Atlas 59172 Assembly instructions

Visit our website at: http://www.harborfreight.com
Battery and charger sold separately
Visit our website at: http://www.harborfreight.com
Battery and charger sold separately
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual (or month and year of purchase if product has no number). Keep this manual and the
receipt in a safe and dry place for future reference. 22i
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright©2022 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Page 2 For technical questions, please call 1-888-866-5797. Item 59172
SAFETY OPERATION MAINTENANCESETUP
Table of Contents
Safety ......................................................... 2
Specifications ............................................. 6
Setup .......................................................... 6
Operation.................................................... 9
Maintenance.............................................. 10
Parts List and Diagram.............................. 12
Warranty .................................................... 15
WARNING SYMBOLS AND DEFINITIONS
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that
follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.
IMPORTANT SAFETY INSTRUCTIONS
When using electric gardening appliances, basic safety precautions should always be followed
to reduce the risk of fire, electric shock, and personal injury, including the following:
READ ALL INSTRUCTIONS
Gardening Appliance Safety
1. Avoid Dangerous Environment -
Do not use appliances in damp or wet locations.
2. Do Not Use In Rain.
3. Keep Children Away - All visitors should
be kept at a distance from work area.
4. Dress Properly - Do not wear loose clothing or
jewelry. They can be caught in moving parts.
Use of rubber gloves and substantial footwear
is recommended when working outdoors.
Wear protective hair covering to contain long hair.
5. Use Safety Glasses - Always use face
or dust mask if operation is dusty.
6. Use Right Appliance - Do not use appliance
for any job except that for which it is intended.
7. Wear ANSI-approved safety goggles,
hard hat and heavy-duty rubber work
gloves. Use face or dust mask if
operation is dusty.
8. Wear thick jeans and steel-toed
work boots to help prevent injury
caused by flying debris.
9. Avoid Unintentional Starting -
Do not carry appliance with finger on switch.
10. Don’t grasp the exposed cutting blades or cutting
edges when picking up or holding the appliance.
11. Do Not Force Appliance - It will do the
job better and with less likelihood of injury
at the rate for which it was designed.
12. Do not Overreach -
Keep proper footing and balance at all times.
13. Stay Alert - Watch what you are doing. Use
common sense. Do not operate appliance when
you are tired.
14. Store Idle Appliances Indoors - When not in use,
appliances should be stored indoors in dry, and
high or locked-up place - out of reach of children.

Page 3For technical questions, please call 1-888-866-5797.Item 59172
SAFETYOPERATIONMAINTENANCE SETUP
15. Maintain Appliance With Care - Keep cutting
edge sharp and clean for best performance and
to reduce the risk of injury. Follow instructions
for lubricating and changing accessories. Keep
handles dry, clean, and free from oil and grease.
16. Check Damaged Parts - Before further use of the
appliance, a guard or other part that is damaged
should be carefully checked to determine that it will
operate properly and perform its intended function.
Check for alignment of moving parts, binding of
moving parts, breakage of parts, mounting, and any
other condition that may affect its operation. A guard
or other part that is damaged should be properly
repaired or replaced by a qualified technician
unless indicated elsewhere in this manual.
17. Keep guards in place and in working order.
18. Keep blades sharp.
19. Keep hands and feet away from cutting area.
20. Wear full eye protection and protective clothing.
21. Stop working when you feel tired or exhausted.
Make regular breaks to rest.
22. People with pacemakers should consult their
physician(s) before use. Electromagnetic fields in
close proximity to heart pacemaker could cause
pacemaker interference or pacemaker failure.
23. When servicing use only identical
replacement parts.
24. Carefully follow cutting procedures
explained in this manual. They are specifically
planned to reduce risk to the operator.
25. Only use accessories and attachments
designed for use with this appliance. Follow
all accessory and attachment instructions.
Use of any other accessory or attachments
may increase the risk of injury.
Battery tool use and care
1. Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to battery pack, picking up or carrying the
power tool. Carrying the power tool with your
finger on the switch or energizing power tool
that have the switch on invites accidents.
2. Disconnect the battery pack from the power
tool before making any adjustments, changing
accessories, or storing power tool. Such
preventive safety measures reduce the risk
of starting the power tool accidentally.
3. Recharge only with the charger specified by
the manufacturer. A charger that is suitable for
one type of battery pack may create a risk of
fire when used with another battery pack.
4. Use power tools only with specifically designated
battery packs. Use of any other battery
packs may create a risk of injury and fire.
5. When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from
one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
6. Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the
battery may cause irritation or burns.
7. Do not use a battery pack or power tool that is
damaged or modified. Damaged or modified
batteries may exhibit unpredictable behavior
resulting in fire, explosion or risk of injury.
8. Do not expose a battery pack or power tool to
fire or excessive temperature. Exposure to fire or
temperature above 140°F may cause explosion.
9. Follow all charging instructions and do not charge
the battery pack or power tool outside of the
temperature range specified in the instructions.
Charging improperly or at temperatures
outside of the specified range may damage
the battery and increase the risk of fire.
10. Have servicing performed by a qualified
repair person using only identical
replacement parts. This will ensure that the
safety of the product is maintained.
11. Do not modify or attempt to repair the power
tool or the battery pack except as indicated
in the instructions for use and care.
12. The battery Charger gets hot during use.
The Charger’s heat can build up to
unsafe levels and create a fire hazard if it
does not receive adequate ventilation,
due to an electrical fault, or if it is used in a
hot environment. Do not place the Charger on a
flammable surface. Do not obstruct any vents on
the Charger. Especially avoid placing the
Charger on carpets and rugs; they are not only
flammable, but they also obstruct vents under
the Charger. Place the Charger on a stable, solid,
nonflammable surface (such as a stable metal
workbench or concrete floor) at least 1 foot away
from all flammable objects, such as drapes or walls.
Keep a fire extinguisher and a smoke detector in the
area. Frequently monitor the Charger and
Battery Pack while charging.

Page 4 For technical questions, please call 1-888-866-5797. Item 59172
SAFETY OPERATION MAINTENANCESETUP
13. To Reduce Risk of Injury to Persons:
a. Do Not Recharge Batteries in a
Confined or Unvented Area; and,
b. Do Not Smoke, Strike a Match, or Cause a Spark
in the Vicinity of the Battery During Charging.
14. Do not charge appliance in rain, or in wet locations.
15. Do not use battery-operated appliance in rain.
16. Remove or disconnect battery before
servicing, cleaning or removing material
from the gardening appliance.
17. Do not dispose of the battery(ies) in a fire.
The cell may explode. Check with local codes
for possible special disposal instructions.
18. Do not open or mutilate the battery(ies). Released
electrolyte is corrosive and may cause damage
to the eyes or skin. It may be toxic if swallowed.
19. Exercise care in handling batteries in order not
to short the battery with conducting materials
such as rings, bracelets, and keys. The battery
or conductor may overheat and cause burns.
Lithium Battery Safety Warnings
LITHIUM BATTERIES STORE
A LARGE AMOUNT OF ENERGY AND
WILL VENT FIRE OR EXPLODE IF MISTREATED:
1. Keep
Battery Pack dry.
2. DO NOT DO ANY OF THE FOLLOWING
TO THE BATTERY PACK:
a. Open,
b. Drop,
c. Short-circuit,
d. Puncture,
e. Incinerate, or
f. Expose to temperatures greater than 140°F.
3. Charge Battery Pack only according
to its Charger’s instructions.
4. Inspect Battery Pack before every use;
do not use or charge if damaged.
Vibration Hazard
This appliance vibrates during use.
Repeated or long-term exposure to vibration may
cause temporary or permanent physical injury,
particularly to the hands, arms and shoulders.
To reduce the risk of vibration-related injury:
1. Anyone using vibrating appliances regularly or for
an extended period should first be examined by
a doctor and then have regular medical check-
ups to ensure medical problems are not being
caused or worsened from use. Pregnant women
or people who have impaired blood circulation
to the hand, past hand injuries, nervous system
disorders, diabetes, or Raynaud’s Disease
should not use this appliance. If you feel
any symptoms related to vibration (such as
tingling, numbness, and white or blue fingers),
seek medical advice as soon as possible.
2. Do not smoke during use. Nicotine reduces
the blood supply to the hands and fingers,
increasing the risk of vibration-related injury.
3. Wear suitable gloves to reduce the
vibration effects on the user.
4. Use appliances with the lowest vibration when
there is a choice between different processes.
5. Include vibration-free periods each day of work.
6. Grip appliance as lightly as possible
(while still keeping safe control of it).
Let the appliance do the work.
7. To reduce vibration, maintain the appliance
as explained in this manual. If any abnormal
vibration occurs, stop use immediately.
General Safety
1. The Blade will continue to rotate for a few seconds
after use. Allow it to stop completely and remove
Battery Pack before putting the appliance down,
making any adjustments, or servicing the appliance.
2. Do not use in rain, snow, sprinklers, or wet grass.
Do not rinse off the Edger.
3. Use only during daylight hours.
4. Carefully inspect the Blade and Guard before
inserting Battery Pack in the Edger. Do not
use Edger if any part is cracked or damaged.
5. Do not use appliance for other than intended use.

Page 5For technical questions, please call 1-888-866-5797.Item 59172
SAFETYOPERATIONMAINTENANCE SETUP
6. Maintain labels and nameplates on the appliance.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
7. The warnings, precautions, and instructions
discussed in this instruction manual cannot
cover all possible conditions and situations
that may occur. It must be understood by the
operator that common sense and caution are
factors which cannot be built into this product,
but must be supplied by the operator.
SAVE THESE INSTRUCTIONS.
Grounding
TO PREVENT ELECTRIC SHOCK AND DEATH FROM INCORRECT GROUNDING:
Check with a qualified electrician if you are in doubt as to whether the outlet is properly
grounded. Do not modify the power cord plug provided with the charger. Do not use the charger
if the power cord or plug is damaged. If damaged, have it repaired by a service facility before
use. If the plug will not fit the outlet, have a proper outlet installed by a qualified electrician.
Extension Cords
Note: Extension cords must not be used with this item’s Charger.
Symbology
VVolts
Direct Current
AAmperes
n0xxxx/min. No Load Revolutions per Minute (RPM)
WARNING marking concerning Risk
of Eye Injury. Wear ANSI-approved
safety goggles with side shields.
Read the manual before
set-up and/or use.
WARNING marking
concerning Risk of Fire.
Do not cover Charger
ventilation ducts.
Charge on fireproof surface only.
WARNING marking concerning
Risk of Electric Shock.
Properly connect Charger’s power
cord to appropriate outlet.
WARNING marking concerning
Risk of Explosion.
Do not puncture, short, or open
battery packs and do not charge
damaged battery packs.
Do not expose to rain or
damp conditions.
Thrown objects can ricochet and result
in personal injury or property damage.
Keep hands and feet
away from the blade.

Page 6 For technical questions, please call 1-888-866-5797. Item 59172
SAFETY OPERATION MAINTENANCESETUP
Specifications
Battery Type Atlas Li-Ion 57014 or 58958 (sold separately)
Charger Type Atlas Li-ion 56993 or 56997 (sold separately)
No Load Speed 7000 RPM
Maximum Cutting Depth 1.75"
Setup - Before Use:
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
Functions
Trigger
Auxiliary Handle
Coupler
Guard Wheel
Rear
Handle
Trigger
Lock
Blade Butterfly Knob
Push Button
Lockout

Page 7For technical questions, please call 1-888-866-5797.Item 59172
SAFETYOPERATIONMAINTENANCE SETUP
Assembly Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Release Trigger of the appliance before performing any procedure in this section.
Note: For additional information regarding the parts listed in the following
pages, refer to the Parts List and Diagram on page 12.
Attach The Auxiliary Handle
1. Remove the two Bolts from the
Auxiliary Handle and Clamp.
2. Assemble the Cover, Auxiliary Handle,
Retaining Plate, and Clamp to the Upper
Shaft and position the Handle for optimal
comfort (do not cover warning labels).
3. Secure the Auxiliary Handle to the Clamp
with the two Bolts and tighten. Retaining
Plate
Auxiliary
Handle
Bolts
Clamp
Cover
Assemble The Shaft
1. Loosen the Screw with the included Hex Key.
Hex Key
Screw
2. Push in the Release Button on the Lower Shaft.
3. Align the Release Button with the Positioning Detent
and slide the Upper and Lower Shafts together.
4. Turn the Lower Shaft until the Release
Button locks into the Positioning Detent.
Coupler
Release
Button
Positioning
Detent
Lower
Shaft
5. Tighten the Screw with the Hex Key.
Hex Key
Screw

Page 8 For technical questions, please call 1-888-866-5797. Item 59172
SAFETY OPERATION MAINTENANCESETUP
Cut Depth Adjustment
1. Slightly loosen the Butterfly Knob to
allow for cut depth adjustment.
Butterfly
Knob
2. With the Edger held in the normal operating
position, adjust the cut depth to where
the Blade barely touches the ground.
Wheel
Blade
3. Tighten the Butterfly Knob to lock
the cut depth adjustment.
4. Hold the Edger in the normal operating
position and confirm the cut depth
adjustment; correct if necessary.

Page 9For technical questions, please call 1-888-866-5797.Item 59172
SAFETYOPERATIONMAINTENANCE SETUP
Operating Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
TO PREVENT SERIOUS INJURY:
Before operating the gardening appliance, put on ANSI-approved safety goggles, steel toe work
boots, long pants, and other safety gear. Safety goggles and other safety gear are sold separately.
TO PREVENT SERIOUS INJURY AND PROPERTY DAMAGE:
Inspect the area before using the Edger. Remove all hard objects from work area.
Use both hands when operating the Edger.
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Make sure that the Power Switch/Trigger is in the off-position and
remove Battery Pack before using the appliance.
Charging Battery Pack
Charge battery before using this tool. Follow instructions included with battery charger (sold separately).
Installing and Removing Battery Pack
1. To install: Slide Battery Pack into slot on
back of Edger until it clicks into place.
2. To remove: Press Battery Pack Release
Button and pull Battery Pack out of slot.
Edger Operation
WARNING! TO PREVENT SERIOUS
INJURY: Do not allow the cutting edge of
the blade to contact a hard surface.
1. Install fully-charged Battery Pack.
NOTICE: To prevent damage to tool or property,
avoid contact with fences, trees, shrubs and the like.
2. Holding Edger with both hands, press the Push
Button Lockout down, then push the Trigger Lock
forward while simultaneously pulling the Trigger up.
Trigger
Trigger
Lock
Push Button
Lockout
3. Use the Edger to cut along sidewalks,
curbs, driveways, and patios.
4. Cut at a steady pace; do not force the Blade into
the ground. If the Blade begins to bog down, slow
your pace to allow the Blade to regain speed.
5. Release Trigger when done.
6. Do not use in wet soil or vegetation. If the
Guard becomes clogged, release Trigger and
remove the Battery Pack. Wearing heavy-duty
gloves clear the Guard of the debris.
7. When finished, to prevent accidents,
remove Battery Pack, then clean and store
tool according to “Cleaning, Maintenance,
and Lubrication” on page 10.

Page 10 For technical questions, please call 1-888-866-5797. Item 59172
SAFETY OPERATION MAINTENANCESETUP
User-Maintenance and Storage
Procedures not specifically explained in this manual must
be performed only by a qualified technician.
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION OR ELECTRIC SHOCK:
Release the Trigger and remove the Battery Pack before performing
any inspection, maintenance, or cleaning procedures.
TO PREVENT SERIOUS INJURY FROM APPLIANCE FAILURE:
Do not use damaged equipment. If abnormal noise or vibration
occurs, have the problem corrected before further use.
Cleaning, Maintenance, and Lubrication
1. BEFORE EACH USE, inspect the
general condition of the appliance. Check for:
• loose hardware,
• misalignment or binding of moving parts,
• cracked or broken parts,
• damaged electrical wiring, and
• any other condition that may
affect its safe operation.
2. AFTER USE, Remove Battery Pack and wipe
external surfaces of the appliance with clean cloth.
3. Li-Ion BATTERY MUST BE RECYCLED OR
DISPOSED OF PROPERLY.
Do not short, incinerate or open battery.
4. Store Battery Pack, Charger, and tool in dry,
indoor area out of reach of children. Store
Battery Pack away from metal objects
(i.e., paperclips, coins) to prevent shorting.
5. All parts are permanently lubricated.
Do not use additional lubrication.
Replacing The Blade
1. Use the Blade Lock Rod to stop Blade from rotating.
2. Remove the Nut CLOCKWISE with the
included Wrench, then remove the Washer.
3. Replace the Blade, Washer, and Nut.
4. Securely tighten the Nut COUNTERCLOCKWISE.
Blade Lock
Rod
Wrench
Washer
Blade
Nut

Page 11For technical questions, please call 1-888-866-5797.Item 59172
SAFETYOPERATIONMAINTENANCE SETUP
Replacing The Wheel
1. Remove the Butterfly Knob with the Nut, Spring
Lock Washer, Axle Sleeve, Wheel, Axle Sleeve,
and Rubber Washer from the Wheel Axle.
2. Replace the Wheel, hold the Wheel Axle Tab facing
down, then hand tighten the Butterfly Knob with
Nut (Nut will nest inside of the Butterfly Knob).
Wheel
Axle
Rubber
Washer
Axle
Sleeve
Nut
Axle
Sleeve
Butterfly
Knob
Wheel
Axle Tab
Wheel
Spring Lock
Washer
Replacing The Rubber Flap
1. Remove the Hex Screw, Flat Washer,
and Rubber Flap from the Guard.
Hex Screw
Flat Washer
Rubber Flap
2. Replace the Rubber Flap; align the Slot
with the Flap Position Guide and insert
the Rubber Flap into the guard.
Slot Flap Position
Guide
3. Position the Rubber Flap so the Guard
Projection fits into the First Hole.
4. Secure the Rubber Flap to the guard with
the Hex Screw and Flat Washer through
the Second Hole. Tighten securely.
First Hole
Guard
Projection
Second Hole
Hex Screw
Flat Washer

Page 12 For technical questions, please call 1-888-866-5797. Item 59172
SAFETY OPERATION MAINTENANCESETUP
Parts List and Diagram
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Parts List
Part Description Qty
1 Left Rear Handle 1
2 Edger PCBA 1
3Male Terminal Assembly 1
4 Wire Retaining Plate 1
5 P Clamp 1
6 Hex Screw 13
7 Right Rear Handle 1
8Lockout Torsional Spring 1
9 Lockout Push Button 1
10 Trigger 1
11 Trigger Lock 1
12 Torsion Spring 1
13 Split Pin 1
14 Speed Control Switch 1
15 B Terminal 1
16 Upper Shaft 1
17 Hex Socket Head Cap Screw 2
18 Coupler 1
19 Hex Socket Head Cap Screw 1
20 Double Thread Nut M6 2
21 Lower Shaft 1
22 Hex Bolt And Washer 2
23 Auxiliary Handle Cover 1
24 Auxiliary Handle 1
25 Retaining Plate 1
26 Clamp 1
27 Hex Socket Pan Head Screw 1
28 Flat Washer 1
29 Rubber Flap 1
30 Guard 1
31 Hex Socket Pan Head Screw 1
32 Spring Washer 3
33 Hex Socket Pan Head Screw 1
Part Description Qty
34 Hex Socket Pan Head Screw 1
35 Hex Bolt, Lock And Flat Washer 7
36 Upper Blow Nozzle 1
37 Lower Blow Nozzle 1
38 Flat Washer 1
39 Wheel Axle 1
40 Wheel Bracket 1
41 Rubber Washer 1
42 Shaft Sleeve 2
43 Wheel 1
44 Lock Washer 1
45 Butterfly Knob 1
46 Locking Nut M8 1
47 Housing 1
48 Motor 1
49 Shock Pad 4
50 Screw (St4 X 14-F) 2
51 Air Deflector 1
52 Fan Base 1
53 Hex Screw And Lock Washer M4x14 4
54 Screw And Serrated Washer 1
55 Fan Blade 1
56 Fan Cover 1
57 Hex Socket Self-Tapping Screw 2
58 Blade Seat 1
59 Backplate 1
60 Self-Tapping Screw 2
61 Blade 1
62 Blade Washer 1
63 Blade Nut 1
64 Hex Key 1
65 Blade Lock Rod 1
66 Wrench 1

Page 13For technical questions, please call 1-888-866-5797.Item 59172
SAFETYOPERATIONMAINTENANCE SETUP
Assembly Diagram

Page 14 For technical questions, please call 1-888-866-5797. Item 59172
SAFETY OPERATION MAINTENANCESETUP
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts. Specify UPC 193175458070 when ordering parts.

Page 15For technical questions, please call 1-888-866-5797.Item 59172
SAFETYOPERATIONMAINTENANCE SETUP
Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards,
and warrants to the original purchaser that this product is free from defects in materials and workmanship for the
period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly,
to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper
installation, normal wear and tear, or to lack of maintenance. We shall in no event be liable for death, injuries
to persons or property, or for incidental, contingent, special or consequential damages arising from the use of
our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation charges
prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.
If our inspection verifies the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.

26677 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
Table of contents
Other Atlas Trimmer manuals
Popular Trimmer manuals by other brands

Black & Decker
Black & Decker GT249 user manual

Gravely
Gravely ST622 CARB Owner's/operator's manual

Grizzly Tools
Grizzly Tools ERT 3525 Translation of the original instructions for use

Weed Eater
Weed Eater 530163479 instruction manual

EINHELL
EINHELL 34.038.35 operating instructions

Fellowes
Fellowes PowerTrim instructions
