Athena Athena as-p300 User manual

“Hey,

my life’s

complicated enough without having

to worry about how to set up a home

theater sound system. I wanted

something that I could bring home

and pretty much plug in and start

enjoying right off the bat. And with

wall brackets already built in, my

POINT5 MKII speakers were easy

to set up where I wanted them.

What could be easier?”

EFFORTLESS: “I’m into

suspense

and action adventure movies. So I

wanted a home theater sound system

that could match the action blow

for blow. I got it with POINT5 MKII.

It’s brilliant as a system, but the

satellite speakers are so amazing on

their own, I created a mini sound

system for my home office. So at

work or play, I never have a dull

moment.”

THRILLING:“We just got

married, but

we still have very individual tastes.

For our home theatre sound system,

I wanted lots of power; she didn’t

want to be overpowered. POINT5

MKII was the clear winner. I was

impressed by the technology that

makes this a true system. And Lisa

fell for the performance. One listen

and we knew we’d found the

balance we were looking for.”

BALANCE:

POINT 5 MKII

Create your sound.

athena TECHNOLOGIES®

3641 McNicoll Avenue

Toronto, Ontario

Canada M1X 1G5

www.athenaspeakers.com

Printed in Canada. Subject to change without notice.

Part #3PAB006E

“When

Russell

and I first listened to POINT5 MKII,

everything clicked. The sound. The

styling. The value. I’ll admit we

don’t always pick the same movies

or listen to the same music, but

when we experienced athena’s

POINT5 MKII sound system, we were

both on the same wavelength. Best

of all, it was so easy to set up, all

we had to do was add popcorn.”

IRRESISTIBLE:

The point is performance…

At a great price point!

C.5 Center Channel Speaker | FEATURES: • Small –

High Power center channel speaker to match the S.5

speaker • C.5 is timbre matched to the other “S” models

as well • Magnetically Shielded – all drivers • Key-Way

wall mount • Bass Reflex design – Dual rear vents

COMPONENTS: • 1-1" Teteron Dome Tweeter • 2-4" Composite Cone Woofers • MDF

Construction • Composite Resin Front and Rear Baffles • Binding Post terminals

SPECIFICATIONS: • Frequency Response: 80-20kHz +/- 3dB • Power Handling: 100

watts per channel RMS • Sensitivity: 86dB anechoic – 89 dB room measurement

• Crossover Point: 2.0kHz • Impedance: 8 ohms compatible • Dimensions: - Width: 15"

(38.1 cm) - Height: 5-5/8" (14.3 cm) - Depth: 6-1/4" (15.6 cm) - Weight: 9.5 lbs

(4.3 kg) each • Color: High Gloss Black with Silver or Black Injection Molded Baffles

Recommended subwoofers (optional)

AS-P300 –300 watt 8”vented subwoofer

AS-P400 –400 watt 10”vented subwoofer

(used for rooms over 400 sq feet in size)

Both models feature athena TECHNOLOGIESTM exclusive

SCT control, for precise blending of the POINT5MK II

system to the subwoofer.

S.5 Speaker | FEATURES: • Small, High Power Full-Range speaker

solution • S.5 is timbre-matched to the other “S” models •

Magnetically Shielded – all drivers • Built-In Wall Mounting System for

flexible and secure wall mounting - Will allow horizontal and vertical

movement – no tools required! • Bass Reflex design – Rear vented

COMPONENTS: • 1-1" Teteron Dome Tweeter • 1-4" Composite Cone

Woofer • MDF Construction • Composite Resin Front and Rear Baffles • Binding

Post terminals

SPECIFICATIONS: • Frequency response: 80-20kHz +/- 3dB • Power handling: 100

watts per channel RMS • Sensitivity: 86dB anechoic – 89 dB room measurement

• Crossover point: 2.0kHz • Impedance: 8 ohms compatible • Dimensions:

- Width: 5-3/4" (14.6 cm) - Height: 8-1/2" (21.6 cm) - Depth: 6-1/4" (15.9 cm) -

Weight: 6 lbs (2.7 kg) each • Color: High Gloss Black with Silver or Black Injection

Molded Baffles

4 Satellite Speakers

1 Center Channel

A STYLE THAT’S ALL YOUR OWN...athena TECHNOLOGIESTM

POINT5 MK II sound system has also been intuitively designed to let you

create your own style. Complement your décor with the sleek, sophisticated

styling of a silver baffle with a high gloss black finish. If you select

the components separately, black baffles are available. And because these

speakers are magnetically shielded, you can place them virtually anywhere

you like. Want to take performance even further? The S.5 satellites from this

system can be used as rear channel speakers with athena’s SCT™(System

Creation Technology) series. Exceptional sound performance to suit your

senses, style and budget.That’s the point of POINT5 MKII.

A PERFORMANCE ENHANCED SYSTEM... athena’s POINT5

MK II sound system has been conceived to dramatically enhance your home

theater and music listening pleasure. Capitalizing on athena’s breakthrough

research and development in acoustics and speaker engineering, this system is

designed inside out to work together perfectly, with such features as timbre-

matched drivers and Medium Density Fiberboard (MDF) cabinets to minimize

resonance and enrich the deep bass.The POINT5 MK II system comes complete

with four S.5 satellite speakers, and the matching C.5 center channel. For bass

enhancement, add the matching active subwoofers AS-P300 or AS-P400.

Both subwoofers feature athena’s exclusive SCT control for perfect subwoofer

to speaker blending, which will provide the sound of large tower speakers in a

small subwoofer satellite combination. For performance enhanced music

and home theater sound, get to the point with POINT5 MKII.

POINT5 MK II S.5 Satellites

POINT5 MKII C.5 Center Channel

Recommended subwoofer (optional)

AS-P300/AS-P400

POINT5 MKII stand

(optional)

POINT5 MKII stand

(optional)

POINT5 MK II system consists of:
