Rosen Aviation 1043-229 User manual

Document Number 101844 Rev D
ELECTRONIC REVISION
CONTROLLED

Rosen Aviation 10.4” Display on Manual Lift
Document Number: 101844
Revision: D
Date: 05/20/10
Template: 4.2.3-6-FM; Revision A; 16 May, 2005
Page 2 of 25
Technical Manual, 10.4” Display on Manual Lift
© 2008–2010 by Rosen Aviation, LLC
All Rights Reserved
The information contained herein is proprietary to Rosen Aviation, LLC. No part of this publication
may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any
language in any form by any means without the written authorization from Rosen Aviation, LLC,
except as allowed under copyright laws.
Disclaimer of Liability
The information contained in this document is subject to change without notice. Because we are
continuously improving and adding features to our products, Rosen Aviation, LLC reserves the right
to change specifications without prior notice. Rosen Aviation, LLC shall not be liable for technical or
editorial errors or omissions contained herein.
Rosen Aviation, LLC
1020 Owen Loop South
Eugene, OR 97402
541.342.3802
888.668.4955
Fax: [phone]
www.rosenaviation.com

Rosen Aviation 10.4” Display on Manual Lift
Document Number: 101844
Revision: D
Date: 05/20/10
Template: 4.2.3-6-FM; Revision A; 16 May, 2005
Page 3 of 25
Contents
1. INTRODUCTION.................................................................................................................4
1.1. Product Information ......................................................................................................4
2. DISPLAY CONNECTIONS .................................................................................................4
2.1. System Integration........................................................................................................5
3. INSTALLATION GUIDELINES ...........................................................................................5
3.1. Raising and Lowering the Manual Lift...........................................................................5
4. FRONT PANEL BUTTONS.................................................................................................6
4.1. Navigational Soft Keys..................................................................................................7
4.1.1. Source Select................................................................................................................... 8
4.1.2. Aspect Ratio..................................................................................................................... 8
4.1.3. Brightness......................................................................................................................... 9
4.1.4. Contrast.......................................................................................................................... 10
4.2. On-Screen Menus.......................................................................................................10
4.2.1. Image Adjustments Menu............................................................................................... 11
4.2.2. Advanced Menu.............................................................................................................. 13
4.2.3. Power Up Mode.............................................................................................................. 14
4.2.4. Backlight Brightness....................................................................................................... 15
4.2.5. Information...................................................................................................................... 15
4.3. Technician Menu ........................................................................................................16
4.3.1. Technician MenuImage Adjustments Menu................................................................. 17
4.3.2. RGB Auto Detect............................................................................................................ 18
4.3.3. Source Select Button Mode ............................................................................................ 18
4.3.4. Select Switch Active Pulse Width.................................................................................... 19
4.3.5. Select Switch Repeat Delay............................................................................................ 19
4.3.6. Information...................................................................................................................... 20
5. MAINTENANCE: TENSION ADJUSTMENTS..................................................................21
6. TECHNICAL REFERENCES AND SUPPORT .................................................................21
6.1. Troubleshooting..........................................................................................................21
6.2. DO-160E Qualifications ..............................................................................................23
6.3. Technical Support.......................................................................................................23
6.4. Specifications..............................................................................................................24
7. DEFINITIONS....................................................................................................................24
8. REVISION HISTORY ........................................................................................................25

Rosen Aviation 10.4” Display on Manual Lift
Document Number: 101844
Revision: D
Date: 05/20/10
Template: 4.2.3-6-FM; Revision A; 16 May, 2005
Page 4 of 25
1. INTRODUCTION
This manual describes how to install the Rosen 10.4” display on manual lift onto your aircraft. It
contains everything you need to know to wire the display and confirm that it is functioning
correctly.
Note: Only trained and qualified personnel should perform installation and service.
1.1. Product Information
The following documentation for the 10.4” display on manual lift specific to each display/video
combination is available on the Rosen web site at www.rosenaviation.com.
Outline and Installation Drawings, 10.4” manual lift
1043-229 or 1043-329 display on manual lift
Technical Manual –(P/N 101844)
User’s Guide 10.4” Display on Manual Lift –(P/N 101845)
From the Rosen Aviation home page, select the Products tab and browse by product category.
2. DISPLAY CONNECTIONS
There are several ways to connect the 10.4 display on manual lift to an aircraft’s entertainment
system.
Use the pinout descriptions on page 2 of the Outline and Installation drawing to assist in the wiring
process. Pay close attention to the pinout information while completing wiring connections.
The 10.4 display on manual lift is available in two different configurations depending on the video
source that you install.
Composite –model 1043-229
SDI (serial digital interface) –model 1043-329
The on-screen menus are different for each configuration. Some options will be shown even
though they are not supported.
Note: This display is for entertainment purposes only; connect to a non-critical power bus.

Rosen Aviation 10.4” Display on Manual Lift
Document Number: 101844
Revision: D
Date: 05/20/10
Template: 4.2.3-6-FM; Revision A; 16 May, 2005
Page 5 of 25
2.1. System Integration
The 10.4” display on a manual lift has one video source and it is typically the only monitor in the
cabin, as shown in the following connection diagram.
Figure 1 Single video input installation
These displays are typically connected to a video distribution unit, which provides a single
composite video signal to each monitor. The video distribution box performs the source
selection.
3. INSTALLATION GUIDELINES
To access the bottom mounting plate, use the latch to raise the display, as shown below. Secure
the lift assembly from the bottom mounting plate with eight 10-32 flat head screws. Refer to page 2
of the outline and installation drawing for details.
3.1. Raising and Lowering the Manual Lift
Use CAUTION when stowing or deploying lift. The spring lift is under pressure and could
seriously injure hands/fingers if caught in mechanism during operation.
Figure 2 Manual lift assembly in stowed position
To raise the display, pull
the latch to the right.
Composite
or SDI
Cabin
Management
System

Rosen Aviation 10.4” Display on Manual Lift
Document Number: 101844
Revision: D
Date: 05/20/10
Template: 4.2.3-6-FM; Revision A; 16 May, 2005
Page 6 of 25
The monitor can pivot 180° and tilt back 30°. When lowering the display, align the screen with
the lift assembly and then push down firmly on the right corner until the latch locks.
The default power setting is Auto On, which means the power turns on and off automatically
when you raise and lower the lift.
Figure 3 Stowing the display on a manual lift
4. FRONT PANEL BUTTONS
The 10.4” display on manual lift has control capability through the front panel buttons or an
external IR remote. On SDI displays, the Source Select and Aspect Ratio buttons are for
navigational purposes only.
Figure 4 10.4” manual lift button layout
Power
On/Off
IR
Sensor
Menu
Contrast
Brightness
Aspect
Ratio
Source
Select
Push down
here
Power
Indicator

Rosen Aviation 10.4” Display on Manual Lift
Document Number: 101844
Revision: D
Date: 05/20/10
Template: 4.2.3-6-FM; Revision A; 16 May, 2005
Page 7 of 25
Table 1 10.4 display on manual lift front panel buttons
Button
How it Works
Power On/Off
Turns the power on and off to the display. The LED indicator is red when the
power is off, and green when the power is on. Previously adjusted settings of
brightness and scaling mode are retained in memory when power is turned off,
or when aircraft power is removed.
Menu
Opens a submenu of options to access other settings and fine-tune the
display’s picture quality. For details about the on-screen menus, see On-
Screen Menus in Section 4.2 on page 10.
Contrast
Adjusts the LCD contrast. See Contrast in Section 4.1.4 on page 10 for details.
Brightness
Adjusts the picture brightness. If the button is held down for more than one
second the brightness will continue to step up or down in ¼–second intervals.
For more information, see Brightness in Section 4.1.3 on page 9for details.
Aspect Ratio
(Composite only)
Two aspect ratio modes: Normal and Vertical Stretch change the proportions
of the composite picture depending on the DVD format. On SDI displays, this
button is for navigational purposes only. See Aspect Ratio in Section 4.1.2 on
page 8for details.
Source Select
Functions only as a secondary soft key for navigation in the on-screen menus.
If pressing Source Select changes the picture to a black screen, set the
Source Select Button Mode to External Select. See Source Select Button
Mode in Section 4.3.3 on page 18 for details.
4.1. Navigational Soft Keys
The icons on the display buttons indicate basic functions. In addition to the basic functions, the
buttons act as soft keys that perform secondary navigational functions to adjust picture quality in
setting screens and the on-screen menus. When you press a button and see a bar of blue soft
keys, as shown below, press the corresponding display button.
Figure 5 Soft key buttons
Selected options will be highlighted in yellow. The menu options that are available depend on the
configuration and which source signal is active: composite or SDI.
Note: Before changing the display settings, try both default color modes first to determine which
set of colors you like best. See Restore Factory Defaults in Section 4.2.2.1 on page 13 for more
information.
The label of the
menu soft key
changes
depending on
the function it is
performing
Basic
function
buttons
Secondary
soft keys

Rosen Aviation 10.4” Display on Manual Lift
Document Number: 101844
Revision: D
Date: 05/20/10
Template: 4.2.3-6-FM; Revision A; 16 May, 2005
Page 8 of 25
4.1.1. Source Select
A secondary key for navigating the on-screen menus.
Figure 6 Source select button
4.1.2. Aspect Ratio
Note: Composite only. This option is not active on SDI displays. Press the Aspect Ratio
button (shown below) to adjust the picture expansion to most closely match the encoding
of the source image. Press the ◄or the ►soft key to switch the display between aspect
ratio modes (described below). Highlight the optimal mode for the image source and
press Set to set the mode and exit the screen.

Figure 7 Aspect ratio button, settings, and soft keys
Normal Mode
Displays standard 4:3 aspect video and widescreen 16:9 video without alteration. A
standard 4:3 image will fill the screen without distortion, as shown in Figure 8.
Figure 8 Standard 4:3 aspect test pattern in Normal Mode
A widescreen 16:9 image will appear with black bars on the top and bottom of the image,
as shown in Figure 9.
Figure 9 Widescreen 16:9 aspect test pattern in Normal Mode

Rosen Aviation 10.4” Display on Manual Lift
Document Number: 101844
Revision: D
Date: 05/20/10
Template: 4.2.3-6-FM; Revision A; 16 May, 2005
Page 9 of 25
Vertical Stretch Mode
Expands the source video in the vertical dimension to fill the display screen. The top and
bottom of a standard 4:3 image will be cropped and circles will appear as ovals, as
shown in Figure 10.
Figure 10 Standard 4:3 aspect test pattern in Vertical Stretch Mode
Widescreen 16:9 videos will not exhibit black bars above and below the image but circles
will appear as ovals, as shown in Figure 11.
Figure 11 Widescreen 16:9 aspect test pattern in Vertical Stretch Mode
4.1.3. Brightness
Adjust the picture brightness by pressing the Brightness button (shown below). Press
the ◄or the ►soft key to decrease or increase the brightness on the LCD. If the button
is held down for more than one second, the brightness will continue to step up or down in
¼–second intervals.
Press the Set soft key to set the brightness and exit the screen.

Figure 12 Brightness button, settings, and soft keys

Rosen Aviation 10.4” Display on Manual Lift
Document Number: 101844
Revision: D
Date: 05/20/10
Template: 4.2.3-6-FM; Revision A; 16 May, 2005
Page 10 of 25
4.1.4. Contrast
Adjust the contrast by pressing the Contrast button (shown below). Press the ◄or the
►soft key to raise or lower the contrast. Press the Set soft key to set the contrast and
exit the screen.

Figure 13 Contrast button, settings, and soft keys
4.2. On-Screen Menus
To open the Main Menu and access the submenu settings, press the Menu button, as shown
below. Press the ▼and ▲soft keys to select (highlight) an option, and press the OK soft key to
select it.

Figure 14 Composite and SDI Main Menu with soft keys
Note: The on-screen menus will time out and close automatically after no screen activity for a
preset amount of time, which is adjustable in the AdvancedMenu Timeout screen.
(Composite only)

Rosen Aviation 10.4” Display on Manual Lift
Document Number: 101844
Revision: D
Date: 05/20/10
Template: 4.2.3-6-FM; Revision A; 16 May, 2005
Page 11 of 25
4.2.1. Image Adjustments Menu
Note: If the screen colors are not what you expect, try changing the default color modes
to determine which one you like best before adjusting the other settings. See section
4.2.2.1 Restore Factory Defaults (Advanced Menu) on page 13 for details.
Use the Image Adjustments menu options, as shown below, to control the color and
picture quality. Press the Menu button and the OK soft key to open the menu. Close the
menus using the Back and Exit options, or wait for the menu to close.
Figure 15 Image Adjustments menu and soft keys
4.2.1.1. Brightness
To adjust the picture brightness, press the OK soft key to open the screen
(Figure 16) below.
Press the ◄or the ► soft keys to change the brightness on the LCD accordingly.
Press the Set soft key to set the brightness and exit the screen.
Figure 16 Picture brightness settings and soft keys
Set Contrast
here or from the
front panel
button. See
section 4.1.4 on
page 10 about
how it works.
Select Back and
press the OK
soft key to close
this submenu
and return to the
Main Menu
(Composite only)

Rosen Aviation 10.4” Display on Manual Lift
Document Number: 101844
Revision: D
Date: 05/20/10
Template: 4.2.3-6-FM; Revision A; 16 May, 2005
Page 12 of 25
4.2.1.2. Saturation
(Composite only.) To adjust the color saturation, press the Menu button and then
select Image AdjustmentsSaturation using the soft keys.
Press the ◄or the ►soft keys to change the color levels.
Press the Set soft key to set the saturation and exit the screen.
Figure 17 Color saturation settings and soft keys
4.2.1.3. Tint (Hue)
To adjust the color hues, press the Menu button and then select Image Adjustments
Tint (Hue) using the soft keys.
Press the ◄or the ►soft keys to change the color hues in the image.
Press the Set soft key to set the tint and exit the screen.
Figure 18 Tint settings and soft keys
4.2.1.4. Sharpness
To adjust the picture sharpness, press the Menu button and then select Image
AdjustmentsSharpness using the soft keys.
Press the ◄or the ►soft keys to adjust the focus.
Press the Set soft key to set the sharpness and exit the screen.
Figure 19 Sharpness settings and soft keys

Rosen Aviation 10.4” Display on Manual Lift
Document Number: 101844
Revision: D
Date: 05/20/10
Template: 4.2.3-6-FM; Revision A; 16 May, 2005
Page 13 of 25
4.2.2. Advanced Menu
Use the Advanced menu options, as shown below, to control the display’s functionality.
Press the Menu button and the OK soft key to open the menu. Close the menus using
the Back and Exit options, or wait for the menu to close automatically.
Figure 20 Advanced menu and soft keys
4.2.2.1. Restore Factory Defaults (Advanced Menu)
There are two Restore Factory Defaults in the on-screen menus. This one restores
only the factory color screen settings: Vivid and Natural modes. Try both modes to
determine which one you like best before adjusting the other picture quality settings.
From the Advanced submenu, press the OK soft key to open the Restore Factory
Defaults screen, as shown below.
Change the color settings mode with any arrow soft key, and then press Set. A
Restoring message will display on screen while the screen settings change.
Figure 21 Restore Factory Defaults menu and soft keys
Although the Restore Factory Defaults screen in the Technician and Advanced
menus look alike, the Technician Menu option (see Section 4.3 on page 16) resets all
default settings, not just color settings.
Select Back and
press the OK
soft key to close
this submenu
and return to the
Main Menu

Rosen Aviation 10.4” Display on Manual Lift
Document Number: 101844
Revision: D
Date: 05/20/10
Template: 4.2.3-6-FM; Revision A; 16 May, 2005
Page 14 of 25
4.2.2.2. Menu Timeout
Use this option to set the amount of time the menu screens are visible, without
making any changes, before they timeout and close automatically.
From the Advanced submenu, press the ▼soft key to select Menu Timeout and
then OK, as shown below.
Press the ◄or ►soft key to select an option.
Press the Set soft key to set the timeout and exit the screen.
Figure 22 Menu timeout options and soft keys
4.2.3. Power Up Mode
Choose from different options of turning on the display.
From the Advanced submenu, press the ▼soft key to select Power Up Mode and then
OK to open the screen, as shown below. Restore Previous starts the display in the
previously selected power state after a power interruption, regardless of the length of the
power interruption.
Press either ◄or ►soft key to select the mode.
Press the Set soft key to set the Power Up Mode and exit the screen.
Figure 23 Power Up mode options and soft keys

Rosen Aviation 10.4” Display on Manual Lift
Document Number: 101844
Revision: D
Date: 05/20/10
Template: 4.2.3-6-FM; Revision A; 16 May, 2005
Page 15 of 25
4.2.4. Backlight Brightness
Use this setting to adjust the intensity of the LCD backlight.
From the Advanced submenu, press the ▼soft key to select Backlight Brightness and
then press OK to open the screen, as shown below.
Press the ◄or the ► soft keys to change the image on the LCD accordingly.
Press the Set soft key to set the brightness and exit the screen.
Figure 24 Picture brightness settings and soft keys
4.2.5. Information
Use the Information screen to review operating status of the display and to access the
Technician Menu. From the Main Menu, press the ▼soft key to select Information and
then OK.
Figure 25 Read-only screens about operating status
B. SDI mode
A. Composite mode

Rosen Aviation 10.4” Display on Manual Lift
Document Number: 101844
Revision: D
Date: 05/20/10
Template: 4.2.3-6-FM; Revision A; 16 May, 2005
Page 16 of 25
4.3. Technician Menu
To protect the display from accidental or unintentional adjustments, the Technician Menu is
accessible only with a special button combination. To avoid repeating this button sequence after
each change, the menu remains active until you manually close it. Note: The Main Menu options
are not selectable while the Technician Menu is open.
To open the Technician Menu, start with the display on, and press the following front panel keys
in this order:
1. Menu
2. Press the ▼soft key to select the Information option on the Main Menu.
3. Inside the Information screen, press the soft keys in this order: ◄, ►, ◄◄, ►►.
4. Then press the Back soft key.
5. The Technician Menu opens.
Figure 26 Technician menus and soft keys
Note: The RS485 Address Selection is not supported in this model.
To select a menu option, press any arrow soft key to highlight and press OK. To close the
Technician menu, press the ▼soft key and choose Exit or allow the screen to timeout and close
automatically. To open the Technician Menu again, press the Menu button.
To exit the Technician Menu Mode and return to the Main Menu, repeat steps 2–4(above). The
Main Menu will open.
Resets all default settings.
See also Advanced
MenuRestore Factory
Defaults in Section 4.2.2.1
on page 13.
Composite only.
The Image
Adjustments
options in the
Technician
Menu are
different from
those in the
Main Menu
B. SDI mode
A. Composite mode

Rosen Aviation 10.4” Display on Manual Lift
Document Number: 101844
Revision: D
Date: 05/20/10
Template: 4.2.3-6-FM; Revision A; 16 May, 2005
Page 17 of 25
4.3.1. Technician MenuImage Adjustments Menu
(Composite only.) Use the following options to adjust the intensity of the three primary
colors when running the display in composite mode.
Figure 27 Image Adjustments menu and soft keys
4.3.1.1. Red
Adjusts the low-level registers of the red values in the picture.
From the Technician MenuImage Adjustments Menu, press the ▼soft key to select
Red and then OK, as shown below.
Press the ◄soft key to show more cyan tones or ►to intensify the red tones.
Press the Set soft key to set the value and exit the screen.
Figure 28 Red settings and soft keys
4.3.1.2. Green
Adjusts the low-level registers of the green values in the picture.
From the Technician MenuImage Adjustments Menu, press the ▼soft key to select
Green and then OK, as shown below.
Press the ◄soft key to show more magenta tones or ►to intensify the green tones.
Press the Set soft key to set the value and exit the screen.
Figure 29 Green settings and soft keys

Rosen Aviation 10.4” Display on Manual Lift
Document Number: 101844
Revision: D
Date: 05/20/10
Template: 4.2.3-6-FM; Revision A; 16 May, 2005
Page 18 of 25
4.3.1.3. Blue
Adjusts the low-level registers of the blue values in the picture.
From the Technician MenuImage Adjustments Menu, press the ▼soft key to select
Blue and then OK, as shown below.
Press the ◄soft key to show more yellow tones or ►to intensify the blue tones.
Press the Set soft key to set the value and exit the screen.
Figure 30 Blue settings and soft keys
4.3.2. RGB Auto Detect
Use RGB Auto Detect to automatically switch to RGB when the source is connected
instead of manually selecting the RGB source with the Source Select button.
To open this setting, press Menu to open the Technician Menu, press the ▼soft key to
select RGB Auto Detect, and then press OK. Use any arrow key to choose the setting,
and then click Set to close the screen. The action of the display changes based on what
you select.
Figure 31 RGB Auto Detect settings and soft keys
4.3.3. Source Select Button Mode
(Composite mode only.) There is no source select on the 10.4” display on manual lift.
External Select sends a source change request to an external device to change between
its sources.
To open the Source Select Button Mode screen, press Menu to open the Technician
Menu, press the ▼soft key to select Source Select Button Mode, and then press OK.
Press the ▼soft key to choose the setting, and then press Set to close the screen.
Figure 32 Source Select Button Mode settings and soft keys
Keep this option set to
External Select

Rosen Aviation 10.4” Display on Manual Lift
Document Number: 101844
Revision: D
Date: 05/20/10
Template: 4.2.3-6-FM; Revision A; 16 May, 2005
Page 19 of 25
4.3.4. Select Switch Active Pulse Width
Use Select Switch Active Pulse Width to set the pulse width of the source select signal.
Pulse width is the amount of time the switch is closed.
From the Technician Menu, press the ▼soft key to choose Select Switch Active Pulse
Width and then OK to open the screen, as shown below.
Press the ◄ soft key to decrease the pulse width, or the ►soft key to increase the pulse
width.
Press the Set soft key to set the pulse width and exit the screen. Each increment
changes the pulse width by 50mSec. The maximum pulse width is 1.1 second.
Figure 33 Select Switch Active Pulse Width settings and soft keys
4.3.5. Select Switch Repeat Delay
Use Select Switch Repeat Delay to change the time delay between source select clicks
on the display.
From the Technician Menu, press the ▼soft key to choose Select Switch Repeat
Delay,and then OK to open the screen, as shown below.
Press the ◄soft key several times to shorten the time delay between repeats, or press
the ►soft key several times to lengthen the repeat delay time.
Press the Set soft key to set the repeat delay time and exit the screen.
Figure 34 Select Switch Repeat Delay settings and soft keys

Rosen Aviation 10.4” Display on Manual Lift
Document Number: 101844
Revision: D
Date: 05/20/10
Template: 4.2.3-6-FM; Revision A; 16 May, 2005
Page 20 of 25
4.3.6. Information
To review the operating status information about the display, open the Technician Menu,
press the ▼soft key to select Information, and then press OK. Press Back to close the
screen.
Figure 35 Read-only screen about the display’s operating status
B. SDI mode
A. Composite mode
