Congratulations on your purchase of the PRO 9232a automotive Keyless Entry
Upgrade Alarm System. This system is a state - of - the - art auto security system
that is designed to automatically arm and disarm when it receives a command from
your existing Factory Keyless Entry Transmitter. Taking a few moments to read this
manual will help to ensure that your vehicle is protected at all times.
NOTE:
Thesystemhastheabilitytobeepthevehicle'shorn,soundasiren,orboth. Where
a beep or chirp is mentioned, consider either or both may sound.
ARMINGTHESYSTEM:(ACTIVE)
1. Turn the ignition key off, exit the vehicle, and close all doors.
2. Press and release the Lock button on the keychain transmitter.
3. The siren and or horn will beep one time, the parking lamps will flash one time,
and the red dash mounted LED will begin to slowly flash, indicating that the
system is ARMED.
If the siren/horn sounds 3 chirps, then you have left a door, trunk, or hood lid ajar.
Simply close the opened entry point to provide full protection. If the siren "chirped"
three times, sometime after arming, the exclusive delayed dome light learn circuit
has been programmed and the system detected a open entry point after the
learned delay expired. Again, closing the hood, trunk, or doors will correct the
problem and you do not need to disarm the system to make the correction. If the
siren/horn did not sound when arming, then the chirps have been turned off, and
youshouldrefertothesectiontitled“ELIMINATINGTHEARM/DISARMCHIRPS“
in this manual.
4. Any time the door lock switch in the vehicle is used to lock the doors while
theignition key is turned off, the system will immediatelyarm. Tolock the doors
after entering the vehicle, make sure the ignition key is switched on first.
Turning the ignition key on first will stop the system from arming.
ARMING THE SYSTEM : ( PASSIVE )
1. Turntheignition keyoff,exitthevehicle, andclosealldoors.
2. The dash mounted LED will begin to flash rapidly, indicating that the system
Model PRO 9232a
OWNER’S MANUAL
KEYLESS ENTRY ALARM UPGRADE MODULE

128-6626
2 of 8
isautomatically ( passively ) arming. As an added convenience, the 30 second
automatic passive arming will not begin until all doors are closed, allowing passen-
gersto exit the vehicle at their convenience.
3. In30 seconds, you willheara single short chip from thesiren, and the vehicle’s
parking lamps will flash one time, indicating that the system has ARMED. At this
time, the red dash mounted LED will begin to flash slowly, providing a visual
indication that the system is fully armed.
4. It is possible to program the system, that when the alarm is allowed to
automatically passive arm, there will be a 15 second delay after a door is opened
before thealarm will sound. However, if the system is programmed for instant
triggertherewillbe nodelay. Checkwith yourinstallerfor thesettingof thisfeature.
IMPORTANT! When the system is programmed for passive arming, the sys-
tem will always arm, even when the keychain transmitter has not
been used to lock the doors.
When you leave the vehicle, and a door has been left opened, the system will
armafter 10 minutes. If you plan to vacuum the car, or if service work isbeing
performed,eitherleavethekeyintheignitionandswitchedtotheonposition,
or put the system into valet mode. If you do not do this, the system will arm in
10minutes,and you willprobably inadvertently trip thealarm.
PROTECTION WHILE THE SYSTEM IS ARMED :
1. Openinganydoor,hood,ortrunkwillcausethealarmtoimmediatelysound.The
alarmwillcontinuetosoundfor30seconds,thenstopandautomaticallyre-arm
thevehicle.Ifthepotentialthiefleftadooropened,thealarmwillsoundforfivemore
30 second cycles, then re - arm and ignore the opened door zone.
2. Whenever the system is armed, the red dash mounted LED indicator will
slowlyflash. This serves as a visual deterrent to the potential thief. The LED
isaverylowcurrentbulb,andwill not cause the vehicle’s battery to drain, even
when the vehicle is left unattended for extended periods.
3. Whenever the system is triggered, the vehicle’s parking lights will flash for the
30second alarm cycle, attracting added visual attention to the vehicle.
4. Whenever the system is armed, the vehicle’s starter will be disabled. The
vehicle will not start.
DISARMING THE SYSTEM :
1. Asyouapproachthevehicle,pressandreleasetheunlockbuttononthekeychain
transmitter.
2. The siren and or horn will beep two times, the parking lamps will flash two
times,and the red dash mounted LED will turn off, indicating that the
system is DISARMED. If the optional entry illumination feature has been
Page2

128-6626
3 of 8
installed, the vehicle’s interior lights will turn on for 30 seconds, or until the
ignition key is turned on.
NOTE: If yoursystemhasbeenprogrammedfor“passive arming “, then it will
begin to re-arm immediately after disarming. This is indicated by a
rapid flashing of the red dash mounted LED Opening one of the
vehicle’sdoorswillsuspendthepassivearmingprocessuntilalldoors
have been closed, or until the ignition key has been turned on.
INTRUSIONWARNINGSIGNALS :
Thesystemwillinformyouifanintrusionattempthasoccurredwhileyouwereaway
fromthevehicle.Ifanintrusionattempthasoccurred,thesirenandorhornwillbeep
four times when the system is disarmed. The vehicle’s parking lights will also flash
threetimes to indicate an intrusion has occurred.
Enter the vehicle and observe the dash mounted LED for further information.
1. If the LED is flashing one time...pause...one time...pause...etc., then an
intrusion attempt was made to a voltage sensing, light activated entry point, or
to an optional sensor that has been connected to zone 1.
2. If the LED is flashing two times...pause...two times...pause...etc., then an
intrusion attempt was made to the hood or trunk, or to an optional sensor that
has been connected to zone 2.
3. If the LED is flashing three times...pause...three times...pause...etc., then an
intrusion attempt was made through one of the vehicle’s doors.
These intrusion warning indicators are stored in the system’s memory, and will
only be erased when the ignition key is turned to the “ on “ position.
OPERATINGTHEEMERGENCYPANIC:
The buttons on your keychain transmitter will allow you to immediately activate the
alarm in emergency situations. To use the remote panic switch;
1. Presstheunlock,thenlock,thenunlockbuttonsonyourkeychaintransmitterwithin
3seconds. Thealarmwillimmediatelysound,andcontinuetosoundfor30seconds.
2. Tostop thealarmbefore the30second cyclehasexpired, simplypressand
releasetheunlockbuttononyourkeychaintransmitter.
USING THE VALET SWITCH :
Thevalet switchallows you totemporarily bypass allalarm functions, eliminatingthe
needto hand yourtransmitter to parkingattendants or garagemechanics. When the
systemis invalet mode, allalarm functions arebypassed, howevertheremote panic
feature and remote door locks will remain operational. To use the valet mode, the
system must first be disarmed either by using your keychain transmitter, or
by activating your personalized manual override code.
Page3

128-6626
4 of 8
TOENTERTHEVALETMODE:
1. Disarmtheunitbyuseofthefactorytransmitterorbyuseofthemanualoverride
sequence.
2. Turn the ignition switch to the “On” position.
3. Press and hold the valet/override pushbutton switch for 5 seconds. The LED
turnson,indicatingvaletmodehasbeen successfullyentered.
TO EXIT VALET:
With the ignition switch in the on position, press and release the valet/override
pushbutton switch one time. The LED turns off indicating the valet mode has
successfullybeenexited.
MANUALOVERRIDEOPERATION:
If your factory transmitter is lost, broken, or otherwise rendered inoperable, your
system can be overridden allowing operation of the vehicle. The manual override
code is pre-programmed at the factory to 11. This code can be changed by the
operatorto a more familiar two digit number. Once you’vebecomefamiliar with the
system’s operation and override procedure, we suggest you change the code for
addedsecurity.
NOTE: The override procedure below describes use, assuming that the factory
pre-set code has not been changed and is still setto thefactorydefault11.
Thevalet/override push button switch is used toenter the tenths and units
digits, pressing and releasing this button one time for each digitrequired.
To manually override your system, with a code of 11, follow the sequence listed
below:
1. The LED is flashing indicating unit is armed, enter the vehicle, the siren will
sound, turn the ignition switch to the “on” position.
2. Within 10 seconds begin to enter tenths digit of override code. (In this ex-
ample the code is 11, so press and release the Valet/Override pushbutton
one time).
3. Within 10 seconds of entering the last tenths digit, turn ignition “off then on”.
4. Within 10 seconds of turning the ignition switch on, begin to enter units digit
of override code. (In this example the code is 11, so press and release
the Valet/Override pushbutton one time).
5. Within 5 seconds after the last units digit is entered, turn the ignition switch
off, then on, and start your vehicle.
If the manual override code is entered properly, the unit stops sounding, the LED
turns off, indicating a successful override. The system is now disarmed and you
can start and operate your vehicle. The unit will allow three attempts to disarm via
Page4

128-6626
5 of 8
the manual override sequence. If the code is not successfully entered within the
three attempts, disarming with the manual override switch will be locked for 10
minutes.
In many cases, to increase the security of your system, you may elect to change
the manual override code to a number that is more familiar to you, or simply to
have a different code than was pre-assigned from the factory. To Change the pre-
assigned override code follow the steps outlined below.
It is advised you read both sections under the headings “Programming Your
Custom Override Code” and, “Custom Code Programming Example”, To com-
pletely understand the procedure before beginning:
Programming Your Custom Override Code:
Unlike override switches easily found, and defeated, the PRO-9232 allows the
consumer to program a personal override code, offering a higher level of security.
Thesystem comes from the factory with a pre-programmed override codeof 11. To
changethis default overridecode, do thefollowing:
1. Disarmthesystem byuse of thetransmitter,or by useofthe emergency override
sequence. Turn the ignition switch to theonposition.
2. Within 10 seconds, press and release the valet/override switch, 3 times.
3. Within 10 seconds turn the ignition switch off, on, off, on, off, on.
(Thesiren or horn will beep and the lightswillflash one time.)
4. Within 10 seconds, begin to enter your chosen 10ths digit by pressing and
releasing the pushbutton switch from 1 up to 9 times.
5. Within10secondsofthelastentered 10thsdigit,turnthe ignitionswitchoffthen on.
6. Within 10 seconds, begin to enter your chosen units digit by pressing and
releasing the pushbutton switch from 1 up to 9 times.
7. Finish by turningthe ignition switch to theoff position.
If the new code was accepted, the unit will report back the newly entered code, by
flashing the LED, first indicating the 10ths digit, pause and then the units digit.
The unit will report the new code three times with a one second pause between
each code, then the system will begin arming. If the LED flash pattern re-
ports the previously stored code, the new code was not entered correctly. Please
repeat steps 1 through 7 above considering the following.
NOTE: Acceptable digits 10ths or units are 1 through 9. The unit will not recognize
a0 (Zero), or no digit entered in any place, units or tenths.
NOTE: If 15 seconds of inactivity expire, or if the ignition switch is turned off for
more then 5 seconds during any of the above steps, the unit will revert back
to the last successfully stored code.
Page5

128-6626
6 of 8
Custom Code Programming Example:
To Change the code from the factory pre-assigned code of 11 to “52” you would do
the following:
1. Disarm the system by use of the transmitter, or by use of the emergency
override sequence.
2. Turn the ignition switch to the on position.
3. Within 10 seconds, press and release the valet/override switch, 3 times.
4. Within 10 seconds turn the ignition switch off, on, off, on, off, on.
(Thesiren or horn will beep and the lightswillflash one time.)
5. Within 10 seconds, begin to press and release the push button switch to set the
tenthsdigit.
(As per the example, press and release 5 times to set the tenths digit to 5)
6. Within 10 secondsof the last press ofthepush-button, turn the ignition switchoff
thenon.
7. Within 10 seconds, begin to press and release the push button switch to set the
unitsdigit.
(As per the example, press and release 2 times to set the units digit to 2).
8. Turn the ignition switch totheoff position. ImmediatelyobservetheL.E.D. flash
pattern.
You will note the LED flashing five times, pause, and then flash two times, pause.
This pattern will be repeated three times indicating the new code (52) has been
accepted and storedin memory.
NOTE: If after step 7, the LED flashes a code other than what was just entered, this
indicates that the code has not been changed. You will have to repeat
steps 1 through 7 above being certain to note the following:
Acceptable digits 10ths or units are 1 through 9. The unit will not recog-
nize a 0 (Zero), or no digit entered in any place, units or tenths.
NOTE: If 15 seconds of inactivity expire, or if the ignition switch is turned off for
more then 5 seconds during any of the above steps, the unit will revert back
to the last successfully stored code.
ADDITIONALREMOTEFUNCTION:
This system allows the control of any one of the following optional accessories;
Remote Car Starter
Remote Window Closure
Remote Window Open
Page6

128-6626
7 of 8
To operate the optional accessory;
1. Pressthelock, thenunlock, thenlock buttonson yourkeychain transmitterwithin
3 seconds.
2. The optional accessory will immediately activate.
OPTIONALAUTOLOCK/UNLOCKFEATURE:
If your existing factory installed keyless entry system did not include the automatic
door lock and unlock feature, then this feature can be activated from the PRO 9232
upgrade module. When this accessory has been added, any time the ignition key
is turned to the on position
and all vehicle doors are closed, the doors will lock in
4seconds. Additionally,anytimetheignitionkeyisturnedtotheoffposition,thedoors
will unlock.
ELIMINATINGTHEARM/DISARMCHIRPS:
The normal arming and disarming confirmation chirps can easily be turned off using
the valet pushbutton switch. To do this;
1.Turntheignitionkeyon,andthenoff.
2. Within10secondsofturningtheignitionkeyoff,pressandreleasethe valet switch
3 times.
3. a. If,beforeproceedingwithstep1,thechirpswereon,thenyouwillhear2chirps
toindicatethatthe chirpshavebeenturned off.
b. If, beforeproceeding with step 1,the chirps wereoff, then you willhear 1 chirp
toindicatethatthe chirpshavebeenturned on.
4. Wheneverpowertothesystemhasbeendisconnected(forrepairorservicetothe
vehicle),thechirpswillbeactivatedwhenthepowerisre-connected.Toturnthe
chirpsoff, simply execute steps 1 through 3 above.
NOTE : Whenever the Arm/Disarm chirps are by-passed, the 3 chirp defective
zoneandthe4chirpintrusionindicatorwillalwaysoperate.Thisfeature
willalwayswarnyouifadoorwasleftajarwhenarming,orthevehiclewas
tampered with in your absence.
Page7

128-6626
8 of 8
PRO 9232a
SYSTEM FUNCTIONS AT A GLANCE
PASSIVE ARMING
ARMED
DISARMED
VALET MODE
INTRUSION ZONE 3
INTRUSION ZONE 2
INTRUSION ZONE 1
ARM
DISARM
ARM / DOOR OPEN
10 MIN. PASSIVE ARM / DOOR OPEN
DISARM / INTRUSION
DISARM / AFTER 10 MIN.
PASSIVE ARM
DISARM / AFTER 10 MIN.
PASSIVE ARM AND INTRUSION
ARM
DISARM
DISARM / INTRUSION
DASH L.E.D. INDICATORS
RAPID FLASHING ..........................................................
SLOW FLASHING ...........................................................................
OFF ...........................................................................................
ON - SOLID ............................................................................
3 FLASH ... PAUSE .....................................................
2 FLASH ... PAUSE .....................................................
1 FLASH ... PAUSE .....................................................
CHIRP INDICATORS
1 CHIRP * ............................................................................................
2 CHIRPS* .....................................................................................
3 CHIRPS ...................................................................
3 CHIRPS .......................................
4 CHIRPS .................................................................
2 SHORT CHIRPS - 1 LONG CHIRP.....................
4 SHORT CHIRPS - 1 LONG ................................
* These chirps are optional, and can be de-activated.
PARKING LAMPS
1 FLASH ..................................................................................................
2 FLASH .........................................................................................
3 FLASH ...................................................................
Your System Has These Features Activated:
StarterDisableWhenArmed
PassiveArming
InstantTrigger
RemoteCarStarter
RemoteWindowOpen
G
G
G
G
G
G
G
G
G
G
FormNo. 128-6626
©2003udiovoxElectroniccCorp. 150MarcusBlvd. Hauppauge,N.Y. 11788
RemoteWindowClosure
Key Activated Auto Lock/Unlock
ShockDetector
VehicleHorn
Hardwire
