Atlona AT-HDVS-200-RX User manual

Ethernet-enabled HDBaseT
Scaler with HDMI and
Analog Audio Outputs
AT-HDVS-200-RX
User Manual
Please check http://www.atlona.
com/products/AT-HDVS-200-RX
for the most recent firmware
update or manual
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515

2
1. Introduction .................................................................................. 3
2. Package Contents .................................................................................. 3
3. Features .................................................................................. 3
4. Panel Descriptions
a. Front Panel .................................................................................. 4
b. Rear Panel .................................................................................. 4
5. OSD Menu .................................................................................. 5-6
6. WebGUI .................................................................................. 7-12
7. RS-232
a. Connection .................................................................................. 13
b. Commands .................................................................................. 14
c. Parameters .................................................................................. 15
d. IP Commands .................................................................................. 15
8. Relay .................................................................................. 16
7. Connection Diagram .................................................................................. 17-18
8. Specifications .................................................................................. 19
9. Safety Information .................................................................................. 20
10. Warranty .................................................................................. 21-22
11. Atlona Product Registration .................................................................................. 22
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Table of Contents
Note: To ensure compatibility, please be certain both transmitter and receiver have blue HDBaseT ports. This ensures
both products are PoE (48V) compliant. The HDVS-200-TX is not compatible with PoCC (black RJ45, 24V) devices

3
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Introduction
The AT-HDVS-200-RX is an HDBaseT scaler with HDMI and analog audio outputs. It features an
HDMI output with balanced analog audio de-embedding and display control using CEC, IP, or RS-
232. The AT-HDVS-200-RX combines the benefits of an extended-distance HDBaseT receiver with
built-in scaling and the capabilities of a control processor for simplified A/V system installation and
operation. When used with the AT-HDVS-200-TX switcher, it receives HDMI signals with embedded
audio and control signals at distances up to 328 feet (100 meters). The switcher/scaler pair enables
automatic display control, automatic input selection, volume adjustment, or optional third-party
control. The AT-HDVS-200-RX supplies power to the AT-HDVS-200-TX switcher via Power over
Ethernet and together they create a standalone A/V switching and control system with scaling for
classrooms and huddle rooms.
Package Contents
Features
• 1 x AT-HDVS-200-RX
• 4 x Captive screw female connector (5 pin: audio, 5 pin: RS-232, 3 pin: relay, 2 pin: power)
• 1 x 48V DC captive screw power adapter
• 1 x pair of mounting brackets
• 1 x User manual
• Scales incoming signals at a variety of common resolutions up to 1080p or 1920x1200
• Dry contact closure control for two signals
• Complete control of video brightness, contrast, saturation, hue, and more
• Projector control through RS-232, IP, webGUI, or CEC*
• Ethernet for configuration, upgrading, and device management/control
• Ethernet-enabled HDBaseT extension
• Automatic display control - powers display on/off based on RX power mode (standby or active)
• Volume control
• Adjust treble and bass of audio output to ensure the best speaker performance
• Audio de-embedding for use with an amplifier (e.g. AT-PA100-G2)
• Power over Ethernet to power compatible transmitters (e.g. AT-HDVS-200-TX)
• EDID management for better compatibility
• Firmware upgrade via USB or webGUI for easy field service
*Note: Consumer Electronics Control (CEC): Atlona does not guarantee the function of CEC with all televisions. We can confirm proper operation with many current
Samsung, Panasonic, and Sony TVs. Many manufacturers do not support the CEC “Off” command when sent from a source and older TVs use proprietary
commands. Atlona only supports those TVs that follow CEC command structure from HDMI 1.2a and support the “off” command when issued by a source. We
encourage any dealer to get evaluation product from Atlona prior to designing a system around this control technology or be prepared to use other methods to
control their displays if Atlona CEC is not compatible with the installed displays.
Note: To ensure compatibility, please be certain both transmitter and receiver have blue HDBaseT ports. This
ensures both products are PoE (48V) compliant. The HDVS-200-TX is not compatible with PoCC
(black RJ45, 24V) devices

4
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Panel Description
1. AUDIO output:Connect to an amplifier (e.g. AT-PA100-G2)
2. RS-232 dual port:Connect to a display (port 1) and a control system (port 2)
3. MENU button:Use to enter, exit, and select within the on-screen display menu
4. AUTO button:When using compatible transmitters (e.g. AT-HDVS-200-TX) will auto adjust VGA
signals
5. ^and vbuttons:Use to navigate the OSD menu
6. PW LED:Will illuminate when receiving power
LINK LED:Illuminates when the HDBaseT connection is functioning properly
1. RELAY dual signal port:Creates a closed/open circuit for device control
2. DC 48V port:Connect included 48V DC adapter here to power RX and compatible transmitters
3. LAN (black) port:Connect network switch or router to this port for Ethernet, TCP/IP, or
webGUI control
4. HDBaseT OUT (blue) port:Connect to an HDBaseT PoE transmitter
e.g. AT-HDVS-200-TX, AT-UHD-SW-52ED, or UHD-CLSO series switchers (e.g. AT-UHD-CLSO-824)
Note: Switchers with internal scalers are not recommended for use with HDVS-200-RX, as it may cause
artifacts due to double scaling of the signal (e.g. AT-UHD-CLSO-601)
5. FW port:Firmware update port, connect a mini USB to USB A cable to a computer
Note: Firmware is downloadable through http://www.atlona.com/products/AT-HDVS-200-RX/
6. HDMI OUT port:Connect to a display
Back Panel
Front Panel
FW
RELAY
AT-HDVS-200-RX
C1 C2COM
HDBaseT INLAN HDMI OUT
L1
-+-
+
R2
RX RXTX TX
AUDIO RS-232 MENU AUTO
^
^
PW
LINK
-+
DC 48V
3 6
5
41 2
FW
RELAY
AT-HDVS-200-RX
C1 C2COM
HDBaseT INLAN HDMI OUT
L1
-+-
+
R2
RX RXTX TX
AUDIO RS-232 MENU AUTO
^
^
PW
LINK
-+
DC 48V
62 53 4
1
Note: To ensure compatibility, please be certain both transmitter and receiver have blue HDBaseT ports. This
ensures both products are PoE (48V) compliant. The HDVS-200-TX is not compatible with PoCC
(black RJ45, 24V) devices

5
Category Cable
For the category cables used in the installation of these products, please be sure to use a 568B
termination as pictured below:
Connector type and size is very important to ensure extenders work correctly. Please use the
matching cable type with the correct RJ45 connector.
CAT5e cables should use only CAT5e RJ45 connectors
CAT6 cables should use only CAT6 connectors
CAT6a cables should use only CAT6a connectors
CAT7 cables should use only CAT7 connectors
Using the wrong size connectors may result in interference causing loss of signal.
Important! “EZ RJ45 connectors” are not recommended with HDBaseT extenders. Doing so may result in interference
with audio and video transmission.
Use the table below to verify the best category cable for the installation.
Important! 4K (UHD) signals are sensitive to cable quality and installation technique. It is recommended to
use CAT6a/7 solid core cables for best results.
Note: For cable distances see the specifications on page 20
Performance Rating Type of LAN cable
Wiring Shielding CAT5e/6 CAT6a/7
Solid Shielded (STP/FTP) *** ****
Unshielded (UTP) ** N/A
Stranded - Patch
cable
(Not recommended)
Unshielded (UTP) * N/A
Shielded (STP/FTP) * N/A
Termination Please use EIA/TIA-568-B termination
1. White - Orange
2. Orange
3. White - Green
4. Blue
5. White - Blue
6. Green
7. White - Brown
8. Brown
Connector
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Note: To ensure compatibility, please be certain both transmitter and receiver have blue HDBaseT ports. This
ensures both products are PoE (48V) compliant. The HDVS-200-TX is not compatible with PoCC
(black RJ45, 24V) devices

6
Menu
Input Select HDMI 1
HDMI 2
VGA
Menu Back
Input Resolution 800x600 1280x800 1920x1200
1024x768 1366x768 Native
1280x720 1920x1080 Menu Back
Output Resolution 800x600 720p25 1080p24
1024x768 720p29.97 1080p25
1280x800 720p30 1080p29.97
1280x1024 720p50 1080p30
1366x768 720p59.94 1080p50
1400x1050 720p60 1080p59.94
1600x900 1080i50 1080p60
1600x1200 1080i59.94 Input
1680x1050 1080i60 Native
1920x1200 1080p23.98 Menu Back
Picture Adjust Brightness 0 to 100
Contrast 0 to 100
Saturation 0 to 100
Hue 0 to 100
Sharpness 0 to 100
Picture Reset
Menu Back
Aspect Full 16:10 TV Keep Ratio
16:9 TV 4:3 TV Menu Back
Overscan Enable Yes or No
H Size % 0 to 50
V Size % 0 to 50
Menu Back
Audio HDMI Audio Enable or Disable
L/R Audio Enable or Disable
Hot Keys None
Mute On or Off
Volume 0 to -80 dB
Treble -12 to +15
Bass -12 to +15
Menu Back
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
OSD Menu

7
Menu Option
OSD Position Left-Top, Right-Top, Right-Bottom, Left-Bottom, Center
Transparency 0 (transparent) to 15 (solid)
Info. Timer 5 to 60 seconds
Menu Timer 5 to 60 seconds
Info. Display Always On, Auto, Always Off
Menu Display Always On, Auto, Always Off
Background Grey, Cyan, Magenta, or Yellow
Menu Back
Others In Auto Switch On or Off
VGA Auto Adjust (used with compatible transmitter)
Display HDCP Auto, Compliant, Noncompliant
Mirror-V On or Off
ASP Background Grey or Black
Menu Back
Information Source
Name
Product
Sink
Model
Native1
Native2
FW Ver
MCU
HDBT
Next Page
-----
-----
-----
-----
-----
-----
-----
-----------------
TX: V. XX
V. XX
- V. XX
RX: V. XX
V. XX
Source Detection
HV Total
HV Display
HV Polarity
Scan Mode
Type
HDCP
Clock
Sync
Identify
Menu Back
X
X
X
X
X
X
X
X
X
-Audio-
Type
SR
FIFO
X
X
X
System Setup Factory Reset No or Yes
MCU F/W Update No or Yes
HDBT F/W Update No or Yes
Menu Back
Menu Exit
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515

8
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
A login screen will appear (this is the same log in for admin and general users). For the first log in (and future
admin changes) the username is “root” and password is “Atlona”.
Note: Only the admin password can be changed (see page 11). The username will always remain “root”.
Network Connections
For convenience, the HDVS-200-RX comes with DHCP on. This enables the scaler to be connected
to a network without knowing available IP addresses. If your network does not allow dynamic IP
addresses or if you are using the switcher with a TCP/IP control system, this feature may be turned
off and the IP address set using RS-232 commands or the webGUI.
WebGUI
Atlona has created an easy to use webGUI for initial setup and later changes to the configuration of
the HDVS-200-RX.
To begin, plug a LAN cable into the LAN port of the HDVS-200-RX and the network switch, then
type the IP address of the unit into a web browser of a PC connected to the same network (as seen
below).
To find the switcher IP: use RS-232 command “IPCFG”.
Important: If any stability issues are experienced, disable any anti-virus or firewall that may interfere with
network communication to the switcher. Once set up is done and the scaler webGUI is no
longer being used, the firewall and anti-virus can be re-enabled.
The Info Page displays general system information.
Note: When connected to a transmitter other than the HDVS-200-TX it will display GENERAL in the
navigation bar.
Note: IP addresses may also be found using common free IP scanner software such as “Advanced IP Scanner”
*Atlona does not assume responsibility for damage caused by other programs installed onto a computer, verify programs before installing*

9
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Aspect Ratio -
0800x600p60 11024x768p60 21280x800p60 31280x1024p60 41366x768p60
51400x1050p60 61600x900p60RB 71600x1200p60 81680x1050p60 9 1920x1200pRB
10 1280x720p25 11 1280x720p29 12 1280x720p30 13 1280x720p50 14 1280x720p59
15 1280x720p60 16 1920x1080i50 17 1920x1080i59 18 1920x1080i60 19 1920x1080p23
20 1920x1080p24 21 1920x1080p25 22 1920x1080p29 23 1920x1080p30 24 1920x1080p50
1 Full 216:9 316:10 44:3 5 Keep Ratio
25 1920x1080p59 26 1920x1080p60 27 Input 28 Native
Output Resolution -
Note: Keep ratio maintains the aspect ratio of the source, even if it does not match connected display’s
aspect ratio
The Video Page enables input selection, VGA alignment, and auto-switch configuration.
Input
Prefer Timing - Select the best resolution to ensure compatibility with the input & output
VGA Adjust - Adjusts the VGA timing on the display
Output Resolution - Select the output resolution for the HDMI output (see resolution list below)
Note: The RX will scale all sources to the chosen resolution
Aspect - Adjusts the height and width of the image (see aspect list below)
Note: When used with the HDVS-200-TX, preferred timing and VGA adjust will not be selectable. Select
preferred timing and VGA adjust through the TX webGUI
Overscan
Enable - Toggle on/off to enable horizontal and vertical sizing
H Size - Adjusts the width of the video
V Size - Adjusts the height of the video

10
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
The Audio Page enables adjustments of volume, bass, and treble
Output Audio:
Mute - Toggle the output audio of both the HDMI and analog audio output
HDMI Audio - Toggle the HDMI audio on and off
L/R Audio - Toggle the analog audio on and off
Output Volume:
Output - Adjust the output volume
Output Bass - Adjust the bass of the output
Output Treble - Adjust the treble of the output
The Picture Page provides output adjustment for brightness, contrast, saturation, hue, and
sharpness.
Note: Calibrate the display before using these settings to adjust the picture
Reset Picture - Resets the picture settings of the unit

11
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
RS-232 Parameter Setting
Zone -
Adjust the RS-232 parameters of RS-232 port 1 of the HDVS-200-RX for display control
Console -
Adjust the RS-232 parameters of the HDVS-200-RX RS-232 port 2 to make it compatible
with control systems.
Save -
Once the RS-232 parameters are changed, press the save button to make it live on the unit.

12
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
The Configuration Page allows non-admin users to be added or the admin password to be
changed.
Only 3 non-admin users can be added. Press the add button. A pop up screen will appear (see
below). Fill in the username and password than press save changes. Users will not have the ability to
access this page.
Admin password can also be changed. Be sure to write this information down as admin is the only
profile allowed to add/remove users.
Note: Default username= “root” and password= “Atlona”

13
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Relay
Control
Follow Display Status: When power is turned on or off, the relays will auto switch based on
signal status
Manual: Open and close the relays through IP/RS-232 commands
Relay 1 & 2 (see set up on page 16)
Open: Breaks the contact
Close: Completes the circuit, sending power to trigger the device function
System
Network - IP address, netmask, gateway, and telnet port can be set to any settings compatible
with your network. The Netmask and Gateway must match your existing network
settings
IP Mode:
Static - Set a fixed IP
Note: For a stable connection when using a control system, it is best to set up a static IP. As you select
an IP address, make certain no other devices on your network are using that IP address
DHCP - Dynamic Host Configuration Protocol will automatically select an IP address
on the network that is not already in use
Telnet Login Mode - Turn on/off - requires a password to adjust settings
Telnet Timeout - Set the auto log-off time between 1 and 3600 seconds
Broadcast - Turn on and off the feedback through all control ports
Reset to Default - Reset the device to factory settings
Firmware Update - Use this feature to find and load the MCU firmware to the switcher
Note: Firmware can be found and downloaded from http://www.atlona.com/products/AT-HDVS-200-RX/
page under the firmware tab
Valens Update - Use this feature to find and load the HDBaseT chip firmware to the switcher

14
RS-232
Connection
Set Up
To set up the RS-232 terminal (if not using 3rd party software) use the following steps:
1. Connect the HDVS-200-RX to a PC using a DB9 to DB9 and DB9 to USB adaptor cable
Note: A gender changer and/or null modem may be needed between some connections
a. Remove the DB9 connector, strip and connect the wires to the included captive screw
connector (as explained above), then connect the captive screw connector to the switcher
2. Go to the Device Manager folder (see picture A)
3. Find the HDVS-200-RX COM port and right click with a mouse and select properties (see picture B)
Note: If unsure which COM port is the HDVS-200-RX, unplug the cable and plug it back in. It will disappear
and reappear on the COM port list.
4. Under the properties menu select the port settings tab and update the menu to the
HDVS-200-RX default settings of: Bits Per Second: 115200, Data Bits: 8, Parity: None, Stop
Bits: 1 and Flow Control: None. (see picture C)
Set up is done and any terminal program may be used to control the HDVS-200-RX now.
ABC
RS-232 is often connected through a DB 9-pin to captive screw
connector. The pins will have specific signals associated with
them, some are unassigned.
Note: Typical DB9 connectors use pin 2 for TX, pin 3 for RX, and pin 5
for ground. On some devices, the functions of pins 2 and 3
are reversed.
54 3 2
9 8 7 6
1
RS-232 pin out will be determined by
the connected device and will connect as
(ground), TX (transmitter), and RX (receiver). (See
picture 1)
Note: To control the unit you will need to
connect to the right three ports of the
captive screw connector.
Wire color will
differ by cable
manufacturer.
1
12
RX RXTX TX
RS-232
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515

15
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Command Feedback Description
Type Type Displays the model number of the unit
Version Version Displays the bootcode and firmware version
Mreset Mreset Reset the unit to factory settings and restarts the switcher
PrefTimg X PrefTimg X Set preferred timing to EDID. X= 0-8 & sta
VOUT +
e.g. VOUT +
VOUT XX
e.g. VOUT -5
Increase the volume output by 1
e.g. Increases the volume output by 1
VOUT -
e.g. VOUT -
VOUT XX
e.g. VOUT -20
Decrease the volume output by 1
e.g. Decreases the volume output by 1
VOUT X
e.g. VOUT -10
VOUT X
e.g. VOUT -10
Set the volume to a specific level from -80 to 0
e.g. Set the volume to -10
VOUTMute X
e.g. VOUTMute on
VOUTMute X
e.g. VOUTMute1 on
Mute/unmute all audio output X= on, off, sta
e.g. Mute all audio output
HDMIAUD X
e.g. HDMIAUD off
HDMIAUD X
e.g. HDMIAUD off
Turns audio on/off for the HDMI output x=on, off, sta
e.g. Turns the audio off for the HDMI output
LRAUD X
e.g. LRAUD on
LRAUD X
e.g. LRAUD on
Turns the audio on/off for the analog audio output
e.g. Turns the analog audio output on
Bass X
e.g. Bass +
Bass X
e.g. Bass 5
Adjusts the bass of the audio output X= +, -, sta, -12 to 15
e.g. Increases the bass by 1
Treble X
e.g. Treble -5
Treble X
e.g. Treble -5
Adjusts the treble of the audio output X= +, -, sta, -12 to 15
e.g. Sets the treble to -5
VidOutRes X
e.g. VidOutRes 22
VidOutRes X
e.g. VidOutRes 22
Set the output resolution x=0-27, sta
e.g. Set the output resolution to 1920x1080p29
Aspect X
e.g. Aspect 2
Aspect X
e.g. Aspect 2
Set the output aspect ratio x=0-4
e.g. Set the output aspect ratio to 16:10
Zoom X
e.g. Zoom on
Zoom X
e.g. Zoom on
Enable/disable overscan (zoom) x=on, off, sta
e.g. Enables overscan
HZoom X
e.g. HZoom 10
HZoom X
e.g. HZoom 10
Adjusts the horizontal overscan x=0-50, sta
e.g. Adjust the width of the signal to 10
VZoom X
e.g. VZoom 12
VZoom X
e.g. VZoom 12
Adjusts the vertical overscan x=0-50, sta
e.g. Adjust the height of the signal to 12
BRT XX
e.g. BRT 30
BRT XX
e.g. BRT 30
Set output brightness value
e.g. Set output brightness to 30
CTRST XX
e.g. CTRST 20
CTRST XX
e.g. CTRST 20
Set output contrast value
e.g. Set output contrast to 20
SATRT XX
e.g. SATRT 65
SATRT XX
e.g. SATRT 65
Set output saturation value
e.g. Set output contrast to 65
HUE XX
e.g. HUE 38
HUE XX
e.g. HUE 38
Set output hue value
e.g. Set output hue to 38
Sharp XX
e.g. Sharp 11
Sharp XX
e.g. Sharp 11
Set output sharpness value
e.g. Set output sharpness to 11
PicReset PicReset Resets all picture settings to default
0 Default 11280x800 21920x1080 31024x768 41280x720
5 1920x1200 6 1366x768 7800x600 8 1600x900 sta
Preferred Timings -
Note: Incorrect aspect ratio will display with horizontal or vertical bars to fill the excess space
Aspect Ratio -
0800x600p60 11024x768p60 21280x800p60 31280x1024p60 41366x768p60
51400x1050p60 61600x900p60RB 71600x1200p60 81680x1050p60 9 1920x1200pRB
10 1280x720p25 11 1280x720p29 12 1280x720p30 13 1280x720p50 14 1280x720p59
15 1280x720p60 16 1920x1080i50 17 1920x1080i59 18 1920x1080i60 19 1920x1080p23
20 1920x1080p24 21 1920x1080p25 22 1920x1080p29 23 1920x1080p30 24 1920x1080p50
1 Full 216:9 316:10 44:3 5 Keep Ratio
25 1920x1080p59 26 1920x1080p60 27 Input 28 Native sta
Output Resolution -
Each command is terminated with a carriage return.
Feedback is terminated with a carriage return and line feed.
Note: If the command fails or is incorrect the feedback should be “Command FAILED”

16
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Zone output parameter commands (for display control)
RS232para[baudrate,data-length,parity,stop-bit]
e.g. To change the output baud rate to 19200 use RS232para[19200,8,0,1]
RS232zone[command]
Once the scaler and zone output have been set up for the best communication, commands can
be sent to control the display. The commands will come from the user manual of the display or
projector. The commands and any carriage returns/line feeds in the commands will need to be
placed in the bracket.
e.g. To turn the display or projector on if the command is PWRON carriage return, use the command:
RS232zone[PWRONCR]CR
Note: CR = carriage return
Note: Use this command if the connected display uses a different baud rate
Note: Use this command if the connected control system does not output 115200
Scaler parameter command
CSpara[baudrate,data-length,parity,stop-bit] (data-length, parity, and stop-bit for switcher must be 8,0,1)
e.g. To change the baud rate to 38400 use CSpara[38400,8,0,1]
RS-232 Parameters
Default baud rate to control the scaler is 115200
Note: For the display’s actual baud rate, refer to the owner’s manual
To change the baud rate of the scaler (for scaler control - port 2) or the zone output (for display/projector
control - port 1), the commands below will be needed:
IP Commands
Command Feedback Description
IPCFG IP Addr : x.x.x.x
Netmask : x.x.x.x
Gateway : x.x.x.x
IP Port: x.x.x
Displays IP address configuration
IPTimeout XX
e.g. IPTimeout 120
IPTimeout XX
e.g. IPTimout 120
Determines amount of seconds of inactivity before TCP/IP
disconnects
IPAddUser TCP/IP username & password
list:
- user password
- user password
- user password
Will display a list of users
IPAddUser X Y TCP/IP user was added Add a user for TCP/IP control. X=User Y=Password
e.g. IPAddUser Atlona 1234 (User=Atlona 1234=Password)
IPDelUser X TCP/IP user was deleted Delete a user from TCP/IP X=User (Ex. IPDelUser Atlona)
IPDHCP sta IPDHCP sta
e.g. IPDHCP on
Displays the status of DHCP
IPDHCP on IPDHCP on Turns DHCP on
IPDHCP off IPDHCP off Turns DHCP off
IPStatic X Y Z
e.g. IPStatic
192.168.1.1
255.255.255.0
192.168.1.200
IPStatic X Y Z
e.g. IPStatic 192.168.1.1
255.255.255.0
192.168.1.200
Sets static IP address
IPStatic Address(X) Netmask(Y) Gateway(Z)
IPPort X IPPort X Set the TCP/IP port (ex. IPPort 230)
IPLogin X
e.g. IPLogin on
IPLogin X
e.g. IPLogin on
Enable/disable and view status of IP login X= on, off, sta
e.g. IPLogin is on
IPLogin on IPLogin on Enables IPLogin
IPLogin off IPLogin off Disables IPLogin
Broadcast X
e.g. Broadcast sta
Broadcast X
e.g. Broadcast on
Enable/disable and view status of broadcast mode X= on, off, sta
e.g. Broadcast is currently on

17
C1
C1
C1
C2
C2
C2
COM
COM
COM
Down
Closed
Open
Open
Closed
Up
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Relay
A dual low-voltage signal relay is built into the HDVS-200-RX for control of devices such as electric
screens and display lifts.
There are 3 connections for the relay: C1, COM, and C2 (Circuit 1, Common, and Circuit 2 - pictured
below). Connect wires from the device to the three pin captive screw connector (see picture below) and
then plug the connector into the relay port.
When using a dual signal relay with an
electric projection screen, it allows for two
different circuits to be controlled: up and
down. Examples of what that would look
like are pictured to the right.
When “Follow Display” is selected, the relay will trigger automatically based on the power/status
of the display/projector. If the HDVS-200-RX stops receiving a signal it will trigger one circuit (e.g.
up in the above example) and if the HDVS-200-RX starts receiving signal from the display it will trigger
the opposite circuit (e.g. down in above example). This provides a simple automatic solution for device
control.
Note: This relay is designed to be used with low voltage/current circuits
FW
RELAY
AT-HDVS-200-RX
C1 C2COM
HDBaseT INLAN HDMI OUT
L1
-+-
+
R2
RX RXTX TX
AUDIO RS-232 MENU AUTO
^
^
PW
LINK
-+
DC 48V

18
Connection Diagram (with HDVS-200-TX)
Video
HDBaseT
Audio
Ethernet
Dry CC
Control
HDMI IN 1
1
2
HDMI IN 2
HDMI
AUDIO IN
PW
VGA IN
VGA
HDBaseT OUTLAN
DISPLAY ^
^
INPUT VOL
FW RS-232
AT-HDVS-200-TX
RX
TX
FW
RELAY
AT-HDVS-200-RX
C1 C2COM
HDBaseT INLAN HDMI OUT
L1
-+-
+
R2
RX RXTX TX
AUDIO RS-232 MENU AUTO
^
^
PW
LINK
-+
DC 48V
ROUTER
2.4 5 1234
i
AT-HDVS-200-TX
Media Player
Laptop
AT-PA100-G2
Drop down projector screen
(contact closure controlled)
Document Camera
AT-HDVS-200-RX
Router
Projector
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515

19
LAN
1
12 1 2
34LRL R
2 3 4
INPUT
AT-UHD-CLSO-824
OUTPUT
5 6 7 8
RX
RS-232 MIC/LINE IN
LINE
MIC
48V
AUDIO IN
TX RX TX RX TX RX TX +-+ +
PWRIR
- -
+ - + -
<
<
DC 48V
-+
FW
RS-232IRAUDIO OUT
MASTER
OUTIN
RX TX
+-+-
56
12 3 4
5ENTER
MENU
678
RX TX RX TX
78
8
1
12
2
RS-232
RX TX RX TX
910
RX TX RX TX
LINE
MIC
48V
+-+-
L R
+-+-
AUDIO OUT
Connection Diagram (with Switchers)
Document Camera
Document Camera
HDMI 1
HDMI 2
HDMI 3
HDMI 4
HDMI 5
VOLUME
AT-UHD-SW-52ED
RIN
IR
OUT
+ + -
-
L
FW LAN
RS-232
RXP S S TX
DC 48V
HDMI IN HDMI OUT HDBaseT OUT
AUDIO
S/PDIF OUT
1 2 3 4 5
POWER INPUT
-+
FW
RELAY
AT-HDVS-200-RX
C1 C2COM
HDBaseT INLAN HDMI OUT
L1
-+-
+
R2
RX RXTX TX
AUDIO RS-232 MENU AUTO
^
^
PW
LINK
-+
DC 48V
FW
RELAY
AT-HDVS-200-RX
C1 C2COM
HDBaseT INLAN HDMI OUT
L1
-+-
+
R2
RX RXTX TX
AUDIO RS-232 MENU AUTO
^
^
PW
LINK
-+
DC 48V
ROUTER
2.4 5 1234
i
ROUTER
2.4 5 1234
i
AT-PA100-G2
Drop down projector screen
(contact closure controlled)
AT-HDVS-200-RX
AT-UHD-CLSO-824
AT-HDVS-200-RX
Router
Router
Projector
Display
Laptop
Laptop
Media Player
Media Player
RS-232
RX TX
IR IN
S
IR OUT
S
HDBaseT OUT
ETHERNET
HDMI IN
FW
DC 48V
LINK
POWER
AT-UHD-EX-100CE-TX
-+
Video
HDBaseT
Audio
Ethernet
Dry CC
Control
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515

20
Video Resolutions
IN 480i, 480p, 576i, 576p, 720p@25/29/30/50/59/60Hz,
1080i@50/59/60Hz, 1080p@23/24/25/29/30/50/59/60Hz
640x480, 720x400, 800x600, 1024x768, 1152x864, 1280x768,
1280x800, 1280x960, 1280x1024, 1366x768, 1400x1050
1440x900, 1600x900, 1600x1200, 1680x1050, 1920x1200RB
OUT 1080p@23/24/25/29/30/50/59/60, 1080i@50/59/60,
720p@25/29/30/50/59/60
1920x1200RB, 1680x1050, 1600x1200, 1600x900RB, 1400x1050,
1366x768, 1280x1024, 1280x800, 1024x768, 800x600
Color Space RGB, YUV
Color Depth 10-bit, 12-bit, 16-bit
Audio
Analog OUT PCM 2Ch
HDMI / HDBaseT PCM 2Ch, LPCM 5.1, LPCM 7.1, Dolby Digital, DTS 5.1, Dolby Digital Plus,
Dolby TrueHD, DTS-HD Master Audio, Dolby Atmos
Sample Rate 44.1kHz, 48kHz, 96kHz, 192kHz
Distance
CAT @ 1080p up to 100 m up to 328 ft
HDMI 10 m 30 ft
Signal
Bandwidth 6.75 Gbps
CEC No
HDCP Compliant
Temperature
Operating 0°C to 50°C 32°F to 122°F
Storage -20°C to 60°C -4°F to 140°F
Humidity 20 to 90% non-condensing
Power
Consumption 30W (when paired with HDVS-200-TX)
Supply Input: AC100-240V ~ 50/60Hz
Output: DC 48V/0.83A
Dimension
H x W x D 30 x 122 x 125 (mm) 1.18 x 4.8 x 4.92 (inch)
Weight
Device 0.46 kg 1.01 lbs
Certification
Unit CE, FCC
Power Supply CE, FCC, Level VI, RoHS, cULus, RCM, CCC
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
Specifications
Note: To ensure compatibility, please be certain both transmitter and receiver have blue HDBaseT ports. This
ensures both products are PoE (48V) compliant. The HDVS-200-TX is not compatible with PoCC
(black RJ45, 24V) devices
