Audiovox AVDINPC User manual

DVD/CD/MP3/WMA PLAYER
PREV
VOL
PLAY
REW
STOP
NEXT
FF
MUTE
TAP
SEL
TAP
VOL
AVDINPC
40G HD
APP LAUNCH
Power APP LAUNCH
AVDINPC
Installation and Operation Manual
Audiovox Electronics Corporation
150 Marcus Boulevard
Hauppauge, NY 11788
Technical Assistance: 1-800-645-4994
www.Audiovox.com
© 2005 Audiovox
v.050205
Printed in Korea

AVDINPC
2
INTRODUCTION
Features
• 40 GB Hard Drive
• 512 MB DDR RAM
•
•
•
•
•
•
•
•
•
•
•
•

AVDINPC
3
PREPARATION
Congratulations on your purchase of the Audiovox AVDINPC Mobile
Multimedia DVD/CD/MP3/WMA personal computer. Please read all of the
instructions before beginning the installation.
Installation Requirements
This unit is designed for installation in vehicles with an existing radio opening.
In many cases, a special installation kit will be required to mount the computer
to the dashboard. These kits are available at electronics supply stores and car
stereo specialty shops. Always check the kit application before purchasing to
make sure the kit works with your vehicle. If you need a kit but cannot locate
one, call our customer support line at 1-800-323-4815. (U.S.A. and Canada
only.)
Tools and Supplies
The following tools and supplies are needed to install the computer.
• Torx type, flathead and Philips screwdrivers
• Wire cutters and strippers
• Tools to remove existing radio (screwdriver, socket wrench set or other
tools)
• Electrical tape
•Crimpingtool
• Volt meter/test light
• Crimp connections
• 18 gauge wire for power connections
• 16-18 gauge speaker wire
Disconnect Battery
Before you begin, disconnect the battery negative terminal (Figure 1)
Toll-Free Installation Assistance
If you require assistance, contact Technical Support at 1-800-323-4815 from
8:30 a.m. to 7:00 p.m. EST Monday through Friday and from 9:00a.m. to 5:00
p.m. EST on Saturday. (U.S.A. and Canada only.)
NOTE: If the AVDINPC is to be installed in a car equipped with an on-
board drive or navigation computer, do not disconnect the battery cable.
If the cable is disconnected, the computer memory may be lost. Under
these conditions, use extra caution during installation to avoid causing
a short circuit.
Figure 1: Battery Terminals

AVDINPC
4
INSTALLATION
The unit has threaded holes in the chassis side panels which may be used
with the original factory mounting brackets of some Toyota, Nissan,
Mitsubishi, Isuzu, Hyundai and Honda vehicles to mount the computer to the
dashboard. Please consult with your local car stereo specialty shop for
assistance on this type of installation.
1. Remove the existing factory radio from the dashboard or center console
mounting. Save all hardware and brackets as they will be used to mount
the new computer.
2. Remove the factory mounting brackets and hardware from the existing
radio and attach them to the new computer.
CAUTION: Do not exceed M5 X 6 MM screw size. Longer screws may
touch and damage components inside the chassis.
3. Place the computer infront of the dashboard opening so the wiring can be
brought through the mounting sleeve. Follow the wiring diagram carefully
and make certain all connections are secure and insulated with wire nuts
or electrical tape. After completing the wiring connections, plug the
connector into the mating socket on the rear of the chassis and turn the
unit on to confirm operation (vehicle ignition switch must be “on”). If the
unit does not operate, re-check all wiring until the problem is corrected.
4. Connect your monitor (purchased separately) and install any software/
drivers supplied with the monitor. Follow the instructions included with the
monitor to mount the monitor in the vehicle.
NOTE: A PS/2 mouse is required for installing any drivers during initial
setup. DO NOT MOUNT the unit to the dashboard until initial setup is
complete and software is installed.
5. Mount the new computer assembly to the dashboard or center console
using the reverse procedure in step 1.
CAUTION: For proper operation of the DVD player, the chassis must be
mounted within 20° of horizontal. Make sure the unit is mounted within
this limitation.
Figure 2: ISO Installation

AVDINPC
5
WIRING
Wiring Connections
1. PS/2 Mouse
2. PS/2 Keyboard
3. VGA
4. LAN (RJ-45)
5. USB 1/USB 2
6. S-Video
7. RCA Video
8. Printer
9. COM Port
10. MIC In
11. Line Out
12. Line In
13. AC Adapter (Purchased Separately) – Only use an AC adapter with the
following specifications: Output – 12V, 4.3A; Input – 100-240V~1.5A, 50/
60Hz; Center pin (+) positive
14. Car Power Input
15. Power Supply
16. ILLUMINATION WIRE (yellow)
17. ACC POWER WIRE (red) – Connect to a +12 volt circuit that is only live
when the ignition is on. The best connection point is at the car’s fuse
block at the “RADIO” or “ACCESSORY” identified terminals.
18. CONSTANT POWER WIRE (yellow) – Connect the 12V PLUS constant
power wire to a live 12 volt wire in the vehicle. Before making a
connection, check that the wire you intend to connect it to is always live,
even when the car’s ignition is turned off. If a live wire is not found, route
the wire to the car’s fuse block and connect it to a live circuit there.
19. GROUND WIRE (black) – Securely fasten the Ground wire to a grounded
metal part of the car’s chassis. If you cannot find an existing bolt or screw
to fasten it to, drill a hole in the metal and secure it with a screw. To
ensure a good ground, remove any paint or grease from areas where the
wire will contact the surface.
20. INLINE FUSE (red) – When running the red ACC Power wire directly to
the battery, the inline fuse MUST be connected between the unit and the
battery (within 18” of the battery). If the ACC Power wire is connected to
the fuse block, the inline fuse is not required.
1
3
4
56
2
7
8
910
11 12 13
14
15
16
17
18
19
Black
Yellow
Red
Yellow
+
Red
Red
20
BATTERY
FUSE BOX
Figure 3: Wiring Connections

AVDINPC
6
Replacing the Fuse
When replacing a fuse, be sure to use the correct type and amperage to avoid
damaging the computer. The AVDINPC uses one 5 amp ATO fuse.
Reconnecting the Battery
When wiring is complete, reconnect the battery negative terminal.

AVDINPC
7
FRONT PANEL OPERATION
1. POWER: Press to power the unit on/off.
2. SEL: Press to “Enter”.
3. VOL +: Raise the volume level.
4. VOL -: Lower the volume level.
5. MUTE: Silence the system volume.
6. S.TAB: This button functions like the keyboard [Shift]+[TAB] key.
7. TAB: This button functions like the keyboard [TAB] key.
8. Disc Slot
9. Disc Eject Button
10. APP LAUNCHER: Press this button to run the iMON Application
Launcher, which can execute many assigned windows applications.
11. STOP: Press this button to execute the “Stop” command in various media
applications.
12. F.FWD: Press this button to execute the “Fast Forward” command in
various media applications.
13. REW: Press this button to execute the “Rewind” command in various
media applications.
14. NEXT: Press this button to execute the “Next” command in various media
applications. The Next button also functions as the “Channel Up” button in
TV related applications.
15. PREV: Press this button to execute the “Previous” command in various
media applications. The Prev button also functions as the “Channel
Down” button in TV related applications.
16. PLAY/PAUSE: Press this button to execute the “Play” or “Pause”
commands in various media applications.
DVD/CD/MP3/WMA PLAYER
PREV
VOL
PLAY
REW
STOP
NEXT
FF
MUTE
TAP
SEL
TAP
VOL
AVDINPC
40G HD
APP LAUNCH
Power APP LAUNCH
1
2
3
4
7
6
5
8 9
10
12
13
11
14
16 15
Figure 4: Front Panel Operation

AVDINPC
8
REMOTE CONTROL OPERATION
The RSC (Remote Stick Controller) allows you to control the mouse pointer in
16 directions using the joystick control. The function of each remote control
button is described in the following table.
Figure 5: Remote Control
Table 1: Remote Control Functions
Icon Name Basic Functions Multi-Median
Power Press this button to turn the PC
on. Press and hold more than 2
seconds to turn the PC off.
App. Exit Press this button to generate the
[ALT] + [F4] keyboard shortcut,
which is used to closing the
active window.
Screen
Saver Press this button to instantly activate the screen saver.
Timer Press this button to run the
Remote Manager timer setup
screen. This timer feature can
automatically turn off the PC or
activate an alarm assigned
through the timer setup.
0-9
Numeric
Buttons
The numeric buttons (0 - 9)
function as shortcuts to the
Multi-Medianapplicationprinted
below each button. These
buttons can be customized by
the user (see??? Page _____.)
In full screen TV view, press the
number buttons to input the
channel directly. In “Find View”,
press the number buttons to
enter alphabetic characters.
0 Press this button to show the
control panel (control bar and
shortcut bar). You can use the
up, down, left and right button to
select the control button on the
control bar and shortcut bar.

AVDINPC
9
1 Press this button to change the
current media to My Music.
2 Press this button to change the
current media to My Movie.
3 Press this button to change the
current media to My Photo.
4 Press this button to change the
current media to My DVD.
5 Press this button to stop the
current media and return to the
Main View.
6 Press this button to change the
current media to My TV.
7 Press this button to search the
media file on the current
playlist.
8 Press this button to call the
setup view.
9 Press this button to call the
current playlist.
Desktop Press this button to toggle
between “show desktop” and
“restore all”. This button has the
same function as the keyboard
shortcut [Windows]+[D].
Max/Res Press this button to toggle
between “maximize” and
“restore” for the active window.
ESC This button functions like the
keyboard [ESC] key. Press this button to return to the previous view.
Table 1: Remote Control Functions
Icon Name Basic Functions Multi-Median
Windows This button brings up the
Windows start menu and
functions like the keyboard
[Windows] key.
Menu This button brings up the menu
and functions like the keyboard
[menu] key.
App.
Launcher Press this button to run the iMON Application Launcher,
which can execute many
assigned windows applications.
Multi
Median Press this button to launch the Multi-Median program provided
with the Remote Manager. Use
Multi-Median to enjoy a variety
of media files including DVD
movies, music, and photos, or to
access a multimedia device like
a TV card, digital camcoder, or
digital camera.
Task
Switcher Press this button to switch between current running
applications. This feature is
similar to the [ALT]+[TAB]
keyboard command.
Backspace This button functions like the
keyboard [Backspace] key.
Table 1: Remote Control Functions
Icon Name Basic Functions Multi-Median

AVDINPC
10
Space/
Select This button functions like the keyboard [Space] key. Press this button to add or remove the media file in the
current playlist in Media Folder/
File View. This will not delete
the media file, but will just
exclude the file from the playlist.
You an add the media file back
to the playlist at any time.
Shift + Tab This button functions like the
keyboard [Shift]+[TAB] key.
Tab This button functions like the
keyboard [TAB] key.
Mouse/
Keyboard Press this button to toggle the Remote RSC joystick operation
mode between Mouse and
Keyboard mode. The following
icons indicate the current mode.
The mouse icon
in the Remote
Indicator means
that you can
movethemouse
pointerusingthe
joystick. Press in on the joystick
to “double click”.
The keyboard
icon in the
Remote
Indicator means
that you can use
the joystick like
keyboard arrow keys. Press in
on the joystick to “Enter”.
Table 1: Remote Control Functions
Icon Name Basic Functions Multi-Median
L. Click This button functions like the left
mouse button.
R.Click This button functions like the
right mouse button.
Drag &
Drop This button performs the “Drag and Drop” function of a mouse.
Push the button at the starting
position to begin “dragging”,
then move to the destination
position using the Joystick. Push
the button again to “drop”.
Joystick Mouse mode: The joystick
functions like a mouse. Press in
on the joystick to “double-click”.
Keyboard mode: The joystick
functions like the four keyboard
arrow keys. Press in on the
joystick to “Enter”.
These buttons are used to
move the focus in the Multi-
Median. After moving the focus,
you can select the icon you
want.
Press in on the joystick button
to enter to the next view. After
moving the focus to the icon
and folder you want, push the
Enter button to move to the
next step.
MUTE Press this button to mute the PC
system volume.
VOL - Press this button to reduce the
PC system volume.
Table 1: Remote Control Functions
Icon Name Basic Functions Multi-Median
