Audiovox GMRS7001 User manual

128-XXXX
1 of
General Mobile Radio Service (GMRS)
Model : GMRS7001
Draft :
Owner's Manual
1-800-290-6650
DRAFT
Feb.04,2003(by TTI).

128-XXXX
2 of
NEVERATTEMPTTOCHARGEALKALINEORDRYCELLBATTER-
IES, AS BATTERIES MAY BURST CAUSING PERSONAL INJURY
ANDDAMAGETOTHEPRODUCT. WHEN RECHARGING NICKEL
METAL HYDRIDE (Ni-MH) BATTERIES WITH THE AUDIOVOX
CHARGER, USE ONLY AUDIOVOX APPROVED RECHARGE-
ABLE BATTERIES. USE OF THE AUDIOVOX CHARGER WITH
OTHER BRANDS OF BATTERIES IS NOT RECOMMENDED, AS
BATTERY CHARGING TIMES WILL VARY WITH
DIFFERENT BRANDS. REFER TO THE MANUFACTURER’S
INSTRUCTIONSFORCHARGINGOTHERBRANDSOFBATTERIES.
AVOID PLACING THE GMRS7001-2 RADIO TRANSCEIVER
FOR PROLONGED PERIODS OF TIME IN DIRECT SUNLIGHT
OR TEMPERATURES BELOW-4° F (-20° C) OR ABOVE 140 °F
(60°C).
KEEP THE ANTENNA AT 1 INCH (2.5 cm) AWAY FROM YOUR
HEAD AND BODY. DO NOT USE YOUR GMRS7001-2 RADIO
TRANSCEIVERWITHADAMAGED ANTENNA.
PLACETHE RUBBER COVERON JACKS WHENNOT IN USE.
GMRSLICENSE:
USEOFTHISRADIOWITHINTHEUNITEDSTATESREQUIRESAN
FCC GMRS LICENSE. AN INDIVIDUAL18 YEARS OF AGE OR
OLDER, WHO IS NOT A REPRESENTATAIVE OF A FOREIGN
GOVERNMENT, IS ELIGIBLE TO APPLY FOR A GMRS SYSTEM
LICENSE. YOU WILL NEED TWO FORMS FROM THE FCC; FCC
FORM 159 AND FCC FORM 605 MAIN FORM AND SCHEDULE F.
YOUCANFIND THE FORMS ONLINEAT:HTTP://WWW.FCC.GOV/
FORMPAGE.HTML,ORCALL1-800-418-3676.
CAUTIONS
2

128-XXXX
3 of
DRAFT
3
1. BatteryCover
2. Monitor/FunctionConfirmation
Button
3. DetachableCarry Clip
4. Push-To-Talk(PTT)andFunc-
tionConfirmation Button
5. Antenna
6. ExternalSpeaker(SP.)/Micro-
phone(MIC) Jacks
7. Built-inSpeaker
8. LiquidCrystal Display (LCD)
9. Built-inMicrophone
Model GMRS7001-2 (FCC License Required)
10. UpChannel/VolumeButton
11. DownChannel/Volume
Button
12. MODE/WXButton
13. Power On/Off&
Keylockbutton
SCAN / VOX Button
14. BatteryCharging Contacts
15
3
5
4
1
2
913
11
8
10
12
7
3
(REF)
1
(REF)
6
15.
14

128-xxxxx
4 of
4
Model GMRS7001-2 DISPLAY
1. Beep Tone Indicator: Icon appears when beep button confirmation
tone is selected; icon disappears when tone is off.
2. Key Lock Indicator: Icon appears when the keypad is locked. This
function disables keys such as channel up/down and MODE.
3. Monitor Indicator: Icon appears when the Monitor (M) button is
pressed and the channel monitor function is activated.
4 . Signal Strength Indicator: Iconappearswhen asignalis beingreceived.
The icon consists of five bars to indicate the received signal level. The
icon also represents transmit signal power during transmission.
6. Large Segment Display: Indicatesthe channel number in use.
7. Scan Indicator: Thisfunction allows the user toscan a channeland/or a
tonecode every .5 second to search for a validsignal.
9. Battery Level Indicator: Icon indicates the battery charge level.
5. Hi/LO Indicators: Appropriate icon appears when the transmit power
is set to desired output power.
1
2
3
4
10
5
6
7
8
9
11
13
14
12
8. RogerBeep Tone On/Off Indicator: This icon appears when the
Roger Beep tone is on, and disappears when tone is not in use.
10.Signal Receiving Indicator: Icon appears whena signal isbeing
received.

128-xxxx
5 of
5
11.Weather Mode Indicator: Icon will be on steady when in the weather
band mode. The icon will blink when in the GMRS mode with the alert
active.
12.Small Segment Display: Displays the CTCSS tone option in the
channel from (00-38).
13.Dual Watch Mode Indicator: Icon appears when dual watch mode is
active.
14.Voice Activated Transmission (VOX) Indicator: This function allows
hands free conversation. The icon appears when the VOX mode is
activated.
Powering the transceiver:
Equipment and Accessories Supplied
1. Radio (2) GMRS7001-2
2. Owner’s Manual (1) 128-xxxx
Your GMRS7001-2 radio transceiver operates on five AAA batteries.
Alkaline batteries will provide slightly better performance than rechargeable
batteries. Only the supplied Audiovox-approved rechargeable batteries
can be recharged in the radio transceiver using the suppiled desk-top
charger and associated wall adapter. This will ensure optimum
performance for the GMRS7001-2. Battery charging time is typically
13-15 hours. Use of the Audiovox charger with other brands of batteries is
not recommended as battery charging times will vary. Refer to the
manufacturer’s instructions for charging other brands of batteries.
Batteries
There are three methods of powering the GMRS7001-2:
1.Alkaline Batteries.
WARNING: Do not attempt to recharge Alkaline batteries.
2.Audiovox Rechargeable Ni-MH Batteries - (Rechargeable Ni-MH
batteries, Wall Adapter and Charging Stand are NOT included).

128-xxxx
6 of
DRAFT
6
2. Slide the cover
down and then lift
cover at bottom to
open.Remove
cover.
3. Insert five AAA batteries
(positive (+) end toward
the right begining at top
side and alternating
positive terminals as
shown).
1. Using thumb,
press down on
battery cover at
arrow and slide
cover down to
open.
Use only Audiovox-approved rechargeable batteries and charger
when charging batteries internal to the unit.
NOTE: To extend battery life, avoid overcharging the batteries.
3. Various Brands of Rechargeable Batteries - Use of the
Audiovox charger with other brands of rechargeable batteries is not
recommended, as battery charging times will vary with different
brands of batteries.Refer to the manufacturer’s instructions for
charging other brands of batteries.
Installing the batteries:
Batteryinstallation is made more convenient whenthe carry clipis removed.
To do this, release the spring clip securing the belt clip to radio and slide
the belt clip upward and away from the radio body. Next, press down with
the thumb at the embossed arrow, slide the battery cover down and lift off
thebattery cover.Insertfive AAAbatteries (alternatepositive ends(+) toward
the top of the transceiver, starting up-to-down.
RELEASE
BUTTON
BATTERY
COVER
BELT
COVER
ARROW
POSITIVE
TERMINALS
CLIP
+
+
+
+
+

128-xxxx
7 of
DRAFT
7
The following guidelines will improve performance and provide longer
operating times for the GMRS7001-2:
1. Do not mix old and new batteries.
2. The use of alkaline-type batteries is recommended to provide the
longest operating time.
3. Do not mix alkaline, standard (carbon-zinc) or rechargeable
batteries.
4. If the unit is not to be used for an extended period of time, remove the
batteries. Old or leaking batteries can cause damage to the unit and
will void the warranty.

128-xxxxx
8 of
7
NOTE:
To switch between GMRS/FRS and Weather Band modes, press and hold
the Mode button for 2 seconds. Refer to the appropriate section of this
manual for detailed operating instruction for each mode.
GMRS7001-2 OPERATIONAL MODES
CHANNEL
SELECT
BUTTON
BEEP
WEATHERBAND
ALERT
CALL
SELECT
GMRS/ FRSBAND
WEATHERBAND
BUTTON
BEEP
ROGER
BEEP
DUAL
WATCH
POWER
SELECT
CTCSS
SELECT
CHANNEL
SELECT

128-xxxxx
9 of
9
Controls:
Power On/Off (13) Button
Press and hold the power on/off button ( ) for at least 2 seconds. You will
hear a confirming melody to indicate the unit is on. To turn the unit off, press
andhold the button for at least 2 seconds.
Adjustingthe Volume
With the unit powered on, press the Up Channel/Volume button ( ) to
increase volume and the Down Channel/Volume button ( ) to decrease
volume. The display will indicate the current volume level by the small
number in the icon ( UL0 - 7 ).
Monitor/Display Backlight Button (2)
This button is used to to check activity on the current frequency before
transmitting. Check activity by pressing the Monitor (M) Button longer
than 2 seconds; the icon will apppear on the display and you will
hearstatic if frequency isclear.
Do not transmit if you hear conversation.
Hold down the Monitor Button again longer than 2 seconds and the
icon will disapppear from the display.
The monitor function will temporarily bypass the squelch setting and play
all signals on a given channel. This feature is useful when communicating
with other parties at extreme range.
By pressing the monitor button momentarily, the LCD backlight is turned
on; the LCD backlight will turn off automatically in about 5 seconds, or
when the monitor button is pressed momentarily once again.
Push To Talk (PTT) Button (4)
Pressing and holding this button will allow you to speak to any transceiver
that is set to the same channel and privacy code setting as yours. Hold the
transceiver approximately 1 to 2 inches from your face as you speak into
the built in microphone (9). After you have finished speaking, release the
PTT Button to allow reception of incoming signals. It is not possible to

128-xxxx
10 of
10
transmit and receive at the same time.
While the PTT Button is pressed,
the signal indicator will display the relative strength of the transmitted
signal. Releasing the button allows the unit to revert to standby mode.
When receiving an incoming signal, the BUSY icon will display in the
LCD and the received signal strength indicator ( ) will display
the relative strenth of the signal. The PTT Button can also be used as a
two-way call ringer. Pressing the button twice quickly will call another par-
ty on the same channel.
Up Channel/Volume Button (10)
In the standby mode, pressing this button will increment the listening
volume. When in function edit mode this button will be used to adjust the
unit's settings.
Down Channel/Volume Button (11)
In the standby mode, pressing this button will decrement the listening
volume. When in function edit mode this button will be used to adjust the
unit's settings.
Mode Button (12)
Thisbutton is usedto select variousfeature settings in the GMRS / FRS or
weather band mode. Holding the MODE button longer than 2 seconds
will toggle between the GMRS/FRS and weather band modes.
