lights on the Parent Monitor
serve two purposes:
1. The default shows the level of sound coming into
the monitor from the Baby Unit. A quiet baby =
green lights; a loud baby = red lights.
2. When the Volume Keys (+) (-) are pressed, the
lights briefly show the volume level that comes
out of speaker in the Parent Monitor; there are 6
volume levels.
QUIET
LOUD
Baby Tracker Overview
You can keep track of Feedings (Breast/ Bottle),
Diapers, Sleep, and Medicines while using the Baby
Tracker. Use Mode button to move between the
categories and Select button to select them. Use
Start/Stop for Sleep and Breastfeeding timers and to
log a time for any data entry.
Time
Baby Unit Battery
signal
Baby Name
and Age
display
Memory (wk. or mo.)
accesses
past inputs
Start/Stop
controls
timers and
logs start
Mode time
navigates
categories
Navigation
Select
3

Setup
Set Time
1. Use Mode button to highlight Settings
and press Select button to select. Screen
displays“SET TIME” and hour digits flash.
2. Use Up/Down buttons to increase.
Use Right button to advance.
3. Minute digits flash. Use Up/Down buttons to
increase. Use Right button to advance.
4. AM/PM flashes. Use Up/Down buttons to
change. Use Right button to Save and
5. advance to Set Date.
Set Date
1. Screen displays “SET DATE” and the month digits
flash.
2. Use Up/Down buttons to increase.
Use Right button to advance.
3. The day digits flash. Use Up/Down buttons to
Set Baby Birthday
1. Screen displays “BABY BDAY” and the month
digits flash.
2. Use Up/Down buttons to increase.
Use Right button to advance.
3. The day digits flash. Use Up to increase. Use
Right button to Save and advance
to Baby Name.
Set Baby Name
1. Screen displays “BABY NAME” and the first letter
flashes.
2. Use Up/Down buttons to change letters.
Use Right button to move characters.
Use the “Blank Letter” to remove characters.
Press Memory to Save.
increase. Use Right button to Save and advance
to Baby Birthday.
4

Edit Settings
All information you have entered and saved during
Setup can be edited in Settings Mode.
Editing Time, Date, Baby Birthday, and Baby Name is
done in the same way as in Setup.
1. Select Settings, screen displays “SET TIME”
and hour digits flash.
2. Use Right to advance between the fields (Time,
Date, Baby Bday, and Baby Name.)
Use Navigation buttons to edit numbers and
letters within a field.
3. Once desired changes are made, press Memory
to Save.
Use
Feeding - Breast
1. Change display to Feeding and press
Select button to select. Screen displays the
last data saved, or it displays “L 00 min”.
2. Toggle “L” (left breast), “R” (right breast), or “b”
(bottle) by using the Left/Right buttons.
3. Press Start/Stop to start the timer counting.
“Start” will flash while timer is actively running.
Note: Other data cannot be entered while a timer
is running.
4. Press Start/Stop to stop the timer; press
Memory to save.
Note: Entries less than 1 minute will not save.
Feeding - Bottle
1. Within Feeding, Toggle “L” (left breast), “R”
(right breast), or “b” (bottle) using
Left/Right buttons.
2. Select “b” for bottle; “00” flashes.
3. Use Up/Down to change the number of ounces
consumed.
4. Press Start/Stop to log time of feeding; press
Memory to save the entry.
Diapers
1. Change display to Diapers and press Select
button to select. Screen displays the last data
saved, or it displays“00” Wet “00” BM.
2. Wet “00” flashes. Use Up/Down buttons to
change. Use Left/Right buttons to toggle.
3. BM “00” flashes. Use Up/Down to change.
4. Press Start/Stop to log the time; press
Memory to save.
5

Sleep
Sleep
1. Change display to Sleep and press Select
button to select. Screen displays the last data, or it
displays “0 00” and “Duration”.
2. Press Start/Stop to start the timer counting.
“Start” will flash while timer is actively running.
Note: Other data cannot be entered while a timer
is running.
3. Press Start/Stop to stop the timer; press Memory
to save.
Note: Entries less than 1 minute will not save.
Medicines
Medicines mode allows you to set an alert reminding
you when to provide the next dose.
It also saves that alert in Memory.
1. Change display to Medicines and press Select
button to select. Screen displays the last data
saved, or it displays “min” and “00” flashes.
2. Use Left/Right buttons to toggle to hours.
Use Up/Down to set medicine alert.
3. Press Start/Stop to log the current time.
4. Press Memory to save.
5. Press Start/Stop to turn off alert once it has
sounded.
Memory
Baby Tracker holds 12 inputs for Feeding, Sleep and
Medicines, as well as the last 14 inputs for Diapers.
While in a certain category (e.g. Feeding), press
Memory to see past saved data. “Memory” will show in
the upper left when viewing past saved data.
Use Left/Right buttons to move through past
entries.
Press Select to exit Memory and start a new entry in
the category you have selected or press Mode to exit
memory and navigate to a different category.
6

Cleaning and Care Trouble Shooting (continued)
To clean your Audio Monitor, disconnect all cables Lost Signal (out of range)
and turn off . Use a soft, lint-free cloth. Avoid
getting moisture in openings. Do not use cleaning
solutions or compressed air.
Keep your Audio Monitor away from direct
sunlight, as well as hot or humid areas. Do not let
the product get wet.
Technical Specifications
Parent Monitor (MOD:05000-02) Baby Unit
• Freq: Digital 2.4 GHz (MOD: 05000-01)
• Display: 2.9” diagonal TFT LCD • Freq: Digital 2.4 GHz
• Pwr Input: 100-240V~50-60Hz 0.2A • Pwr Input: 100-240V
• Pwr Output: 5V-500mA ~50-60Hz 0.2A
• Battery: Lithium-ion 3.7V 750mAh • Pwr Output:
• Volume Control: 6 levels 5V-500mA
Trouble Shooting
No Sound
Are the Parent Monitor and Baby Unit plugged in to
a working electrical outlet?
• Make certain any light switches that control power
to the wall outlet are on.
• Check for pinched power cords.
Are Parent Monitor and Baby Unit turned on?
• To turn Parent Monitor on, press and hold
Power button for 3 seconds.
• To turn Baby Unit on, slide Power switch to
right. Power LED illuminates.
• The battery of Parent Monitor needs
to be recharged.
• Parent Monitor is too far from the Baby Unit.
• The Volume is too low (volume is turned down).
Audio Feedback
• The units may be too close, move Parent Monitor
further away from Baby Unit.
• Find the noise source in the baby’s room. Remove
source or move the Baby Unit away from noise.
• The Volume may be too high.
• Make certain that Baby Unit is turned on; the
green Power LED is lit.
• Parent Monitor may be too far from the Baby Unit,
bring Monitor closer to Baby Unit.
• Ensure that Parent Monitor and the Baby Unit
are away from obstacles that may interfere with
signal such as walls, floors, ceilings, Wi-Fi routers,
microwave ovens, cordless phones, Bluetooth
devices, home computers, and other electronic
devices. It is recommended to keep your Audio
Monitor at least 5 ft. away from these types of
devices . If signal is weak, try moving Parent
Monitor and the Baby Unit to different places in
the rooms.
Connection Lost (pairing)
The Parent Monitor and Baby Unit are already paired.
In the event that the connection is lost, you will notice
that the Baby Unit signal bars disappear. You will need
to pair the Baby Unit to the Parent Monitor. To pair,
follow these steps:
1. Bring Parent Monitor and Baby Unit within arm’s
reach.
2. Press the Pair button located on top of the Baby
Unit; the Power LED will blink for 12 seconds.
3. While the LED is blinking, use a paper clip to press,
for one second, the Pair button on the side of the
Parent Monitor; you will hear a beep sound. The
signal bars will reappear on the screen indicating
that the units are paired.
Parent Monitor Not responding
In the event that Parent Monitor and the Baby Unit are
paired, but the Monitor’s buttons are not responding,
you may need to do a soft factory reset. To reset, use
a paper clip to press and hold the Reset button on the
side of the Parent Monitor - which will then turn off. To
turn on, hold the Power button for 3 seconds.
Note: Data saved to memory will remain on unit.
7

Important Safety Instructions
CAUTION: Keep small parts out of
the reach of children.
To prevent cord entanglement and strangulation:
• Do not place the Baby Unit or AC adapter cord
within reach of children.
• Do not place the Baby Unit or AC adapter cord in,
or attach to, a crib or playpen.
• Always use enclosed Cord Clips to help secure
Baby Unit AC adapter cord away from
children’s reach.
• Never use extension cords with AC adapters.
• Use only AC adapters provided.
• Adult assembly is required. Keep small parts away
from child’s reach.
• This product is not a toy. Do not allow children to
play with it.
• This Audio Monitor is not a substitute for
responsible adult supervision.
• Test the Audio Monitor and all its functions so that
you are familiar with it prior to actual use.
• When the power adapter is plugged into an
electrical outlet, do not touch exposed end.
CAUTION: Risk of heat generation,
fire, or explosion.
Li-ion battery is built into the product.
• Charge the product by the designated
charging method.
• Do not place the product in or near fire, or put the
product in a microwave.
• Do not expose the product to high temperatures
above 140 F.
• Do not disassemble the product.
• Do not expose the product to excessive shock
such as dropping from a high place.
• Keep the product dry.
• Dispose of the product appropriately.
FCC - Part 15
This device complies with part 15 of the FCC Rules.
Operation is subject to the following 2 conditions: (1)
this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Warning: Changes or modifications to this unit not
expressly approved by the party responsible for
compliance could void the user’s authority to operate
the equipment.
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not
occur in a particular installation. If this equipment
does cause harmful interference to radio or can be
determined by turning the equipment off and on, the
user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase distance between equipment
and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
To ensure safety of users, the FCC has established
criteria for the amount of radio frequency energy
that can be safely absorbed by a user or bystander
according to the intended usage of the product.
Radiation Exposure Statement
This equipment complies to FCC radiation exposure
limits set forth for an uncontrolled environment.
The baby unit shall be installed and used such that
parts of the user’s body other than the hands are
maintained at a distance of approximately 20 cm
(8 in.) or more.
8

Warranty
Baby Monitor & Accessory Limited Warranty
The AT&T brands are used under license. Thank
you for purchasing this AT&T branded product
manufactured under license by Baby’s Journey,
Inc. (“Baby’s Journey”). Any repair, replacement or
warranty service, and all questions about this AT&T
branded product should be directed to Baby’s
Journey; 999 Main Street, Suite 703, Pawtucket, RI
02860 by either calling us at:
1-855-661-8333
or by contacting us via email at:
[email protected].
When contacting Baby’s Journey, please provide (1)
your name, address and telephone number, (2) date
and place of purchase, (3) nature of the problem, (4)
Model Number, and (5) Serial Number (on bottom of
Baby Unit).
What Does this Warranty Cover? Subject to the
terms, conditions and exclusions stated below, Baby’s
Journey warrants that this AT&T branded product
(“Product”) and certified accessory sold for use with
this Product (“Accessory”) are manufactured to be
free from defects in materials and workmanship
under normal consumer usage for the period outlined
below. This Warranty is your exclusive warranty and is
not transferable.
Who is covered? Warranty extends only to the first
consumer purchaser; it is not transferable.
What will Baby’s Journey do? Baby’s Journey or its
authorized distributor at its sole option and within a
commercially reasonable time, will at no charge repair
or replace any Product or Accessory that does not
conform to this Warranty. We may use a functionally
equivalent reconditioned/ refurbished/ pre-owned or
new Product, Accessory or parts.
What Other Limitations Are There? ANY
AND ALL IMPLIED WARRANTIES, INCLUDING
WITHOUT LIMITATION, THE IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, SHALL BE LIMITED TO
THE DURATION OF THIS LIMITED WARRANTY. THE
REPAIR OR REPLACEMENT OF THE PRODUCT AND/
OR ACCESSORY PROVIDED HEREUNDER IS THE
EXCLUSIVE REMEDY OF THE CONSUMER. IN NO
EVENT SHALL AT&T OR BABY’S JOURNEY BE LIABLE,
WHETHER IN CONTRACT OR TORT (INCLUDING
NEGLIGENCE) FOR DAMAGES IN EXCESS OF
THE PURCHASE PRICE OF THE PRODUCT OR
ACCESSORY, OR FOR ANY INDIRECT, INCIDENTAL,
SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY
BUSINESS, LOSS OF INFORMATION OR DATA, AND/
OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN
CONNECTION WITH THE ABILITY OR INABILITY TO
USE THE PRODUCT OR ACCESSORY TO THE FULL
EXTENT. THESE DAMAGES MAY BE DISCLAIMED
BY THE LAW. Some jurisdictions do not allow the
limitation or exclusion of incidental or consequential
damages, or limitation on the length of an implied
warranty, so the above limitations or exclusions may
not apply to you. This Warranty gives you specific
legal rights, and you may also have other rights that
vary from one jurisdiction to another.
Product and Accessory Covered; Length of
Coverage. AT&T branded product manufactured
under license by Baby’s Journey and certified
accessory sold for use with the product one (1) year
from the date of the product’s original purchase
by the first consumer purchaser of the product or
accessory. AT&T branded product manufactured
under license by Baby’s Journey and certified
accessory sold for use with the product that are
repaired or replaced. The balance of the original one
(1) year warranty, or for ninety (90) days from the
date the repaired or replaced product or accessory is
returned to the consumer, whichever is longer.
Warranty Exclusions
Normal wear and Tear. Periodic maintenance, repair
and replacement of parts due to normal wear and tear
are excluded from coverage.
Abuse and Misuse. Defects or damage that result
from: (a) improper operation or failure to follow
the instructions; (b) storage, misuse, or abuse,
accident or neglect, such as physical damage
(cracks, scratches, etc.) to the surface of the product
resulting from misuse; (c) contact with liquid, water,
rain, extreme humidity or heavy perspiration, sand,
dirt or the like, extreme heat, or food; (d) use of the
Product or Accessory for commercial purposes or
subjecting the Product or Accessory to abnormal
usage or conditions; or (e) other acts which are not
the fault of AT&T or Baby’s Journey, are excluded.
Use of Non-AT&T branded Products and
Accessories. Defects or damage that result from
the use of Non-AT&T branded or certified products
or accessories or other peripheral equipment, are
excluded.
KIND, OR LOSS OF REVENUE OR PROFITS, LOSS OF 9

Warranty Exclusions (continued)
Unauthorized Service or Modification. Defects or
damages resulting from service, testing, adjustment,
installation, maintenance, alteration, or modification
in any way by someone other than AT&T, Baby’s
Journey or its authorized service centers, are
excluded from coverage.
Altered Products. A Product or Accessory with
(a) a serial number or date tag that has been
removed, altered or obliterated; (b) a broken seal
or that shows evidence of tampering; or (c) a
mismatched board serial number, are excluded from
coverage.
These terms and conditions constitute the complete
warranty agreement between you and Baby’s Journey
regarding the Product or Accessory purchased
by you, and supersede any prior agreement or
representations, including representations in any
literature, publications or promotional materials
issued by Baby’s Journey or representations made
by any agent, employee or representative of Baby’s
Journey, that may have been made in connection with
said purchase. No agent, employee, or representative
of Baby’s Journey has authority to make any
representations or promises except as stated above.
Find More Information
On the Web
For a digital copy of this guide and more about the
Smart Trac Digital Audio Monitor visit:
www.att.com/mhealthbabymonitors
Give us a Call
Call our Consumer Care at 1-855-661-8333 for
assistance with your monitor.
Product Registration
Registering your AT&T mHealth monitor allows us
to send important updates, service information and
help related to your baby monitor. Registering your
product also allows us to notify you in the event of a
safety notification. Visit:
www.mhealthbabymonitors.com/productregistration
AT&T Authorized Licensee. AT&T, the AT&T Globe Design and all other AT&T
marks contained herein are trademarks of AT&T Intellectual Property and
AT&T affiliated companies.
© 2014 AT&T Intellectual Properties
Manufactured and Distributed by: Baby’s Journey, Inc.
999 Main Street, Unit 703, Pawtucket, RI 02860
Product and design are TM and ©2014 Baby’s Journey, Inc.
Please retain information for future reference.
Colors and styles may vary. MADE IN CHINA
Issue 1.0 AT&T 12/14 0
10
