Audio international AI-LCD68-01-xx User manual

7300 Industry Drive, North Little Rock, AR 72117
Phone: [phone] Fax: [phone]
www.audiointl.com
Installation and Operation
Manual
AI-LCD68-01-xx
6.8" LCD Monitor w/Arm
Document # 540300
a DeCrane Aircraft Company

Audio International, Inc. AI-LCD68-01-xx Installation and Operation Manual
Document # 540260, Rev IR, 11/2004 Page 1 of 15
Document Revision History
Rev. Level Date Description
IR 11/2004 Initial Release
Reference Documents
Document # Description
525176 Rev IR AI-LCD68-01-02 Outline Drawing
525186 Rev IR AI-LCD68-01-13 Outline Drawing
Service Bulletin List
Service
Bulletin # Subject Manual Revision
Revision
Date
Table of Illustrations
Section # Description Page #
2.1 Monitor Buttons 4
4.1 Arm Mobility 10
6.1 AI-LCD68-01-02 Reference Drawing 14
6.2 AI-LCD68-01-13 Reference Drawing 15
PROPRIETARY NOTICE: Despite any other copyright notice, this document and information
disclosed herein contains confidential, proprietary designs owned by Audio International, Inc.
Neither this document nor the data contained herein shall be reproduced, used, or disclosed to
anyone without the written authorization of Audio International, Inc.

Audio International, Inc. AI-LCD68-01-xx Installation and Operation Manual
Document # 540260, Rev IR, 11/2004 Page 2 of 15
Table of Contents
Section Description Page
1.0 General Information ……………………………………………. 3
1.1 Introduction ……………………………………………………….. 3
1.2 Purpose of the Equipment ………………………………………. 3
1.3 Operation Features………………………………………………. 3
1.4 Optional Equipment ……………. .…………………………….. 4
2.0 Application ……………………………………………………….. 4
3.0 Installation ……………………………………………………….. 5
3.1 Prior to Installation ……………………………………………….. 5
3.2 Unpacking and Inspection ………………………………………. 5
3.3 Cautions & Warnings …………………………………………….. 6
3.4 Wiring Requirements …………………………………………….. 6
3.5 Electrical Characteristics…………………………………………. 7
3.6 Physical Characteristics………………………………………….. 8
3.7 Mating Connector Information ……………..……………………. 8
3.8 Pinout Assignment Descriptions ………………………………... 9
4.0 Operation…………………………………………...…………….. 10
4.1 Arm Mobility………………………………………….…………… 10
5.0 Troubleshooting Guide……………………..………………….. 11
5.1 Post-Installation Test …………………………………………….. 11
5.2 Cleaning Method………………………………………………….. 11
5.3 General Troubleshooting Procedures ………………………….. 12
5.4 Instructions for Continued Airworthiness……………………….. 12
5.5 Troubleshooting Chart……………………………………………. 12
6.0 Specifications …………………………………………………… 13
7.0 Reference Drawings ……………………………………………. 14
7.1 AI-LCD68-01-02…………………………………………………… 14
7.2 AI-LCD68-01-13…………………………………………………… 15

Audio International, Inc. AI-LCD68-01-xx Installation and Operation Manual
Document # 540260, Rev IR, 11/2004 Page 3 of 15
AI-LCD68-01-xx
6.8" LCD Monitor Plug In
1.0 General Information
1.1 Introduction
This manual contains information for the proper installation of the Audio
International, Inc. (AI) 6.8" LCD Monitor with Arm Assembly, Model No:
AI-LCD68-01-xx. The “-xx” suffix in the model number designates the type
of connector utilized by the plug-in arm; “-02” utilizes the Cannon
MS3126F12-10P connector and “-13” utilizes the MDM-9SH003B micro
D-Sub 9-pin connector. Also included are physical and electrical
characteristics of the unit.
1.2 Purpose of the Equipment
Audio International’s AI-LCD68-01-xx is a compact, lightweight LCD
monitor specially designed for use with AI 202000xx plug-in arm assembly
in a corporate aircraft environment. The monitor's unique display and
control electronics architecture allow a compact size while still maintaining
robust mechanical strength and reliability.
To ensure excellent display quality, the AI-LCD68-01-xx monitor combines
high resolution and the latest TFT technology, which provides brilliant and
accurate color reproduction, excellent high contrast images, cross talk
suppression, and fast response time with no distortion or smearing.
AI-LCD68-01-xx connects to a versatile plug-in arm with three (3) axis
points designed to provide the user with maximum viewing options (see
Section 4.0) while maintaining low weight.
1.3 Operational Features
• DO-160 tested
• 16 million, 24-bit colors
• Excellent viewing angle
• NTSC video format
• Operates directly from +28 VDC with low power consumption
• Compact, lightweight package
• Solid state circuitry
• Ultra thin construction
• NTSC video input

Audio International, Inc. AI-LCD68-01-xx Installation and Operation Manual
Document # 540260, Rev IR, 11/2004 Page 4 of 15
• Utilizes a versatile arm mount to give user maximum viewing options
• Easy to mount and connect
1.4 Optional Equipment
Audio International, Inc. offers a comprehensive family of source
equipment and cabin speaker systems. These modules can provide
excellent additions for any cabin environment. Audio International
furnishes equipment suited for any desired in-flight entertainment system.
Contact your AI representative for details.
2.0 Application
2.1 The monitor possesses three (3) buttons mounted on the lower face; far
right-most button (Power On/Off), Center Button (Brightness Up), and far
left-most button (Brightness Down).
Brightness Up and Brightness Down controls allow the user the ability to
increment or decrement through 16 levels of brightness, from 5 to 250 NIT
range.

Audio International, Inc. AI-LCD68-01-xx Installation and Operation Manual
Document # 540260, Rev IR, 11/2004 Page 5 of 15
2.2 Typical interfaces include various types of video source equipment. This
unit is capable of interfacing and accepting NTSC video input from all
standard COTS (Commercial-Off-The-Shelf) video source equipment
including but not limited to: Camcorder, Live-Feed Camera, DVD, VCP
and VCR players as well as Moving Map Systems utilizing NTSC, and
Personal Game Systems.
3.0 Installation
3.1 Prior to Installation
During the design and layout of the aircraft cabin, careful consideration of
the location of this module is necessary. Some of the items to be
considered include:
3.1.1 The AI-LCD68-01-xx shall be installed to conform to the standards
designated by the customer, installing agency, and existing
conditions as to the unit location and type of installation.
3.1.2 Locate the monitor as close as possible to source equipment to
reduce the possibility of noise introduced into the video.
3.1.3 The –02 version's base unit is furnished with MS connector and
hardware to mount connector to base while the –13 version is
furnished with a D-Sub connector. Install mating connector keyway
facing the same direction as the swivel arm keyway to insure
proper alignment.
3.2 Unpacking and Inspection
3.2.1 Carefully open the packaging and remove the AI-LCD68-01-xx.
Verify that all components have been included in the package per
the packing list. Inspect the unit for damage. Retain the packing
materials and packing list.
3.2.2 If damage has occurred during shipping, a claim should be filed
with Audio International WITHIN 24 hours and a Return Request
Authorization Number shall be obtained from AI by contacting the
Repair Department at 501.801.0640. Repackage the unit in its
original packaging materials and return it to AI following instructions
given by the AI representative. Refer to the front cover of this
manual for address. If no return is necessary, retain the packing
list and the packing materials for storage.

Audio International, Inc. AI-LCD68-01-xx Installation and Operation Manual
Document # 540260, Rev IR, 11/2004 Page 6 of 15
3.3 Cautions and Warnings
3.3.1 It is important to do a pin-to-pin power and ground check on all
connectors. Audio International recommends using an Electrical
Meter set to read Ohms or an Audible Continuity Tester to confirm
that the pins are connected via wiring. Ensure that power and
ground are applied only where specified. Damage to the unit may
result if power or ground is applied to the wrong points.
3.3.2 DO NOT connect or disconnect the monitor while power is applied.
3.3.3 DO NOT remove any factory-installed screws. Damage to the units
may result and void any warranties.
3.3.4 DO NOT expose to moisture.
3.3.5 Maintain an operating temperature of -15°to +55°C (+5°to +131°
F). Storage temperature must remain between -20°to 70°C (-4°to
158°F)
3.3.6 ESD (Electro Static Discharge) guidelines shall be followed.
3.4 Wiring Requirements
3.4.1 Introduction
The installing agency shall supply and fabricate all external cables
and mating connectors. The length and routing of external cables
should be carefully studied and planned before attempting
installation of the equipment in order to help avoid potential noise
sources and ground loops. Length and routing of external cables
should be considered to avoid possible noise sources and ground
loops. Maintain a minimum clearance of three (3) inches from any
control cable. If wiring is run parallel to combustible fluid or oxygen
lines, maintain a separation of six (6) inches between the lines.

Audio International, Inc. AI-LCD68-01-xx Installation and Operation Manual
Document # 540260, Rev IR, 11/2004 Page 7 of 15
3.4.2 Power Wires
Audio International recommends that power and ground wires be
20 AWG minimum. The chassis shall be electrically bonded to the
airframe structure by a conductive mounting point with <0.1 Ω
resistance using <50 Ωimpedance cable. Aluminum wool, nylon
webbing impregnated with aluminum oxide abrasive or fiber bristle
brushes are the approved tools for removing anodized surfaces at
mounting point where the bonding wire is attached. Power and
Ground wires shall be in accordance with NEMA WC 27500 or
equivalent. Protect power wires with circuit breakers or fuses
located close to the electrical power source bus.
3.4.3 Video Lines
Composite video connections shall be shielded coaxial cable in
accordance with M17/94-RG179 or equivalent. Cable shields shall
be grounded at the source. Use of individual wires rather than
proper coaxial cable connections through production breaks is
unacceptable, and will cause significant and detrimental noise
introduction to the video signal supplied to the AI-LCD68-01-xx.
3.5 Electrical Characteristics
3.5.1 Electrical Specifications, AI-LCD68-01-xx:
Electrical Input Power 300 mA @+28 VDC
Operating Voltage
Range
+14 VDC to +32 VDC
(Nominal +28 VDC)
Screen Size 6.8" diagonal
Aspect Ratio 4:3
Resolution 1152 V x 234 H pixels
(non-interfaced)
Color Configuration RGB Stripe
Pixel Pitch 0.120(H) x 0.442(V) mm
Colors 16 Million, 24 Bit
Viewing Angle > 120° H, > 90° V
Brightness 250 NITS
Contrast Ratio 150:1 typical
Response Time 30 mS typical
Backlight Fluorescent Tube
Video Format NTSC
Video Input 1 V(p-p), 75 Ω

Audio International, Inc. AI-LCD68-01-xx Installation and Operation Manual
Document # 540260, Rev IR, 11/2004 Page 8 of 15
3.5.2 Power protection via internal thermal fuses and thermal current
limiting.
3.5.3 Video inputs cannot be paralleled to two (2) monitors. Call AI
Systems Engineering Department for video installation assistance.
3.6 Physical Characteristics
3.6.1 Monitor utilizes plug-in shaft with key-way for “one-way alignment”
and top mounted release button.
3.6.2 Arm assembly is black anodized 6061-T6 aluminum.
3.6.3 Monitor chassis material is 6061-T6 milled aluminum with a black
powder coat finish.
3.6.4 This unit is designed for vertical mounting only.
3.6.5 Maintain an operating temperature between -15°to +55°C (+5°to
+131°F)
3.7 Mating Connector Information
All wiring harnesses to the unit shall be supplied and fabricated by the
installing agency.
Model # Connector # Mating Connector
AI-LCD68-01-02 J1
Cannon
MS3120F12-10S installed in
AI-BSE65-04-x
AI-LCD68-01-13 J1 Mounted in AI-BSE65-02-x Base,
MDM-9PH003B

Audio International, Inc. AI-LCD68-01-xx Installation and Operation Manual
Document # 540260, Rev IR, 11/2004 Page 9 of 15
3.8 Pinout Assignment Descriptions
3.8.1 Pinout assignment for the AI-LCD68-01-02 base (AI-BSE65-04-x) is
as follows:
J1
Pin # Description
A POWER GROUND
B RESERVED
C +28VDC POWER INPUT
D RESERVED
E RESERVED
F RESERVED
G VIDEO -
H VIDEO +
J RESERVED
K RESERVED
3.8.2 Pinout assignment for the AI-LCD68-01-13 base (AI-BSE65-02-x )
is as follows:
J1
Pin # Description
1 GROUND
2 RESERVED
3 +28VDC POWER INPUT
4 RESERVED
5 RESERVED
6 RESERVED
7 VIDEO -
8 VIDEO +
9 RESERVED

Audio International, Inc. AI-LCD68-01-xx Installation and Operation Manual
Document # 540260, Rev IR, 11/2004 Page 10 of 15
4.0 Operation
4.1 Arm Mobility
The arm assembly possesses three (3) axis points of articulation as
shown below. Note the tension adjust positions for the rotation axes as
well as the Release Button used when tilting monitor forward or backward
(70˚rotation). The Release Button must be pressed to remove monitor
from base. AI-LCD68-01-02 shown for reference purposes. "Monitor
Face" labels indicate side with viewing screen.

Audio International, Inc. AI-LCD68-01-xx Installation and Operation Manual
Document # 540260, Rev IR, 11/2004 Page 11 of 15
5.0 Troubleshooting Guide
5.1 Post-Installation Test
5.1.1 Verify +28 VDC power has been connected to the unit.
5.1.2 Ensure that AI-LCD68-01-xx retains full range of motion (see
Section 6.0, Reference Drawings, for motion limits).
5.1.3 Ensure video can be seen on monitor.
5.2 Cleaning Method
AI-LCD68-01-xx should be cleaned at least once every three (3) months
or when excessive dust or dirt becomes apparent.
Use a twin pack cleaning system that employs a wet pad pre-moistened
with an Isopropyl Alcohol based cleaner/anti-static solution and a lint-free
drying cloth. Audio International, Inc. recommends using “Kleen & Dry”
RR1205 manufactured by READ RIGHT, Nanuet, NY 10954.
 Do not use benzene, ammonia, thinner, or any other volatile
substances to clean the monitor or screen. These chemicals may
damage the screen or internal circuitry.
 Do not allow cleaner to puddle or pool around edges. Seepage
may damage internal circuitry.
Audio International’s recommended cleaning method follows:
A. Turn off monitor.
B. Open pre-moistened pad and gently wipe evenly
across display glass. Do not allow solution to “pool”
or puddle around display edges.
C. Immediately dry display using the absorbent, lint-free
cloth. Gently wipe display to a dry, clear finish.

Audio International, Inc. AI-LCD68-01-xx Installation and Operation Manual
Document # 540260, Rev IR, 11/2004 Page 12 of 15
5.3 General Troubleshooting Procedures
• Verify power to the unit by rechecking +28 VDC power is applied to the
proper pins on the unit. Use a voltmeter to verify correct level.
• Remove power from the unit for at least one (1) minute and reapply
power.
• Recheck all connections to the unit for security. Check all harness
runs for possible pinching. Recheck all pinouts for application
accuracy.
5.4 Instructions for Continued Airworthiness
No periodic scheduled maintenance or calibration is required for continued
airworthiness of the AI-LCD68-01-xx, 6.8" Monitor Plug In. If the unit fails
to perform to specifications, it must be removed and serviced by a
qualified service facility.
5.5 Troubleshooting Chart
Problem Possible Cause Solution
Poor picture
quality or
scrambled video
 LCD backlight
malfunction
 Poor video source
• Contact AI
• Ensure source
equipment and
source material
are functioning
properly
Blank screen*  LCD not receiving power
 Mother board
malfunctioning
• Check all cable
connections
• Contact AI
Arm not retaining
position when
moved
 Repeated use has
loosened tension adjust
screws in arm assembly
(see Section 7.0 for
location of tension
screws)
• Tighten screws
until arm retains
chosen position.
Avoiding using
excessive force
as this may
damage arm
assembly
*The monitor displays a blue screen with the unit turned on and no video
signal present.

Audio International, Inc. AI-LCD68-01-xx Installation and Operation Manual
Document # 540260, Rev IR, 11/2004 Page 13 of 15
6.0 Specifications
Unit Specifications for AI-LCD68-01-xx:
Physical Specifications – AI-LCD68-01-xx
Screen Size 6.8" (56 cm) Diagonal
Monitor Dimensions
(l x w x h)
7.0" x 1.4" x 6.1"
17.8 cm x 3.56 cm x 15.5 cm
Extended Arm
Dimensions for
(l x w x h)
See Section 7.0 for dimensions
Weight Approx. 3.5 lb / 1.59 kg

Audio International, Inc. AI-LCD68-01-xx Installation and Operation Manual
Document # 540260, Rev IR, 11/2004 Page 14 of 15
7.0 Reference Drawings
7.1 AI-LCD68-01-02
The following diagrams show the unit dimensions and connector locations
for the AI-LCD68-01-02. "Monitor Face" labels indicate side with viewing
screen.

Audio International, Inc. AI-LCD68-01-xx Installation and Operation Manual
Document # 540260, Rev IR, 11/2004 Page 15 of 15
7.2 AI-LCD68-01-13
The following diagrams show the unit dimensions and connector locations
for the AI-LCD68-01-13.
