Atomos Ninja V User manual

QUICK START GUIDE

2 NINJA V - Quick Start Guide
Introduction...............................3
Checklist .................................3
You will also need .........................3
Getting started ............................4
Connect and Power-up ....................5
Physical features ..........................6
Format SSD Media ........................8
Touchscreen/User Interface ...............9
Connect and Edit .........................10
AtomX Accessories ......................10
Warranty & Conditions ....................11
Contents

NINJA V - Quick Start Guide 3
Thank you for purchasing the Atomos Ninja V, utilising professional
HDMI 2.0 connectivity to record professional 4Kp60 and High
frame rate HD to Apple ProRes and Avid DNxHR. The class leading
AtomHDR monitor lets you visualize 10+ stops of dynamic range,
with 1000nit brightness for daylight viewing and 10-bit processing for
smooth gradations. With so many Recorder, Monitor, Playback & Edit
features, please take the time to read through this Quick Start Guide
and register your product for free updates and extended warranty.
DOWNLOAD THE FULL
NINJA V USER MANUAL
www.atomos.com/support
ACTIVATE AVID LICENSE
FOR DNxHD® and DNxHR®
www.atomos.com/activation
EXTENDED 3 YR WARRANTY
Register now to extend your warranty to
3 years from date of purchase.
www.atomos.com/registration
HDMI Cable
To support 4Kp60 recording please use cables that support HDMI 2.0
specication. Atomos have a range of 4Kp60 cables with die cast
connectors and coiled cables in a range of lengths and connections
(sold separately). See the full range of Atomos HDMI cables on our
website: www.atomos.com/hdmi-cables
SSD Drives and Docking Station
We test and approve SSD drives from the world’s leading media brands.
There are specic approved drives depending on the resolution and
frame rate you are capturing - for the full list of compatible drives please
refer to: www.atomos.com/drives
We also have a range of Docking Stations suitable for use with Ninja V
and compatible SSD media. Visit your nearest reseller or purchase online
at: shop.atomos.com
Checklist
You will also need (sold separately)
q 1 x Ninja V Recorder
q 1 x Master Caddy II
q 1 x AC Power Adaptor
q 1 x Battery Eliminator
q 1 x Quick Start Guide
Introduction

4 NINJA V - Quick Start Guide
Battery
You can power the device using the supplied AC power supply and
Battery Eliminator, but if you plan to use a battery we recommend you
fully charge before use.
Choosing the right battery for your application
Size Cells Battery Life Function
5200mAh 4Up to 2.0hrs monitor & record 4Kp60
7800mAh 6Up to 3.0hrs monitor & record 4Kp60
We recommend using Atomos NP-F series batteries.
Connect SSD
Before powering up the Ninja V unit, simply slide your selected disk into
disk slot (see page 7). To remove, ensure the unit is off and gently
slide out. We strongly recommend SSD for optimal performance and
recording.
IMPORTANT: Never remove the SSD whilst recording as this may
cause data corruption.
Introducing AtomX SSDmini
Atomos has teamed with the world’s leading media manufacturers to
design SSD media that is better suited to our ever evolving Recorder
Monitors.
The new AtomX SSDmini is a little over 1/4 inch tall and 3” long. It is
also 20% shorter than traditional SSDs, yet keeps the standard SATA
III connector. It is backward compatible with previous Atomos devices
by adding a clever extension handle. These tiny, slimline SSDs are
a true innovation and our close drive partners Angelbird and Sony
Storage Media Solutions Corporation are making custom versions
for your Ninja!
For more information about supported drives and accessories, visit:
www.atomos.com/drives
Getting started

NINJA V - Quick Start Guide 5
Connect and power-up
Battery
Ninja V has a single battery slot. To connect a compatible battery,
place the battery in front of the retaining lug, align with the
connectors and slide the battery into the lock position.
To connect the supplied Battery Eliminator, follow the same
procedure and lock battery into position. Once the Battery Eliminator
is in place, secure the supplied AC/DC power supply to the DC jack.
Alternatively, the Ninja V unit can be powered via a D-Tap power
source using D-Tap battery cable (ATOMDTPCB1).
Touching the Battery icon in the top right of your screen will allow you
to accurately see remaining battery life. Refer to the User Manual for
more information.
Expansion Port
The Ninja V features a built in Expansion Port that will soon enable
- Synchronization control
- I/O Expansion
- Continuous Power Module
(See page 7)
DC jack
Supplied Battery Eliminator
P/N: ATOMDCA001

6 NINJA V - Quick Start Guide
a. On/O and Screen Lock
To turn the Ninja V on, press the power button on the side of the unit.
To shut down, hold the button for at least 4 seconds (until unit turns off).
b. Remote Control/LANC and Calibration
Optionally control the Ninja V using LANC/Remote from your camera.
Additionally, the Ninja V screen can be calibrated using the X-Rite
i1Display Pro. To connect you will need a USB to serial cable. Refer to
the AtomX accessory range. USB to serial cable (ATOMCAB004).
c. HDMI In/Out
HDMI input connection used to record to the Ninja V supports up to
4Kp60. HDMI Output connection provides a live loop out or play out
when in Playback mode. Supports up to 4Kp60.
d. Battery Release Button
Press the release button and slide battery away from unit to remove.
e. Tally Light
Red Tally light on the rear of the unit indicates active recording.
The Tally Light can be turned off in the menu options.
f. Screw Holes / Mounts + Locking Pin Holes (Arri)
3/8” screw hole with 1/4” adapter. Top and bottom.
g. Disk Slot
The NinjaV is compatible with Master Caddy II media and also the
latest AtomX SSDmini.
Physical features
f. 3/8” screw hole with 1/4” adapter
f. 3/8” screw hole with 1/4” adapter
a.On/Off and
Screen
Lock
c. HDMI In
c. HDMI Out
b. Remote
d. Battery
release

NINJA V - Quick Start Guide 7
e. Tally light f. 3/8” screw hole with 1/4” adapter
f. 3/8” screw hole with 1/4” adapter
d. Battery
release
g. Disk slot
Expansion Port

8 NINJA V - Quick Start Guide
DC
1
Touchscreen / User Interface
Main controls
The Ninja V is controlled by a simple user-friendly touchscreen
interface. Pictured below is the home screen and main controls seen
when the Ninja V is rst powered up. Touching the icons will open
menus for the relevant functions. Touch the settings icon located on
bottom right to access more menus, or touch individual icons for
specic settings such as timecode, audio, remaining disk space and
more. For the most up-to-date information visit: atomos.com/ninjav
and click SUPPORT tab

NINJA V - Quick Start Guide 9
Connect and Edit
To access and edit your recorded material
You will require a USB 3.0 Docking Station or USB-C 3.1 Docking Station.
These are available from your reseller, or visit shop.atomos.com to
purchase the Docking Station that is best suited to your requirements.
Connect the Docking Station to a Mac®or Windows®editing
workstation via USB 2.0 / USB 3.0 / USB-C 3.1 compatible port/s.
When using USB 2.0, you may need to connect the second USB
power cable on the dock to a second USB 2.0 port. This will ensure
enough power is provided when using USB 2.0.
Insert SSD it into the Docking Station. After a short wait your recorded
video will become accessible as a standard external disk.
