Atlona AT-PA100-G2 User manual

User Manual
Atlona Stereo/Mono Audio Amplifier
AT-PA100-G2
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515

2
1. Introduction ............................................................................................ 3
2. Package Contents ............................................................................................ 3
3. Features ............................................................................................ 3
4. Specifications ............................................................................................ 4
5. Panel Descriptions
a. Front Panel ............................................................................................ 4
b. Rear Panel ............................................................................................ 5
c. Top Panel ............................................................................................ 5
6. MIC Connection ............................................................................................ 6
7. Output Connection ............................................................................................ 7-8
8. Connection and Installation ............................................................................................ 8
9. RS-232 ............................................................................................9-10
10. Safety Information ............................................................................................ 11
11. Warranty ............................................................................................ 12
12. Atlona Product Registration ............................................................................................ 13
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Table of Contents

3
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Introduction
Small, energy efficient, and affordable the Atlona Stereo/Mono Audio Amplifier fits the needs
of most offices, classrooms and more. Unlike traditional A/B amplifiers the Class D audio
amplifier is energy efficient and easily integrated behind a TV where space is limited.
Package Contents
Features
• 1 x AT-PA100-G2
• 1 x AC Adapter
• 1 x User Manual
• AT-PA100-G2 is a class D amplifier which uses less energy, doesn’t require heat syncs or
power transformers, making it smaller than a class A/B amplifier
• Stereo, mono, and bridge audio speaker output connections available through captive
screw
• Has a variable 3.5mm audio loop out for cascading to another AT-PA100-G2 or
connecting to other audio amplifiers
• 3 pin captive screw MIC input can support balanced and unbalanced signals (suppresses
external noise)
• Energy efficient standby mode only requires 0.4Ws of power. AT-PA100-G2 goes into
standby mode if an audio signal isn’t present
• Control through the panel buttons, an (optional) IR remote, and RS-232
• 3 position input switch:
48V phantom power - best for condenser MICs without battery power
MIC - Great for Dynamic MICs and battery powered condenser MICs
Line - Connect a Wireless MIC
• Volume, Bass, and Treble can be controlled through RS-232, IR, or panel buttons

4
Input Ports 2 x RCA connectors
1 x 3.5mm Audio
1 x 3.5mm IR
1 x Captive Screw MIC
1 x Captive Screw RS-232
Output Ports 1 x Captive Screw Audio
1 x 3.5mm Loop Out
Dimensions (HxWxD) 1.5 x 3.78 x 3.43 (inch) or 38 x 96 x 87 (mm)
Weight 0.66lbs or 0.3kg
Power consumption 3.6W
Audio
Gain: 32dB
Frequency Range: 20Hz to 20KHz
Signal/Noise Ratio: 80dB (at max output)
Total Harmonic Distortion: 1% (1KHz), 0.3% (20KHz) -- at nominal levels
Input Impedance: Input 1&2: >10KΩ
MIC Input Impedance: 48V: 35KΩ
MIC: 10KΩ
LINE: 75KΩ
Output Impedance: 3.5mm Loop Out: 50Ωstereo
Speaker out: 4 ~ 8ΩAmplifier
Stereo Channel Separation: >75dB from 20Hz to 20KHz
Common Mode Rejection Ratio: >70dB from 20Hz to 20KHz
MIC Audio Detection Delay: 1ms
1 2 3
4 5 6 7
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Specifications
Panel Description
Front Panel
1. Audio output format switch: Use to switch between Stereo, Dual Channel Mono, and
Bridged audio outputs
2. 3.5mm IR: Connect optional IR receiver here for use with optional IR remote (AT-PA1-IR)
3. Captive Screw RS-232: Connect RS-232 here for control
4. Captive Screw Input: Connect a MIC
5. Audio input switch: Switch between 48V Phantom powered condenser MIC, Dynamic
MIC, or LINE
6. L/R audio: Connect Analog audio into this port
7. 3.5mm audio: Connect Analog audio into this port

5
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Back Panel
1. 24V Port: Connect included power supply here.
2. 3.5mm variable audio loop out: Loop out to another AT-PA100-G2 or audio amplifier
with a 3.5mm stereo audio connector
3. Captive Screw Audio: Connect to speakers
1. Input Selection Button: Toggle between the RCA input and 3.5mm audio input
2. Audio Control Button: Adjust the volume of the MIC, Line, or the level of Bass and
Treble with this button
3. Volume adjustment buttons: Use the up and down arrows to turn the volume up or
down or adjust the level of the Bass and Treble
4. Mute button: Use to mute the Line volume
Top Panel
321
1 2 3 4

6
MIC Connection
MIC
(Condenser)
+ Positive ╧Ground ─ Negative
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Connect a condenser
MIC using Positive to the
“+”, negative to the “-”
and your ground/power to the “╧”. The
48V option is for MICs that require phantom
power from an external device. Typically
used by condenser MICs. Only a balanced
connection is used in this mode.
Connect Dynamic or
Self-Powered Condenser
MICs in this mode.
Connections can be either balanced or
unbalanced.
48V (Condenser MIC)
MIC (Dynamic MIC)
Line Input (or Wireless MIC)
Connect Wireless MICs
to this port. Either
balanced or unbalanced
connections may be used.
MIC
MIC
MIC
MIC
MIC
MIC
(Balanced)
(Balanced)
(Unbalanced)
(Unbalanced)
(Unbalanced)
(Unbalanced)
+ Positive + Positive
+ Positive + Positive
╧ Ground ╧ Ground
╧ Ground ╧ Ground
╧ Ground ╧ Ground
─ Negative ─ Negative
─ Negative ─ Negative
Either Unbalanced connection may be used.
Either Unbalanced connection may be used.
NOTE: The MIC input has a power saving standby mode. When the MIC does not receive an
audio signal for 8 seconds it will go into mute/standby mode.

7
Output Connection
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Mono (dual)
Mono
Channel
(20W)
Mono
Channel
(20W)
Stereo (Default)
R (20W)
L (20W)
Default output connection is Stereo. Connect
the “+” and “-” of the left side to the left
speaker and the “+” and “-” of the right side to
the right speaker. Each speaker receives 20W in
this mode.
When Mono is selected, the audio output is
Dual Channel Mono and will output 20W per
channel in this mode.

8
Connection and Installation
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Bridged
Mono
Channel
(40W)
Bridged audio will combine both L and R
channels into one and outputs 40W to a single
speaker.
Mono: 40W
Stereo
20W
20W
Line Input MIC Input
Line Input

9
RS-232
Connection
RS-232 is connected through a 9-pin female D connector. The pins will have functions
associated with them, some will be unassigned.
No. Pin Function
1 ---- Not used
2Tx Transmit
3Rx Receive
4 ---- Not used
5Gnd Ground
6 ---- Not used
7 ---- Not used
8 ---- Not used
9 ---- Not used
1
2
3
4
5
5
9 8 7 6
Command
The command codes are very sensitive, do not change capitalization, spacing, or lettering.
Command Feedback Description
1A1. 1A1 Switching the audio to input 1
2A1. 2A1 Switching the audio to input 2
0A0. Mute Audio Mute Audio of MIC and Line out
0A1. UnMute Audio UnMute Audio
1A0. Mute MIC Mute audio of MIC
2A0. Mute LINE Mute audio of line out
600% A: 1 -> 1
Volume: 30
Bass: 00
Treble: 00
Shows the audio status
601% Volume of MIC: 51 MIC volume up
602% Volume of MIC: 51 MIC volume down
603% Volume of LINE: 51 Line volume up
604% Volume of LINE: 51 Line volume down
605% Bass of LINE: 04 Bass level up
606% Bass of LINE: 04 Bass level down
607% Treble of LINE: 04 Treble level up
608% Treble of LINE: 04 Treble level down
609% A: 1 -> 1
Volume: 50
Bass: 04
Treble: 04
Resets back to default settings
Baud Rate: 9600bps Data Bit: 8bits Parity: None Stop Bit: 1bit
2 3
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515

10
Command Feedback Description
5xx% Volume of MIC: xx Preset MIC volume, [xx] arranges from [00] to [60].
Example: 509% --> Volume of MIC: 09
7xx% Volume of LINE: xx Preset line volume, [xx] arranges from [00] to [60].
Example: 723% --> Volume of LINE: 23
8xx% Bass of LINE: xx Preset the bass level, [xx] arranges from [00] to [08].
Example: 803% --> Bass of LINE: 03
9xx% Treble of LINE: xx Preset the treble level, [xx] arranges from [00] to [08].
Example: 905% --> Treble of LINE: 05
Do not use a carriage return at the end of the commands. “.” and “%” terminate the commands.
