FastFrame™ 10GbE Network Interface Card
Getting Started Guide
Thank you for purchasing the ATTO FastFrame 10GbE Network Interface Card (NIC). This
guide gives you the basics for installing and configuring your adapter. For more information,
please visit our website at www.attotech.com
1 Overview
This guide covers hardware and software
installation, setup procedures, and
troubleshooting tips for ATTO FastFrame 10Gb
Ethernet adapters.
Note
This guide refers to drivers and features available on
IA-32 based computer platforms and platforms based
on Intel® Extended Memory 64-bit Technology. These
drivers are not compatible with Itanium®-based
computers.
Ensure you have the equipment and software
you need for the installation:
• FastFrame NIC
• A computer with an available PCIe or PCIe
2.0 expansion slot
• Cables, connectors and SFP+ modules
2 System Requirements:
Before installing the ATTO FastFrame 10Gb
Ethernet Adapter, check your system for the
following minimum configuration
requirements.
Supported Operating Systems
Please visit https://www.attotech.com/ for an
up-to-date list of all currently supported
operating systems.
The installer for the adapter drivers will only
list the drivers that are compatible with the
currently running operating system.

3 Installing Drivers
Configure your system to recognize and use your
FastFrame NIC by installing drivers for your
operating system.
Windows
1 Power on your system and log in as the
administrator or a user with proper
administrative privileges
2Gotowww.attotech.com
3 Click on downloads.
4 Register or log in if previously registered.
5 Click on Ethernet Adapters in the left dialog.
6 Navigate to your HBA model/family in the
right dialog and click on it.
7 Scroll down to and click the desired driver
depending on the operating system.
8 A download window appears. Choose Save
File.
9 Double-click the downloaded file to extract
and launch the driver setup program.
10 Follow the on-screen instructions to complete
the driver installation.
11 Click Install Windows Driver XX next to the
appropriate item to initiate the driver setup
program.
12 Follow the on-screen instructions to complete
the driver installation.
Note
XX refers to the version number.
Mac OS X
1 Power on your system and log in as the
administrator or a user with proper
administrative privileges
2Gotowww.attotech.com
3 Click on downloads.
4 Register or log in if previously registered.
5 Click on Ethernet Adapters in the left dialog.
6 Navigate to your HBA model/family in the
right dialog and click on it.
7 Scroll down to and click the desired driver
depending on the operating system.
8 A download window appears. Choose Save
File.
9 Launch the installer package.
10 Follow the on-screen instructions.
4 Hardware Installation
Note
If you are replacing an existing adapter with a new
adapter, you must re-install the driver.
Insert a PCI Express Adapter in the Server
1 Turn off the server and unplug the power
cord, then remove the server's cover.
CAUTIONCAUTION
Turn off and unplug the server before removing the
server's cover. Failure to do so could endanger you and
may damage the adapter or server.
2 Remove the cover bracket from a PCI
Express slot (v1.0a or later).
PCI-Express slots and adapters vary in the
number of connectors present, depending on
the data lanes being supported.
3 Insert the adapter in an available, compatible
PCI Express slot. Push the adapter into the
slot until the adapter is firmly seated. The
adapter can be installed in x8 or x16
mechanical PCIe slot.
CAUTIONCAUTION
Some PCI-Express adapters may have a short connector,
making them more fragile than PCI adapters. Excessive
force could break the connector. Use caution when
pressing the board in the slot.
4 Repeat steps 2 through 3 for each adapter
you want to install.
5 Replace the server cover and plug in the
power cord.
6 Turn the power on.
Connect a 10GbE Fibre Network Cable
CAUTIONCAUTION
This product uses a Class 1M laser module. Viewing the
laser output with certain optical instruments designed for
use at a distance (for example, telescopes and binoculars)
may pose an eye hazard.
Remove and save the fiber optic connector
cover. Insert a fiber optic cable into the ports on
the network adapter bracket.
Most connectors and ports are keyed for proper
orientation. If the cable you are using is not
keyed, check to be sure the connector is
oriented properly (transmit port connected to
receive port on the link partner, and vice versa).
For ATTO FastFrame 10Gb Ethernet Adapters:
Laser wavelength: 850 nanometer
Cable type to use: Multi-mode fiber with 62.5µm
or 50µm core diameter
Connector type: LC.
Maximum cable length: 300 meters (with laser
optimized).
The adapter must be connected to a compatible
link partner, such as an IEEE 802.3ae-compliant
10-gigabit switch, which is operating at the same
laser wavelength as the adapter.
5 Configure Network Settings
To configure your network settings, consult your
System Administrator or System
Documentation.
6 Configure your Adapter
Default settings are appropriate for most
systems but you may change settings using the
Device Manager in Windows, EthTool in Linux
or Network section of System Preferences in OS
X.
