Audiovox ADUO-100-MAZ Troubleshooting guide

for selected Mazda vehicles
Installation Guide/User manual
OMA-DUO-100-MAZ-012012_rev012312.indd 1 1/23/2012 8:59:52 PM

2
Copyrights and Trademarks
Copyright 2012 Audiovox Electronics Corporation
The Audiovox and Audiovox Driven by DICE Electronics logos are trademarks of
Audiovox Electronics Corporation
iPod and iPhone are trademarks of Apple, Inc.
All Trademarks and Logos are the property of their respective owners.
All rights reserved.
Printed in the U.S.A.
OMA-DUO-100-MAZ-012012_rev012312.indd 2 1/23/2012 8:59:52 PM

3
Warning and safety
Product registration
Silverline DUO kit contents
DIP switch overview
DIP switch settings
Supported iPod models
Note to Installer
Connection diagram
Installation
iPod content browsing
Charging .
iPod locked/unlocked settings and features
Basic operation
SAT emulation
CDC emulation
Internet Radio App support
Data connection requirements
Controlling the Internet Radio App
Text display from the Internet Radio App
Terminating the Internet Radio App
Optional Remote Kit: iPod/App
Optional Remote Kit: SIRIUS
Troubleshooting
Firmware update
Warranty
..........................................................4
.........................................................5
..............................................6
.........................................................7
...........................................................8
....................................................9
..............................................................10
.......................................................11
.....................................................................12
...................................................13
.......................................................................13
..................14
..............................................................15
..................................................................6
...................................................................18
................................................20
...........................................20
.....................................21
...........................22
....................................23
...........................................24
.............................................25
..................................................................26
................................................................28
.............................................................................29
Table of Contents
OMA-DUO-100-MAZ-012012_rev012312.indd 3 1/23/2012 8:59:52 PM

4
Please read these instructions carefully before proceeding. Failure to follow instructions may result in
improper operation or injury. Audiovox Electronics Corporation nor Apple Inc., its regional ofces, distributors
or resellers take any responsibility for any damage or injury as a result of using the integration kit.
- Do not open, disassemble or alter the interface in any way.
- Do not insert anything into the casing.
- Do not cut or try to alter cables in any way and always use the correct connections.
- Only operate unit when stationary or ask passengers to operate it for you.
- Do not allow the Apple iPod/iPhone to distract you from driving.
- Exercise good judgement and keep your eyes on the road at all times.
- Do not expose unit to extreme temperatures, humidity or shock.
- Keep the unit and iPod/iPhone away from uids.
- Keep away from children! - Interface components may contain small parts, can be broken or disassembled
and components may become loose from vibration and heat. Small components and packaging materials
may be a choking hazard when handled by children.
Warning and safety!
OMA-DUO-100-MAZ-012012_rev012312.indd 4 1/23/2012 8:59:52 PM

5
Thank you for purchasing this integration kit. Please review this booklet before operating the unit. This
interface was designed and manufactured to seamlessly integrate with your vehicle’s factory audio system.
We recommend registering your Audiovox product so you can receive news about important rmware updates
and have unlimited access to our online support system.
To register your Audiovox product, please complete the following steps:
1. Visit http://www.audiovoxproducts.com
2. Look up and save the serial number of the product.
3. Complete the product registration form.
4. Submit the form.
5. Save the registration sheet in a safe place for future reference.
If you are unable to complete the registration via internet, please call Audiovox at 1-800-645-4994.
Congratulations on your purchase!
Product registration
Prior to installation make sure the module’s rmware is up to date to ensure compatibility
with the latest features and enhancements. Please refer to page 28 to update rmware.
OMA-DUO-100-MAZ-012012_rev012312.indd 5 1/23/2012 8:59:52 PM

6
Silverline DUO kit contents
Optional accessories (sold separately):
Silverline DUO module
AUX connector
user manual
Vehicle bus
connector
(SAT)
iPod docking
cable
for selected Mazda vehicles
Installation Guide/User manual
Cradle
(A-DCR-50-PTH)
For more accessories, visit www.audiovoxproducts.com
IR Receiver &
Remote
OMA-DUO-100-MAZ-012012_rev012312.indd 6 1/23/2012 8:59:53 PM

7
The conguration switches located on the Silverline DUO module are used to set various operation modes of
the interface. Incorrect dip switch settings may cause the interface to not work properly or to not operate at all.
Disconnect the vehicle harness from the module and cycle ignition off for 60 seconds after changing
the switches then reconnect the module!
Silverline DUO module
DIP switches overview
IR Receiver &
Remote
OMA-DUO-100-MAZ-012012_rev012312.indd 7 1/23/2012 8:59:53 PM

8
Dip switch setting
Car conguration switches
Use this setting for best user experience. Only
available on SAT capable radios. To enable
usage of the SIRIUS ConnectTM tuner, SAT
emulation must be used.
ON ON
Car conguration switches
Use this setting when the SAT emulation is not
available due to the limitation of the radio.
- Radio does not display text in CDC mode
- Connection of SIRIUS ConnectTM tuner is not
available in this mode.
SAT Emulation CDC Emulation
OFF OFF
The dip switch positions will congure the Silverline DUO module to interface with the ve-
hicle’s radio in various emulation modes. Depending on which conguration is chosen, you
will need to refer to the instructions in this manual specic to that emulation mode.
OMA-DUO-100-MAZ-012012_rev012312.indd 8 1/23/2012 8:59:53 PM

9
Supported iPod models and rmware version requirements
Model Model
1G nano 160 GB classic
iPod 5G 5G nano
2G nano 3G touch
iPod classic iPhone 4
3G nano
4G touch
iPod touch
6G nano
iPhone
iPhone 3G
4G nano
120 GB classic
2G touch
iPhone 3GS
Firmware / OS Version Firmware / OS Version
1.3.1 2.0.4
1.3 1.0.2
1.1.3 iOS 5
1.1.2 iOS 5
1.1.3
iOS 5
iOS 3.1.3
1.2
iOS 3.1.3
iOS 4.2.1
1.0.4
2.0.1
iOS 4.2.1
iOS 5
iPhone 4S iOS 5
OMA-DUO-100-MAZ-012012_rev012312.indd 9 1/23/2012 8:59:53 PM

10
Attention installer! Please read the following!
Audiovox strongly recommends that the unit be installed in an easily accessible place!
DO NOT PLACE IT BEHIND THE RADIO AND DO NOT HIDE UNDER CARPET!
Whether the unit is professionally or self installed, put the module where you, the end user can get to it easily
in the future. (Have the installer show you where the interface module is installed.)
Installing the module behind the radio will make it difcult to:
-Add possible future upgrades, changing software, adding new features, improving operation;
-Access the AUX input on the module to attach any audio device;
-Access the DIP switches located on the module;
-Remove the unit in case of failure.
MAKE SURE THAT THE MODULE IS IN AN ACCESSIBLE PLACE!
OMA-DUO-100-MAZ-012012_rev012312.indd 10 1/23/2012 8:59:53 PM

11
Connection Diagram
*Do not connect the iPod dock cable under any circumstance to the SIRIUS module
connector! Improper connection can cause permanent damage to iPod/SIRIUS module.
IR receiver
(optional)
Silverline DUO module
(front)
Silverline DUO module
(back)
Update port
(USB to PC) iPod dock cable*
iPod/iPhone
(not included)
Vehicle BUS
connector
SIRIUS SAT radio
(not included)
Auxiliary device
(not included)
AUX connector
(optional)
SIRIUS connector*
OMA-DUO-100-MAZ-012012_rev012312.indd 11 1/23/2012 8:59:53 PM

12
Installation
1. Verify compatibility 5. Route kit to glove box or other accessible location
6. Connect battery & test
7. Complete install by re-installing radio
2. Disconnect battery
3. Remove radio from car
4. Install Silverline DUO cable
Some radios will enter an anti-theft security mode and will lock requiring the radio’s security code
to be entered to unlock it. This code can be requested from the vehicle’s dealership.
OMA-DUO-100-MAZ-012012_rev012312.indd 12 1/23/2012 8:59:53 PM

13
By default, the interface creates a Playlist having a name that is the same
as the name of the iPod. This Playlist is the very rst on the list of Playlists
shown while browsing in Playlist mode. This Playlist contains all the songs
on the iPod. Once a Playlist is selected an Artist may be selected within
that Playlist using the Artist Mode. Albums by the selected Artist within
the selected Playlist may be selected in Album Mode. “ALL ARTIST” and
“ALL ALBUM” designate all available content in those categories.
The interface automatically charges the battery of the iPod when
connected and your vehicle ignition key is in the ACC/ON position.
Charging may be shown by an
icon that appears on the upper
right corner of the iPod screen.
May vary by model.
Less browsable content
More browsable content
iPod content browsing
Charging
Playlist
Artist
Album
Song
OMA-DUO-100-MAZ-012012_rev012312.indd 13 1/23/2012 8:59:53 PM

14
SAT emulation: Basic operation
Accessing the DUO as the audio source:
Much like the radio’s AM/FM tuner, satellite radio or CD audio sources, the Silverline DUO is integrated to be
part of the vehicle’s audio system. To access the DUO source, press the SAT button on the radio.
DUO source selection:
The DUO adds additional audio sources including iPod, SIRIUS Satellite Radio* and auxiliary audio input*. To
cycle between these sources, use the SEEK, TRACK or TUNE buttons within the rst 5 seconds of accessing
the DUO as the audio source.
*These sources require additional parts/accessories/service from Audiovox and/or third parties.
Note: When changing source, radio may temporarily display “UPDATING” when switching between iPod and SIRIUS
Connect sources.
Silverline DUO Interface settings (within rst 5 seconds of accessing the DUO as the audio source):
Press remote button 1 to apply settings and resume audio playback.
Press remote button 3 to change default volume level; use track up/down to adjust between Min and Max.
Press remote button 6 to view Silverline DUO serial number and rmware version.
PRESET 2, 4 and 5 have no settings available.
OMA-DUO-100-MAZ-012012_rev012312.indd 14 1/23/2012 8:59:53 PM

15
SAT Emulation: Operating Silverline DUO as an audio source
1Radio source selector (SAT / Silverline DUO)
2Press for Next / Previous track.
3
Press to toggle between available text elds.
Turn to scroll text.
T
U
N
E
P
U
S
H
A
U
T
O
-
M
-
D
I
S
P
-
E
S
N
P
U
S
H
A
U
D
I
O
C
O
N
T
PUSH
PWR
1
2
3
SAT
4
4
Press to enter/exit shufe and repeat settings.
Press track up to cycle between random
song, random albums, random OFF.
Press track down to cycle between repeat
song, repeat all or repeat OFF.
Press SCAN to save settings and exit.
Note: You may use the remote control to change browsing modes.
OMA-DUO-100-MAZ-012012_rev012312.indd 15 1/23/2012 8:59:54 PM

16
• Stations can be saved to PRESET 1-6 by holding a preset or remote button (1-6).
• TEXT or DISP button will toggle between the text elds.
• If a Sirius Connect compatible tuner is not detected, then an “AUX” message will be displayed. Please refer
to the factory manual of your radio system about operating the Satellite mode.
• Go to Channel 000 to view the Sirius Tuner ID for activation. The 12 digit SID display format is in two halves
as SID “123456-” followed by “-789ABC”.
SAT emulation: Sirius ConnectTM operation
Press
Press Press Press
Press & Hold
NOTE: It may be possible to tune
to an invalid channel number with
certain radios. Invalid channel
numbers are indicated by an
“INVALID” message on the radio.
OMA-DUO-100-MAZ-012012_rev012312.indd 16 1/23/2012 8:59:54 PM

17
CDC emulation: Basic operation and settings
Accessing the DUO as the audio source:
Much like the radio’s AM/FM tuner, satellite radio or CD audio sources, the Silverline DUO is integrated to be part of
the vehicle’s audio system. To access the DUO source, press the CD button. Pressing this button repeatedly will cycle
through sources present in the vehicle (CD > DUO).
DUO source selection:
The DUO adds additional audio sources including iPod and auxiliary audio input*. To cycle between these sources,
use the TRACK buttons within the rst 5 seconds of accessing the DUO as the audio source.
*This source requires additional parts/accessories/service from Audiovox and/or third parties and can only be selected if devices are connected.
DUO Interface Settings
Select DISC 1 to apply settings and resume audio playback. Use TRACK up/down to select DUO audio source:
TRACK 1 = iPod TRACK 2 = Auxiliary audio source
Select DISC 3 to change default volume level; use track up/down to adjust between Min and Max. Use
TRACK up/down to cycle settings:
TRACK 1 = min. volume TRACK 5 = mid volume (default) TRACK 9 = max volume
DISC 2, 4, 5 and 6 have no settings available.
OMA-DUO-100-MAZ-012012_rev012312.indd 17 1/23/2012 8:59:54 PM

18
CDC emulation: Operating Silverline DUO as an audio source
1Radio source selector (CDC / Silverline DUO)
2Press for Next / Previous track
3
T
U
N
E
P
U
S
H
A
U
T
O
-
M
-
D
I
S
P
-
E
S
N
P
U
S
H
A
U
D
I
O
C
O
N
T
PUSH
PWR
1
2
SAT
3
Press to FFW or RW currently playing track
4
Change iPod browsing mode
4
OMA-DUO-100-MAZ-012012_rev012312.indd 18 1/23/2012 8:59:54 PM

19
Radio source selector (CDC / Silverline DUO)
Press for Next / Previous track
This kit includes support for internet radio streaming apps available on
the iTunes® Store. Thousands of stations can be streamed through data
connections. Supported apps include Livio Car Internet Radio, Pandora,
iHeart Radio and more. Supported features such as text display on screen,
and next/previous track functions will vary by app.
To learn more about each app specically, please visit the website for the
app you need information about.
Users must have an active wireless data connection in order to stream music from an app while in the car. Data
connections including “3G” or “4G” through wireless carriers, or a third party wireless Internet access point
connected to your mobile device through WiFi will work. Because this app requires a data connection, it will only
work on connected devices such as the iPhone and iPod touch.
Internet Radio Application support (iPhone/iPod touch)
Data connection requirements (3G/4G/WiFi)
OMA-DUO-100-MAZ-012012_rev012312.indd 19 1/23/2012 8:59:54 PM

20
NOTE: The following features may not be supported by all apps. For
demonstration purposes the following examples will show the features
for the Livio Car Internet Radio app.
The app must be active on the screen of the device. To do so, simply tap
the app’s icon and it will load.
Next/previous TRACK buttons execute application specic features
such as skipping stream or cycling between station presets. DISC/
PRESET (1-6) buttons are associated with station presets when used
with the Livio Car Internet Radio application.
iPhone operating system iOS5 enabled application developers to share
the “now playing” screen information. For example, when using the
Pandora App, you will see artist, album and song information on the
radio’s screen. When using an application that doesn’t implement this
feature, or running iOS4, only the name of the application will be shown.
Please note that although iOS 4 (4.2.1) is supported on iPhone 3G and
iTouch 2nd generation, applications do not run in the background. As
such, loading the app takes longer than on devices where the app is
present in the background.
Controlling Internet Radio Apps
OMA-DUO-100-MAZ-012012_rev012312.indd 20 1/23/2012 8:59:55 PM
