Rose electronics Rackview LCD Panel Mount 19" User manual

Rackview LCD Monitor
INSTALLATION AND
OPERATIONS MANUAL
Rackview LCD Monitor 17”
Rackview LCD Monitor 19”
Rackview LCD Monitor 20”
Rackview LCD Widescreen Monitor 17” (1080p)
Rackview LCD Widescreen Monitor 17” (1920 x 1200)
Rackview LCD Widescreen Monitor 19”
Rose Electronics 10707 Stancliff Road
Houston, Texas 77099
Phone [phone] WWW.ROSE.COM

.

Page 3
Rackview LCD Monitor WWW.ROSE.COM
LIMITED WARRANTY
Rose Electronicswarrantsthe Rackview Product to be in good working order for one year from the date of
purchase from Rose Electronic s. Should this product fail to be in good working order at any time during this one-
year warrantyperiod, Rose Electronics will, at its option, repair or replace the Unit as set forth below. Repair
parts and
replacement units will be either reconditioned or new. All replaced parts become the property of Rose
Electronics. This limited warrantydoes not include service to repair damage to the Unit resulting from accident,
disaster, abuse, or unauthorized modification of the Unit, including static discharge and power surges.
Limited
Warranty service may be obtained by delivering this unit during the one-year warranty periodto Rose
Electronics or an authorized repaircenter providing a proof of purchase date.
If this Unit is delivered by mail, you agree to insure the Unit or assume the risk of loss or
damage in transit,to
prepay
shipping chargesto the warranty service location, and to use the original shipping container or its
equivalent. You must call for a return authorizationnumber first. Under no
circumstances will a unit be accepted
without a return
authorization number. Contact an authorized repair center or Rose Electronics for further
information.
ALL EXPRESS AND IMPLIED
W ARRANTIES FOR THIS PRODUCT INCLUDING THE WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITEDIN DURATION TO A
PERIODOF ONE YEAR FROM THE DATE OF
PURCHASE, AND NO WARRANTIES, W HETHER EXPRESS
OR IMPLIED, W ILL APPLY AFTER THIS PERIOD. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW
LONG AN IMPLIED
W ARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLYTO YOU.
IF THIS PRODUCT IS NOT IN GOOD
W ORKINGORDER AS W ARRANTED ABOVE,
YOUR SOLE
REMEDY SHALL BE REPLACEMENT OR REPAIR AS PROVIDED ABOVE. IN NO EVENTWILL
ROSE
ELECTRONICS BE LIABLETO YOU FOR ANY DAMAGES
INCLUDING ANY LOST PROFITS, LOST SAVINGS OR OTHER
INCIDENTAL OR CONSEQUENTIAL
DAMAGES ARISING OUT OF THE USE OF OR THE INABILITY TO USE SUCH PRODUCT, EVEN IF ROSE
ELECTRONICS OR AN AUTHORIZED DEALER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES, OR FOR ANY CLAIM BY ANYOTHERPARTY.
SOME STATES DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES FOR CONSUMER PRODUCTS, SO THE ABOVE MAY NOT APPLY TO YOU. THIS W ARRANTY
GIVES YOU SPECIFIC LEGAL RIGHTSAND YOU MAY ALSO HAVEOTHER RIGHTS W HICH MAY VARY
FROMSTATETO STATE.
IBM, AT, and PS/2 are trademarks of InternationalBusiness Machines Corp. Microsoft and Microsoft
W indows
are registered trademarks of Microsoft Corp. Any other trademarks mentionedin this manual are
acknowledged
to be the property of the trademark owner.
.
Copyright ©Rose Electronics 2013. All rights reserved.
No part of this manual maybe reproduced, stored in a retrieval system, or transcribed in any form or any means, electronic or mechanical, including
photocopying and recording, without the prior written permission of Rose Electronics.
Rose Electronics Part # MAN-RV1-LCDAnn
Printed In the United States of America – Revision 1.0

Page 4
Rackview LCD Monitor WWW.ROSE.COM
Table of Contents
Safety Instructions Page 5
Pre-Installation and Package Contents Page 6
Rackview Layout Diagram and Dimensions Page 7-9
Installation Page 10-11
OSD (On-Screen Display Control Panel) Operation Page 12-13
PIP and PBP Page 14-15
Product Options Page 16-17
Video Format Page 18
Specifications Page 19
Product Codes Page 19
Technical Support Page 20

Page 5
Rackview LCD Monitor WWW.ROSE.COM
Safety Instructions
Please read all of these instructions carefully before you use the device. Save this manual for
future reference.
•Unplug equipment before cleaning. Don’t use liquid or spray detergent; use a moist cloth.
•Keep equipment away from excessive humidity and heat. Preferably, keep it in an air-conditioned
environment with temperatures not exceeding 40º Celsius (104º Fahrenheit).
•When installing, place the equipment on a sturdy, level surface to prevent it from accidentally
falling and causing damage to other equipment or injury to persons nearby.
•When the equipment is in an open position, do not cover, block or in any way obstruct the gap
between it and the power supply. Proper air convection is necessary to keep it from overheating.
•Arrange the equipment’s power cord in such a way that others won’t trip or fall over it.
•If you are using a power cord that didn’t ship with the equipment, ensure that it is rated for the
voltage and current labeled on the equipment’s electrical ratings label. The voltage rating on the
cord should be higher than the one listed on the equipment’s ratings label.
•Observe all precautions and warnings attached to the equipment.
•If you don’t intend on using the equipment for a long time, disconnect it from the power outlet to
prevent it being damaged by transient overvoltage.
•Keep all liquids away from the equipment to minimize the risk of accidental spillage. Liquid spilled
on to the power supply or on other hardware may cause damage, fire or electrical shock.
•Only qualified service personnel should open the chassis. Opening it yourself could damage the
equipment and invalidate its warranty.
•If any part of the equipment becomes damaged or stops functioning, have it checked by qualified
service personnel.
Regulatory Notices Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
Any changes or modifications made to this equipment may void the user’s authority to operate this
equipment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
•Re-position or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.

Page 6
Rackview LCD Monitor WWW.ROSE.COM
Pre-Installation and Package Contents
Before Installation:
It is very important to mount the equipment in a suitable cabinet or on a stable surface.
Make sure the mounting location has good ventilation, is out of direct sunlight, and away from sources of
excessive dust, dirt, heat, water, moisture and vibration.
Unpacking:
The equipment comes with the standard parts shown in package content. Check and make sure they are
included and in good condition. If anything is missing, or damaged, contact your supplier immediately.
Package Contents:
1x Rackview LCD Unit
1x set of Mounting Bracket (sliding rails)
1x Power Cord
1x VGA Cable
1x User Manual
1x set of screws and washers for assembly
Product Operation:
a) Power On Procedure
•Power on the Rackview LCD Monitor (see power switch on back panel)
•Power on the CPU
b) Video Input Select Button (see OSD Section, Page 12)
The Rackview remembers the last valid video input selection, so if the CPU input has changed, the user needs
to re-select the video input.
•Locate the “Video Input Select” button on the OSD display control panel
•Push the Video Input Select button to toggle between VGA and DVI Input
•Select the appropriate Video Input format (VGA or DVI)
c) Cleaning Your Monitor
To clean your LCD safely, please follow these steps:
•Disconnect the power cord.
•Gently wipe the surface using a clean, dry microfiber cloth. Use as little pressure as possible.
•Use only screen cleaning products designed for use with LCD monitors.

Page 7
Rackview LCD Monitor WWW.ROSE.COM
Rackview LCD Monitor - Layout Diagram & Dimensions
Layout for Rackview LCD Monitor (17”, 19”, 20”)
6
3
Model
Product Dimension
(W x D x H) approx
Packing Dimension
(W x D x H) approx
Net
Weight
Gross
Weight
RV1-LCDA17
441.6 x 500 x 44 mm
17.4 x 19.7 x 1.73 inch
588 x 758 x 120 mm
23.1 x 29.8 x 4.7 inch
10.5 kg
23 lb
16.5 kg
36 lb
RV1-LCDA19
441.6 x 500 x 44 mm
17.4 x 19.7 x 1.73 inch
588 x 758 x 120 mm
23.1 x 29.8 x 4.7 inch
12.5 kg
28 lb
18.5 kg
41 lb
RV1-LCDA20
439.6 x 650 x 44 mm
17.3 x 25.6 x 1.73 inch
595 x 860 x 140 mm
23.4 x 33.9 x 5.5 inch
13.5 kg
30 lb
17.5 kg
39 lb
RV1-LCDA17/DWS/HD
441.6 x 480 x 44 mm
17.4 x 18.1 x 1.73 inch
588 x 758 x 120 mm
23.1 x 29.8 x 4.7 inch
11 kg
24 lb
15 kg
33 lb
RV1-LCDA17/FHD
441.6 x 480 x 44 mm
17.4 x 19.7 x 1.73 inch
588 x 758 x 120 mm
23.1 x 29.8 x 4.7 inch
11 kg
24 lb
15 kg
33 lb
RV1-LCDA19/DWS
441 x 460 x 44 mm
17.4 x 18.1 x 1.73 inch
588 x 758 x 120 mm
23.1 x 29.8 x 4.7 inch
13 kg
28.6 lb
17 kg
37.4 lb
The package weight can vary with accessories included

Page 8
Rackview LCD Monitor WWW.ROSE.COM
Rackview LCD Chassis Dimensions
Unit: mm
1mm = 0.03937 inch
Rackview LCD Monitor 17” and 19”
Rackview LCD Monitor 20”

Page 9
Rackview LCD Monitor WWW.ROSE.COM
Rackview LCD Widescreen Monitor 17”
Rackview LCD Widescreen Monitor 19”

Page 10
Rackview LCD Monitor WWW.ROSE.COM
Installation of Rackview LCD Monitor 17” and 19” (including Widescreen)
STEP 1
Insert the Left and Right rear-mounting slides into
the Rackview Console Drawer.
STEP 2
Measure the depth of the front and rear rack rails.
Align each rear-mounting slide to a suitable length
(depth).
STEP 3
Complete the Installation.
Fix the Rackview Console Drawer into the Rack
using the screws, cage nuts and cup washers
provided.

Page 11
Rackview LCD Monitor WWW.ROSE.COM
Installation of Rackview LCD Monitor 20”
STEP 1
Attach the left and right mounting brackets to the 19”
rack rails.
Adjust the mounting brackets to fit the rack.
STEP 2
Insert the LCD tray into the mounting bracket.
Pull and hold the left and right black arrow buttons on
the rails.
Return the LCD tray to the park position.
STEP 3
Fix the rear kit to the mounting brackets using the
screws provided.
STEP 4
Complete the installation
Fully tighten all screws, front and back, left and right.

Page 12
Rackview LCD Monitor WWW.ROSE.COM
On-Screen Display Operation ( OSD )
Rackview 17”, 19” and 20” Standard and Widescreen Models

Page 13
Rackview LCD Monitor WWW.ROSE.COM
Rackview 17” Widescreen models only

Page 14
Rackview LCD Monitor WWW.ROSE.COM
Picture In Picture and Picture By Picture Modes (PIP and PBP)
Rackview 17” Widescreen models only
1. Picture-In-Picture (PIP)
2. Screen Size
Note, the Rackview 17”/DWS/HD supports up to 1920x1080p.
The Rackview 17”/FHD supports up to 1920 x 1200

Page 15
Rackview LCD Monitor WWW.ROSE.COM
3. Picture-By-Picture (PBP)
4. PIP / PBP Source

Page 16
Rackview LCD Monitor WWW.ROSE.COM
Options for Rackview LCD Monitor, Standard and Widescreen Models
a) HDMI - HDMI 1.1, CEA-861-D
b) Audio -3.5mm analog audio jacks, 2W +speakers
c) AV - S-Video + Composite, BNC (Standard 17”/19”/20” and Widescreen 19” only)
d) 3G/SDI - 3G/HD/SDI video (Widescreen 17” and 19” models only)
Select either DVI or HDMI connector.
Back panel of the Rackview LCD Monitor showing standard and optional connectors.
Back panel of the Rackview LCD Monitor showing standard and optional SDI connectors.
e) DC Power
Back panel of the Rackview LCD Monitor showing the location of DC power connector block.
Note: For all above options, the Rackview LCD Monitor chassis depth will be extended by approximately
70mm (2.75”) more than the standard chassis depth.

Page 17
Rackview LCD Monitor WWW.ROSE.COM
Touchscreen Options
a) Resistive and Capacitive Touchscreens
Rackview 17”, Widescreen High Resolution (1920x1200) and 19” models only
a) Resistive Touchscreens
Rackview 17” Widescreen 1080p model
Back panel of Rackview LCD Touchscreen Monitor, showing the location of the connectors.
Note: For the touchscreen option, the Rackview LCD chassis depth will be extended by approximately
70mm (2.75”) more than the standard chassis depth.
A bundled software setup disc is included with this option.
Please check with Rose Electronics for pricing and availability of these options.

Page 18
Rackview LCD Monitor WWW.ROSE.COM
Video Format
Rackview LCD Monitor 17”, 19”, 20”
DVI-D / VGA
Input Rackview LCD Monitor, 17” and 19”
Resolution/Refresh Rate
Rackview LCD Monitor, 20”
Resolution/Refresh Rate
--- 1600 x 1200 x 60Hz
--- 1440 x 1050 x 60Hz
--- 1440 x 900 x 60Hz
--- 1360 x 768 x 60Hz
1280 x 1024 x 60Hz / 75Hz 1280 x 1024 x 60Hz / 75Hz
1280 x 960 x 60Hz 1280 x 960 x 60Hz
1280 x 760 x 60Hz / 75Hz 1280 x 760 x 60Hz / 75Hz
1152 x 864 x 75Hz 1152 x 864 x 75Hz
1024 x 768 x 60Hz / 70Hz / 75Hz 1024 x 768 x 60Hz / 70Hz / 75Hz
848 x 480 x 60Hz 848 x 480 x 60Hz
800 x 600 x 60Hz / 72Hz / 75Hz 800 x 600 x 60Hz / 72Hz / 75Hz
720 x 400 x 70Hz 720 x 400 x 70Hz
640 x 480 x 60Hz / 72Hz / 75Hz 640 x 480 x 60Hz / 72Hz / 75Hz
640 x 400 x 70Hz 640 x 400 x 70Hz
640 x 350 x 70Hz 640 x 350 x 70Hz
Rackview LCD Widescreen Monitor 17” and 19”
DVI-D / VGA Input LCD Monitor, 17” (1080p)
Resolution/Refresh Rate LCD Monitor, 17” (1920 x 1200)
Resolution/Refresh Rate
LCD Monitor, 19” (1440 x 900)
Resolution/Refresh Rate
1920 x 1200 x 60Hz ---
1920 X 1080 X 60Hz
--- ---
---
--- 1440 x 900 x 60Hz
1360 x 768 x 60Hz
1360 x 768 x 60Hz ---
1280 x 1024 x 60Hz / 75Hz 1280 x 1024 x 60Hz / 75Hz 1280 x 1024 x 60Hz / 75Hz
1280 x 960 x 60Hz 1280 x 960 x 60Hz 1280 x 960 x 60Hz
1280 x 760 x 60Hz / 75Hz 1280 x 760 x 60Hz / 75Hz 1280 x 760 x 60Hz / 75Hz
1152 x 864 x 75Hz 1152 x 864 x 75Hz 1152 x 864 x 75Hz
1024 x 768 x 60Hz / 70Hz / 75Hz 1024 x 768 x 60Hz / 70Hz / 75Hz 1024 x 768 x 60Hz / 70Hz / 75Hz
848 x 480 x 60Hz 848 x 480 x 60Hz 848 x 480 x 60Hz
800 x 600 x 60Hz / 72Hz / 75Hz 800 x 600 x 60Hz / 72Hz / 75Hz 800 x 600 x 60Hz / 72Hz / 75Hz
720 x 400 x 70Hz 720 x 400 x 70Hz 720 x 400 x 70Hz
640 x 480 x 60Hz / 72Hz / 75Hz 640 x 480 x 60Hz / 72Hz / 75Hz 640 x 480 x 60Hz / 72Hz / 75Hz
640 x 400 x 70Hz 640 x 400 x 70Hz 640 x 400 x 70Hz
640 x 350 x 70Hz 640 x 350 x 70Hz 640 x 350 x 70Hz

Page 19
Rackview LCD Monitor WWW.ROSE.COM
Rackview LCD Monitor - Specification
Rackview LCD
Monitor
17” LCD
17” WS LCD
17” HI-RES LCD
19” LCD
19” WS LCD
20” LCD
Dimensions (in)
W x D x H (mm)
17.4x19.7x1.73
441.6 x 500 x 44
17.4x 18.9x1.73
441.6 x 500 x 44
17.4x 18.9x1.73
441.6 x 500 x 44
17.4x19.7x1.73
441.6 x 500 x 44
17.4 x18.1x1.73
441.6 x 460 x 44
17.3x25.6x1.73
440 x 650 x 44
Weight
23lbs (10.5kg)
24lbs (11kg)
24lbs (11kg)
28lbs (12.5kg)
28.6lbs (13kg)
30lbs (13.5kg)
Size
17” TFT
17.3” TFT
17.1” TFT
19” TFT
19” Wide TFT
20.1” TFT
Resolution
1280 x 1024
1920 x 1080p
1920 x 1200 HD
1280 x 1024
1440 x 900
1600 x 1200
Brightness c d/m2
250
300
210
250
250
300
Backlight
CCFL
LED
LED
LED
LED
CCFL
Colors
16.7M
1.07 B (10 Bit)
16.7M (8 bit)
16.7M
16.7M
16.7M
Contrast Ratio
1000:1
600:1
600:1
1000:1
1000:1
800:1
Viewing Angle H/V
160°x 160°
178°x 178°
130°x 110°
170°x 160°
160°x 160°
178°x 178°
Active Area (mm)
338 x 270
382 x 215
367 x 230
376 x 301
408 x 255
408 x 306
Screen Surface
Haze 25%. Hard
Anti Glare. Hard
Anti Glare. Hard
Haze 25%. Hard
Haze 25%. Hard
Anti Glare.Hard
Response Time - ms
5
35
30
5
5
16
PIP Function
No
Yes
Yes
No
No
No
Touchscreen-USB
Yes (Cap + Res)
Yes (Res only)
Yes (Cap + Res)
Yes (Cap + Res)
No
No
Video Signal
VGA (Analog 0.7Vp-p). DVI-D (TMDS single link)
Shock
10G acceleration (11ms duration)
Vibration
5~500Hz 1G RMS random vibration
Audio (Option)
3.5mm with L/R Speakers. Impedance 30KΩ/ 750mV. Speaker Power – 2*2W
AC Power
100-240VAC, 50/60HZ
Consumption-Watt
Max 25 / Idle 5
Max 34 / Idle 5
Max 34 / Idle 5
Max 25 / Idle 5
Max 25 / Idle 5
Max 48 / Idle 5
Environmental
Operating Temp
Storage Temp
Reltv Humidity
32°F–122°F / 0°C–50°C
23°F–140°F / -5°C–60°C
5–90% non-condensing
Approvals
FCC, CE, RoHS2, Reach
Part Numbers
RV1-LCDA17
17” LCD Monitor
RV1-LCDA19
19” LCD Monitor
RV1-LCDA20
20” LCD Monitor
RV1-LCDA17/DWS/HD
17” LCD Monitor/Widescreen (1080p)
RV1-LCDA17/FHD
17” LCD Monitor/Full HD
RV1-LCDA19/WS
19” LCD Monitor/Widescreen
Optional Items: (check with Rose Electronics for pricing and availability)
HDMI Interface
Audio Option
AV - S-Video Composite, BNC (Standard 17”/19”/20” and Widescreen 19” only)
3G/HD/SDI (Widescreen 17” and 19” models only)
Touchscreen - Resistive Panel (Standard 17”, 19” , Widescreen 1080p and Widescreen 1920x1200 models only)
Touchscreen - Capacitive Panel (Standard 17” , 19” and Widescreen 1920 x1200 models only)
DC Voltage Option (12/24/48VDC)

Page 20
Rackview LCD Monitor WWW.ROSE.COM
Technical Support
If you are experiencing problems, or need assistance in setting up, configuring or operating your product,
consult the appropriate sections of this manual. If, however, you require additional information or
assistance, please contact the Rose Electronics Technical Support Department at:
Phone: [phone]
E-Mail: [e-mail]
Web: www.rose.com
Technical Support hours are from: 8:00 am to 6:00 pm CST (USA), Monday through Friday.
Please report any malfunctions in the operation of this Unit or any discrepancies in this manual to the Rose
Electronics Technical Support Department.
WWW.ROSE.COM sale[email protected] [phone]
Rose USA [phone] Rose Europe [phone] Rose Asia [phone] Rose Australia [phone]
Rose Electronics 10707 Stancliff Road Houston, Texas 77099
© Copyright 2013 Rose Electronics. All rights reserved. Specifications subject to change without notice
