Audio enhancement Ultimate III Instruction manual

DVD
Level controls for Media (Line) Sources
Front Panel line
input for a
portable device
Output level control
for Assistive Listening
Front Panel line level
output for Assistive
Listening Device such
as a Student FM transmitter
Teacher and Student Volumes are
remotely controlled from the
Teacher Microphone and not from
the front panel of the amplier.
See the other side of this sheet for
detailed remote volume control
information.
Turn power on to
activate classroom
sound system
UP Volume
control button
DOWN Volume
control button
Charging the Microphone
Press and hold for 3
seconds to activate
SAFE alert system.
See the other side
for detailed
SAFE System
information
Press and hold PWR button
to turn microphone On/O
A momentary press of PWR
button will Mute/Unmute
microphone audio
Student
Microphone
Active
System Power ON
Teacher
Microphone
Active
Step 1. Position the Micro Teardrop Teacher Microphone with
the black back of the microphone facing towards you.
Step 2. Align the charger connector so that the small triangle
shaped arrow on the charging connector is facing you.
Step 3. Insert the connector into the microphone.
Front Panel Controls
IR-Satellite LED Indicators
Ultimate III Amplier
Quick-Start Manual
1

DVD
2
Equalizer
Auxiliary Inputs
Speaker Outputs
Paging Input
IR-Satellite Input Terminal Line Output
Teacher Override
DC Power Connector
Conference Mode

3
Optional SAFE System Alert Activation
Press and hold
the Function button for
3 seconds
[Requires installation of SAFE (Security Alert For Education)
System components]
You can tell that the microphone
sent the Alert signal when the
Red CHG light is illuminated.
The three LEDs on the ceiling mounted
dome sensor will turn Red indicating
that the signal has been sent.
Remote Volume Control of the Teacher
and Student Microphones
UP Volume
control button
DOWN Volume
control button
Teacher Microphone (OWN) Level Adjustment
Student Microphone (OTHER) Level Adjustment
Blinks with each
button press
Blinks with each
button press
The “SELECT” button determines which level
will be controlled by the UP/DOWN buttons
If your classroom is equipped with the
SAFE System you can send an alert by
pressing and holding the Function
button on your microphone. The Red
CHG light will illuminate on the face of
the microphone and three Red LEDs
will illuminate on the ceiling mounted
IR-Satellite dome sensor indicating
that the ALERT signal has been sent.
Multimedia Level Adjustment
Press either the UP or DOWN arrow
button to increase or decrease the
level of the Teacher microphone. A
blue LED over the“OWN”(for own
microphone) will ash with each
press.
The appropriate LED (#1) on the
dome sensor will blink with each
button press of UP or DOWN.
To adjust the Student (OTHER)
volume, rst press the“SELECT”
button so that the blue LED over the
“OTHER” label comes on. Now press
the UP/DOWN buttons to control the
level of the “OTHER”microphone,
which is typically the Student
microphone.
If multimedia is routed through the
IR-Satellite, then the Line Level
Control on the microphone does
adjust the level for those devices.
DC-40337.01
