AUDAC ARU2 Series Installation instructions

1
ARU2xx commands manual
Index
Introduction 2
Using the commands 3
Configuration and settings commands 4
GIP Get IP 4
SIP Set IP 4
SEVNT Set event 4
SGEVNT Get event 5
SXEVNT Execute event 5
SAS Set address Switch Unit 5
ASF End set address Switch Unit 5
SDPUD Set delayed power up Delay 6
SDPU Set delayed power up 6
SGTYPE Get the type of switch unit 6
SGCFG Get config 6
Relay commands
SRON Switch on relay 7
SROFF Switch off relay 7
SRBUT Switch on 1 relay, rest is switched off 7
SPULS Puls relay 8
SDELON Switch delay on 8
SDELOFF Switch delay off 9
Paging commands
PGRQ Paging request 10
PG Start/Stop paging 10
Misc commands
WOS Who is online switch unit 10
GTIME Get time 10
GDATE Get date 11
SGREV Get hardware revision 11
SGHW Get hardware type 11
SGSV Get software revision 11
FLCLR Erase flash 11
EECLR Erase EEPROM 12

2
Introduction
Welcome to the commands user manual of the Audac ARU2xx series. This manual describes the commands whereby
the range of relay units can be controlled using their remote control ports. The ARU2xx series can be controlled using
the web interface, audac touch 2 or by RS485 and TCP/IP commands which are listed further in this document.

3
Using the commands
Depending of the type of device the different kinds of communication ports are:
- RS-485 port
- TCP/IP port
RS485 Configuration details
RJ45 (RS485, Digital audio, +24V DC):
For connection to Wall Panels & Paging Consoles
Pin 1 White-Orange AUDIO TX A
Pin 2 Orange AUDIO TX B
Pin 3 White-Green +24V DC
Pin 4 Blue RS485 A
Pin 5 White-Blue RS485 B
Pin 6 Green GND
Pin 7 White-Brown AUDIO RX A
Pin 8 Brown AUDIO RX B
TCP/IP Configuration details
IP Address User configurable
Port 5001
Max connections 1
Command overview
Startsymbol | Destination | Source | Command | Argument(s) | Checksum | Stopsymbol
Each command is followed by an ‘x’ character, which represents the number of the slot whereto the command
is sent. If the audio player doesn’t support multiple slots, the number ‘1’ shall always be used.
Example: Get IP---
ASCII: #|S001|F001|GIP|U|return
HEX: 237C533030317c463030317c4749507c557c72657475726e0a
Notes
• The checksum is CRC-16 excluding the ‘#’. The checksum can always be replaced by
‘U’, which is always accepted.
• Return in ASCII : <CR> <LF> HEX : 0x0D 0x0A (carriage return & line feed)
• Source address has a maximum length of 4 characters and cannot contain ‘|’ or ‘#’
Command flow
1) The client sends a command to the relay unit (Command)
2) The relay unit acknowledges the command by returning the same
command and a ‘+’ as Argument. (Acknowledge)
3) The relay unit updates with the new information (Update)

4
CONFIGURATION AND SETTING COMMANDS
GIP
Get info about the ip address, subnet mask and gateway the relay unit is using:
Command: GIP
Arguments: None (0)
Feedback: dhcp^ip4.ip3.ip2.ip1^mask4.mask3.mask2.mask1^gw4.gw3.gw2.gw1^
DHCP: dhcp ON(1) or OFF(0)
IP: IP4 address of unit
MASK: subnet mask
GW: IP4 address of gateway
Example: Get info about the IP address
#|S001|F001|GIP||crc|<CR><LF>
ARU replies: #|F001|S001|IP|0^192.168.0.197^255.255.255.0^192.168.0.1|crc|<CR><LF>
SIP
Set IP address, subnet, gateway and dns servers:
Command: GIP
Arguments: ^ip4.ip3.ip2.ip1^mask4.mask3.mask2.mask1^gw4.gw3.gw2.
gw1^dns4.dns3.dns2.dns1^adns4.adns3.adns2.adns1
dhcp : dhcp ON(1) or OFF(0)
ip : IP4 address of unit
mask : subnet mask
gw : IP4 address of gateway
dns : IP4 address of dns server 1
adns : IP4 address of dns server 2
Feedback: + : acknowledge
Example: Set the IP address
#|F001|S001|SIP|0^192.168.0.197^255.255.255.000^192.168.0.1^8.8.8.8^0.0.0.0|U|<CR><LF>
ARU replies: #|F001|S001|SIP|+|crc|<CR><LF>
SEVNT
Set event:
Command: SEVNT
Arguments: ^xx^cc^hhmmss^yymmdd^ww^dest^cmd^param^U
xx: event nr
cc: header, must be 55 for valid event
hhmmss: time for event to execute
yymmdd: date for event to execute
ww: weekday for event to execute
dest: Address of ARU
cmd: cmd to execute
can be SRON, SROFF, SRPULS, SRBUT
param: parameters of command
Feedback: + : acknowledge
Example: Set event
#|S001|F001|SEVNT|^01^55^170500^181206^01^S001^SRON^00000055^U|U|<CR><LF>
ARU replies: #|F001|S001|SEVNT|+|crc|<CR><LF>

5
SGEVNT
Set event:
Command: SGEVNT
Arguments: xx
xx: event nr
Feedback: ^xx^cc^hhmmss^yymmdd^ww^dest^cmd^param^U
xx: event nr
cc: header, must be 55 for valid event
hhmmss: time for event to execute
yymmdd: date for event to execute
ww: weekday for event to execute
dest: Address of ARU
cmd: cmd to execute
can be SRON, SROFF, SRPULS, SRBUT
param: parameters of command
Example: Get event
#|S001|F001|SGEVNT|01|U|<CR><LF>
ARU replies: #|F001|S001|EVNT|^01^55^170500^181206^01^S001^SRON^00000055^U|crc|<CR><LF>
SXEVNT
Execute event:
Command: SXEVNT
Arguments: xx
xx: event nr
Feedback: +
+: Acknowledge
Example: Execute event 01
#|S001|F001|SXEVNT|01|U|<CR><LF>
ARU replies: #|F001|S001|SXEVNT|+|crc|<CR><LF>
SAS
Set address switch unit
Command: SAS
Arguments: xxx
xxx: address of the unit
On receive the LED flashes.
Feedback: +
+: Acknowledge, if switch is pressed
Example: Set unit address 199
#|ALL|web|SAS|199|U|<CR><LF>, when received, led starts flashing
ARU replies: #|web|S199|SAS|+|crc|<CR><LF> after switch has been pressed.
ASF
End Set address switch unit
Command: ASF
Arguments: xx
xx: event nr
Feedback: +
+: Acknowledge
Example: End set address
#|ALL|web|ASF||crc|<CR><LF>
ARU replies: led stops flashing after receive of command

6
SDPUD
Set delayed power up Delay
Command: SDPUD
Arguments: x
x: 1 to 9999 ms power up sequence at startup
0 Use potentiometer for timing
Feedback: +
+: Acknowledge
Example: set delay to 99ms
#|S001|web|SDPUD|99|crc|<CR><LF>
ARU replies: #|web|S001|SDPUD|+|crc|<CR><LF>
SDPU
Set delayed power up
Command: SDPU
Arguments: x
x: 1 delayed power up sequence at startup
0 No delayed power up sequence at startup
Feedback: +
+: Acknowledge
Example: set delayed power up
#|S001|web|SDPU|1|crc|<CR><LF>
ARU replies: #|web|S001|SDPU|+|crc|<CR><LF> and #|ALL|S001|DPU|x|crc|<CR><LF>
SGTYPE
gets type of the switch unit
Command: SGTYPE
Arguments:
Feedback: xx
xx: 04 - 4channel
xx: 08 - 8channel
Example: get type of switch unit
#|S001|web|SGTYPE||crc|<CR><LF>
ARU replies: #|web|S001|SGTYPE|04|crc|<CR><LF>
SGCFG
gets config
Command: SGCFG
Arguments:
Feedback: TT^SAAA^PP^DDDD
TT: Type 04, 08, 16
SAAA: own address “S001”
PP: Powerup delay if 01
DDDD: delay time in ms
Example: get config
#|S001|web|SGCFG||U|<CR><LF>
#|web|A001|SCFG|08^S0001^01^0099|crc|<CR><LF>

7
RELAY COMMANDS
In paging mode (set by jumper B in top position)
The relays are by default powered ( relay is in NO position )
The relay switches off when bit is set( relay is in NC position )
In normal mode (set by jumper B in bottom position)
The relays are by default not powered ( relay is in NC position )
The relay switches on when a bit is set( relay is in NO position )
SRON
Switch on relay
Command: SRON
Arguments: 000000rr
rr: 8 bit hex value, bit0 = relay 1 bit7 = relay 8
if bit = 1 then relay is active
Feedback: +
+: Acknowledge
Example: Activate relay 1
#|S001|web|SRON|00000001|crc|<CR><LF>
ARU replies: #|web|S001|SRON|+|crc|<CR><LF> and #|ALL|S001|SZSET|0001|crc|<CR><LF>
SROFF
Switch off relay
Command: SROFF
Arguments: 000000rr
rr: 8 bit hex value, bit0 = relay 1 bit7 = relay 8
if bit = 1 then relay is active
Feedback: +
+: Acknowledge
Example: Deactivate relay 1
#|S001|web|SROFF|00000001|crc|<CR><LF>
ARU replies: #|web|S001|SROFF|+|crc|<CR><LF> and #|ALL|S001|SZSET|0000|crc|<CR><LF>
SRBUT
Activate 1 relay, rest is deactivated
Command: SRBUT
Arguments: 000000rr
rr: 8 bit hex value, bit0 = relay 1 bit7 = relay 8
if bit = 1 then relay is active
Feedback: +
+: Acknowledge
Example: activate relay 3
#|S001|web|SRBUT|00000004|crc|<CR><LF>
ARU replies: #|web|S001|SRBUT|+|crc|<CR><LF> and #|ALL|S001|SZSET|0004|crc|<CR><LF>

8
SPULS
Puls relay
Command: SPULS
Arguments: tttt^00rr
tttt: time to pulse relay in 1/10s
rr: 8 bit hex value, bit0 = relay 1 bit7 = relay 8
if bit = 1 then relay is active
Feedback: +
+: Acknowledge
Example: Relay 1 of S001 is pulsed for 0.5 seconds
#|S001|web|SPULS|0005^0001|crc|<CR><LF>
ARU replies: #|web|S001|SPULS|+|crc|<CR><LF> and #|ALL|S001|SZSET|0001|crc|<CR><LF>
SDELON
Switches all relays on with a delay.
Command: SDELON
Arguments: dddd
dddd: 0 to 9999ms delay between each relay
Feedback: +
+: Acknowledge
Example: swith all relays on with 100ms delay time
#|S001|web|SDELON|0100|crc|<CR><LF>
ARU replies: #|web|S001|SDELON|+|crc|<CR><LF> and status from all relays
#|ALL|S001|SZSET|0001|crc|<CR><LF>
#|ALL|S001|SZSET|0003|crc|<CR><LF>
#|ALL|S001|SZSET|0007|crc|<CR><LF>
#|ALL|S001|SZSET|000F|crc|<CR><LF>
#|ALL|S001|SZSET|001F|crc|<CR><LF>
#|ALL|S001|SZSET|003F|crc|<CR><LF>
#|ALL|S001|SZSET|007F|crc|<CR><LF>
#|ALL|S001|SZSET|00FF|crc|<CR><LF>
Note: All relays will be switched on with a delay, direction relay1 -> relay8
This function can also be programmed to do at powerup
- with the command “SDPU” argument ‘1’
- by placing jumper A into lower position
The delay time is set by the command “SDPUD” argument 0 to 9999
The potentiometer is used for timing when delay is set to 0

9
SDELOFF
Switches all relays off with a delay.
Command: SDELOFF
Arguments: dddd
dddd: 0 to 9999ms delay between each relay
Feedback: +
+: Acknowledge
Example: swith all relays off with 100ms delay time
#|S001|web|SDELOFF|0100|crc|<CR><LF>
ARU replies: #|web|S001|SDELOFF|+|crc|<CR><LF> and status from all relays
#|ALL|S001|SZSET|007F|crc|<CR><LF>
#|ALL|S001|SZSET|003F|crc|<CR><LF>
#|ALL|S001|SZSET|001F|crc|<CR><LF>
#|ALL|S001|SZSET|000F|crc|<CR><LF>
#|ALL|S001|SZSET|0007|crc|<CR><LF>
#|ALL|S001|SZSET|0003|crc|<CR><LF>
#|ALL|S001|SZSET|0001|crc|<CR><LF>
#|ALL|S001|SZSET|0000|crc|<CR><LF>
Note: All relays will be switched off with a delay, direction relay8 -> relay1
This function can also be programmed to do at powerup
- with the command “SDPU” argument ‘1’
- by placing jumper A into lower position
The delay time is set by the command “SDPUD” argument 0 to 9999
The potentiometer is used for timing when delay is set to 0

10
PAGING COMMANDS
PGRQ
Paging request
Command: WOS
Arguments: pppp^ww^0000rrrr^l
pppp: priority level 0000 to 9999
ww: wallpanel port (must be 00 for ARU)
rrrr: zones to page : 32 bit bit0=zone 1 bit31=zone 32
l: local=0 or global=1 (must be 1 for ARU)
Feedback: +
+: Acknowledge
Example: A001 send request to S001 for zone4
#|S001|A001|PGRQ|0999^01^00000008^0|U| <CR><LF>
ARU replies: #|A001|S001|PGRQ|+|crc|<CR><LF> (for ACK if paging not busy in requested zones)
or: #|A001|S001|PGRQ|-|crc|<CR><LF> (for NACK if paging busy in requested zones)
PG
Paging start/stop
Command: PG
Arguments: s
s: status start=1 stop=0
Feedback: +
+: Acknowledge
Example: start paging
#|S001|A001|PG|1|U|<CR><LF>
MISC COMMANDS
WOS
Check which relay units are online
Command: WOS
Arguments:
Feedback: +
+: Acknowledge
Example: who is online
#|ALL|web|WOS||U|<CR><LF>
ARU replies: #|web|S001|OS|+|crc|<CR><LF>
GTIME
Get time
Command: GTIME
Arguments:
Feedback: hh:mm:ss
Example: get time from relay unit
#|SOO1|web|GTIME||U|<CR><LF>
ARU replies: #|web|S001|TIME|15:04:35|crc|<CR><LF>

11
GDATE
Get date
Command: GDATE
Arguments:
Feedback: dd/mm/yyyy
Example: get date from relay unit
#|SOO1|web|GDATE||U|<CR><LF>
ARU replies: #|web|S001|DATE|24/10/2019|crc|<CR><LF>
SGREV
Get hardware Revision
Command: SGREV
Arguments:
Feedback: Vxxx
Example: get hardware Revision
#|S001|web|SGREV||U|<CR><LF>
ARU replies: #|web|S001|SREV|V1.0|crc|<CR><LF>
SGHW
Get hardware type
Command: SGHW
Arguments:
Feedback: ARU2xx
Example: get hardware Revision
#|SOO1|web|SGHW||U|<CR><LF>
ARU replies: #|web|S001|HW|ARU208|crc|<CR><LF>
SGSV
Get software revision
Command: SGSV
Arguments:
Feedback: Vxxx
Example: get software Revision
#|SOO1|web|SGSV||U|<CR><LF>
ARU replies: #|web|S001|SV|V1.0|crc|<CR><LF>
FLCLR
Erase flash
Command: FLCLR
Arguments:
Feedback: +
+: Acknowledge
Example: erase flash
#|S001|web|FLCLR||U|<CR><LF>
ARU replies: #|web|S001|FLCLR|+|crc|<CR><LF>

12
EECLR
Erase EEPROM
Command: EECLR
Arguments:
Feedback: +
+: Acknowledge
Example: erase EEPROM
#|S001|web|EECLR||U|<CR><LF>
ARU replies: #|web|S001|EECLR|+|crc|<CR><LF>
