Auger Torque ALIGNMENT MONITOR User manual

www.augertorque.com 11
ALIGNMENT MONITOR
INSTALLATION /OPERATION
www.augertorque.com
99-95522001 ISSUE 5-2 ENGLISH

www.augertorque.com 22
INSTALLATION
Contents
a. Alignment Monitor (x1)
b. Sensor Unit (x1)
c. 12-24v Power Cable (x1)
d. Sensor Cable Assembly (x1)
e. Small P Clips (x4)
f. Large P Clip (x4)
g. Sensor Mounting Kit (x1)
Check that nothing has been damaged during
transit. In case of damage contact dealer.
The Sensor
The Sensor Unit is mounted on the inside of
the Earth Drill hood, to the underside of the top
plate, in a suitable position.
Attach the Sensor to the Earth Drill hood,
ensuring the Sensor is fitted with the cable
facing towards the operator’s station. Hold
sensor in place for 10 seconds.
Sensor Mounting Kit
The Alignment Monitor is supplied with a spare
Sensor Mounting Kit. Fit the mounting plate
to the resin side of the sensor. Fix the plate in
place with screws supplied, adding medium
strength Loctite to the threads.
NOTE:
- Sensor must sit flat to the hood top plate.
- At room temperature approximately 50% of
ultimate bond strength will be achieved after 20
minutes, 90% after 24 hours and 100% after 72
hours.
- The adhesive strip is very strong. Attempting to
remove may cause damage to the sensor.
a b c
de
f
g

www.augertorque.com 33
Sensor Cable
Connect the Sensor Cable plug to the Sensor
and, starting from the Earth Drill route the
cable along the machine to the operator’s
station. Secure the cable using P clips or
cable ties, paying particular attention to pivot
and articulation point, ensuring cable is not
stretched or trapped.
Alignment Monitor
Secure Monitor using the suction pad on any
suitable flat surface in a position visible to the
operator. The screen can be adjusted up/down
left/right by using the central thumb screw on
the mounting bracket.
Sensor Cable
With the Monitor in the correct position connect
Sensor Cable to the rear of the Monitor.
Power Cable
Connect cable to the rear of the Monitor and the
auxiliary power socket.
Suction Pad
Thumb Screw
Sensor Cable
On / Off (hold)
Button
Sensitivity
Button
24V Max
Power Cable

www.augertorque.com 44
OPERATION
Press and hold the red On/Off button on the
Monitor wait until the display is shown as (Fig 1).
Alignment Calibration
Lift Earth Drill and Auger clear of the ground
so they hang free and still. With the Monitor
switched on, press and hold the Sensitivity button
for 3 seconds display will change to (Fig 2).
The Monitor is now calibrated; this operation will
need to be carried out each time the monitor is
switched on.
Sensitivity Settings
To change the sensitivity press the black button
until the required level is obtained indicated at
the bottom right of the screen (Fig3).
There are four sensitivity levels:-
HIGH = 0.5° 1° 2° LOW = 3°
Select the sensitivity setting suitable for your
drilling requirements.
Drilling
When drilling keep the white alignment marker in
the centre of the circle by using forward, aft, left
and right movements (Fig4).
For correct drillng alignment the outer circle
should remain green. As the white alignment
marker moves away from the centre the outer
circle will change to amber and then red
NOTE: When using auger extensions, it may be
necessary to use the LOW sensitivity setting to
maintain a green light.
Operating Temperature Range:
-40°C to +80°C / 40°F to +176°F
Fig1
Fig2
TROUBLESHOOTING
No power Check Power Cable and auxiliary socket
No sensing Check Sensor and Cable
Alignment marker moving in wrong direction Sensor mounted incorrectly
Auger alignment incorrect Calibrate Alignment Monitor
Fig3
Fig4

www.augertorque.com 55
WARRANTY STATEMENT
Auger Torque provide a LIFETIME parts replacement warranty on the dislodgement of the Earth
Drill shaft and any failure of the Shock Lock system to prevent loss of teeth under normal operating
conditions.
All Auger Torque products are warranted to be free from defects in materials or workmanship for the
periods summarised below:
•Planetary Gearbox Components - 72 Months
•Hydraulic Motors - 36 Months
•All Other Parts / Products - 12 Months
The warranty periods will commence from Date of Sale by an authorised Auger Torque Dealer. Evidence of
the date of sale may be required and for Planetary and Hydraulic Motor warranties to be valid the product
must be registered with Auger Torque within 4 weeks of the date of sale. Extended Warranty (> 12 months)
Products can be registered by returning the Registration Card or completing the form on page 8. This
warranty is not transferable beyond the initial purchaser of the product.
A warranty claim should be reported to the Auger Torque Dealer who supplied the unit. The Dealer, with the
technical backup of Auger Torque, will make an initial assessment.
The customer is responsible for returning the product for warranty inspection to the original supplying
dealer’s facility. Parts should not be delivered without the prior agreement of the dealer or Auger Torque.
During the warranty period Auger Torque, at its option, will repair or replace any parts free of charge
determined as defective by Auger Torque. Such repairs will be undertaken by Auger Torque or its
nominated representative at an Auger Torque facility or a location deemed suitable by Auger Torque. Auger
Torque are not liable for any associated costs relating to a warranty failure.
Parts repaired or replaced by Auger Torque are then covered by this warranty for the remainder of the
original warranty as if such parts were original parts.
Products or parts which, as determined by Auger Torques examination, show wear from normal use, have
been improperly operated, damaged by accident or negligence, altered or modified are not considered
defective and are not covered by this warranty.
This warranty is void if any attempt is made to make field repairs unless these have been pre-approved in
writing by Auger Torque.
This warranty is void if the products are not serviced in-line with the instructions in the Operators Manual.
Particular care should be taken to perform regular oil changes in gearboxes.
This warranty is exclusive and in-lieu of any other expressed warranties. There are no warranties of
merchantability or fitness for a particular purpose. Auger Torque shall not be liable for any consequential,
incidental or punitive damages, losses or expenses, including those resulting from or caused by any
defects.
As you would expect from Auger Torque, with our extensive experience and product reliability we’ll
always go the extra mile to keep you working.
