Product Features
Tech-
For More Information:
RAID Adapter
3-Gb SAS/SATA II Connectivity with
Integrated RAID Support
ATTO introduces the ExpressSAS R380 Low-
Profile RAID Adapter. Providing 3-Gb SAS/SATA II
connectivity with integrated RAID support and eight
external ports, the ATTO SAS RAID adapter is
ideal for both IT and digital video environments that
require a high level of data protection and perform-
ance.
The ATTO ExpressSAS host adapter product
family provides enhanced reliability and
performance thanks to more than 15 years of
experience with SCSI hardware and storage
connectivity solutions. Using PCI Express bus tech-
nology and an eight external port configuration, the
ATTO ExpressSAS R380 RAID adapter delivers
blazing fast performance with transfer rates of up to
3-Gb per second per port. With two external x4
Mini SAS connectors, the R380 provides connec-
tivity of up to 128 SAS/SATA targets. The R380
also features 256MB of ECC-protected DDR2
DRAM to allow support for multiple RAID groups.
The ATTO ExpressSAS R380 RAID adapter is
engineered for the most stringent IT server and
digital media workgroup environments. To satisfy
the data protection requirements of these
environments, ATTO leverages it’s time tested
ATTO RAID Stack (ARS™) technology based on a
proven RAID core that is compatible with multiple
operating systems, applications, and drives.
The easy-to-use GUI utility enables RAID
management, monitoring, and configuration. ATTO
also incorporates it’s field proven Advanced Data
Streaming (ADS™) technology to meet the most
demanding performance requirements of data
intensive applications. In addition, ATTO provides
industry standard PCIe to SAS control using Serial
SCSI Protocol (SSP), Serial ATA Tunneling
Protocol (STP), and Serial Management Protocol
(SMP).
Technical Highlights
• x8 PCIe host interface
• True low-profile form
factor
• 8 external ports
• Outstanding performance
with up to 3-Gb/sec per
port
• Highly configurable
RAID (0, 1, 4, 5, 6, 10, 50,
60, JBOD and DVRAID
support)
• SAS, SATA and SATA II
connectivity
• Supports up to 128
virtual SAS/SATA drives
• Exclusive Advanced Data
Streaming (ADSTM)
technology
• User friendly GUI
configuration utility
• Driver support for
Windows®, Linux and
Mac®OS X
• RoHS Compliant
• 3-year standard
product warranty
Blazing Fast Performance
• Up to 3-Gb/sec per port
transfer rates with SAS, SATA
and SATA II attachment
• Increased bandwidth through
x8 PCI Express host interface
• Point-to-point technology
delivers full throughput to
each connected storage
device
Smooth Data Streaming
• Alleviate data transfer
bottlenecks and move data
more efficiently while
managing latency with
ATTO’s exclusive ADS™
technology
• Improve I/O through
optimized data movement
One Click Installation
• One-click installation allows
for quick and easy set-up
• Simple GUI based utility for
effortless adapter
configuration
• BIOS setup utility provides
flexibility for custom
applications
ExpressSAS R380 RAID Adapter
ExpressSAS R380
Low-Profile SAS RAID Adapter

Rev 9/08
©2008 ATTO Technology, Inc. Specifications subject to change without notice
Technical Specification Power Behind the Storage
For More Information:
Hardware Specifications
Applications • Support for IT server and digital media workgroup solutions requiring high-bandwidth and data
protection. Applications include audio/video, VOD, fixed content, database and other data intensive
environments.
Maximum Transfer Rate • Up to 3-Gb/sec per port
Advanced Capabilities • Device support for SAS, SATA and SATA II
• SES Support
• S.M.A.R.T Support
• Support for Staggered drive spin-up
• Pass-through mode to support tape devices
• Support for RAID levels 0, 1, 4, 5, 6, 10, 40, 50, 60, JBOD and DVRAID
• On-line capacity expansion
• Hot spare, auto-rebuild
• Native Command Queuing
• Cache memory—256MB ECC protected memory
• User friendly GUI for RAID setup
• External LEDs for on-line status
PCI Bus Specifications • x8 PCI Express host interface
• Supports PCI Express Base Spec 1.0a
Connectivity • Easy-to-install full height connection bracket; low-profile bracket included in Finished Goods packaging
• Two x4 External Mini SAS (SFF-8088) connectors
Software Specifications
Driver Support • Windows® Server 2003, 2008, XP, Vista
• Mac®OS X (10.4.x & 10.5.x)
• Linux (Fedora, Red Hat and SuSE)
Agency Approvals
Safety and Environmental • FCC Rules, Part 15, Class B
• CE Mark: CISPR 22:2002
• EN55022:2002, Class B
Compliancy • RoHS Compliant
Environmental & Physical Specifications
Dimensions • Conforms to PCI low-profile form factor specifications
• Length 6.600”
• Height 2.713”
Operating Environment • Temperature: 0-40° C (32°-104°F)
• Humidity: 5 - 95% non-condensing
Storage Environment • Temperature: -40°-70°C (-40°-157°F)
• Humidity: 5 - 95% non-condensing
Power • 12V @ 1.05A max.
• 3.3V @ 0.45A max.
Airflow • 150 lf/m (min) recommended
Ordering Information
Model Number • ESAS-R380-000 (RoHS)
ExpressSAS Low-Profile RAID Adapter
3-Gb SAS/SATA II Connectivity with Integrated RAID Support
ExpressSAS R380 RAID Adapter
