Aurora ASP-44-4K User manual

i
USERS GUIDE
Manual Number: 150217
ASP-44-4K
4x4 4K HDMI Matrix

i
User Guide
SAFETY INSTRUCTIONS
Please review the following safety precautions. If this is the first time using this model, then read this manual
before installing or using the product. If the product is not functioning properly, please contact your local
dealer or Aurora for further instructions.
The lightning symbol in the triangle is used to alert you to the presence of dangerous voltage
inside the product that may be sufficient to constitute a risk of electric shock to anyone opening
the case. It is also used to indicate improper installation or handling of the product that could
damage the electrical system in the product or in other equipment attached to the product.
The exclamation point in the triangle is used to alert you to important operating and maintenance
instructions. Failure to follow these instructions could result in injury to you or damage to the
product.
Be careful with electricity:
Power outlet: To prevent electric shock, be sure the electrical plug used on the product power cord
matches the electrical outlet used to supply power to the Aurora product. Use only the power adapter
and power connection cables designed for this unit.
Power cord: Be sure the power cord is routed so that it will not be stepped on or pinched by heavy
items.
Lightning: For protection from lightning or when the product is left unattended for a long period,
disconnect it from the power source.
.
Also follow these precautions:
Ventilation: Do not block the ventilation slots if applicable on the product or place any heavy object on
top of it.
Blocking the air flow could cause damage. Arrange components so that air can flow freely. Ensure that
there is adequate ventilation if the product is placed in a stand or cabinet. Put the product in a properly
ventilated area, away from direct sunlight or any source of heat.
Overheating: Avoid stacking the Aurora product on top of a hot component such as a power amplifier.
Risk of Fire: Do not place unit on top of any easily combustible material, such as carpet or fabric.
Proper Connections: Be sure all cables and equipment are connected to the unit as described in this
manual.
Object Entry: To avoid electric shock, never stick anything in the slots on the case or remove the cover.
Water Exposure: To reduce the risk of fire or electric shock, do not expose to rain or moisture.
Cleaning: Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the
device before cleaning.
ESD: Handle this unit with proper ESD care. Failure to do so can result in failure.
FCC
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interferences received, including interference that may cause undesired
operation.
Trademarks
All trademarks in this document are the properties of their respective owners.

ii
User Guide
TABLE OF CONTENTS
PACKAGE CONTENTS.............................................................................................................1
INTRODUCTION........................................................................................................................2
About..................................................................................................................................................... 2
Features................................................................................................................................................ 2
Front ASP-44-4K................................................................................................................................... 3
Rear ASP-44-4K ................................................................................................................................... 4
APPLICATION...........................................................................................................................5
ASP-44-4K Application ......................................................................................................................... 5
OPERATION..............................................................................................................................6
Routing.................................................................................................................................................. 6
EDID ..................................................................................................................................................... 6
Presets.................................................................................................................................................. 6
WEB SERVER...........................................................................................................................7
Web Browser Control............................................................................................................................ 7
SERIAL COMMANDS................................................................................................................8
RS-232 & Telnet Commands................................................................................................................ 8
APPENDIX 1 Troubleshooting...........................................................................................11
APPENDIX 2 Technical Specifications..............................................................................12
APPENDIX 3 Warranty .......................................................................................................13

1
User Guide
PACKAGE CONTENTS
Please make sure the following items are included within your package. Contact your dealer if any items
are missing or damaged.
ASP-44-4K x 1
1 12v DC Desktop Power Supply
Note: Go to www.auroramm.com for latest manual and firmware

2
User Guide
INTRODUCTION
About
The ASP-44-4K is an 4x4 4K HDMI Matrix offering the power and flexibility you need at a cost
effective price. Route Ultra High Definition video sources and multi-channel digital audio from any
of the four (4) HDMI inputs to the any of the four (4) HDMI outputs at the same time. The front
keypad and LCD display are designed for easy operation and quick status of routing while the
integrated web control pages allow for remote control from any device with a web browser
(Tablets, Computers, Smartphones, etc.). LAN and RS-232 ports have advanced protocols
allowing hot plug detection, signal detection, EDID table loading/recalling, presets, and more.
The advanced protocol features and integrated web control make the ASP-44-4K perfect for
commercial applications with auto switching, digital signage with device detection, or residential
systems with home automation.
Features
Resolutions up to 4K2K @ 30Hz
HDMI 3D Compliant
HDCP Compliant
Allows any source to be displayed on multiple displays at the same time
Allows any HDMI display to view any HDMI source at any time
Supports 7.1 channel digital audio
Advanced EDID Functions
Built in Web Control Pages
Easy installation with rack-mounting
Front LCD Status Display

3
User Guide
Front ASP-44-4K
Front
LCD Display –Top row shows the input routed to relative Output number below.
Power LED –When power is applied to the unit and the rear switch is set to the on position
the LED will illuminate.
EDID Auto –If the EDID is set to automatically learn the output the LED will be lit.
EDID Manual –If the EDID has been manually set to a specific EDID from an output the LED
will light accordingly.
Route –Press this button at the end of setting up the Input and Output for the route to take
place.
Input –Press this to choose the Input to route to an Output(s). If no number is pressed it will
unroute the current source routed to the selected output(s). If an Input is selected, pressing
the same input number will deselect. If input is selected after an output was selected first
then you can choose which inputs will store the associated outputs EDID.
Output –After the input is selected press the Output button to choose one or more outputs to
route to. If output is selected first then it will allow for a single output to save its EDID to one
or more inputs.
1-4 –Input/output number selections
Save –Preset save function. Press Save then a number to store a preset into one of the 4
locations of the current routing setup.
Recall –Preset recall function to restore a saved preset from one of the 4 stored presets.
EDID –Press this after the Output then Input has been set up for EDID learning.

4
User Guide
Rear ASP-44-4K
Rear Connections
LAN –Server up the built in web page control with a web browser or control remotely using
Telnet.
RS232 –Connect RS-232 device up at 9600 baud for remote control.
Inputs 1-4 –Four HDMI inputs for a variety of sources up to 4K resolutions.
Outputs 1-4 –Four HDMI outputs for a variety of destinations up to 4K resolutions.
DC12V –Connect the included 12v DC desktop style power supply.
OFF/ON –Power switch for turning the ASP-44-4K on or off.

5
User Guide
APPLICATION
ASP-44-4K Application
4x HDMI Input
PC or Laptop
4x HDMI Output
PS3
HDMI camcorder
HDMI cables or
HDMI extenders
Blu-ray disc player
HDTV
HDMI projector
HDMI monitor

6
User Guide
OPERATION
Routing
To route a source to a source to a destination(s):
Step 1. Press Input
Step 2. Press desired input number correlating to the rear of the unit’s HDMI input. If no route is required
then do not press a number. If a number has been pressed and you wish to deselect press the same
number again.
Step 3. Press Output followed the output number(s) correlating to the rear of the unit’s HDMI output(s).
Step 4. Press Route for the selections to take.
EDID
Step 1. Press Output than a number of an Output to select the EDID of the destination to be learned and
saved into an input(s).
Step 2. Press Input followed by the HDMI input number(s) to store the EDID.
Step 3. Press EDID and the information will be stored to the selected inputs.
Note: More advanced EDID functions can be done through the Serial or LAN interface commands.
Presets
To save a preset:
Step 1. Setup the routing as desired.
Step 2. Press Save.
Step 3. Press desired preset number 1-4 to store the preset.
To recall a preset:
Step 1. Press Recall
Step 2. Press the desired number of the preset location to be recalled.

7
User Guide
WEB SERVER
Web Browser Control
The ASP-44-4K has a built in Web Control Interface. By typing into a browser’s address bar the
IP address of the ASP-44-4K a password screen will appear. Factory default is ten zeros
0000000000. Once entered the routing page will appear. It will allow the routing of sources and
the recalling and saving of presets. In addition, the password and firmware updates can be
done as well.
Note: IPAddress is set by the RS-232 command.

8
User Guide
SERIAL COMMANDS
RS-232 & Telnet Commands
Baud Rate: 9600 8N1 DB9 Female (Pins 2-TX, 3-RX, 5-GND), Straight through Cable to PC
!is the start character to active a command
?is the start character to query status
~is the start character of the response
/x0D (<cr> aka carriage return) is the end character
Commands are not case sensitive.
Command
String Format
Information
Route
Command
!RTx1 x2 x3 x4<cr>
x1-x4 = output relative to input.
Example: !RT314x<cr>
0 = Unroute
X = ignore (do nothing)
In this example
Output 1 is routed to 3
Output 2 is routed to 1
Output 3 is routed to 4
Output 4 is ignored and left alone
Response:
~RTx1 x2 x3 x4<cr>
Preset Recall
!PRx<cr>
x = 1-4
Responds: ~Px<cr>
Preset Store
!PSx<cr>
x = 1-4
Responds: ~PSx<cr>
Query Route
?RT<cr>
Responds with ~RTx1 x2 x3 x4<cr>
x1-x4 = output relative to input. Example: Output
1 is routed to input 3 so position x1 would equal 3.
If nothing is routed to an output then the value
will be 0 (zero).
Firmware
Version
?VR<cr>
Responds with the current firmware version
number
Example ~VR1.00<cr>
Factory Default
!FD<cr>
Responds with ~FD<cr>
IP Address
!IPA-xxx.xxx.xxx.xxx<cr>
x= IP Address ex. 192.168.1.13
Responds with ~IPA-xxx.xxx.xxx.xxx<cr>
EDID Write
!EDWx-y0 y1…y255<cr>
x= HDMI Input 1-4
y0-y255 = EDID Data in ASCII HEX representation
EDID Read
?EDRx<cr>
x= HDMI Input 1-4
y0-y255 = EDID Data in ASCII HEX representation
Response: ~EDIDx-y0 y1…y255<cr>

9
User Guide
y0-y255 = EDID Data in ASCII HEX representation
EDID Learn
!EDLx1 x2 x3 x4<cr>
x1-x4 = output relative to input.
Example: !EDL312x<cr>
0 = Clear EDID
X = ignore (do nothing)
F = Factory EDID default
In this example
Input 1 gets output 3 EDID
Input 2 gets output 1 EDID
Input 3 gets output 2 EDID
Input 4 is ignored and left alone
Response:
~EDLx1 x2 x3 x4<cr>
Factory default EDID should be 1080p 24bit stereo
Front Keypad
Lockout
!KLx<CR>
x = (1=ON, 0=OFF)
Response: ~KL<cr>
HDCP Input
On/Off
!HDCPIN x1 x2 x3 x4<CR>
x1-x4 = Input relative to HDCP function.
0 = HDCP is forced off. This helps with devices that
always have HDCP on unless it sees there is no key
to exchange.
1 = HDCP is available
Note: Default is HDCP Available
Hotplug Input
Detect
?HPIN<cr>
Detects and reports back if a signal is present at a
specific input. It will also send the response back
automatically if there is a change in state.
Response: ~HPIN x1 x2 x3 x4<cr>
0 = nothing
1 = signal
Hotplug Output
Detect
?HPOUT<cr>
Detects and reports back if a device present at a
specific output. It will also send the response back
automatically if there is a change in state.
Response: ~HPOUT x1 x2 x3 x4<cr>
0 = nothing
1 = signal
Note 1: Upon power up or detection of a new device on an output the port should read the EDID to see if
it is DVI connected and if so remove the audio automatically for proper compatibility. This way if the input
EDID is HDMI the HDMI will still work with ports that have DVI connected.
Note 2: If change is made from front panel the appropriate response command should be sent out. For
example if a route was made then the ~RTx1 x2 x3 x4<cr> should be sent automatically. This way polling

10
User Guide
is not required.
Note 3: If an input has no HDCP then the output should not have HDCP either unless the force HDCP
command is enable.

11
User Guide
APPENDIX 1 Troubleshooting
Problem
Solution
1. LED is not lit on any LEDs or
buttons
a. Check 12v power supply is plugged in rear of unit
b. Check to see if Wall supply is plugged into wall outlet.
c. Make certain wall outlet has power.
d. Make certain switch on rear of unit is on.
2. RS-232 does not work
a. Check connection on RS-232 port. Make certain TX goes to RX and
RX goes to TX of the device to be connected. Don’t forget about
ground.
b. Check baud rate.
c. Verify commands being sent are correct protocol.
3. Some functions do not work
a. Make certain unit has latest firmware.

12
User Guide
APPENDIX 2 Technical Specifications
Model Name
ASP-44-4K
Technical
ASP-44-4K
RS-232 Baud Rate
9600 8N1
DB9 Female (Pins 2-TX, 3-RX, 5-GND), Straight through Cable to PC
Front Panel
Blue Backlit LCD and Selection Keys
Bandwidth
340MHz
Resolutions
480i / 480p / 720p / 1080i / 1080p60 8-12 bit color / 3840x2160 @ 30Hz / 4Kx2K @
30Hz
HDCP Compliant
Yes
HDMI Output Distance
1080p up to 25m, 4K up to 15m (Note: Cable quality may impact distance)
HDMI Connector
Type A (19 Pin Female)
RS-232 Connector
DB-9 Female
LAN Port
RJ-45 (Telnet Communications)
Mechanical
ASP-44-4K
Housing
Aluminum enclosure
Dimensions
[L x W x D]
8.66" x 17" x 1.7" [220 x 430 x 44mm]
Weight
7.2lbs (3.25kg}
Mounting
1RU Rack Mount 19” x 1.75”
Power supply
12v 3A DC
Power consumption
20 Watts [max]
Operation temperature
0~40C [32~104F]
Storage temperature
-20~60C [-4~140F]
Relative humidity
20~90% RH [no condensation]
Package Contents
1x ASP-44-4K
1x 12v Desktop Power Supply
Specifications subject to change without notice.

13
User Guide
APPENDIX 3 Warranty
Limited 3 Year Warranty
Aurora Multimedia Corp. (“Manufacturer”) warrants that this product is free of defects in both materials and
workmanship for a period of 3 years as defined herein for parts and labor from date of purchase. This Limited Warranty
covers products purchased in the year of 2009 and after. Motorized mechanical parts (Hard Drives, DVD, etc),
mechanical parts (buttons, doors, etc), remotes and cables are covered for a period of 1 year. Touch screen displays
are covered for 1 year; touch screen overlay components are covered for 90 days. Supplied batteries are not covered
by this warranty. During the warranty period, and upon proof of purchase, the product will be repaired or replaced (with
same or similar model) at our option without charge for parts or labor for the specified product lifetime warranty period.
This warranty shall not apply if any of the following:
A. The product has been damaged by negligence, accident, lightning, water, act-of-God or mishandling; or,
B. The product has not been operated in accordance with procedures specified in operating instructions: or,
C. The product has been repaired and or altered by other than manufacturer or authorized service center; or,
D. The product's original serial number has been modified or removed: or,
E. External equipment other than supplied by manufacturer, in determination of manufacturer, shall have
affected the performance, safety or reliability of the product.
F. Part(s) are no longer available for product.
In the event that the product needs repair or replacement during the specified warranty period, product should be
shipped back to Manufacturer at Purchaser's expense. Repaired or replaced product shall be returned to Purchaser
by standard shipping methods at Manufacturer's discretion. Express shipping will be at the expense of the Purchaser.
If Purchaser resides outside the contiguous US, return shipping shall be at Purchaser's expense.
No other warranty, express or implied other than Manufacturer's shall apply.
Manufacturer does not assume any responsibility for consequential damages, expenses or loss of revenue or property,
inconvenience or interruption in operation experienced by the customer due to a malfunction of the purchased
equipment. No warranty service performed on any product shall extend the applicable warranty period. This warranty
does not cover damage to the equipment during shipping and Manufacturer assumes no responsibility for such
damage.

14
User Guide
This product warranty extends to the original purchaser only and will be null and void upon any assignment or
Aurora Multimedia Corp.
205 Commercial Court
Morganville, NJ 07751
Phone: 732-591-5800 Fax: 732-591-6801
www.auroramm.com
Table of contents
Other Aurora Matrix Switcher manuals
Popular Matrix Switcher manuals by other brands

Comprehensive
Comprehensive CVG-606xl user manual

Extron electronics
Extron electronics DTP CrossPoint 4K Series user guide

Key Digital
Key Digital KD-MS8x8G-2 manual

KVMSwitchTech
KVMSwitchTech AB-4184 instruction manual

Rose electronics
Rose electronics UltraConsole Remote 2 Installation and operation manual

syncrotek
syncrotek NOXAUDIO MTX106 owner's manual
