Audio Control Digital Equalizer User manual

DQT
Owner’s Enjoyment Manual
Stereo One-Third Octave
Digital Equalizer
AudioControl®
22410 70th Avenue West • Mountlake Terrace, WA 98043 USA
Phone [phone] • Fax [phone]
www.audiocontrol.com
Digital
FusionTM Mobile Audio
Digital
FusionTM Mobile Audio
tm

Owner’s Enjoyment Manual
AudioControl
This page was intentionally left bland

Owner’s Enjoyment Manual
Digital
Fusion™
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Features and Highlights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Quick Installation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
A Guided Tour of the DQT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installing the DQT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Placement and Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Power Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Audio Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Level Matching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
DQT Menu Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Equalization Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Graphic versus Parametric Equalization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Owner’s Enjoyment Manual
AudioControl

Owner’s Enjoyment Manual
Digital
Fusion™
Introduction
Welcome to the world of Digital Fusion. The
fusion of AudioControl’s lengthy experience in
performance signal processing combined with
state-of-the-art Digital Signal Processing (DSP)
technology. Congratulations also on your pur-
chase of the DQT, the world’s first thirty-band,
one-third octave stereo and parametric, digital
equalizer, utilizing AudioControl’s Digital Fusion
technology. Whether you are a die-hard sound-off
competitor or you just enjoy good music, you will
definitely enjoy how great the DQT will make
your performance autosound system sound.
Now before you start salivating too much just
thinking about the benefits of the DQT, take a few
minutes to sit back, have a latte’, decaffeinated if
necessary, and read through this manual. It con-
tains lots of useful facts and information - - and
besides, we spent a lot of time writing it!
KEY FEATURES OF THE DQT
Here are some of the cool features that are
enclosed in this magical box:
• 30 bands of constant-Q equalization
• Dual, fully-adjustable parametric equalizers
• Eight non-volatile memories
• 24 bit digital signal processing
• Digital Fusion technology
• Balanced differential inputs
FEATURES AND HIGHLIGHTS
24 bit Digital Signal Processing:
AudioControl’s Digital Fusion signal processors
use a special 24 bit DSP that was specially designed
for equalization and other dynamics processing.
In addition, matching 24 bit A/D - D/A converters
are incorporated for maximum sound quality.
Constant-Q equalization controls: Car
interiors vary widely in size and acoustic make-
up. In addition doors, kick-panels, and rear decks
don’t make the best location for speaker place-
ment causing your high performance speaker
system to sound somewhat lackluster. The DQT
offers thirty precise equalization controls, spread
equally across the audio spectrum, at one-third
1

Owner’s Enjoyment Manual
AudioControl
octave increments for maximum control. In addi-
tion each equalization filter utilizes precise constant-
Q topology, traditionally utilized only in the highest
performing professional audio products.
Parametric equalization controls: In
addition to the thirty, one-third octave spaced
controls, the DQT also offers two, fully-adjustable
parametric equalization controls for each channel.
With the DQT’s parametric controls, a user can
select a center frequency, dial in the ideal band-
width and apply the appropriate amount of boost
or cut. The precise filtering of the DQT allows you
to select bandwidths as narrow as 1/12 octave!
Non-volatile memories: The DQT has the
ability to allow the user to set and store eight
different equalization settings in individual
memory locations.
Pre-Amp Line Driver: The DQT offers a high
quality line driver that takes the low output
voltage of a source unit and increases it up to 18dB.
This allows you to drive your amplifiers to their
maximum output without clipping. No hiss,
clicks, or pops plus maximum sound quality.
Bulletproof Warranty: The most impor-
tant feature of all. Every AudioControl product is
selflessly designed and manufactured by the
occupants of our Pacific Northwest rainforest
factory. We take every effort to ensure that you
will have many years of enjoyment out of your
DQT. To ensure the performance of this new
Digital Fusion product, we highly recommend
that you allow your authorized AudioControl
dealer to perform the installation. Not only do
they have all the right knowledge and tools, but
in the unlikely chance your DQT should stop
working, we will back it with a limited five years
parts and labor warranty. Should you choose to
install it yourself we will still give you one-year
parts and labor warranty. To activate your war-
ranty, you need to FILL OUT AND SEND IN YOUR
WARRANTY CARD!
We also recommend that you save your invoice
or sales slip as proof of installation and ownership.
Not only is it necessary for warranty purposes, but
should your DQT “disappear” one day while your
car is parked at your local latte’
stand, you will find insur-
ance companies very
unforgiving without
proof of purchase.
2

Owner’s Enjoyment Manual
Digital
Fusion™
QUICK INSTALLATION
INFORMATION -
For those of you short on time, but high on
ambition, we offer the following section to speed
up your installation of the DQT:
1. The DQT needs to be installed in the signal path
between your source unit and your external
amplifier(s). If this is not obvious to you,
quickly pack up your DQT and run to your
nearest authorized AudioControl dealer to have
them perform the installation. You will thank
us later.
2. Physically mount the DQT in a location that
keeps it away from soda spills, food crumbs, and
curious fingers. However you will want to select
a location that allows you to see the display and
access the equalization controls.
3. Hook up +12 volt power, ground, and remote
turn-on. If you need to know more, then read
on. Heck if you don’t think you need to know
more, you should still read on, because you can
never know too much.
4. Adjust the “Input Level” control on your DQT
to match the source unit’s and then adjust the
“Output” to match with your amplifier inputs.
5. Now comes the fun part. Set your equalization
controls to where your system sounds the most
balanced yet dynamic. More about this in the
section titled “Adjusting Your Equalizer”...and
you thought you would not have to read the
rest on the manual. Hah!
3
Note:
You will want to turn the gains on
your amplifiers DOWN to maximize
your systems performance.
Figure 1: Basic DQT System

Owner’s Enjoyment Manual
AudioControl
A GUIDED TOUR OF THE DQT
1) Inputs: The DQT has two RCA inputs that
need to get their audio signals from your source
unit. If your source unit has multiple outputs (like
a front, rear, and/or subwoofer) you only need to
connect the front or rear outputs to your DQT.
2) Input Level: This knob allows you to
maximize the signal level from your source unit
that goes into your DQT to achieve maximum
signal to noise. Keep in mind, that despite what
the literature says, most aftermarket source units
produce a relatively low voltage signal when it
comes to playing music at normal levels.
3) Input Maximized Indicator: This nifty
LED light indicates that you are supplying the
DQT its maximum amount of signal voltage. If
the LED indicator never comes on, don’t assume
that you it is not working (since LED’s rarely
break) but you might consider adding a line driver
to your system.
4) Output Level Control: Although your
DQT has the ability to increase your signal voltage
18 dB, your amplifiers may not necessarily accept
that much signal. These controls allow you to
regulate the proper amount of pre-amp signal
from the DQT to the amplifiers.
5) Equalization Overload Indicator: This
convienient LED indicates when the DSP (digital
signal processor) of your DQT is clipping or
distorting. The usual cause of this is having the
“Input Level” turned up too high or you have
boosted too many frequencies on your equalizer.
6) Select: This allows you to scroll through the
various equalization or memory modes of your
DQT.
7) Navigation Arrows: These multi-func-
tion buttons let you navigate within each of the
various modes and utilize the features of your
DQT.
8) Output Voltage Indicators: These
brightly colored LED’s indicate the level of signal
voltage at the outputs of your DQT. You will be
happy to know that they dance up and down
with your music.
9) Outputs: These RCA connectors should be
connected to the next component after the DQT,
such as a crossover or amplifier. Do not connect
any speakers directly to your DQT or connect
your DQT to any home appliances, like your
toaster.
4

Owner’s Enjoyment Manual
Digital
Fusion™
10) Power Connections: This
nifty connector is a godsend to
anyone who has tried to wire up
their gear with their body crammed
in the trunk. You can wire up the
power, ground, and remote turn-on
from the convenience of outside
your car and then casually plug it
into your DQT.
5
Figure 2: Top view of DQT
¶·¸¹ º»¼
¾½
DQT 24bit Digital EQ
By AudioControl

Owner’s Enjoyment Manual
AudioControl
INSTALLING THE DQT
Up to this point everything you have read has
served to educate you on the operations of your
DQT. We are sure that you are now chomping at
the bit to install your DQT so we recommend you
read the following sections very carefully.
A. Placement and mounting of the DQT
Placement: The DQT needs to be installed in
the signal path after your source unit but defi-
nitely before your amplifiers and/or any other
signal processors or active crossovers. The chassis
is usually mounted in the rear of the vehicle, as
close to the amplifiers as possible.
Mounting: Once you have selected a perma-
nent mounting location, position the unit and
mark the appropriate mounting holes with a felt-
tip pin or scratch awl. Before doing anything else,
make sure you are not about to drill a hole in a gas
tank or piercing any existing wiring. Nothing
ruins your day more than an expensive repair bill.
Drill a few small pilot holes and secure the chassis
of the DQT with self-tapping screws.
6
B. DQT Power Wiring
WARNING: Failure to disconnect the
negative terminal of your battery prior to the
installation of your DQT can result in a
warm tingly feeling.
Remote Turn-On: Connect a 22 to 18 gauge
wire from the head-unit’s remote turn-on to the
“Remote” connector on the DQT .
Positive(+12V) Connection: Insert a 12-18
gauge wire into the connector labeled “Power” on
the nifty connector of your DQT. Connect it to a
good constant source of 12 volts (we suggest the
battery), fused at 1 amp.
Ground Connection: Use the same gauge
wire as you did for the positive connector and run
it from the “Ground” connector on the DQT to
the negative terminal of the battery, a ground bus,
or a verified ground location. The factory head
unit ground is not a good ground!
Figure 3: Side view of DQT
with power connector and RCAs
Remote Power Ground

Owner’s Enjoyment Manual
Digital
Fusion™
Figure 4: DQT with DXS
Figure 5: DQT with a FOUR.1
When the electrical connections are complete,
you may reconnect the negative terminal to your
battery.
C. DQT Audio Wiring
Planning: As you may already have guessed,
there are numerous ways to configure the DQT in
your audio system. Spend a little quality time
7

Owner’s Enjoyment Manual
AudioControl
planning out your system and even sketching it
out on paper. The following diagrams are just a
few of the system options:
D. Level Matching
If you have ever listened to a friend’s “killer” car
audio system and heard lots of hiss, clicks or pops,
then you have experienced an improperly level
matched system. When a performance
autosound system is properly level matched, you
should get the maximum output from your
source unit processors and amplifiers without any
clipping or that annoying hiss! The following
steps will help guide you through the process,
although at the end of the day, your ears will be
your guides!
1) Set your source units fader and balance controls
to their center positions.
2) Disconnect the output RCA connections be-
tween your DQT and the amplifier(s). . . or next
processor in line.
3) Start playing some relatively dynamic music
and set the volume on your source unit to
about 3⁄4of maximum. You should not be
hearing anything at this point. If you are
hearing music, go back to step #2; if you are
hearing voices go see a doctor!
8
4) Starting with the DQT “Input Level” control,
increase or decrease the control knob until the
“Input Maximized” LED begins to flicker
steadily with the music.
5) Now adjust the output level control until the “2
volt” or “5 volt” light starts to flicker. You will
want the output voltage to match up your
amplifiers input gain levels. If you don’t know
how much this is, ASK the amplifier manufac-
turer or read the owners manual of the ampli-
fier.
6) Very Important - Set the input gains on the
amplifier(s) at minimum!
7) Double check that you performed Step #6
8) Decrease the volume control on your source
unit and re-connect the RCA’s between the DQT
and the amplifier(s).
9) Now increase the volume on your source unit
to your normal listening level. For some of you,
this may be louder than others!
10) At this point you may find yourself going back
and adjusting the “Output Level” controls on
your DQT to accommodate for the speaker
placement and efficiency.
Note After making your equalization
settings you may need to readjust your output
levels.

Owner’s Enjoyment Manual
Digital
Fusion™
9
1) Digital Status Display: This sexy blue
display reflects which mode your DQT is in.
2) Select: Every time you touch this button, your
display will change reflecting the fact that you
are now accessing a one of the various modes in
the DQT. Your choices are GraphicEQ, ParaEQ 1,
ParaEQ 2, Memories, or Display. After a brief
period of no key presses, the display will return
the Splash Screen.
3) “+” and “-” Navigation Buttons: Depend-
ing upon where your cursor is flashing, these
buttons will allow you to change a frequency,
apply boost and/or vary the bandwidth of your
equalization filters.
4) Left and Right Navigation Buttons:
Within each mode there are generally 4 or 5
different functions you can select (i.e. Freq,
Width, Save, Bright,) By tapping on
these buttons and following the
cursor, you can navigate
through each function on
the screen.
Digital Fusion
By AudioControl(r)
Figure 6: DQT main menu screen
¶
·¸¹
DQT MENU SCREENS
One of the major benefits of using Digital Fusion
technology is the ability to use less knobs and
buttons and get more control. The DQT has two
mono 30 band graphic equalizers plus two stereo
parametric equalizers. This is a stack of equipment
that would normally fill your trunk. Digital Fusion
technology allows the DQT to offer a plethora of
features in one compact chassis. In addition there
are only a few buttons to learn so navigating
through the DQT’s functions is quite simple.
When you first apply power to your DQT, it will
go through a “wake up” screen, including some
subliminal advertising for AudioControl. It will
then display a friendly blue screen. Fear
not, the blue screen on the
DQT is actually a good
thing. Press the Select
button to select through
the menus. Once your
DQT has settled on one of
these menu screens, you will
want to spend a few minutes
familiarizing yourself
with the various modes.

Owner’s Enjoyment Manual
AudioControl
symbol “>o<“ in the middle of the lower part of
the screen. By tapping the “+ or -” buttons you can
apply an equal boost or cut to both channels.
Separate left and right equalization: If
you wish to apply boost or cut to the left or right
channels individually, tap the left or right arrows
and the cursor will move to the number after “L=
or R=”. You can now apply boost or cut, using the
“+ or -” controls.
Once you have made your equalization setting,
you will want to tap the Select button, go to the
Memories screen, and save your equalization
settings in one of the memory locations.
MODE: ParaEQ 1and ParaEQ2
Besides offering a 30 band graphic equalizer,
your DQT also has two, fully programmable
parametric stereo equalizers. These allow you to
10
MODE: GraphicEQ
Your DQT has 30 built-in graphic equalization
filters with fixed, constant-Q, center frequencies.
They just happen to match those on the Audio-
Control SA-3055 real time analyzer. In the
GraphicEQ mode, you can select any of the 30
frequencies, one at a time and apply boost or cut.
In addition you can select whether you want the
equalization controls to affect the left and right
channels individually or control both channels at
the same time.
Freq (uency): This corner of the screen shows
which frequency you are boosting and cutting. If
you wish to select another frequency, just tap the
left or right arrow buttons until the cursor is
flashing on the number next to “Freq=.” Then use
the + or - controls allows to select the frequency
you wish to apply boost or cut.
Stereo Equalization: After you have selected
a frequency, use the left and right navigation
controls to move the cursor until it stops on the
Figure 8: Para EQ1 screen
Para EQ1 Freq=3.15k
Width=1/6 LVL=+12dB
Figure 9: Para EQ2 screen
Para EQ2 Freq=3.15k
Width=4 oct LVL=0dB
Figure 7: Graphic EQ screen
Graphic EQ Freq = 1kHz
L= +6dB >o< R =+4dB

Owner’s Enjoyment Manual
Digital
Fusion™
MODE: Memories
This screen allows you to save or recall settings
using one of the eight memory locations. Using
the Left and Right navigation arrows will cause
the cursor to highlight one of the following
functions:
Recall: Use the left or right navigation arrows
to move the cursor next to the word Recall. Push
the “+” or “-” button to change the memory to
which you are listening. All the stored settings are
automatically recalled as you change the memory
number.
Save: Once you have made your graphic and
parametric equalization settings, you will want to
store them in one of the eight memory locations.
To save a memory, you need to use the left/right
navigation arrows to move the cursor until it is
select a frequency, apply the proper amount of
boost or cut, and change the bandwidth or “Q” of
the filter.
Para EQ1 mode allows you set the controls for
one of the parametric equalizers.
Para EQ2 lets you change the settings for the
second parametric EQ band.
Freq (uency): This corner of the screen shows
which frequency you are boosting and cutting. If
you wish to select another frequency, just tap the
left or right arrow buttons until the cursor is
flashing on the number next to “Freq. Then use
the + or - controls allows to select the frequency
you wish to apply boost or cut.
Lvl: When the cursor highlights on this screen,
you can now apply boost or cut to both channels,
using the “+ and -” controls. You will note that
you cannot use the parametric equalizers on the
left and right channels individually.
Width: This control lets you select how wide of
an area the DQT’s parametric equalizer affects.
You can choose a real narrow bandwidth, like 1/
12th of an octave or go as wide as three full oc-
taves.
11
Memories Recall #7
Save
Figure 10: EQ Recall Memories screen
Memories Recall
N (-) Y(+) Save #5
Figure 11: EQ Save Memories screen

Owner’s Enjoyment Manual
AudioControl
flashing next to Save. Push the “+” or “-” buttons
to select the memory destinsation to where you
are saving. Then use the left/right navigation
buttons to move N(-) Y(+) display area. Tap the
“(+)” button to complete the saving process or (-)
to quit the memory saving process.
MODE: Display
In this mode, you have the ability to select
between two levels of brightness for the display on
your DQT. Using the left and right navigation
buttons, toggle back and forth between “Bright”
and “Dim” and stop on the level of lighting you
are most comfortable with you. Tap the “Select”
button and your last display brightness setting
will be retained as you move on to the next mode.
ADJUSTING THE EQUALIZER
When it comes to music, everyone has his or her
own particular taste. Some people want pounding
bass and crisp, blood curdling highs. Others may
prefer a “flat” response, or at least think it is flat.
At the end of the day, most people just want their
system to sound balanced, “just like it did in the
store” or their buddy’s car. The following equal-
ization guidelines should help you achieve your
own personal audio nirvana.
1) For optimum performance, get your hands on a
test compact disc that contains pink noise and
a good quality RTA (real time analyzer); we
happen to know someone who makes a really
good one. If you cannot locate an RTA, you
probably want to have your authorized
AudioControl dealer perform the equalization
adjustments as they will have one. You can
certainly “try” adjusting your DQT using your
ears, however an RTA will give you the best
results.
2) Begin playing pink noise through your system
and place the microphone for your analyzer on
a microphone stand in the drivers seat. The
microphone should be sitting where your head
12
Display
Bright Dim
Figure 12: Display screen

Owner’s Enjoyment Manual
Digital
Fusion™
13
Figure 13: sample curve
designed to give enough control to maximize
your systems performance but not enough to
get you in trouble. Here is an explanation of the
key areas you should focus on:
Sub-bass: 100 Hz and below - A car without
bass is like a day without sunshine... unless you
live where we do because most of the days in the
Pacific Northwest do not have sunshine. This area
is one of the more difficult to properly reproduce.
Most people refer their bass frequencies to be 6 to
9 dB louder than the rest of their system, although
there are some crazy folks that prefer their bass
substantially louder. The key in this area is to
have enough speakers and power to produce the
amount of bass you desire but don’t use the con-
trols on the DQT to try and force your speakers to
produce sounds they can’t. Too much bass boost
creates a condition called “speakerus explodus”,
which is not pretty to
hear or watch.
Midbass: 100 Hz
to 300Hz - The
phrase, “too much of a
good thing” can cer-
tainly apply to the
midbass frequencies.
This is the transition
usually goes. Take a careful look at the “curve”
on your analyzer and how one frequency
combines with the next. There is no one curve
that will satisfy every person, as we all have
different tastes. How else can you explain
Liberace or rice cakes? The key is to use your
DQT to help balance your system from one
frequency to the next and give your speakers
the sparkle, sizzle, detail or punch that the
acoustics of the car have compromised.
3) You will want to start equalizing by removing
any large bumps, peaks, or areas with too much
energy at a particular frequency. Next, boost
the ranges that do not have enough energy. We
strongly recommend that you cut or decrease
energy before you boost.
4) Although the plethora of controls on your DQT
can be intimidating, fear not as they were

Owner’s Enjoyment Manual
AudioControl
14
area of the audio spectrum that is an octave above
your sub-bass frequencies and several octaves
below your midrange. Most autosound systems
have too much midbass due to the fact that
speakers mounted in the doors or kick panels
cause resonance’s or peaks in the response curve.
These peaks in the midbass can actually mask or
block sounds in the all-important midrange area
causing your system to sound dull or lifeless. This
is one of the areas where the parametric controls
on your DQT will work well.
Midrange: 300Hz to 3Khz - Musical instru-
ments, vocals, mid-range percussion and many
things we associate with imaging and staging
happen in this area of the bandwidth. For that
reason you will want to keep this area as smooth
and balanced as possible. Too much boosting can
make you feel like your listening to your system
in a tile bathroom. Not enough energy midrange
sounds empty and dry.
Treble: 3KHz and Up - If midrange is the
cake, then these high or upper frequencies are
considered the frosting. Many autosound systems
start a gradual decline in this area due to low
speaker placement (which is why speaker place-
ment is very important). Too much boosting can
really make a speaker sound unnatural.
GRAPHIC VERSUS
PARAMETRIC EQUALIZATION
Your DQT is a very unique equalizer as it con-
tains both a 30 band Graphic and a 2 band para-
metric equalizer. Depending upon the situation
in your system you will probably find yourself
using both graphic and parametric controls. Both
perform special functions that you will want to
take full advantage of.
The graphic equalizer in your DQT has 30
frequency controls with fixed center frequencies
and fixed bandwidths that use a precise constant-
Q topology. What this means is that if you are
applying boost or cut at 500 Hz, you will have
very little affect on the frequencies below and
above 500 Hz.
On the other hand, the parametric equalizer
gives you the ability to select a center frequency,
increase or decrease the bandwidth (how wide or
narrow of an area you wish to equalize) and then
apply boost or cut. A parametric works best in
areas where you would generally be combing
several graphic bands to affect a certain area of the
audio spectrum. For example, if your system has a
too much midbass, you would normally have to
use several of the Graphic Equalization controls at

Owner’s Enjoyment Manual
Digital
Fusion™
100 Hz, 125 Hz, 160 Hz, 200 Hz, and 250 Hz to
control the area. Or you can use one parametric
control centered at 160 Hz and set the bandwidth
at 1 octave and you can perform a global adjust-
ment of the entire midbass region.
The other excellent use for a parametric band is
very narrow cut of a problem area. The 1⁄12 and 1⁄6
octave band width allows this narrow fine tuning.
TROUBLESHOOTING
No Power: If the Power LED on your DQT does
not turn on, check to make sure that the power
wire and remote turn on wires are connected or a
fuse is not blown.
System Sounds Unbalanced: Check your
graphic equalization settings to make sure that
one channel is not dramatically different than
another.
Sounds Distorted: Should your system sound
distorted or your speakers are moving way too
much, you should make sure you have your levels
matched properly and that your amplifier gains
are set at minimum. Make sure the “Maximized”
or “Overload” LEDs are not on steady. If this
checks out okay, you will want to look at your EQ
controls to insure that your boost levels are not
too high.
Still Sounds Distorted: Look at the frequen-
cies that you have selected for Para EQ 1 and Para
EQ 2 and see how much boost or cut you have
applied. Than look at those same frequencies on
your Graphic EQ. If you have boost applied to the
same frequencies on both types of equalizers,
there is a strong chance you are overdriving your
speakers and amplifiers at that frequency.
Output Voltage LED’s Don’t Light Up: If
your system is playing music but none of the
output LED’s are on, there is a good chance that
the output voltage of your source unit is not that
strong. Now before you call us and say, “The guy
at the store said my radio has high-voltage out-
put”, you might want to face the fact that there is
“Engineering Voltage” and there is “Marketing
Voltage”. Most source units are also tested at
maximum output, not the level that most of us
listen to. Without picking on any particular
source unit, remember that you do get what you
pay for.
15

Owner’s Enjoyment Manual
AudioControl
16
UNDER THE COVER
Beside all of the clever buttons on the outside of
your DQT, there are a few factory preset functions,
located under the cover, that assist in maximizing
the performance of your DQT. To access these
jumpers you will need to remove the 4 each top
screws and carefully lift the chassis top. You will
note that there is a ribbon cable that connects the
display, mounted on the chassis top, to the main
circuit board. Once under the cover, you will
access to the following jumpers:
1. Input Grounding: For most systems you
can leave this jumper set in the BALANCED
position. In some systems, the amplifier may look
for a ground through the RCA connection to the
source unit and create a ground loop, which in
turn can cause a whine (not the type that comes
in a bottle) in your system. In that event, you
should go ahead and change the jumper to the
UNBALANCED position.
2. Ground Isolation Selector: Occasionally
alternator noise may appear in a system because
the source unit and amplifier are using different
grounding schemes. To help in this situation, we
have provided alternative grounding connections.
Make sure your system is turned OFF before you
move these jumpers.
FACTORY SETTINGS
Shipped Options
Input
Grounding Balanced Unbalanced
Ground
Isolation Isolated 200ohm or Ground
Choice
of beverage Micro-brew Latté
·¶
Figure 14: Inside of DQT
DQT 24bit Digital EQ
By AudioControl
