Audiovox Pursuit Series User manual

128-6628
1 of 8
Model PRO 9246CH
Owner's Manual
Active/PassiveOperation
Remote Keyless Entry
CONGRATULATIONS! Your purchase of this state-of-the-art security system expresses a
deepconcernforthesecurityofyourvehicle,itscontents,andpassengers. Tofullyappreciate
the many functions and safeguards incorporated in this system, please spend a few minutes
reading this manual. You may find unexpected features that could mean the difference
between “protected” and “fully protected”
IMPORTANT ! In order to provide the highest possible level of security to your vehicle, this
system is equipped with selectable manual override circuitry. It is possible that you will need
to manually override your security system if the transmitter becomes lost, or inoperative due
to battery failure. Reading the sections on "MANUALLY OVERRIDING YOUR SYSTEM" is
necessary to fully understand the procedure required to enable your vehicle in such
situations. In addition, the chart on the last page of this manual has a section for the
particular features and options installed in your vehicle as well as the override method
selected. Valet Switch manual override is pre-selected from the factory, however, the
system can be configured for "Custom Code" operation. Confirm the override mode selected
on the last page of this manual, and familiarize yourself with the section on it's operation.
FEATURES :
w2 Three Button Programmable RF Transmitters (capable of accepting 4 transmitters)
wSeparate Lock/Unlock Transmitter Buttons
wFour Channel Receiver
wCode Hopping Technology
wSelectable Manual Override Mode
wUser Programmable Manual Override Code
wActive or Passive Arming Selectable
wProgrammable Auto Lock On / Off
wProgrammable Auto Unlock, Drivers, All, None
wProgrammable Door Lock Pulse Duration 1 Second / 3.5 Seconds / 1 Sec, Dbl. 1 Sec
wProgrammable Active or Passive Door Locks
wRF Inhibit with ignition on
wInterior Light Flasher (Arm/Disarm/Programming)
wRemote Trunk Release (must have electronic trunk release)
wLED Status Indicator Displays Arming, Armed, Disarmed & Valet
OPTIONS :
wParking Light Flasher (Relay Required) (Arm/Disarm/Programming)
wStarter Disable (Relay Required)
wHorn Output (Relay Required)
wMultipleVehicleCapable
wRemote Vehicle Starter
wRemote Power Window Roll Up
wRemote Garage Door Interface
Note: The "Arming" and "Disarming" references in this manual apply only to those vehicles
which have the optional starter inhibit relay installed, and take place when the vehicle
is locked and unlocked respectively.

128-6628
2 of 8
-2-
NOTE: Because this system has an optional horn annunciation circuit, where light flash is
mentioned, the horn may also beep a tone pattern synonymous with the flash pattern of the
lights.
Locking / Arming (Active)
1. Turn off the engine, exit the vehicle, and close all doors.
2. Press and release the Lock button on the keychain transmitter. The doors will lock, the
LEDwill begin to flash slowly and thevehicle’s parking lamps will flash once, if the optional
parking light flasher was added. The horn will beep once if the optional horn annunciation
circuit was added.
Locking / Arming (Passive)
Passive (Automatic) arming and locking is a selectable feature and may not be activated in
your vehicle.
1. Turn off the engine, exit the vehicle, and close all doors.
Note: Automatic passive arming will not begin until all doors are closed, allowing passenger
to exit the vehicle at their convenience.
2. The LED will begin flashing rapidly, 30 seconds later the system is armed, the vehicle’s
parking lamps will flash one time, if the optional parking light flasher was added.
NOTE: The keyless entry control module can be programed to either;
A. Automatically lock the doors during step 2 above.
or....
B. Only lock the doors when step 3 is executed.
3. If you wish to Lock/Arm the system immediately, simply press and release the Lock button
onthekeychaintransmitter.Thedoorswilllock,theLEDwillbegintoflashandthevehicle’s
parking lamps will flash once, if the optional parking light flasher was added. The horn
will beep once if the optional horn annunciation circuit was added.
Protection While The System Is Armed
Whenever the system is armed, the vehicle’s starter will be bypassed (optional). If a thief
should attempt, the vehicle can not be started.
Unlocking / Disarming
1. As you approach the vehicle, press and release the Unlock button on the key chain
transmitter.
2. The LED will turn off, the vehicle’s parking lamps will flash 2 times, if the optional parking
light flasher was added, the doors will unlock, and the vehicle’s interior courtesy light will
turn on for approximately 20 seconds, indicating that the system is disarmed. The horn
will beep twice if the optional horn annunciation circuit was added.
Note: If the passive arming feature is activated in your vehicle, the LED will begin to flash
rapidly when the unlock button is pressed. Opening any door will suspend the arming
process.

128-6628
3 of 8
-3-
NOTE: If the optional 2-step unlock feature was installed, then only the driver's door will
unlock during step 1 above. To unlock all doors, press the unlock button of the
transmitter a second time.
3. Neverattempttodisarmthesystemfromadistancethatpreventsyoufromopeningadoor
within 30 seconds, when the system is programmed for passive arming as the system
will begin to re-arm until a door is opened. Opening the door will suspend the passive
arming cycle.
CARFINDER:
As an added convenience, your system has the ability to flash the parking lights and sound
the vehicle's horn, (If these options have been added), on command from the transmitter.
This feature is particularly useful to help locate your vehicle in a crowded parking lot. To
access this feature, simply press and hold the Lock or Unlock button of your keychain
transmitter for three seconds. This mode will cancel automatically after 30 seconds, or
you can cancel it from the transmitter by pressing the same transmitter button again for
three seconds. This mode can also be canceled immediately, by pressing any button other
than the lock or unlock button.
VALET SWITCH
The valet switch allows you to temporarily bypass your system's security functions,
eliminating the need to hand your transmitter to parking attendants or garage mechanics.
When the system is in valet mode, the starter inhibit feature, if installed, is bypassed,
however the remote door locks will remain operational. To use the valet mode, the system
must first be disarmed either by using your keychain transmitter, or by manually overriding
the system.
1. Enter the vehicle, and turn the ignition key to the on position.
2. Press and hold the valet push-button switch until the dash mounted LED turns
on solid indicating that the valet mode has been entered successfully.
3. To return to normal operation, press and release the push-button switch any
time the ignition is on.
NOTE: Always remember to exit the valet mode to ensure that the vehicle remains
protected at all times.
MANUALLYOVERRIDINGYOURSYSTEM:
USING THE VALET SWITCH MANUAL OVERRIDE
Your Security System can be disarmed without the use of the keychain transmitter. This is
necessary, since you will need the ability to operate your vehicle if the transmitter is lost or its
battery fails. If your system has been selected for Valet Switch manual override as indicated
on the last page of this manual, to bypass the alarm system;
1. Open the vehicle door.
2. Turn the ignition key to the on position.
3. Within 5 seconds, press and release the valet push-button switch.
The system will enter the (bypassed) mode. You can now start and operate the vehicle
normally. Typically this override mode is used only if the transmitter has become inoperative.

128-6628
4 of 8
Programming Your Custom Override Code:
Unlike override switches easily found, and defeated, this security system allows the
consumer to program a personal override code, offering a higher level of security. To take
advantage of this option, programmable feature # 6 must be selected for the Custom Code
Option. Consult your installation center for programming details. The system comes from the
factory with a pre-programmed override code of 11. To change this default override code,
do the following:
1. Disarm the system by use of the transmitter, or by use of the emergency override
sequence. Turn the ignition switch to the on position.
2. Within 10 seconds, press and release the valet/override switch, 3 times.
3. Within 10 seconds turn the ignition switch off, on, off, on, off, on.
(The lights will flash one time.)
4. Within 10 seconds, begin to enter your chosen 10ths digit by pressing and releasing the
push-button switch from 1 up to 9 times.
5. Within 10 seconds of the last entered 10ths digit, turn the ignition switch off then on.
6. Within 10 seconds, begin to enter your chosen units digit by pressing and releasing the
push-button switch from 1 up to 9 times.
7. Finish by turning the ignition switch to the off position.
If the new code was accepted, the unit will report back the newly entered code, by flashing
the LED, first indicating the 10ths digit, pause and then the units digit. The unit will report the
new code three times with a one second pause between each code, then the system will
begin arming (If Passive Arming Has Been Selected). If the LED flash pattern reports the
previously stored code, the new code was not entered correctly. Please repeat steps 1
through 7 above considering the following.
NOTE: Acceptable digits 10ths or units are 1 through 9. The unit will not recognize a 0
(Zero), or no digit entered in any place, units or tenths.
NOTE: If 15 seconds of inactivity expire, or if the ignition switch is turned off for more then 5
seconds during any of the above steps, the unit will revert back to the last success-
fully stored code.
Custom Code Programming Example:
To Change the code from the factory preassigned code of 11 to “52” you would do the follow-
ing:
1. Disarm/Unlock the system by use of the transmitter, or by use of the emergency override
sequence.
2. Turn the ignition switch to the on position.
3. Within 10 seconds, press and release the valet/override switch, 3 times.
4. Within 10 seconds turn the ignition switch off, on, off, on, off, on.
(The lights will flash one time.)
5. Within 10 seconds, begin to press and release the push button switch to set the tenths
digit.
(As per the example, press and release 5 times to set the tenths digit to 5)
6. Within 10 seconds of the last press of the push-button, turn the ignition switch off then on.
-4-

128-6628
5 of 8
7. Within 10 seconds, begin to press and release the push button switch to set the units
digit.
(As per the example, press and release 2 times to set the units digit to 2).
8. Turn the ignition switch to the off position. Immediately observe the LED flash pattern.
You will note the LED flashing five times, pause, and then flash two times, pause. This
pattern will be repeated three times indicating the new code (52) has been accepted and
stored in memory.
NOTE: If after step 7, the LED flashes a code other than what was just entered, this
indicates that the code has not been changed. You will have to repeat steps 1
through 7 above being certain to note the following:
Acceptable digits 10ths or units are 1 through 9. The unit will not recognize a 0 (Zero), or no
digit entered in any place, units or tenths.
NOTE: If 15 seconds of inactivity expire, or if the ignition switch is turned off for more then 5
seconds during any of the above steps, the unit will revert back to the last success-
fully stored code.
MANUALLY OVERRIDING YOUR SYSTEM:
USING THE CUSTOM CODE OVERRIDE
Assuming the override code programmed has not been changed, and the default override
code of 11 is in the system's memory.
1) Enter the vehicle and turn the ignition switch to the on position.
2) Within 5 seconds, press and release the push-button switch 1 time.
3) Within 5 seconds, turn the ignition switch off then on.
4) Within 5 seconds, press and release the push-button switch 1 time.
5) Turn the ignition switch off then on and start the vehicle. (If optional parking light relay
was installed, the lights will flash twice, if the optional horn annunciation circuit was
installed, the horn will beep twice)
Note:If you have changed the programmed override code then substitute your new code
tenths for step 2 above, and units for step 5 above.
OPTIONAL DEVICE OUTPUT ( CHANNEL 3 )
Controlled By: oOption Button, oBoth Lock & Unlock Button, oBoth Option & Lock
Button, or oBoth Option and Unlock Button.
This security system is equipped with an output which will activate when the appropriate
transmitter button is depressed for 4 seconds. Optional devices that may be connected to
this channel are;
-5-

128-6628
6 of 8
oRemote Electric Trunk Release
oRemote Car Starter
oRemote Window Closure
oRemote Garage Door Interface
NOTE: In addition there may be a second optional feature connected to your system that
when the same transmitter button is pressed and released 2 times within 3 seconds
(double pressed), the second optional feature will activate. This output is typically
used for a remote start option and will likely prevent inadvertent activation of the
remote start device if young children are playing with the hand held transmitter.
If your vehicle is not equipped with an electronic trunk release switch, or other option listed,
this feature may have been connected to another accessory. Please ask your dealer for
further information.
ADDITIONAL REMOTE FUNCTION ( CHANNEL 4 )
Controlled By: oOption Button, oBoth Lock & Unlock Button, o Both Option & Lock Button,
oroBoth Option and Unlock Button.
This security system has an additional feature that can be connected to a number of
different optional accessories. Some of the more common uses for this channel are;
oRemote Car Starter
oRemote Window Closure
oRemote Garage Door Interface
To remotely operate the device indicated, momentarily press, or press and hold the
appropriate transmitter button(s) as indicated above.
SELECTABLEFEATURESETTINGS
oIgnition Controlled Locks
oIgnition Controlled Unlock
oDrivers Door
oAll Doors
oPassive Arming
oPassive Door Locks
oStarter Disable
oValet Override System
oCustom Code Override System
-6-

128-6628
7 of 8
THISPAGELEFTBLANKINTENTIONALLY
-7-

128-6628
8 of 8
© 2003 Audiovox Electronics Corporation, Hauppauge, NY 11788 128-6628
-8-
