AudioSource Amp Seven T User manual

midpoint and use your signal source (receiver, CD player, preamplifier, etc.) to adjust the volume.
Stereo Power Amplifier with Internal Bridging
We hope that you will enjoy your AudioSource Amp Seven T. Please take a few moments to read this manual, and be sure
to retain this document for future reference. Note: If any part of this product is damaged or missing, do not contact your
AudioSource dealer. Please call us directly at 800-435-7115.
Owner’s Manual
Using the Controls/Front Panel
Power
This front panel button will manually switch the Amp Seven T on or off. A multicolored LED indicates its power status. To use the
Auto On feature, leave this front panel switch in the on position.
Speaker Selector
The Amp Seven T has two pairs of speaker outputs. Press button Ato activate the Aoutputs. Press button Bto activate the Boutputs.
Both Aand Boutputs may be used simultaneously, provided the combined impedance does not fall below 2 ohms. Before pressing
either of the speaker selector buttons, be sure that the level controls are set at the minimum position.
Input Level Controls
These knobs adjust the incoming signal level and thereby act as volume controls. We recommend that you set these at
Amp Seven T

Using the Controls/Back Panel
Manual/Auto Power Switch (Rear Panel)
In the Auto mode, the Amp Seven T will turn on automatically when an input signal is sensed. In the absence of an input signal, the
Amp Seven T will shut down automatically. (In the Auto mode, the front panel power switch should always remain in the on posi-
tion.) In the Manual mode, use the front panel power switch to activate the Amp Seven T.
Hooking up the Wires
Audio signals travel out of one component and into another, so all of your connections should go from out to in.
Line In
If you are connecting a preamp or other signal source to the Amp Seven T, connect the this signal source’s line out jacks to the
Amp Seven T’s line in jacks.
Bridging Switch
In addition to providing 200 watts RMS per channel in the stereo mode, your Amp Seven T can be used as a high power, 500 watt
RMS mono amplifier. Simply toggle the bridging switch from the stereo position to the mono position. For mono applications, use
only the right channel input. Similarly, use only the right channel input level control.
Be sure to observe the correct speaker connections for bridged applications. Because of the Amp Seven T’s high power output in the
mono mode, we recommend initially setting the right level control at minimum, and then adjusting the volume to the desired level.
Line Out/Thru
The line in/thru jacks are used to connect to other amplifier or component inputs, including when daisy chaining components. These
Stereo Setup
In this configuration, the bridging
switch is off for stereo operation.
Connect the line out jacks from a stereo
signal source to the line in jacks of your
Amp Seven T. Next, connect your speak-
ers to the terminals marked Speaker A
(observing proper polarity: red for "+",
and black for "-"). Connect a second
pair of speakers to the terminals marked
Speaker B. Select between the A and/or
B speakers using the front panel speaker
selector buttons.
Mono Setup
In this configuration, the bridging
switch is on. Connect the line out from
a signal source to the right line in of
your Amp Seven T. Connect your mono
speaker to the terminals of your Amp
Seven T, following the example in the
diagram opposite. Use the right level
control on the front panel to adjust
the volume.

Read Instructions
All the safety and operating instructions should be read before
the appliance is operated.
Retain Instructions
The safety and operating instructions should be adhered to.
Heed Warnings
All warnings on the appliance and in the operating instructions
should be adhered to.
Follow Instructions
All operating and use instructions should be followed.
Water and Moisture
The applianceshould not be used near water. For example, near a
bathtub, washbowl, kitchen sink, laundry tub, in a wet basement,
or near a swimming pool, etc.
Ventilation
The appliance should be situated so that its location or position
does not interfere with its proper ventilation. For example, the
appliance should not be situated on a bed, sofa, rug, or similar
surface that may block the ventilation openings; or, placed in a
built-in situation, such as a bookcase or cabinet that may impede
the flow of air through the ventilation openings.
Heat
The appliance should be situated away from heat sources such as
radiators, heat registers, stoves, or other appliances (including
amplifiers) that produce heat.
Power Sources
The appliance should be connected to a power supply only of
the type described in the operating instructions or as marked on
the appliance.
Grounding or Polarization
Precautions should be taken so that the grounding or polariza-
tion means of an appliance is not defeated.
Power Cord Protection
Power supply cords should be routed so that they are not likely
to be walked on or pinched by items placed on or against them,
paying particular attention to cords at plugs, convenience recep-
tacles, and the point where they exit from the appliance.
Cleaning
The appliance should be cleaned only as recommended by the
manufacturer.
Power Lines
An outdoor antenna should be located away from power lines.
Non-Use Periods
The power cord of the appliance should be unplugged from the
outlet when left unused for a long period of time.
Object and Liquid Entry
Care should be taken so that objects do not fall and liquids are
not spilled into the enclosure through openings.
Damage Requiring Service
The appliance should be serviced by qualified service personnel
when: a) The power supply cord or the plug has been damaged;
b) Objects have fallen, or liquid has been spilled into the appli-
ance; c) The appliance has been exposed to rain; d) The appli-
ance does not appear to operate normally or exhibits a marked
change in performance; or e) The appliance has been dropped,
or the enclosure damaged.
Servicing
The user should not attempt to service the appliance beyond that
described in the operating instructions. All other servicing
should be referred to qualified service personnel.
Product Servicing
In the event that your Amp Seven T fails to operated properly,
please contact the dealer where you purchased the unit. Or you
may contact AudioSource directly for further assistance.
Safety Instructions
Warning: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.
Caution: To reduce the risk of electric shock, do not remove cover (or back); no user serviceable parts inside. Refer servicing to
qualified service personnel.
Caution: To prevent electric shock, match wide blade of plug to wide slot, fully insert.
Attention: Pour eviter les chocs electriques, introduire la lame la plus large de la fiche dans la borne correspondante de la prise et
pousser jusqu'au fond.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated dangerous
voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electrical shock to persons. The exclamation point
within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION:
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
Enjoy your new purchase. This manual provides detailed diagrams and instructions for setting up your
equipment. Our commitment to your satisfaction doesn't end there. We also offer friendly, toll-free assistance.
1-800-HELP-115

Amplifier Power Output . . . . . . . .200 watts per channel
500 watts monobridged
Total Harmonic Distortion . . . . . . . . . . . . . . . . . .<0.04%
Intermodulation Distortion . . . . . . . . . . . . . . . . . <0.04%
Frequency Response . . . . . . . .20 Hz to 20K Hz, ±0.5 dB
Signal to Noise Ratio . . . . . . . . . . . . . . . . . . . . . .110 dB
Input Sensitivity . . . . . . . . . . . . . . . . . . . . . .0.8 V (Line)
Input Impedance . . . . . . . . . . . . . . . . . . . .30K Ω(Line)
Headroom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2dB
Functions . . . . . . . . . . . . . . Mono Bridging (Rear Panel)
Auto/Manual Power Switch (Rear Panel)
Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . .Line (RCA) In
Outputs . . . . . . . . . . . . . . . . . . .Speaker A (Left, Right),
Speaker B (Left, Right), Line Out/Thru (RCA)
Dimensions . . . . . . . . . . .16 1/2"W x 4"H x 13 1/4"D
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 lbs.
Design and specifications are subject to change without notice.
9300 NorthDecatur
Portland, OR, 97203
Tel. [phone]
Fax [phone]
[email protected]
www.audiosource.net © 2000 AudioSource, Inc.
Amp Seven T Specifications
