Audioaccess AVR21EN User manual

The Whole-House Entertainment Network
from Audioaccess®is a radically simple
approach to whole-house entertainment.
Built around the world’s first high-
performance A/V receiver integrated
with source control and multizone
audio and video distribution, W.H.E.N.
systems are capable of streaming eight
central entertainment sources (including
up to six video sources) to a home theater
and as many as 20 additional rooms.
W.H.E.N.
™begins here and now
The centerpiece of every W.H.E.N. system
is the Audioaccess AVR21EN, a high-
performance surround receiver that
incorporates exciting new technologies
from Audioaccess to enhance the whole-
house and home theater experience. It
features a cutting-edge digital amplifier
design and every popular surround sound
processing technology, including Dolby®
Pro Logic®IIx, DTS Neo:6®and Logic 7.
®
Furthermore, the patented EzSet equalization
technology makes fine-tuning the system
to the particular acoustic needs of the lis-
tening space virtually automatic.
Outstanding audio, and DCDi by
Faroudja®video
Audioaccess has been producing premium-
quality custom audio systems for more
than 20 years. The AVR21EN continues
that tradition and extends it to the world
of home theater and video. In addition
to its comprehensive sound-processing
capabilities, the AVR21EN includes DCDi
by Faroudja video-processing technology.
The award-winning DCDi by Faroudja
codec effectively “upconverts” standard-
definition video pictures to the HDTV format
(to 1080i via an HDMI™output), enhancing
viewer enjoyment and extending the useful
life of existing DVD libraries.
But it also features something unprecedented:
control of up to six external A/V sources
and two internal AM/FM tuners, and
two-way remote routing of composite
video and digital audio and control signals.
The system extends audio signals through-
out the home by using a proprietary
Digital Signal Transfer bus.
As the first 7.1-channel receiver with an
onboard multizone system controller, the
AVR21EN doesn’t just provide outstanding
A/V performance – it reduces system
complexity and improves ease of use. With
intuitive on-screen programming and a
built-in library of IR codes, the AVR21EN
can be set up to control a variety of
components and whole-house features –
without the use of a PC.
As the heart of a premium home theater
installation or as the central component of
a fully integrated whole-house infotainment
system, the AVR21EN is both unique and
uniquely capable.
www.audioaccess.com
AV R 21E N
W.H.E.N.
™
A/V Receiver
Multizone System Controller

Audio
▲70 Watts x 2 stereo mode
▲70 Watts x 7 multichannel mode
▲Two AM/FM tuners
▲Six rear-panel analog inputs; one front-panel
analog input
▲Four rear-panel digital inputs: two optical,
two coax; front panel: one coax, one optical
▲EzSet/EQ; includes microphone
▲Surround modes include: Dolby®Digital EX,
Dolby Pro Logic®II, Dolby Pro Logic IIx,
Dolby Headphone, DTS,
®DTS Neo:6, ®
Logic 7®and more
▲Additional 7.1-channel DVD audio input
▲7.1-Channel preamp outputs
▲Flash-upgradeable
Video
▲Seven rear-panel composite and S inputs;
one front-panel composite and S input
▲Five rear-panel component video inputs;
one front-panel component input
▲DCDi by Faroudja®upconverter scales all
inputs to 1080i via HDMI™output and
480P via component output
▲Composite video camera input
Controller
▲On-screen programming for all AVR and
whole-house functions
▲Six dedicated IR outputs with built-in IR library
and front-panel IR learning
▲Three RS-232 source interface ports
▲Six “Flag In” source status ports
▲One 12-volt trigger output
▲One RS-232 port for control of AVR functions
and programming upgrades
▲One external IR receiver input and loop-
through output
Multiroom
▲Two multiroom digital audio bus outputs
stream eight digital audio sources and
two-way control signals
▲Six composite multiroom video outputs
Features
Connector Complement/Preliminary Specifications
Audio Section
▲Stereo mode: 70 Watts per channel, continuous
average power (FTC), 20Hz – 20kHz, @ <0.1%
THD, both channels driven into 8 ohms
▲Seven-channel surround modes:
70 Watts per channel, all channels driven,
@ <0.1% THD, 20Hz – 20kHz into 8 ohms
▲Input sensitivity/impedance
linear (high-level): 200mV/47k ohms
▲Signal-to-noise ratio (IHF-A): 97dB
▲Surround system adjacent channel separation –
Dolby®Pro Logic®I/II/IIx: 40dB
Dolby®Digital: 55dB
DTS®: 55dB
▲Transient intermodulation distortion (TIM):
Unmeasurable
FM Tuner Section
▲Frequency range: 87.5 – 108MHz
▲Usable sensitivity: IHF 1.3µV/13.2dBf
▲Signal-to-noise ratio (mono/stereo): 70/68dB
▲Distortion (mono/stereo): 0.2/0.3%
▲Stereo separation: 40dB @ 1kHz
▲Selectivity: ±400kHz, 70dB
▲Image rejection: 80dB
▲IF rejection: 90dB
AM Tuner Section
▲Frequency range: 520kHz – 1720kHz
▲Signal-to-noise ratio: 45dB
▲Usable sensitivity: Loop 500µV
▲Distortion: 1kHz, 50% mod 0.8%
▲Selectivity: ±10kHz, 30dB
Video Section
▲Television format: NTSC
▲Input level/impedance: 1V p-p/75 ohms
▲Output level/impedance: 1V p-p/75 ohms
▲Video frequency response –
Composite and S-video: 10Hz – 8MHz (–3dB)
Component video: 10Hz – 50MHz (–3dB)
General
▲Power requirement: AC 120V/60Hz
▲Power consumption –
Standby: 14W
Idle: 77W
Max (seven channels driven): 768W
▲Dimensions (H x W x D) –
Product: 6-5/8"x 17-5/16"x 17-1/8"
(168mm x 439mm x 434mm)
Shipping: 10-7/8"x 22-3/4"x 21-3/4"
(276mm x 578mm x 552mm)
▲Weight –
Product: 25 lb (11.4kg)
Shipping: 32 lb (14.5kg)
Audioaccess
250 Crossways Park Drive
Woodbury, NY 11797
www.audioaccess.com
888.691.4171
Fax: [phone]
©2006 Harman International Industries, Incorporated. All rights reserved.
Part No. AAAVR21ENPI
Audioaccess, Harman International and Logic 7 are registered trademarks,
and W.H.E.N. is a trademark, of Harman International Industries, Incorporated.
DCDi by Faroudja is a registered trademark of Genesis Microchip Inc.
Dolby and Pro Logic are registered trademarks of Dolby Laboratories.
DTS and DTS Neo:6 are registered trademarks of DTS, Inc.
HDMI is a trademark of HDMI Licensing LLC.
Specifications are preliminary and subject to change.
