Aussie AS-360P-IP User manual

- 1 -
Installation Warning
Do not touch the camera during lighting storm.
Do not drop the camera when installing.
Power off the camera as soon as possible when the smoke or
abnormal odors are detected.
Please place the camera tight and steady.
Do not strike the camera when installing.
Do not abrade the transparent case of the camera.
Package Contents
Fisheye Panoramic Camera
1pcs
Plastic Bag
1pcs
Screws
3pcs
Installation Guide
1pcs
Software CD
1pcs
Warranty Card
1pcs
Installation Sticker
1pcs
Plastic Anchors
3pcs
Focus Tool
1pcs

- 2 -
Physical Description
Front View
Power LED: always Red, it will light up after connecting the power
supply.
Network LED: Green, it will light up after connecting the power
supply, and it will be blink when the network is workable.
Reset Button: Use a sharp and thin stick to push the button with 5
seconds to reset the IP address to default. Only the IP address will
be reset.
Side View
Speaker
Lens
Network LED
Power LED
Mic
Reset Button
Mounting
Holes
Cover
Lens
FOV Top Arrow

- 3 -
Top Arrow: it shows the direction of the camera video for wall
installation. Please keep the arrow toward the ceiling when the
camera is stalled on a wall.
Vertical View
Connector Define
Connector Define
Back
Cover
Mounting
Holes
TF card slot
Line
Outlet
DC12V
Jack
Network
RJ45

- 4 -
Dimension (Unit: mm)
Installation Steps
TF card install
Please refer to the instruction to plug in or plug out the TF card. And
the TF card installation must be completed before the camera
installation.
TF card slot
Plug in Plug out

- 5 -
1. Attach the installation sticker to the ceiling/wall. Please check the
arrow direction. The arrow should be kept the same direction with
the Top arrow on the camera case when installing on the wall.
2. Drilling 3 pilot mounting holes and a cable hole according the
circles on the sticker. The diameter of mounting hole is 7mm. Then
hammer the 3 plastic anchors into the mounting holes. The cable
hole should bigger enough to feed the cable though the hole.
3. Feed the external Ethernet and power cable though the cable
hole, and connect the cables to the camera connector. Please
make sure the connecting is firm.
4. Check the arrow direction of the camera, keep it as same as the
arrow of attached sticker. Secure the screws and please make sure
the camera is securely installed.
Ceiling and wall mount
The recommend wall installation height is about 2.5 to 3 meters.
Notice: Please confirm the installation FOV before mount the
camera on the wall, and keep the Top arrow on the camera is
towards the ceiling.
5. Angle modify

- 6 -
Rotate the camera body to modify the FOV, the maximum rotating
angle is 20°.
6. Focus modify
If the camera image is not clear enough, please use the focus
modify tool in the package to plug into the two small holes beside
with the lens, then open the live view and the same time rotate the
lens to focus the image.
Rotate to focus
TF card
Plug in Plug out
Focus
Focus modify holes
Rotate to focus

- 7 -
Panoramic camera typical application
Connect the power supply and network of the panoramic camera
and power on when all the connecting has been done. Please
accord to the label of the power supply connector to connecting the
DC 12V power.
NVR
Network Cable
PCMS
PC
Power DC12V
Switch
Panoramic camera typical application connecting diagram

- 8 -
IP Setting
The default IP address of each network panoramic camera is
192.168.0.123. According the network system different, the camera
IP address maybe need to be changed to the same range of the
network system, or the operating will fail.
It is recommended to change the control computer’s IP address to
192.168.0.xxx at first, and connect the camera into the same
network system with the computer. Then open the panoramic
camera software or open the IE explorer to modify the camera IP
address.
Open the explorer and input the address 192.168.0.123, download
and install the Web plug in component.
When the first time use the IE explorer to login on the camera,
maybe it need to setting the ActiveX . Please set all the ActiveX
relative items to Enable or Prompt.
Steps: IE ExplorerInternet OptionsSecurity Custom level.
Input the user name and the password after get into the login
window. The default user name is “admin”, and the password is
“123456”.
Click the “Config” to remote setting window, click the Network
setting to change the IP address. Please save the new IP address
after changed. Then please waiting the camera auto restart to
active the new IP address.
