AudioEngine A5 User manual

Features:
• USB power charging (ComboPort)
• 2 audio inputs
• Built-in power amps in left speaker
• Rear panel AC outlet
• Front panel volume control
• Kevlar woofers for super low end
• Silk tweeters for smooth highs
• Subwoofer outputs
• High-quality speaker connectors
• Auto-sleep power saving mode
• Hand-nished cabinets
• Video shielded
• 3-year warranty
• All cables included
Compatible With:
• Audioengine W1 and W2
• AirPort Express and other wireless systems
• iPod and all other music players
• Internet radio and network music systems
• Apple Universal Dock and other docks/remotes
• Desktop computers, laptops, notebooks
• Flat panel TVs
• Mobile phones and PDAs
• CD and DVD players
• Videogame consoles
• Digital radio and satellite receivers
• All products with 1/8" mini-jack or RCA outputs!
“Power and Substance…
the oasis in the MP3 Desert.”
–Home Theater Magazine
LINE OUT
OUT TO
RIGHT
AUX OUTLET
www.audioengineusa.com
Audioengine
Model: A5
POWER ON/OFF
AC SELECT
AUDIO IN
L
R
115
Output to
right speaker
Line Out
Aux AC outlet
VolumePower LED
Front
Back (active speaker)
Power On/O
AC Input
USB Power
7”
Voltage Select
Audio Input
10”
7 ⁄”
Audio Input
Top
Self-Powered Works With Everything Wireless Ready
A5
A2
AS8
AW1
AW2
Power output:
Inputs:
Outputs:
Main voltages:
Weight:
Amplier type:
Signal-to-noise:
THD:
Crosstalk:
Freq. response:
Input impedance:
50W RMS/ 75W peak per channel (AES)
(2) Stereo ⁄”mini-jack
USB Type A (power only), RCA line out
115/230V, 50/60Hz manually switchable
6.4Kg/ 14lbs (left), 4Kg/ 9lbs (right)
Dual Class AB monolithic
>95db (typical A-weighted)
<0.05% at all power settings
<50db
50Hz-22kHz ±1.5db
10K ohms unbalanced
•AC power cable
•⁄” audio cable, 2 meters (~6.5 ft)
•(2) ⁄” audio cables, 20 cm (~8”)
•⁄” to RCA “Y” cable
•USB power extender cable, 1 m (~3.3 ft)
•Speaker wire (16AWG), 3.75 meters (~12.3ft)
•Drawstring cable bags
•(2) High-density foam protectors/sonic pads
•Setup Guide
•1” thick MDF cabinet
•5” Kevlar woofers with advanced voice coils
•20mm silk dome tweeters with neodymium
magnets
•Torroidal power transformers
Included Accessories Materials and Construction
Specications
Audioengine 5
Upgrade your audio
Premium Powered Bookshelf Speaker System

Audioengine 5N
Premium Powered Bookshelf Speaker System
Eco Smart
A5N Eco-Friendly Features:
Made from renewable and sustainable solid bamboo - no veneers
No stains or paint used - naturally "carbonized" nish sealed with hand-rubbed
water-based satin polyurethane
Other green facts and features:
•Audioengine products are now 100% lead-free and meet the EU's RoHS initiative
•All speaker cabinet materials use environmentally-friendly binders and resins
•Formaldehyde-free adhesives are used in our cabinet assembly
•All Audioengine products meet ENERGY STAR requirements in standby
•Limited use of plastics in our products
•Easy-to-recycle packaging
A5
A2
AS8
AW1
AW2
Power output:
Inputs:
Outputs:
Main voltages:
Weight:
Amplier type:
Signal-to-noise:
THD:
Crosstalk:
Freq. response:
Input impedance:
50W RMS/ 75W peak per channel (AES)
(2) Stereo ⁄”mini-jack
USB Type A (power only), RCA line out
115/230V, 50/60Hz manually switchable
6.4Kg/ 14lbs (left), 4Kg/ 9lbs (right)
Dual Class AB monolithic
>95db (typical A-weighted)
<0.05% at all power settings
<50db
50Hz-22kHz ±1.5db
10K ohms unbalanced
•AC power cable
•⁄” audio cable, 2 meters (~6.5 ft)
•(2) ⁄” audio cables, 20 cm (~8”)
•⁄” to RCA “Y” cable
•USB power extender cable, 1 m (~3.3 ft)
•Speaker wire (16AWG), 3.75 meters (~12.3ft)
•Drawstring cable bags
•(2) High-density foam protectors/sonic pads
•Setup Guide
•1” thick solid bamboo
•5” Kevlar woofers with advanced voice coils
•20mm silk dome tweeters with neodymium
magnets
•Torroidal power transformers
Included Accessories Materials and Construction
Specications
Upgrade your audio
Audioengine 5N (A5N) - All of the simple but useful features and same signature
sound of the award-winning A5 wrapped in rock solid and beautifully hand-nished
bamboo.
Bamboo is an excellent alternative to hardwoods and the dark bamboo used for the
Audioengine A5N cabinets is not a stain, but achieved through a specialized heating
process. As the wood is pressure heated, the sugar compounds inside the bamboo
are "carbonized" which in turn darkens the bamboo to a rich caramel color.
Awesome sound, great looks, eco-friendly, and panda-safe.
Features:
•USB power charging (ComboPort)
•2 audio inputs
•Built-in power amps in left speaker
•Rear panel AC outlet
•Front panel volume control
•Kevlar woofers for super low end
•Silk tweeters for smooth highs
•Subwoofer outputs
•High-quality speaker connectors
•Auto-sleep power saving mode
•Hand-nished cabinets
•Video shielded
•3-year warranty
•All cables included
Compatible With:
•Audioengine W1 and W2
•AirPort Express and other wireless systems
•iPod and all other music players
•Internet radio and network music systems
•Apple Universal Dock and other docks/remotes
•Desktop computers, laptops, notebooks
•Flat panel TVs
•Mobile phones and PDAs
•CD and DVD players
•Videogame consoles
•Digital radio and satellite receivers
•All products with 1/8" mini-jack or RCA outputs!
