Model PRO9056TW
Installation Manual
Vehicle Remote Start System
PATENTED: www.voxxintl.com/company/patents
PRO9056TW New FormatAdd Timing PASD & Light Blue + DBI Lock, Lock, Lock 5/2013
Table Of Contents:
BeforeYouBegin Page 2
Wire Harnesses Quick View Page 3 & 4
Installationof theMajorComponents Page 5
Wiringthe 6 Pin MainPower Harness Page 5 & 6
WiringConnections: 12PinAccessoryInput/OutputHarness Page 7 - 9
Wiringthe 4 PinAuxiliary Output Harness Page 10
6WireAntenna/Receiver Program Push Button Switch Page 10
2PinTransponderControlOutput Page 11
MonitoringtheVehicle'sEngine Page 11
Diagnostics Page 12
Multi Coil PackAdaptor Page 12
TestingYourInstallation Page 13
HoodPinSafetyShutDown Page 13
RemoteStartOverrideMode/ManualShutDown Page 13
NeutralStartSafetyTest Page 14
MechanicalNeutralSafetySwitch Considerations Page 15
KeyInSensorCircuits Page 15 - 17
CompletingTheInstallation Page 18
InstallationNotes Page 19
Programming Bank1(Transmitters) Page 18
ProgrammingBank2 (Alarm Features) Page 20
SelectableFeatures Page 21
ProgrammingBank3(Remote Start) Page 22
TachRateProgramming Page 22
RFProgrammable Features Bank3 Page 23
Wiring Diagram Page 24

128-8857b
2 of 24
2
Before You Begin
PROFESSIONAL INSTALLATION IS
STRONGLYRECOMMENDED
Rolldownwindowtoavoidlockingthekeysinthevehicleduring
installation.
Avoidmountingcomponentsorroutingwiresnearhotsurfacesor
nearmovingpartslike the steering wheel as it mayprevent proper
operationofthevehicle.
Tapeor loom wires under thehoodanddashfor protection as well
appearance.
Usegrommets when routingwiresthroughmetalsurfacestoprevent
chafingand shorting.
UseaDigital Multi Meter for testing andverifyingcircuits. DONOT
USEA"TEST LIGHT" OR "COMPUTER SAFE PROBE" as these
canset off airbags or damage sensitivevehicle computers and
electronics.
For technical support go to www.prestigecarsecurity.com
or call 1 800 225 6074
This device complies with FCC Rules Part 15 Operation is subject to the following two conditions
(1) This device may not cause harmful interference and
(2) This device must accept any interference that may be received, including interference that may cause
undesired operation.
NOTE:The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifica-
tions to this equipment. Such modifications could void the user’s authority to operate the equipment.

128-8857b
3 of 24
3
6 Pin Power / Start Harness #1123742
1
2
3
4
5
6
Purple Accessory(+)
Blue Ignition1 (+)
Red Battery 2 - 12V (+)
Red/White Battery 1 - 12V (+)
Yellow StarterOutput
Green Ignition2 (+)
1
2
3
4
Black/Blue FactoryDisarm / Pulse Beffore Start(-)
Black/Green FactoryArm /PulseAfterStart (-)
Black/Red PulseAfterShutdown(-)
Black/Yellow PulseDuringCrank(-)
Green/Orange TachometerInput
12 Pin Main Wiring Harness #1123751
1
2
3
4
5
6
7
8
9
10
11
12
Yellow/Black (+)OutputToControl FactoryAlarm
Green/Yellow DieselWaitTo StartInput
Brown PositiveInhibitShutdownInput(+)
Brown/Black BrakeShutdownInput(+)
Black Chassis Ground
Gray/Black NegativeInhibitShutdownInput(-)
LightBlue Ground OutputWhile Running (-) 300mA
Grey ShutdownInput(-)
White ParkingLightOutput
White Parking Light Input
NoConnection
4 Pin Alternate Output Harness #1122585

128-8857b
4 of 24
4
2 Pin Transponder Output Harness Part #1123292
1
2Red Battery(+)100mA
Black (-)Output WhileRunning100mA
6 Pin Antenna Harness Part # 1123908

128-8857b
5 of 24
5
ThisRemote Start/Alarm System is designed tobe used withAutomatic Transmission - Fuel Injection
Gas or Diesel Vehicles Only!
INSTALLATION OF THE MAJOR COMPONENTS:
CONTROLMODULE: PART#1365036
Selecta mounting locationinside the passengercompartment (up behindthe dashboard). Themounting
location selected must be within 24" of the ignition switch wiring harness to allow connection of the 6 pin
main wiring harness. Be certain that the chosen location will not interfere with proper operation of the
vehicle. Avoid mounting the module to or routing the wiring around the steering shaft/column, as the
moduleorwiring may wraparoundor blockthesteering wheelpreventingproper controlofthe vehicle. The
modulewill be securedafter all wiring is completed which will allowcomplete access untilthe job isdone.
Do Not Mount The Module In The Engine Compartment, as it is not waterproof.
HOOD PIN SWITCH: PART# 1363699
Thepin switchincluded in this package isintended forprotecting thehood areaof thevehicle. Inall cases,
theswitch must be mounted to a groundedmetal surface. When thepin switch is activated, (hood open),
itwill supply aground to theinput wire activatingthe alarm. Inaddition, the hoodswitch is requiredfor the
safety shut down of the remote start unit. If the vehicle is being worked on, this hood switch prevents the
remote start activation even if the RF command to start is issued. This switch must be installed in all
applications. Failure to do so may result in personal injury or property damage.
THE PUSH-BUTTON PROGRAM SWITCH/LED/RECEIVER/ANTENNA: PART # 1181230
The Superheterodyne ReceiverAntenna Assembly provided with this unit allows routing from below the
dashboardformaximum operatingrange. Choosea locationabovethe beltline (dashboard)of the vehicle
for best reception. Special considerations must be made for windshield glass as some newer vehicles
utilizea metallic shielded window glass thatwill inhibitor restrictRF reception.In thesevehicles, routethe
antenna toward a rear window location for best reception. Secure the antenna with double stick tape
provided. IMPORTANT!
DONOTPLUGTHESIXPINMAINPOWERHARNESSORTHEMULTIPININPUT/OUTPUTHARNESS
INTO THE CONTROL MODULE UNTILALL CONNECTIONS TO THE VEHICLE HAVE BEEN MADE.
AFTER SELECTING YOUR TARGET WIRES AS DEFINED BELOW, DISCONNECT THE NEGATIVE
BATTERYCABLEFROM THE VEHICLEBATTERYPRIORTOMAKINGANYCONNECTIONS.
NOTE: Do not remove the fuse holders from this wire harness. Fuses must be used and located
as close as possible to the power source for adequate protection of the vehicle.
WIRING THE 6 PIN MAIN POWER HARNESS: PART # 1123742
NOTE: Do not remove the fuse holders from this wire harness. Fuses must be used and located
as close as possible to the power source for adequate protection of the vehicle.
1 VIOLET Wire: Accessory Output
Connect this wire to theAccessory wire from the ignition switch. This wire will show + 12 Volts when the
ignition switch is turned to the "ACCESSORY" or "ON" and "RUN" positions, and will show 0 Volts when
the key is turned to the "OFF" and "START" or "CRANK" positions.
2 BLUE Wire: Ignition 1 Output
Connect this wire to the ignition 1 wire from the ignition switch. This wire will show +12 Volts when the
ignition key is turned to the "ON" or "RUN" and the "START" or CRANK" positions, and will have 0 Volts
when the key is turned to the "OFF" and "ACCESSORY" positions.
ForDieselApplications,this wiremust be connected to theignition circuitthat powersthe glowplugs ifthe
vehiclerequires glowplug pre-heating.(See selectablefeatureBank 3#11)

128-8857b
6 of 24
6
3 Fused RED WIRE: + 12 Volt Battery 2 Source
Locatethe vehiclebattery wire(s) atthe ignitionswitch. Verification:These wireswill register voltageinall
positionsofthe ignition switch.Connectthe Redwireto thevehicle'sbattery wire.Thiswire provides power
for the start relay and the accessory relay.
4 Fused RED/WHITE WIRE: + 12 Volt Battery 1 Source
Locatethe vehiclebattery wire(s) atthe ignitionswitch. Verification:These wireswill register voltageinall
positions of the ignition switch. Connect the Red w/White wire to the vehicle's battery wire. This wire
provides power for the control circuit as well as the ignition 1 and ignition 2 relays.
5 YELLOW Wire: Starter Output
Careful consideration for the connection of this wire must be made to prevent the vehicle from
starting while in gear. Understanding the difference between a mechanical and an electrical
Neutral Start Switch will allow you to properly identify the circuit and select the correct installa-
tion method. In addition you will realize why the connection of the safety wire is required for all
mechanical switch configurations.
Failureto make this connection properly can resultin personal injury and property damage.
Inall installationsit is theresponsibility of theinstalling technicianto test theremote start unitand ensure
that the vehicle cannot start via RF control in any gear selection other than park or neutral.
Inboth mechanicaland electricalneutral startswitchconfigurations, theconnection of theYellowwirewill
bemade to thelow current startsolenoid wire of the ignition switchharness.This wire willhave +12 Volts
when the ignition switch is turned to the start (crank) position only. This wire will have 0 Volts in all other
ignition switch positions.
NOTE: This wire must be connected to the vehicle side of the starter cut relay (when used). For the
electrical neutral switch configuration, this connection must be made between the starter inhibit
relay, ( when used ) and the neutral safety switch as shown in the following diagram.
Failure to connect this wire to the ignition switch side of the of the neutral safety switch can result
in personal injury and property damage.
SEENEUTRALSTARTSAFETYTESTFORFURTHERDETAILS.
YELLOWSTART WIRE DETAIL
6 GREEN Wire: Ignition 2 Output
Connect this wire to the ignition 2 wire from the ignition switch. This wire will show + 12 Volts when the
ignition key is turned to the "ON" or "RUN" position and is some cases the "START" or CRANK" position.
This wire will show 0 Volts when the key is turned to the "OFF" and "ACCESSORY" positions.
NOTE: Seeprogramminginformation (Bank3Selection #2)concerningthis wireto allow outputduring the
"START" mode.

128-8857b
7 of 24
7
WIRING CONNECTIONS: 12 Pin Accessory Input/Output Harness PART # 1123751
1 Yellow/Black Wire: + 12 VoltAlarm By - Pass Output
NOTE: You must disconnect the ignition input of the alarm from any other wire that is presently
connected to the vehicle.
Thiswireprovidesa+12 Voltoutputwhentheignitionkeyisturnedtothe“ON”position,and0Voltswhen
the ignition key is “OFF” or when the vehicle is running under the control of the remote starter.
This wire should be connected to the ignition input of the alarm system.
Thisoutputwillallowyoutoremotestartthevehiclewhileleavingthealarmarmed,andtolock/unlockthe
doorswhile runningunder controlof theremote startunit.
2Green w/ Orange Wire: Tachometer Input Signal
This wire will continually monitor the engine's tach rate while the unit is under power of the Remote Start
module. This wire will be routed to the vehicle ECM tach input or through the firewall into the engine
compartment and connect to the negative side of the ignition coil.This Remote Start unit learns the tach
rate of the vehicle and in most cases will operate properly from one multi coil pack regardless of the
number of cylinders. If the vehicle has a single coil unit for each cylinder, it may be necessary to connect
thiswire tomore thanone cylinderfor propertach reference.See theMulti CoilPackAdaptor wiringdetail
shownlater inthis manual foradditional information.
NOTE:ForHybridmodeselection,Bank3featureselection5,thisconnectionisnotrequired,theunitwill
start the vehicle and run the allotted time based on feature selection and crank duration.
3 Black Wire: Chassis Ground Source
Connectthe Black wireto a knownvehicle ground sourceor to asolid clean metal part of the chassis. Be
certain to remove any paint or grease and secure this wire with a self tapping screw and ring terminal.
4 Gray w/ Black Wire: Negative Inhibit Input 2
Anytimethegrayw/blacktracerwireisgrounded,theRemoteStarterwillstopoperating,evenifthesignal
isreceivedfromthetransmitter.
Ifthebrakelightswitchinthevehicleswitchesgroundtothebrakelightcircuit,connecttheGrayw/Black
tracewiretotheoutputofthebrakelightswitch.Ifthebrakelightswitchinthevehicleswitches+12Volts,
do not use the Gray w/ Black wire; see Brown w/ Black tracer wire.
5 Light Blue Wire: Ignition 3 / Ground While Running Output
Thiswire provides a 300 mAground output that becomes active 3 seconds before the Remote StartUnit
initializes,and remains groundedwhile running plus an additional 2 secondsafter theRemote Start Igni-
tion1 turns off.In allof the applicationsdescribed below, arelay will be required.The Light Bluewire can
be used to accommodate the following situations:
A. Shock Sensor By Pass:
If there is Shock Sensor used with an alarm system and it is not shunted during the Remote Start
activation period, then vibration from the running vehicle can cause the alarm to trigger. In this case,
connect the Light Blue Wire to terminal #86 of a external relay. Connect terminal #85 of the relay to a
fused + 12 Volt battery source. Cut the shock sensor trigger wire and connect one end of the cut wire
toterminal #30 and theother end of thecut wire to terminal#87a. Just before theRemote Startunit is
activated,the relay contacts will open,preventing the shocksensor's operation untilthe Remote Start
unit shuts off.

128-8857b
8 of 24
8
B. Ignition 3 Output:
Some newer vehicles use a third ignition wire, which is required to start and keep the vehicle's engine
running. If this is the case, connect the Light Blue wire to terminal #86 of an external relay. Connect
terminal#30 &#85 toa fused+ 12Volt battery sourcerated fora minimumof 25Amp. Connect terminal
#87 to the third ignition wire in the vehicle.
C. GM VATS Key Override:
If the vehicle has the General Motors VATS system installed, you will need to bypass the system while
the vehicle is operating under the control of the Remote Start Unit.To do this:
1. Measure the resistance of the resistor pellet on the ignition key then select a resistor within 5% of the
key'svalue from the resistorpack supplied.
2. Locatethe pairof VATSwires inthe vehicle, usuallya pairof thingauge wiresrunning from theignition
switch to the VATS control module.
NOTE: These wires are typically White w/ Black trace and Violet w/Yellow trace, however in later model
Cadillacs, they are run through an orange sleeve, and are either both Black, both Yellow, or both
Whitewires. Consultthe factory servicemanual for additional information.
3. Connect the Light Blue Wire from the Remote Start Unit to terminal #86 of an external relay. Connect
terminal #85 of the relay to a fused + 12 Volt battery source.
4. Cut (#1) wire (as shown), and connect the ignition switch side of the cut wire to terminal #87a of the
relay. Connect the other side of the (#1) wire to terminal #30.
5.Connect the previously selectedresistor from terminal #87 to the second (#2) wire(as shown).
NOTE: Theabove information is for the GM VATS system only.
6 Green/Yellow Wire: Diesel Wait To Start Input
TheGreen/Yellow wire ofthe 12pin connectorwill connectto adiesel vehicle'sglow plugwire. When the
unitreceivesastartcommand,thiswiremustgoto+12thentogroundtoallowthecranksequencetobegin.
Whenignition#1isactivatedbytheremotestartunit,theglowplugcircuitgetsenergized,(+12Volts),when
theglowplugcircuitofthevehicledropsthe+12Volts,whicheffectivelygroundsthewaittostartinput,then
500mSlaterthestarterwillengage.ThiswirecanalsobeconnectedtotheGlowPlugBulbwireinthevehicle
if this bulb wire gets + 12 Volts when the ignition comes on and drops low when the glow plug circuits
temperatureisreached.Besuretofusethewirewitha1AmpFusewhenconnectingtoahighcurrentcircuit
suchasafactoryglowplugwire.Thefuseshouldbeinstalledasclosetothehighcurrentwireaspossible.
If you are installing this unit in a Gasoline vehicle, this wire is not used.
7 Gray Wire: Negative Inhibit Input 1
ConnecttheGRAYwiretothepreviouslymountedhoodpinswitchprovided.Thiswirewillberoutedthrough
the firewall into the engine compartment. It is necessary to use an existing grommet when passing wires
throughthefirewalltopreventshortcircuiting.ThisisanimportantsafetyfeatureoftheSystem,failuretouse
this feature can result in serious injury. Route the wire to the pin switch and connect it using the bullet
connectorprovided.

128-8857b
9 of 24
9
8 Brown Wire: Positive Inhibit Input 1
Anytime+ 12 Voltsisapplied totheBrown wire,theRemote Starter willstopoperating, evenifthe signalis
receivedfromthetransmitter.
Ifthevehiclehasafactoryinstalledhoodpinswitchandthatswitchprovides+12Voltstoanunderhoodlight,
the Brown wire can be connected to the existing pin switch.
9 Brown w/ Black Wire: Positive Inhibit Input Plus Trigger When Armed
TheBrownw/ BlackTracewireprovides aninstantshutdownforthe Remote StartControl modulewhenever
it gets + 12 Volts also triggers the alarm when armed. If the Brake lights switch in the vehicle switches + 12
Volts to the brake light circuit, connect the Brown w/ Black trace wire to the output side of the brake switch.
This will allow the Remote Start to shut down if an attempt is made to operate the vehicle without the key
while running under the control of the Remote Start. In most vehicles, in order to shift into gear, the brake
pedal must be depressed. The brake input will in turn cause the remote start unit to shut off.
10 No Connection
11 White Wire: Parking Light Flasher Output
This wire is the normally open contact of the on board parking light flash relay. Connect this wire to the
vehicle's parking light feed wire. This is the wire that gets switched on, either (+) or (-), when the vehicle's
parking light switch is activated.
12 White Wire: Parking Light Flasher Input
Thiswire is the common contactof theon board parking lightflasher relay.Ifthe vehicle youare workingon
has +12 Volt switched parking lights, connect this wire to a fused + 12 Volt source. (Max. 15Amps)
NOTE: Ifthe vehicle's parkinglights are ground switched,connect this wireto chassis ground.

128-8857b
10 of 24
10
WIRING THE 4 PIN AUXILIARY OUTPUT HARNESS Part#1122585
Theauxiliary 4 pinconnector provides low current outputs to controlvarious functions inthe vehicle during
differentstages ofthe RemoteStartunit'soperation. Understandingtheseoutputsand thetime inwhichthey
occur will allow you to determine if they are needed for the particular vehicle you are working on as well as
how to use them.
1 Black w Blue Trace Wire: Pulsed Ground Output Before Start
TheBlack w/ BlueTrace wire willprovide a 1second 300 mApulsed ground output1.5 seconds before the
remotestartunit activatesas well as when the transmitter is used to disarmthe system.Typical usefor this
output would be to disarm a factory theft deterrent system to prevent false triggering of the factory alarm
when the remote start unit engages or when the system is used to unlock the doors. This will also activate
when the transmitter is used to disarm/unlock the system
NOTE: Thisoutput can be selected tooperate like thedoor lock outputas set inalarm feature setting #1 by
selecting feature #17 in Bank 3 for 2 Chirps.
2 Black w/ Light Green Trace Wire: Pulsed Ground OutputAfter Start
TheBlackw/ LightGreen Trace wirewill providea1 second300mA pulsedgroundoutput afterthevehicle is
startedunder control of theremote startunit.Typicallythiswire willbe used tore-lock thevehicle doorsif the
doorsunlock automaticallywhen the factoryanti-theft systemis disarmed. Thiswire willalso activate when
the transmitter is used to arm/lock the system.
3 Black w/ Red Trace Wire: Pulsed Ground OutputAfter Shutdown
TheBlackw/ RedTrace wirewillprovide a1 second300 mA pulsedground outputafter the remotestart unit
shuts down. This output will occur regardless of whether the circuit times out or is manually terminated.
Typically this output will be used to re-lock the vehicle doors if the doors unlock automatically when the
ignition circuit transitions to off.
4 Black w/ Yellow Trace Wire: Ground Output During Start (Crank)
The Black w/ Yellow Trace wire will provide a 300 mAground output while the starter output of the remote
start unit is active. This output can be used to activate the Crank Low/Bulb Test wire found in some GM
vehicles. This wire is also referred to as the ECM wake up wire in some vehicles.
NOTE: Theoutputs aboveare lowcurrent outputsand mustbe usedwith a relay if thecircuit's requirement
is more than 300 mA.
6 Wire Antenna/Receiver Program Push-Button Switch/LED Connector: Part # 1123908
Plugthepreviously routed antennaconnectorfrom theantennareceiver assembleintothe matingconnector
ofthe controlmodule.Thisconnector supplies12 Volts,ground andRF datainput,LED Cathode,and Valet
Enable to and from the antenna receiver and the remote start module. Be certain these connectors are
firmly seated making good contact to the control unit.

128-8857b
11 of 24
11
2 Pin Transponder Control Output: (YellowConnector) Part # 1123292
a: When selected for while remote start on, the Black wire will be active at the same time ign. 3
becomes active, and will remain active all the time the unit is operational under the control of the
remote start.
b: When selected for output during the start sequence, the Black wire will be active at the same time
Ign. 3 becomes active, and will remain active until the vehicle has started. This will be used for one
time read transponder circuits.
c: When the unit is selected for until ignition off, the Black wire will become active at the same time
ign. 3 becomes active and will remain active even after the key take over and until the ignition in the
vehicle is turned off. This will allow the unit to be used for continuous read transponders circuits.
1 Black: 250mA Output (-)
The black wire switches on when the remote start is activated and will stay on as programmed in the
remotestart feature Bank3 Feature 12.
2 Red: 250mA Output (+) 12 Volts Constant
Thisoutput is intendedto allow thecontrol of atransponder bypass interfacemodule or transponder
bypass relay.
Monitoring The Vehicle's Engine: (ProgramFeature #5Bank 3)
There are 4 ways that the remote start monitors the engine running, one or the other must be selected for
your application for the remote start to operate correctly.
1)VOLTAGE SENSE SETTING:
The unit will monitor the voltage level of the battery during remote start, wait for the voltage to drop while
cranking,then look forthe voltagelevel togo abovethe level itwas beforethe vehiclebegan tocrank which
indicates the vehicle is running. Feature #14 of Bank 3 must be set for preset time or the voltage sense
feature will not operate indicated by the parking lights flashing 7 times.
2)TACHRATE SETTING:
1. Turn the ignition key to the On position.
2. Press and release the valet/program push button switch 3 times.
3. Immediately turn the ignition key Off.
4. Press and hold the valet/program push button switch, then start the vehicle using the key.
5. When the unit senses the tach signal, the parking lights will begin to flash.
6.Releasethe valet/programpushbutton switch. Theparking lightswill turn onfor threesecondsto indicate
that the learned tach signal is stored and the unit is out of the tach learn mode.
NOTE: If the unit fails to learn tach rate due to an improper tachometer connection or a poor tach source,
the parking lights will not flash.To correct this situation, locate and connect the Green/Orange wire
to the proper tach signal, and then repeat the tach learn routine.

128-8857b
12 of 24
12
3) DBI TACH SETTING:
Selectingthis setting inthe option menuindicates that youhave a DBImodule and havedetermined that a
tach signal is available for the vehicle you are connecting to. The unit will look at the DBI data port for the
tachsignal. Ifthe vehiclefails to start, or the unit flashes 7 times, recheck theDBI manualto insurethat tach
isavailable for yourvehicle. If notthe tach connectionwire, Green/Orange mustbe used.
4)HYBRIDSETTING:
Selectingthis setting inthe option menu allows for Hybrid vehicles.Alsofeature #14of Bank 3 mustbe set
for preset time or the Hybrid feature will not operate indicated by the parking lights flashing 7 times.
CRANKAVERAGING:
When Feature 14 Bank 3 is set for crank averaging, the remote start unit constantly monitors and learns
the cranking patterns of the vehicle each time the car is started with the key. The vehicle must be started
atleast 4 times with the key for the crank averaging circuit to begin it's monitoring the vehicle's engine.
DIAGNOSTICS:
Enter Bank 3 and turn on selectable feature # 9 as described on the front pages of this manual.
NOTE: Diagnosticmode isa temporary mode.Once you haveaccessed thediagnostic mode, theunit will
pause for two seconds then begin to flash the last stored shut down code. This code will be
displayed three times in succession, then the unit will automatically exit the diagnostic on mode.
Theparking lightswill flash anumber of times indicating thereason for thelast remotestart shutdown. The
light flash indications are as follows:
1 Flash Run timer expired
2 Flashes Low or no tach signal (RPM)
3 Flashes Positive inhibit wire activation
4 Flashes NA
5 Flashes RF shutdown, Remote signal received, or manual start trigger wire reactivated.
6 Flashes High tach signal (RPM)
7 Flashes Tach signal has not been learned
8 Flashes Negative inhibit wire
Multi Coil PackAdaptor: (Optional)
The multi coil pack adapter, is designed for use with vehicles that do not respond to single coil tach
programming. Althoughthe tachresolution of thiscircuit is designedto interface directwith most vehicles,
there may be an occasion where the following circuit may be required. Construct the adaptor as shown
below.
To use the adaptor, the Green/Black wires must connect to the negative side of the ignition coil(s).
1. For vehicles utilizing independent coils per cylinder, connect the three Green/Black leads to alternate
coils.To achieveoptimum performance the coil signalsmust beevenly distributed.Thisis accomplished
by first mapping out the firing order of the engine in groups of as indicated below. Draw a circle around
any of the columns. The Green/Black wires should be connected to the negative (-) terminal of the
respectivecylinder number whichappears in any ofthe circles.
2. For vehicles utilizing 2 cylinder firing per coil pack, connect Green/Black to the tach side of each coil
pack. For 8 cylinder, four coil systems, connect to any of the three coils.
3. Connect the Yellow wire to a +12 Volt ignition 1 source.This wire will have +12 Volts with the ignition in
the on and start position and have 0 Volts with the ignition in the off position.
4. Connectthe Green wire to the (Green) or(Orange/Green) tachinput of theAudiovoxremote start unit.

128-8857b
13 of 24
13
TESTINGYOURINSTALLATION:
WARNING!! Thefollowingprocedure must beperformed aftertheinstallationofanyRemote StartDevice.It
is the responsibility of the installing technician to complete these tests. Failure to test the unit
in the following manner may result in personal injury, property damage, or both.
HOOD PIN SAFETY SHUT DOWN:
Theintent of thehood pin safety shutdown is toprevent the Remote Start unit frombeing activated while a
mechanicor vehicle owneris performingnormal routinevehicle maintenance.
To test the integrity of this circuit:
1. With the drivers window in the down position, start the vehicle using the RF transmitter.
2. Reach inside the car and pull the hood release.
3. Raise the hood and confirm that the remote start unit shuts down.
Ifthe unit failsthis test, recheckyour pin switchconnection to theGray/Black wire ofthe Remote StartUnit.
DONOT RELEASE THISVEHICLE TO THECONSUMER UNTIL YOUCONFIRM THE
OPERATION OF THE HOOD PIN SAFETY SHUT DOWN FEATURE.
REMOTESTARTOVERRIDEMODE / MANUALSHUT DOWN:
Theintent of the remote start override / manual shutdown circuit is to allow the vehicle operator toprevent
operationof the RemoteStartUnit regardless ofthe RF transmitter operation.
To Enter The Remote Start Override Mode:
1. With the system disarmed/unlocked, and the ignition switch off Press and Hold the pushbutton switch
located on the receiver unit on.
2. Turn the ignition switch on, off, on, off, on, off.
3. The LED begins to flash two short flashes followed by one long flashes and continues this pattern until
returned to normal mode of operation.
Theaction above putsthe unit into theRemote Start Overridemode or vehicleservice mode andwill not
start from the RF transmitter or any other input.

128-8857b
14 of 24
14
To Exit Remote Start Override Mode:
1. With the system disarmed, Press and Hold the PBLED on.
2. Turn the ignition switch on, off, on, off, on, off.
3. The LED turns off indicating that the R/S unit is fully functional one again.
DONOT RELEASE THISVEHICLE TO THECONSUMER UNTIL YOUCONFIRM THE
OPERATIONOF THE MANUALSHUT DOWN / ENABLE FEATURE.
NEUTRALSTARTSAFETYTEST:
Theintent of the neutral startswitch is to prevent thevehicle from starting while thegear selector is in any
positionother than Park, or Neutral.When installinga Remote StartDevice, it is imperative thattheYellow
Starter wire be connected to the ignition switch side of the Neutral Start Switch. Consideration for the
placementof a starterinhibit relay is importantas well andshould be connected tothe ignition switchside
of the Yellow Start Wire.
To test the integrity of the Neutral Start Safety Circuit:
1. Set the vehicle parking brake.
2.Block thedrive wheelsto preventvehicle movement.
3. Temporarily disconnect the Brown/Black positive shut down wire from the vehicle's brake switch.
4. Sitting in the vehicle, start the engine using the vehicle's ignition key.
5. Step on the brake pedal and shift the gear selector into reverse.
6. Allowthe transmissionto shift.Whenyoufeel theengine pull,do notmove thegear selectorjust turnthe
ignition switch off. DO NOTattempt to remove the key.
7. Keeping the brake pedal depressed, activate the RF transmitter in an attempt to start the vehicle. The
car should not start.
8. Repeat the above test this time move the gear selector to the drive position.
If the unit attempts to start, failing this test, recheck your Yellow Wire's connection. This wire must be
connected to the ignition switch side of the Neutral Start Switch. If the vehicle you are working on does
not have an Electrical Neutral Safety Switch, it will be necessary to reconfigure the Remote Starts Wiring
toaccommodate thevehicle. Theinformation concerningthe Mechanical Neutral Safety Switchprovided
below will help you to determine if the vehicle you are working on has this type of safety switch and will
providealternate wiring methods to accommodatethis situation.

128-8857b
15 of 24
15
CAUTION! REMEMBERTORECONNECTTHEBROWN/BLACKNEUTRALSAFETYWIRE
TEMPORARILYDISCONNECTED IN STEP3
MECHANICALNEUTRALSAFETYSWITCH CONSIDERATIONS:
Mechanicalneutralsafety switchconfigurationsdiffer slightlyinthat theydo not offerthe samelevelof safety
when installing a remote start device. Often when the ignition switch is turned off while the gear selector is
in any position other than park or neutral, the mechanical function will not allow the key to be turned to the
start position or be removed from the ignition cylinder. This configuration prevents mechanical operation
while the vehicle is in gear but offers no consideration for electrical operation. Because of this potential
problem,this installation requires the additional connectionof a safety wire from the remote start device to
the vehicle Park/Neutral ECM Input or the vehicle key in sensor. This connection will prevent remote start
operation if the key is left in the ignition switch regardless of the gear selectors position.
DO NOT RELEASE THIS VEHICLE TO THE CONSUMER UNTILYOU CONFIRM THE OPERATION OF
THEMECHANICALNEUTRALSAFETYSTART FEATURE.
KEYIN SENSOR CIRCUITS:
Ifthe vehicle youare working ondoes not have or you cannot locatethe ECM referencewire, there are
twoalternatives available.Althoughnotpreferred, the vehicle Key InSensor maybe reconfiguredto allow
amargin of safety and will prevent the vehicle with a MechanicalNeutral StartSwitch fromstarting in gear.
AUDIOVOXADVISESTHATYOU MAINTAINTHEFACTORYCIRCUITWHENEVERPOSSIBLE.The
following two circuits may be used only if the above circuit is not available.
NOTE: When completing an installation using either of the following key in sensor circuits, if the operator
inserts the ignition key while the vehicle is running under the control of the Remote Start, the
vehicle will shut down. This must be explained to the operator as it is in contrast to the normal
operation of a vehicle utilizing an electrical neutral start switch and is inconsistent with the
operator's manual.
Additionalinformation concerning KeyIn Sensor methods1 & 2are listed belowand should be reviewed
beforeconsideringeitheralternative.
Method1 will allowthe safety required for the remote startunit and preventthe vehicle fromstarting while
in any gear other than Park or Neutral while the key is in the ignition cylinder however, if the key is left in
the ignition switch and the door is left opened, the added relay will be energized causing a 150mA drain
on the battery.
Method2 will allowthe safety required for the remote startunit and preventthe vehicle fromstarting while
in any gear other than Park or Neutral while the key is in the ignition cylinder however, the original factory
key in chime module will not alert the owner that the key has been left in the ignition switch. In addition,
this may also effect other warning tones such as the light on reminder.
Thesesituations should be carefully consideredbefore altering thevehicle's wiring and must befully
explainedto the consumer.

128-8857b
16 of 24
16
METHOD 1
To connect to the key in sensor as shown in method 1:
1. Locate the control wire that connects the drivers door pin switch to the key in sensor switch.
2. Cut this wire and connect the ignition cylinder side to chassis ground.
3. Locate the key in sensor switch wire that connects the chime module to the ignition cylinder .
4.Cut thiswire andconnect the ignition cylinder sideto terminal30 ofa P&B VF45F11or equivalentrelay.
5. Connect the cathode (striped) side of a 4002 series diode to this same wire, and connect the (non
striped) side to the negative shut down safety wire (Gray / Black) of theAudiovox Remote Start Unit.
6. Connect terminal 86 of the relay to a fused +12 volt constant battery source.
7. Connect terminal 87 of the relay to the Chime Module side of the previously cut wire in step D.
8.Connect terminal 85 of the relay tothe Drivers Door sideof the pin switch wire previously cutin step B.
NOTE:Asecond 4002 seriesdiode maybe required tomaintainthe integrityof thehood open, shutdown
circuit. If this is the case, it must be installed as shown in the diagram above. The anode (Non
Striped) side must be connected to the Gray/Black wire of the Remote Start Unit. The cathode
(Striped) side must be connected to the hood pin switch. If the hood pin switch is also used for an
alarm trigger input, be certain to use the dual diode set up shown earlier in this manual.

128-8857b
17 of 24
17
METHOD 2:
To connect to the key in sensor circuit as shown for method 2:
1. Locate the control wire that connects the drivers door pin switch to the key in sensor switch.
2. Cut this wire and connect the ignition cylinder side to chassis ground.
3. Locate the key in sensor switch wire that connects the chime module to the ignition cylinder .
4. Cut this wire and connect the ignition cylinder side to the Remote Start Negative Safety Shut down
Wire Gray/Black, using a 4002 series diode as shown above.
NOTE:Asecond 4002 series diode may be required to maintain the integrity of the hood open, shut
down circuit. If this is the case, it must be installed as shown in the diagram above. The anode (Non
Striped) side must be connected to the Gray/Black wire of the Remote Start Unit.The cathode (Striped)
side must be connected to the hood pin switch.If the hood pin switch is also used for an alarm trigger
input, be certain to use the dual diode set up shown earlier in this manual.
AFTERTHE CONNECTION OFTHE NEUTRALSTART SAFETYWIREAS
INDICATED INANYOFTHE PREVIOUSALTERNATE CONFIGURATIONS,THISCIRCUIT
MUST BE TESTED FORPROPER OPERATION.
Retest by following the steps outlined in the NEUTRALSTART SAFETYTEST section of the manual.

128-8857b
18 of 24
18
COMPLETINGTHE INSTALLATION
1. Mount the control module up and behind the dash securing it in place with cable ties or screws. Be
certain that the chosen mounting location will not inhibit any of the controls of the vehicle.
2. Securely harness and tie all wiring up and away from all hot and moving parts that they may come in
contact with under the dash board or in the engine compartment areas.
CAUTION: Particularly avoid the area around the steering shaft and column, as wires can wrap around
thesemechanisms and impairthe safe operationof the vehicle.
3. Applythe Caution Labelssupplied with thiskit to a conspicuous area in theengine compartment.Make
sureto clean thesurface before affixingthe label.
4. Check the vehicle's wipers, lights, horn, etc.... to insure proper operation.
5. Replace all panels that were removed during installation, and retest the system.
6. Explain all activated features and safety systems associated with the Remote Start Unit installed.Also
point out the location of the Push-Button LED Override/Valet switch to the customer and explain its
operation.

128-8857b
19 of 24
19
INSTALLATIONNOTES

128-8857b
20 of 24
20
The transmitters are pre-programmed from the factory, If you find you need to program new or additional
transmittersfollow the instructionsbelow.
PROGRAMMINGBANK1(TRANSMITTERS):
1. Turn the ignition key to the on position.
2.Press and releasethe valet/programming switch 3times (Siren Chirps).
3. Press the Button of each transmitter you want programmed until you hear the parking light relay click.
4.Turn the ignition switch off.
Theabove action programs theStart/Unlockbuttons ofthe system.
PROGRAMMINGBANK 2 (ALARM FEATURES):
You can enter bank 2 from bank 1 by turning the ignition key off then on from step 4 of Bank 1.
(Siren Short then Long Chirp), or You can also go right to bank 2 by:
1. Turn the ignition key to the on position.
2.Press and releasethe valet/programming switch 3times (Siren Chirps).
3.Turn the ignitionkey off thenon. (Siren ShortThen long Chirp)
4.Press the pushbutton switch once to advanceto feature 1, twiceto advance to feature 2, etc, thenuse the
lock button of the transmitter to select the feature setting.
Example to set door lock output to double lock & unlock pulse:
1. Turn the ignition key to the on position.
2.Press and releasethe valet/programming switch 3times (Siren Chirps).
3.Turn the ignitionkey off thenon. (Siren ShortThen long Chirp)
4. Press the pushbutton switch once to advance to features 1, Door Lock/Unlcok Timing, then use the lock
button of the transmitter to select five chirps "Dbl L, DBL U/L".
5. To exit the programming mode, turn the ignition key off.The program mode is automatically exited when
there is no activity on the pushbutton switch or the transmitter lock button.
