Audiovox Car Security System AX-900 User manual

128-6996A
1 of 28
Model AX-900
Installation Manual
RY
SELECTABLEFEATURES
Note : The method of manual override can either be selected to operate from the valet switch or operate as custom code. Be
certain to place a check mark indicating the method used in the box located on the last page of the owner's manual.
RF Programmable Features :
Feature Selection 1 Chirp 2 Chirps 3 Chirps 4 Chirps Default
1st DoorL/UL 1 Sec. 3.5 Sec. 1 Sec L, Dbl. U/L 1 Sec.
2nd Accy Lock Auto Lock On Auto Lock Off Auto Lock Off
3rd Accy. UL Auto UL Dr. Auto UL All Auto UL Off Auto UL Off
4th Headlights OnArm OnDisarm On Both Off Both
5th Passive Locks Passive Active Active
6th Passive/Active Arm Passive Arm Active Arm Active Arm
7th Black/Blue (Aux O/P) SinglePulse As Feature #1 Single
8th Siren/Horn Siren/Horn Siren Only Horn Only Siren/Horn
9th Horn Chirp 10mS 16mS 30mS 16mS
10th Override Method CustomCode Valet Valet
11th Two Step Unlock On Off Off
12th Chirp Delete From Tx On Off Off
To program these selectable features;
Action System Response
Turn ignition on No response
Press and release the valet switch 3 times 1 Chirp - LED 1 flash
Within 3 seconds, turn ignition Off Short chirp, then long chirp
First Then turn the ignition back On 1 chirp = 1 second door locks
Press transmitter Lock button to change 2 chirps = 3.5 second door locks
Press transmitter Lock button to change 3 chirps = 1 sec. lock, dbl 1 sec. unlock
or
Second Press and release the valet switch 2 chirps = auto locks off
Press transmitter Lock button to change 1 chirp = auto locks on
or
Third Press and release the valet switch 3 chirps = auto unlock off
Press transmitter Lock button to change 1 chirp = auto unlock drivers door only
Press transmitter Lock button to change 2 chirps = auto unlock all doors
or
Fourth Press and release the valet switch 3 chirps = headlight output when arming and disarming
Press transmitter Lock button to change 4 chirps = headlight output off
Press transmitter Lock button to change 1 chirp = headlight output when arming
Press transmitter Lock button to change 2 chirps = headlight output when disarming
or
Fifth Press and release the valet switch 2 chirps = active locks
Press transmitter Lock button to change 1 chirp = passive locks
or
Sixth Press and release the valet switch 2 chirps = active arming
Press transmitter Lock button to change 1 chirp = passive arming
or
Seventh Press and release the valet switch 2 chirps = as feature #1
Press transmitter Lock button to change 1 chirp = single pulse
or
Revision A: 4-21-04 Changed remote start and tach rate programming features.

128-6996A
2 of 28
ThisPageIntentionallyLeft Blank
2

128-6996A
3 of 28
Eighth Press and release the valet switch 1 chirp = siren and horn output
Press transmitter Lock button to change 2 chirps = siren output only
Press transmitter lock button to change 3 chirps = horn output only
or
Ninth Press and release the valet switch 2 chirps = horn chirp output 16mS
Press transmitter Lock button to change 3 chirps = horn chirp output 30mS
Press transmitter Lock button to change 1 chirp = horn chirp output 10 mS
or
Tenth Press and release the valet switch 2 chirps = valet switch override operation
Press transmitter Lock button to change 1 chirp = custom code override operation
or
Eleventh Press and release the valet switch 2 chirps = 2 step unlock off
Press transmitter Lock button to change 1 chirp = 2 step unlock on
or
Twelfth Press and release the valet switch 2 chirps = chirp delete from transmitter inactive
Press transmitter Lock button to change 1 chirp = chirp delete from transmitter active
Press and release the valet switch Exit program mode
or
Turn ignition key off Exit program mode
Note : Once you enter the feature programming mode, do not allow more than 15 seconds to pass between steps or the
programming will be terminated.
This Remote Start/Alarm System is designed to be used with Automatic Transmission- Fuel Injection
Vehicles Only! The unit provides a selectable ignition control that allows a number of selectable timed outputs
for glow plug preheat in addition to a "Wait To Start Input" either of which may be required for certain diesel
vehicles, (see selectable feature #9 & or Green/Yellow Wire). If the diesel engine has a instant fire, (no glow
plug preheat system), feature #9 should remain in the default Gasoline mode setting. For diesel applica-
tions,consultyourdealerfor the type of ignition system used in your particular vehicle. Regardlessofthe
vehicle, Gasoline or Diesel, for every installation, the vehicle MUST HAVE a Tach Signal Input, Auto-
matic Transmission and Fuel Injection.
INSTALLATION OF THE MAJOR COMPONENTS:
CONTROLMODULE:
Selectamountinglocationinside the passenger compartment (up behind the dashboard). The mounting
location selected must be within 24" of the ignition switch wiring harness to allow connection of the 6 pin
mainwiringharness.
Becertainthatthechosenlocation willnot interferewithproper operationof thevehicle. Avoidmountingthe
moduleto or routingthewiring around thesteeringshaft/column, asthemodule or wiringmaywrap around
or block the steering wheel preventing proper control of the vehicle. Secure the module in the chosen
location using cable ties or screws as necessary.
Do Not Mount The Module In The Engine Compartment, as it is not waterproof.
SIREN:
Select a location in the engine compartment that is not accessible from below the vehicle. The selected
location must be clear of hot or moving parts within the engine compartment The siren must be pointed
downwardtopreventwaterretentionandtheflaredendmust be pointed away from and out of the engine
compartment for maximum sound distribution. Before securing the siren, check behind your chosen
location to assure that the mounting screws will not penetrate any factory wiring or fluid lines. Secure the
siren mounting bracket using #8 self taping screws or by first using the mounting bracket as a template,
scribeormarkthemountingholes. Drillthemarkedholesusinga1/8"drillbit,thenmountthesirenusing
#8 sheet metal screws.
3

128-6996A
4 of 28
HOODAND TRUNK PINSWITCHES:
The pin switches included in this package are intended for protecting the hood and trunk areas of the
vehicle. In all cases, the switch must be mounted to a grounded metal surface. When the pin switch is
activated,(hood/trunkopen), itwill supply a ground to the inputwireactivatingthealarm. In addition, the
hoodswitchis required for the safety shutdownoftheremote start unit. If the vehicle isbeingworkedon,
this hood switch prevents the remote start activation even if the RF command to start is issued. This
switch must be installed in all applications. Failure to do so may result in personal injury or
property damage. Mount the switches in the hood and trunk locations away from water drain paths. If
necessary, the included brackets may be used to move the switch away from rain gutters or allow
mounting to the firewall behind the hood seal. In both cases the switch must be set up to allow the hood
or trunk door to depress the switch at least 1/4 inch when the hood or trunk is closed and fully extended
when the hood or trunk is opened. For direct mounting, a 1/4 inch hole must be drilled. Carefully check
behindthe chosen locationtoinsure thedrillwill not penetrateanyexisting factorywiringor fluidlines. Drill
a 1/4" hole in the desired location and thread the pin switch into it using a 7/16" nut driver or deep well
socket. If using the mounting bracket, first secure the bracket to the desired location and secure the pin
switchinthe pre-threaded mounting bracket hole.
DASHMOUNTEDLED:
Thesmall LEDincluded in thekit willserve as a visualindicatorof the alarm's status andprovidea visual
deterrentto a potentialthief.The LEDalsoprovidesimportant feedbackinformation during thetransmitter
andfeature programmodes.The LEDshouldbe installedinthe dashin anareahighly visiblesothat itmay
be seen from the driver's seat as well as from outside the vehicle. Inspect behind the chosen location to
insure that the drill will not penetrate any existing factory wiring or fluid lines. Carefully drill a 1/4" hole in
the desired location and pass the connector end of the LED through the hole and toward the control
module. Press the LED firmly into place until it is fully seated in the mounting hole.
THERECEIVER/ANTENNAASSEMBLY:
The Superheterodyne ReceiverAntennaAssembly provided with this unit allows routing from below the
dashboard formaximum operatingrange. Choosea locationabove thebeltline (dashboard)of thevehicle
for best reception. Special considerations must be made for windshield glass as some newer vehicles
utilize a metallic shielded window glass that will inhibit or restrict RF reception. In these vehicles, route
theantennatowardarearwindowlocation for best reception. Secure the antenna with double stick tape
provided. Aftersecuring the antennawithtape,we advise also securing asectionoftheantenna cable to
afixed support. This willpreventthe antennafromdropping downincase the doublesticktape isexposed
to extreme heat which may loosen it's gummed surface. Route the connector toward the control module
using caution not to pinch the cable as this will cause poor or no RF reception to the control module.
VALET/PROGRAM/MANUALOVERRIDE SWITCH:
Select a mounting location that is easily accessible to the operator of the vehicle. It is not necessary to
conceal the switch. However, concealment is recommended as it offers a higher level of security. The
switchcanbe mounted to the lowerdashpanelin the driver's area. Inspect behindthechosenlocationto
insurethat adequateclearanceis allowedforthe bodyofthe switch,andalso thatthedrill willnot penetrate
any existing factory wiring or fluid lines. Drill a 9/32" hole in the desired location and mount the switch by
passingit through the panelfromtheunderside. Secure the switch using the nut, starwasher. Routethe
switch'sconnectortowardthecontrol module.
NOTE: During the program sequence, there are times when this switch and the ignition switch will be used
simultaneously. We recommend that the pushbutton switch be mounted on the left side of the ignition
switch to facilitate this operation.
4

128-6996A
5 of 28
CONTROLSWITCH:
Selectamounting location known andaccessibletothe operator of thevehicle. Alower dash panel,kick
panel,orglove box is desirable. Inspectbehindthechosen location to insurethatadequateclearance is
allowed for the body of the switch, and also that the drill will not penetrate any existing factory wiring or
fluid lines. Drill a 1/4" hole in the desired location and mount the switch by passing it through the panel
from the underside. Secure the switch using the nut, star washer, and on/off face plate. It is suggested
that the switch be oriented to allow the on position to be up toward the driver and the off position to be
downorawayfromthe driver. Routetheswitch'sconnectortoward the control module.
SHOCKSENSOR:
Select a centrally located, solid mounting surface for the shock sensor that will allow consistent opera-
tionfromallareas of the vehicle. The selected location must bewithin18"ofthecontrol module to allow
routing and connecting of the 4 pin harness. Secure the shock sensor to the chosen location using two
#8 self tapping sheet metal screws. The sensor can also be secured to an existing dash brace using
cable tie straps. Whichever mounting method is used be sure to allow access to the sensitivity adjust-
ment potentiometer for use later in the installation.
STARTER INHIBIT RELAY:
Select a mounting location within 12" of the ignition switch's low current start solenoid wire. Secure the
relay to an existing harness in the chosen location using a cable tie around the relay's wiring harness.
CAUTION! Donotwire tiethemetal brackettoan existingwiringharness asvibrationmay causechaffing
and shorting damaging the factory wiring. If an existing harness is not available then secure the relay's
metalmounting tabto an underdashmetalbracewith a #8selftapping sheet metalscrew. Wirethe relay
as per the diagram found later in this manual.
TheAX-900 is tobeusedin vehicles with AUTOMATIC TRANSMISSIONS only! Althoughthiscombina-
tionAlarm/Remote Start unit is a sophisticated system with many advanced features, IT MUST NOT be
installed into a vehicle with a manually operated transmission. Doing so may result in serious per-
sonalinjuryand property damage.
IMPORTANT!
DONOTPLUGTHESIXPINMAINPOWERHARNESSORTHEMULTIPININPUT/OUTPUTHARNESS
INTO THE CONTROLMODULE UNTILALL CONNECTIONS TO THE VEHICLE HAVE BEEN MADE.
AFTER SELECTING YOUR TARGET WIRESAS DEFINED BELOW, DISCONNECT THE NEGATIVE
BATTERYCABLEFROMTHE VEHICLEBATTERYPRIORTOMAKINGANYCONNECTIONS.
WIRING THE 6 PIN MAIN POWER HARNESS:
RED w/ PURPLE Trace Wire: + 12 volts Battery 1 Source
Connect this wire to a + 12 VDC constant source found at the vehicle's ignition switch using the 30Amp
fuse and holder provided. This wire provides power for the control circuit as well as the ignition 1 and
ignition 2 relays.
RED Wire: + 12 Volts Battery 2 Source
Connect this wire to a + 12 VDC constant source found at the vehicle's ignition switch using the 30Amp
fuseand holder provided, butNOTthe same vehiclewireas used bythebattery 1 source. Mostvehicles
havemorethanone battery source supplying power to the ignition switch. Separate feedwiresmustbe
usedfor the RedandRed/White wires. If yourvehicledoes not havetwobattery feedwiresatthe ignition
switch then it is possible to connect both wires to the vehicle's battery. This wire provides power for the
start relay and the accessory relay.
5

128-6996A
6 of 28
PURPLE Wire: Starter Output
Careful consideration for the connection of this wire must be made to prevent the vehicle from
starting while in gear. Understanding the difference between a mechanical and an electrical
Neutral Start Switch will allow you to properly identify the circuit and select the correct installa-
tion method. In addition you will realize why the connection of the safety wire is required for
all mechanical switch configurations.
Failureto make this connection properly can result in personal injury and propertydamage.
Inallinstallationsit is the responsibility of the installingtechniciantotestthe remote start unit and assure
that the vehicle cannot start via RF control in any gear selection other than park or neutral.
Inbothmechanical and electricalneutralstartswitchconfigurations,the connection of theYellowwirewill
bemadetothe low current start solenoid wire of theignitionswitchharness. Thiswirewill have +12 volts
when the ignition switch is turned to the start (crank) position only. This wire will have 0 volts in all other
ignition switch positions.
NOTE: This wire must be connected to the vehicle side of the starter cut relay (when used). For the
electrical neutral switch configuration, this connection must be made between the starter inhibit
relay, (when used) and the neutral safety switch as shown in the following diagram.
Failure to connect this wire to the ignition switch side of the of the neutral safety switch can result in
personalinjury and propertydamage.
SEENEUTRALSTARTSAFETYTESTFORFURTHERDETAILS.
PURPLESTART WIRE DETAIL
PINK Wire: Ignition 1 Output
Connect this wire to the ignition 1 wire from the ignition switch. This wire will show +12 volts when the
ignition key is turned to the to the "ON" or "RUN" and the "START" or CRANK" positions and will have 0
volts when the key is turned to the "OFF" and "ACCESSORY" positions.
ForDieselApplications, thiswiremustbe connected to theignitioncircuit that powers theglowplugs if the
vehiclerequires glow plugpreheating.(See selectable feature#9)
6
IMPORTANT!
It is the responsibility of the installing technician to determine the load factor of the vehicles electrical
circuitswhenthe vehicle is running, and toadequatelyfusethe two power wires based onthatload. Ifthe
vehicle,running under loadwiththe air conditioner,heaterblowermotor and accessoriesexceed24Amps
continuous, we recommend that two fuses be used in combination on each power wire as shown below.
Foradditionalinformation seeTechUpdate issued 9/30/96.

128-6996A
7 of 28
WIRING CONNECTIONS: Multi Pin Accessory Input/Output Harness
White w/ Red Trace Wire: Parking Light Flasher Feed
Thiswireis the common contactofthe on board parkinglight flasher relay. Ifthevehicleyouareworking
on has +12 volt switched parking lights, connect this wire to a fused + 12 volt source. (Max. 15Amps)
NOTE: Ifthevehicle'sparkinglightsare ground switched, connect this wire to chassis ground.
White Wire: Parking Light Flasher Output
Thiswireis the normally open contactofthe on board parkinglightflasherrelay. Connect this wire tothe
vehicle parking light feed wire. See diagram below for details on wiring positive switched parking light
circuits.
7
PINK/WHITE Wire: Ignition 2 Output
Connect this wire to the ignition 2 wire from the ignition switch. This wire will show + 12 volts when the
ignition key is turned to the "ON" or "RUN" position and is some cases the "START" or CRANK" position.
This wire will show 0 volts when the key is turned to the "OFF" and "ACCESSORY" positions.
NOTE:See programminginformationconcerning this wire.
ORANGE Wire: Accessory Output
Connect this wire to theAccessory wire from the ignition switch. This wire will show + 12 volts when the
ignition switch is turned to the "ACCESSORY" or "ON" and "RUN" positions and will show 0 volts when
the key is turned to the "OFF" and "START" or "CRANK" positions.

128-6996A
8 of 28
Brown Wire: (+) Siren Output
Thisisthepositive siren feed wire. Route this wire through a grommet inthefirewalltothesiren location.
Connect the Brown wire to the Red wire of the Siren. Secure the Black wire of the Siren to a known
chassis ground or solid clean metal surface.
Siren Wiring Detail
8
Parking Light Wiring Detail
Purple Wire: (+) Door Trigger Input
If the vehicle's door courtesy light switches + 12 volts when the door is opened, (Some Fords and some
Imports),youmustconnect this wire to the positive output from one of the vehicle's door pin switches. In
mostcases,thePurple wire will need to be connected to onlyonedoorswitchno matter how many doors
thevehiclehas as most door lighting circuits are wired in parallel. This wire will be shunted when remote
startingthevehicle and willremainshunted,if active, whilerunningundercommand of theremotestart. If
this wire is active when the system is armed, the siren will emit three chirps. When the zone clears, the
siren will emit 1 chirp to confirm full arming. See below for wiring details.
Noteforvehicles with interior delay lightingseeprogrammingunder title "Completing The Installation".
Positive Door Switch Wiring Detail

128-6996A
9 of 28
Blue Wire: (-)InstantTriggerInput
This is the instant on ground trigger input wire. This wire must be connected to the hood and trunk pin
switchespreviouslyinstalled.
Note: Thiswire willbeshunted when remotecontrolchannel 2isaccessed, (trunkrelease). Thiswire will
remainshunted allthewhile thereisground presentandfor 5seconds aftertheground isremoved.
Thisallowstheoperatortoopen the trunk via the remote transmitter without having to first disarm
the alarm system. See below for wiring detail.
Hood Pin Switch Detail
Blue w/Black Trace Wire: Ignition 3 Output
Thiswireprovidesa 300mAground output that becomes active 3 secondsbeforetheRemoteStart Unit
initializes,andremainsgroundedwhilerunning plus an additional 4 seconds aftertheRemoteStartUnit
turns off. In all of the applications described below, a relay will be required.
This wire can be used to accommodate the following situations:
A. Shock Sensor By Pass:
If there is a Non Plug in Shock Sensor used with the alarm system and it is not shunted during the
RemoteStartactivationperiod,then vibrationfrom therunning vehiclecancausethealarmtotrigger. In
this case, connect the Blue/Black Wire to terminal #86 of a external relay. Connect terminal # 85 of
the relay to a fused + 12 volt battery source. Cut the shock sensor trigger wire and connect one end
of the cut wire to terminal #30 and the other end of the cut wire to terminal #87a. Just before the
Remote Start unit is activated, the relay contacts will open, preventing the shock sensor's operation
until the Remote Start unit shuts off.
B. Ignition 3 Output:
Somenewervehiclesusea third ignition wire which is required to start and keep the vehicle's engine
running. If this is the case, connect the Blue/Black wire to terminal #86 of an external relay. Connect
terminal # 30 & # 85 to a fused + 12 volt battery source rated for a minimum of 25 Amp. Connect
terminal # 87 to the third ignition wire in the vehicle.
C. GM VATS Key Override:
Ifthevehicle has the GeneralMotorsVATS system installed,you will needtobypassthesystemwhile
the vehicle is operating under the control of the Remote Start Unit. To DoThis;
1. Measure the resistance of the resistor pellet on the ignition key then select a resistor within 5% of
the key's value from the resistor pack supplied.
2. Locate the pair of VATS wires in the vehicle, usually a pair of thin gauge wires running from the
ignition switch to the VATS control module.
NOTE: ThesewiresaretypicallyWhitew/ Black trace and Violet w/Yellow trace, however in later model
Cadillacs,theyarerunthroughanorangesleeve, and are either both Black, bothYellow,orboth
Whitewires. Consultthefactory service manual for additional information.
3. Connect the Blue/Black Wire from the Remote Start Unit to terminal #86 of an external relay.
Connect terminal #85 of the relay to a fused + 12 volt battery source.
9

128-6996A
10 of 28
10
Black w/ White trace Wire: Entry Illumination Ground Output
Thiswireprovidesa30secondgroundoutput(300mAMax.)wheneverthe remote is used to disarm the
alarmor tounlock thedoors andprovidesacontinuouspulsed outputwhenever thealarm istriggered. This
wireshould beconnectedto anexternalrelay andwired tothe vehiclesinteriorentry lighting wheneverthe
optionalInteriorIlluminationcircuit is desired. See below for relay wiring details.
Entry Illumination Detail
Grey Wire: Negative Inhibit Input plusTriggerWhenArmed
TheGrey wire provides aninstantshutdownfor the RemoteStart ControlModulewhenever it is grounded
andtrigger whenever the unitisarmed. Connect the Greywiretothe hood pinswitchpreviously installed.
Thiswire mustberouted through agrommetin thefirewalland connectedtothe hoodpinswitch. If thepin
switch is to be used with an alarm system, connect this wire using the diode assembly provided.
IMPORTANT! This connection is a safety wire and must be connected as shown and tested as
specified.
4.Cut(#1)wire(asshown),andconnecttheignitionswitchsideofthecutwiretoterminal#87a of the
relay. Connect the other side of the (#1) wire to terminal #30.
5.Connectthepreviouslyselectedresistorfromterminal#87tothesecond(#2)wire(asshown).
NOTE: The above information and following diagram is for the GM VATS system only. For GM PASS
LOCK System you will require theAudiovoxAS-PASS II Module.
General Motors VATS By-Pass Diagram
