GB-5
¾THE PRE-SET TIME WILL BE RE-SET COMPLETELY IF DIS-CONNECTING THE MAIN POWER SUPPLY.
YOU ARE RECOMMENDED TO SWITCH THE SYSTEM INTO STANDBY MODE FOR CONVENIENCE
USAGE.
LISTENING TO RADIO
OPERATION
1. TURN ON THE POWER (18) & THEN PRESS THE FUNCTION BUTTON (10) UNTIL IT REACH THE “ TUNER ” MODE.
2. PRESS THE CD “ STOP / BAND “ BUTTON (6) TO SELECT EITHER “ MW (AM) “ OR “ FM “ RADIO BAND.
3. TURN THE TUNING KNOB (19) TO SET THE STATION FREQUENCY AS DESIRED.
4. ADJUST VOLUME CONTROLS (8,9) FOR THE DESIRED VOLUME LEVEL.
FM & FM-STEREO RECEPTION
zSET THE FM MODE SELECTOR (14) AT “ MONO ” POSITION. PROGRAMS ARE RECEIVED IN MONO MODE. IN
PARTICULAR WHEN STEREO SIGNALS ARE WEAK. IT IS PREFERABLE TO RECEIVE THE PROGRAM IN MONO.
zSET THE FM MODE SELECTOR (14) AT “ STEREO ” POSITION FOR RECEIVING STEREO PROGRAMS. THE “ FM-ST
“ LED INDICATOR (2) WILL LIGHT UP TO SHOW FM STEREO PROGRAM IS BEING RECEIVED.
HINTS FOR BEST RECEPTION:-
THE RECEIVER HAS A BUILD-IN FM WIRE ANTENNA (23) HANGING AT THE REAR CABINET. THIS WIRE SHOULD BE
TOTALLY UNRAVELED AND EXTENDED FOR THE BEST RECEPTION.
PLAYING COMPACT DISC
zGETTING START
1. PRESS THE FUNCTION BUTTON (10) UNTIL IT REACH THE “ CD ” MODE.
2. OPEN THE CD COMPARTMENT BY PRESSING THE CD DOOR OPEN BUTTON (15). PUT A CD DISC INTO THE
COMPARTMENT AND CLOSE THE CD DOOR.
3. FOCUS SEARCH IS PERFORMANCE IF DISC IS INSIDE. TOTAL NUMBER OF TRACKS IS READ.
zPLAY / PAUSE MODE
1. IF PLAY/PAUSE BUTTON (3) IS RESSED DURING STOP MODE, THE FIRST TRACK WILL BE PLAYED AND THE
PLAY INDICATOR WILL APPEAR AT THE LCD DISPLAY (7).
2. IF PLAY/PAUSE BUTTON (3) IS PRESSED DURING PLAY MODE, GOTO PAUSE MODE AND THE PLAY
INDICATOR WILL START FLASHING AT THE LCD DISPLAY (7).
zSTOP MODE
1. IF STOP /BAND BUTTON (6) IS PRESSED DURING PLAY OR PAUSE MODE. GO TO STOP MODE AND DISPLAY
TOTAL NUMBER OF TRACK ON THE LCD DISPLAY (7).
zSKIP MODE (SKIP UP /SKIP DOWN )
1. DURING PLAY OR PAUSE MODE, IF SKIP UP BUTTON (5) IS PRESSED IT WILL GO TO NEXT TRACK AND
DISPLAY THE TRACK NO. AND THEN CONTINUOUS THE PLAY OR PAUSE MODE.
2. DURING PLAY OR PAUSE MODE, IF SKIP BACK BUTTON (4) IS PRESSED, IT WILL GO BACK TO THE
BEGINNING OF THE TRACK, SAME TRACK NO. IS DISPLAY AND CONTINUOUS THE PLAY OR PAUSE MODE.
3. AFTER STEP 2, PRESS SKIP BACK BUTTON (4) AGAIN, IT WILL GO TO THE PREVIOUS TRACK AND
CONTINUOUS THE PLAY OR PAUSE MODE.
zFOR MP3 DISC/FILE
1. AFTER FOCUS SEARCH IS PERFORMING, THE TOTAL NUMBER OF TRACK WILL BE SHOWN ON THE LCD DISPLAY
(7).
2. PRESS “ SKIP UP “ OR SKIP DOWN (5,4) BUTTON TO SELECT THE TRACK NUMBER.
3. WHEN THE DESIRED TRACK AND ALBUM IS BEING SELECTED, PRESS THE “ PLAY/PAUSE ” BUTTON (3) TO
START PLAYBACK.
REMARK
- PRESS “ FOLDER UP OR DOWN “ BUTTON AT REMOTE CONTROL CAN SELECT THE FOLDER DRIECTLY.
- THE NUMBER OF FOLDER WILL DISPLAY ON LCD (7) FOR 2-3 SECONDS SELECTED AND THEN IT WILL RESUME
TO THE NUMBER OF THE TRACK BEING PLAYBACK
zREPEAT/INTRO/RANDOM MODE (BY REMOTE HANDSET)
PRESS THE “ REP/RAN “ BUTTON DURING PLAYBACK TO SELECT REPEAT AND RANDOM FUNCTION, A SINGLE TRACK,
SINGLE FOLDER (MP3 ONLY) OR ALL THE TRACKS CAN BE PLAYED IN DIFFERENCE MODE AS FOLLOW:-
FOR CD
(1) REPEAT 1 (2) REPEAT ALL TRACK (3) RANDOM (4) OFF MODE
