AUDIOLINE M 4500 - V1.0 8-10-2009 User manual

Mobile Phone
Operating Instructions
M 4500

2
M 4500

1
Contents
3
1 Safety Information 4. . . . . . . . . . . . . .
2 Preparing the Telephone 8. . . . . . . . .
3 Operating Elements 16. . . . . . . . . . . . .
4 Preliminary Information 23. . . . . . . . . .
5 Methods of Entering Data 29. . . . . . . . .
6 Telephoning 31. . . . . . . . . . . . . . . . . .
7 Emergency Call Function 37. . . . . . . . .
8 Phone Book 39. . . . . . . . . . . . . . . . . .
9 Call List 48. . . . . . . . . . . . . . . . . . . . .
10 SMS − Text Messages 50. . . . . . . . . . .
11 Mailbox 57. . . . . . . . . . . . . . . . . . . . .
12 Services 59. . . . . . . . . . . . . . . . . . . . .
13 Settings 64. . . . . . . . . . . . . . . . . . . . .
14 Menu Structure 74. . . . . . . . . . . . . . . .
15 In Case of Problems 93. . . . . . . . . . . .
16 Technical Properties 97. . . . . . . . . . . .
17 SAR Information 103. . . . . . . . . . . . . . .
18 Maintenance / Guarantee 105. . . . . . . . .
19 Index 107. . . . . . . . . . . . . . . . . . . . . . .
Service−Hotline Germany: Tel. [phone], cost via German landline at time of going to print:
14 ct/min., different costs possible via mobile telephone systems

Safety Information
4
1 Safety Information
Please read this operating instruction manual thor-
oughly.
Risk of suffocation!
Keep packaging materials and protective foils
out of reach of children.
Intended use
This mobile phone is designed for use when con-
nected to a mobile phone network. Any other use is
considered unintended use. Unauthorised modifica-
tion or reconstruction is not permitted. Under no cir-
cumstances open the device or complete any repair
work yourself.
Areas of use
Do not use the phone in prohibited areas.
Switch the phone off in the vicinity of medical
equipment (e.g. in hospitals).
Do not use the phone in petrol stations or near
fuels and chemicals.
Inquire by the airline company whether mobile
phones may be used before using the phone in
aircraft.
Service−Hotline Germany: Tel. [phone], cost via German landline at time of going to print:
14 ct/min., different costs possible via mobile telephone systems

Safety Information
5
General information
Prevent exposure to smoke, dust, vibration,
chemicals, moisture, heat and direct sunlight. The
phone is not waterproof; therefore, keep it dry.
Only use original accessories and batteries.
Never attempt to connect other products.
If you want to connect the phone to another
device, read the manual supplied with that device
with regard to any detailed safety information.
Never attempt to connect incompatible products.
Repairs to this device may only be completed by
qualified service personnel.
All mobile communication equipment is subject to
interference which may impair its performance.
Keep the phone and accessories out of the reach
of children.
The SIM card can be removed. Caution! Small
children can swallow them.
The ringing tone is issued via the loudspeaker.
Take an incoming call first and then hold the
phone to your ear.
This prevents any possible hearing damage.
Only use the phone while driving or riding a
transport vehicle in road traffic when using the
approved handsfree equipment and appropriately
positioned holders. Ensure that no safety−related
functions are interfered with when operating the
Service−Hotline Germany: Tel. [phone], cost via German landline at time of going to print:
14 ct/min., different costs possible via mobile telephone systems

Safety Information
6
phone. It is essential to observe the applicable
laws and national regulations.
Always maintain a distance of at least 15 cm to
implanted heart pacemakers to prevent any
possible interference. If you have had a
pacemaker implanted, do not carry the phone in a
breast pocket when switched on. Always hold the
phone to the ear furthest away from the
pacemaker during calls.
Switch the phone off immediately if you notice or
suspect any adverse effects.
Do not rely on the mobile phone as a safeguard
for emergencies. For a variety of technical
reasons, it is not possible to guarantee a reliable
connection under all circumstances.
Power adapter plug
Attention: Only use the power adapter plug
supplied because other power supplies could
damage the telephone. Ensure access to the
power adapter plug is not obstructed by furni-
ture or such.
Rechargeable batteries
Attention: Never throw batteries into a fire.
Only use batteries of the same type.
Service−Hotline Germany: Tel. [phone], cost via German landline at time of going to print:
14 ct/min., different costs possible via mobile telephone systems

Safety Information
7
Disposal
In order to dispose of your device, take it to a
collection point provided by your local public
waste authorities (e.g. recycling centre). The
adjacent symbol indicates that the device must
not be disposed of in normal domestic waste!
According to laws on the disposal of electronic
and electrical devices, owners are obliged to
dispose of old electronic and electrical de-
vices in a separate waste container.
Batteries must be disposed
of at the point of sale or at the
appropriate collection points
provided by the public waste
authorities.
Packaging materials must be disposed of according
to local regulations.
Service−Hotline Germany: Tel. [phone], cost via German landline at time of going to print:
14 ct/min., different costs possible via mobile telephone systems

2
Preparing the Telephone
8
2 Preparing the Telephone
Safety information
Attention: It is essential to read the Safety
Information in Chapter 1 before starting up.
Checking the package contents
The package contains:
1 mobile phone 1 charging unit
1 Li−ion battery 1 operating manual
Accessories
A desktop charging unit and leather belt pouch are
optionally available as accessories. If you are inter-
ested in these accessories, please contact the sales
outlet where you purchased the equipment or visit us
in Internet at www.audioline.de.
In addition, you can purchase a commercially avail-
able headset (earphones) and vehicle charging
cable as accessories for the device.
Barcode label in the phone
The barcode label contains information on the
phone, such as the serial number, for example. Do
not remove it.
Service−Hotline Germany: Tel. [phone], cost via German landline at time of going to print:
14 ct/min., different costs possible via mobile telephone systems

3
4
Preparing the Telephone
9
Passwords
This mobile phone provides the option of using pass-
words. After activating the passwords, unauthorised
third−parties cannot access the data stored on the
phone. If the option is activated, access to certain
functions, e.g. the phone book, is only possible after
entering the correct password.
PIN* & PIN2 codes
The PIN and PIN2 codes are 4 to 8−digit numbers.
The PIN and PIN2 codes are given to you, together
with the SIM card, by your network provider.
PUK** & PUK2 codes
PUK and PUK2 codes are 4 to 8−digit numbers.
These are only necessary if you enter the PIN code
for the SIM card incorrectly three times in succession
and the SIM card is blocked. The PUK and PUK2
codes are given to you, together with the SIM card,
by your network provider.
Switching the mobile phone off and on
You can switch the mobile phone off to save the bat-
tery.
3 sec. Switch the mobile phone off
3 sec. Switch the mobile phone on
*PIN = Personal Identity Number
** PUK = Personal Unblocking Key
Service−Hotline Germany: Tel. [phone], cost via German landline at time of going to print:
14 ct/min., different costs possible via mobile telephone systems

Preparing the Telephone
10
Installing the SIM card
Risk of swallowing small objects!
The SIM card can be removed.
Small children can swallow them.
The emergency call number 112 can still be
dialled even if there is no SIM card installed.
The number is automatically dialled if the
Emergency Call switch is activated!
Switch the phone off.
Pay attention that the SIM card is not bent or
scratched. Prevent any contact with water, dirt
or electrical charges.
Slide the mobile phone’s
battery compartment cover
towards the bottom using a
little force. Lift the battery
compartment cover off the
phone completely.
If there is already a battery
inside, remove it.
Service−Hotline Germany: Tel. [phone], cost via German landline at time of going to print:
14 ct/min., different costs possible via mobile telephone systems

Preparing the Telephone
11
Slide the SIM card with the
golden contacts facing
down in the SIM card
holder provided for it.
Insert the battery. The
golden contacts on the bat-
tery must face towards the
top left. Press lightly on the
bottom end of the battery
until it snaps into place.
Replace the battery com-
partment cover back on
the phone. Slide the bat-
tery compartment cover
upwards until it snaps in to
place.
Service−Hotline Germany: Tel. [phone], cost via German landline at time of going to print:
14 ct/min., different costs possible via mobile telephone systems

5
Preparing the Telephone
12
Charging the battery
Before starting to charge the battery, check
that it has been installed properly.
Do not remove the battery while it is being
charged. This could damage the phone.
When charging the battery for the first time, it
should be charged for at least 4 hours. Some
batteries only reach their full capacity after se-
veral complete charge/discharge cycles.
Charging via the mini USB port
Open the protective USB
cover on the phone and plug
the charging unit in the mini
USB port.
Connect the charging unit as
illustrated in the diagram. For
safety reasons, only use the
charging unit supplied.
Service−Hotline Germany: Tel. [phone], cost via German landline at time of going to print:
14 ct/min., different costs possible via mobile telephone systems
Mains power
outlet

6
7
Preparing the Telephone
13
Charging via the desktop charging unit (option)
Plug the charging unit in the
mini USB port on the charging
unit. Insert the phone in the
charging unit to charge it.
The current battery charge status is indicated in the
display as follows:
Full Half empty Low Empty
It may take a few seconds before the phone
indicates the charging process.
You can use the phone during the charging
process.
You can also charge the phone via a PC. To do this,
connect the phone to the PC using an approved mini
USB cable. The charging process takes longer via
the PC than when using the charging unit.
Only use the mini USB cable approved by the
mobile phone manufacturer. The terms of
guarantee are annulled if a different cable is
used.
Service−Hotline Germany: Tel. [phone], cost via German landline at time of going to print:
14 ct/min., different costs possible via mobile telephone systems

Preparing the Telephone
14
Battery status warning
When the battery charge is low, a corresponding
warning message appears in the display.
Charge the battery.
In cases where the battery charge is extremely low, it
is possible that the back−lighting no longer works and
certain functions are no longer available.
When the battery charge drops below the minimum
status, the phone switches off automatically.
Tips on the battery
Only use batteries, cables and charging units ap-
proved by the manufacturer, otherwise the battery
could be damaged.
Do not short circuit the battery. Always leave the bat-
tery in the phone to avoid accidentally short circuiting
the battery contacts.
Keep the battery contacts clean and free of dirt.
The battery can be charged/discharged hundreds of
times but its service life is limited. Replace the bat-
tery when the battery power has decreased percepti-
bly.
Service−Hotline Germany: Tel. [phone], cost via German landline at time of going to print:
14 ct/min., different costs possible via mobile telephone systems

Preparing the Telephone
15
Setting the display language
Select the language required.
Refer to Menu Structure; Page 83
The following languages are available: German,
English, French, Dutch and Spanish.
Setting the time and date
Set the time and date.
Refer to Menu Structure; Page 78.
Service−Hotline Germany: Tel. [phone], cost via German landline at time of going to print:
14 ct/min., different costs possible via mobile telephone systems

Operating Elements
16
3 Operating Elements
Service−Hotline Germany: Tel. [phone], cost via German landline at time of going to print:
14 ct/min., different costs possible via mobile telephone systems
1
2
3
5
6
7
48
9
10
11
12
13
14
16
15
18 1717

Operating Elements
17
1 LED
2 Earpiece
3 Display
4 One−touch dialling buttons / Softkeys
5 Call button
6 Digit keys
7 Emergency Call button
8 Scroll Up button
9 On/Off button / On−hook button
10 Scroll Down button
11 Microphone
12 Loudspeaker for handsfree mode
13 Battery compartment cover
14 Volume control
15 Attachment eye for strap
16 Headset socket
17 Charging contact
18 Mini USB port with cover
Service−Hotline Germany: Tel. [phone], cost via German landline at time of going to print:
14 ct/min., different costs possible via mobile telephone systems

Operating Elements
18
1 Red LED The LED lights up
continuously when the device
is being charged.
The LED flashes fast when
the phone rings.
The LED flashes slowly when
you have missed calls
received but not yet viewed
the call list.
The LED also flashes slowly
when the phone is switched
on but the PIN has not yet
been entered.
2 Earpiece The voice of the caller can be
heard here when no headset
is being worn or the handsfree
equipment has not been
installed and activated and the
device set to handsfree mode.
3 Display The information which
appears in the display guides
you through the menu
structure and helps operate
the mobile phone.
The display is protected by foil. Remove it, if
necessary.
Service−Hotline Germany: Tel. [phone], cost via German landline at time of going to print:
14 ct/min., different costs possible via mobile telephone systems

Operating Elements
19
4  One−touch dialling buttons / Softkeys
The one−touch dialling buttons
are used to save phone
numbers and then dial them
simply by pressing and
holding the respective button.
 are also softkeys. The
softkeys are assigned
different functions in the
various menus. The function
currently assigned is always
indicated by a text in the
display directly above the
softkey.
5 Call button Take a call or dial a number.
Open the call list.
6 −Digit keys
Enter phone numbers and
names or write a text.
7 Emergency Call button
You can assign an emergency
number to the button and call
it directly by pressing and
holding it. The button can be
programmed so that the
handsfree function is
automatically activated.
Service−Hotline Germany: Tel. [phone], cost via German landline at time of going to print:
14 ct/min., different costs possible via mobile telephone systems

Operating Elements
20
8  Scroll Up button
The button is used to navigate
through menus and texts.
Open the menu.
9 On/Off button, On−hook button
Switch the mobile phone on
and off.
Cancel the current process.
End or reject a call.
10 Scroll Down button
The button is used to navigate
through menus and texts.
Open the phone book
11 Microphone Is activated during a call.
12 Loudspeaker You can hear the caller’s
voice from here when the
phone is in Handsfree mode.
13 Battery compartment cover
Cover of the battery
compartment.
14  Volume control Regulates the volume of the
caller.
15 Attachment eye Attach a wrist strap (not
contained in the material
supplied).
Service−Hotline Germany: Tel. [phone], cost via German landline at time of going to print:
14 ct/min., different costs possible via mobile telephone systems
