Austin Hughes Electronics CyberView DB-15-IP802H User manual

UM-CV-751-USBKVM-KIT-Q215V3 www.austin-hughes.com
Designed and manufactured by Austin Hughes 751
dedicated KVM switch and rackmount screen technology
back
back
back
User Manual - KVM Rear Kit Version
for LCD Console Drawer
USB Hub DB-15 KVM
USB Hub DB-15 KVM
USB Hub DB-15 2-console KVM -802H
-1602H
-IP802H
-IP1602H
-801H
-1601H

UM-CV-751-USBKVM-KIT-Q215V3 www.austin-hughes.com
Legal Information
First English printing, October 2002
Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness
of the contents. The information in this document is subject to change without notice. We are not liable for any injury or
loss that results from the use of this equipment.
Safety Instructions
Please read all of these instructions carefully before you use the device. Save this manual for
future reference.
■Unplug equipment before cleaning. Don’t use liquid or spray detergent; use a moist cloth.
■Keep equipment away from excessive humidity and heat. Preferably, keep it in an air-conditioned environment with
temperatures not exceeding 40º Celsius (104º Fahrenheit).
■When installing, place the equipment on a sturdy, level surface to prevent it from accidentally falling and causing
damage to other equipment or injury to persons nearby.
■When the equipment is in an open position, do not cover, block or in any way obstruct the gap between it and the
power supply. Proper air convection is necessary to keep it from overheating.
■Arrange the equipment’s power cord in such a way that others won’t trip or fall over it.
■If you are using a power cord that didn’t ship with the equipment, ensure that it is rated for the voltage and current
labeled on the equipment’s electrical ratings label. The voltage rating on the cord should be higher than the one listed
on the equipment’s ratings label.
■Observe all precautions and warnings attached to the equipment.
■If you don’t intend on using the equipment for a long time, disconnect it from the power outlet to prevent being
damaged by transient over-voltage.
■Keep all liquids away from the equipment to minimize the risk of accidental spillage. Liquid spilled on to the power
supply or on other hardware may cause damage, fire or electrical shock.
■Only qualified service personnel should open the chassis. Opening it yourself could damage the equipment and
invalidate its warranty.
■If any part of the equipment becomes damaged or stops functioning, have it checked by qualified service personnel.
What the warranty does not cover
■Any product, on which the serial number has been defaced, modified or removed.
■Damage, deterioration or malfunction resulting from:
□Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product modification, or
failure to follow instructions supplied with the product.
□Repair or attempted repair by anyone not authorized by us.
□Any damage of the product due to shipment.
□Removal or installation of the product.
□Causes external to the product, such as electric power fluctuation or failure.
□Use of supplies or parts not meeting our specifications.
□Normal wear and tear.
□Any other causes which does not relate to a product defect.
■Removal, installation, and set-up service charges.
Regulatory Notices Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation.
Any changes or modifications made to this equipment may void the user’s authority to operate this equipment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
■Re-position or relocate the receiving antenna.
■Increase the separation between the equipment and receiver.
■Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

UM-CV-751-USBKVM-KIT-Q215V3 www.austin-hughes.com
-801H -1601H
3.1 Package contents
3.2 KVM port connection
3.3 Built-in USB hub usage & connection
3.4 Specifications
-IP802H -IP1602H
1.1 Package contents
1.2 KVM port connection
1.3 IP console connection
1.4 IP console setting
1.5 Important Preconfiguration for IP console
1.6 Built-in USB hub usage & connection
1.7 Specifications
-802H -1602H
2.1 Package contents
2.2 KVM port connection
2.3 Remote console connection
2.4 Built-in USB hub usage & connection
2.5 Specifications
Contents
4.1 KVM Button
4.2 Password
4.3 KVM OSD
4.4 KVM Hotkey & Remote Console Hotkey
4.5 DC Power Option : 12V / 24V / 48V / 110 ~ 125V
4.6 Resolution Support Information
< Part 1 > USB Hub DB-15 2-console KVM
< Part 2 > USB Hub DB-15 2-console KVM
P. 1
P. 2
P.2
P. 3
P.4 - 5
P. 6
P. 7
P. 8
P. 9
P.9 - 10
P. 11
P.12
< Part 4 > Usage
< Part 3 > USB Hub DB-15 KVM
P.13
P.14
P.15
P.16
P.17
P.18
P.19
P.20
P.21
P.22

UM-CV-751-USBKVM-KIT-Q215V3 www.austin-hughes.com
back
KVM Rear Kit
-IP802H
-IP1602H
The power of the KVM rear kit may be changed to external power design
based on the LCD console drawer series and model.
-IP802H
-IP1602H
P. 1
< 1.1 > Package Contents USB Hub DB-15 IP KVM
< Part 1 > USB Hub DB-15 KVM
Daisy-chain feature for this model is NOT available.
Flash
2 x USB 2.0
( USB hub for device connection )
12VDC

UM-CV-751-USBKVM-KIT-Q215V3 www.austin-hughes.com
I
n
t
e
r
n
e
t
I
n
t
e
r
n
e
t
Drawer KVM Rear Kit
CAT 5 / 6 cable
max. 100m
Network device
hub or router
CB-6 / CB-10 / CB-15
■6 / 10 / 15 ft USB KVM cable
■Support USB server
< 1.2 > KVM port connection
P. 2
< 1.3 > IP console connection
USB Hub DB-15 IP KVM
DB-15 USB KVM port
USB Servers
USB Servers
CB - 6 / 10 / 15 USB KVM cable
support USB server
Drawer KVM Rear Kit

UM-CV-751-USBKVM-KIT-Q215V3 www.austin-hughes.com
After the cable connection, please take the following steps to configure the IP KVM :
1. Download IPKVMsetup.exe from the link:
www.austin-hughes.com/support/utilities/cyberview/IPKVMsetup.exe
2. Double click IPKVMsetup.exe to configure the IP KVM by device setup as below.
< 1.4 > IP console setting
- http://192.168.1.22
11. Open Internet Explorer ( I.E. ), version 6.0 or above
12. Enter the IP KVM address into the address bar
- For Single IP - http://192.168.1.22
13. Enter username ( default is super )
Password ( default is pass )
14. After successful login to IP KVM, the user will enter the main page of IP KVM
The setting is enough for intranet.
If the users access KVM GUI via internet, please ask MIS for assistance and
download IP KVM user manual from the link :
www.austin-hughes.com/support/usermanual/cyberview/UM-CV-IP.pdf
3. Click Refresh Device to search the connected IP KVM
4. Select the M.A.C. address, which you want to setup, then click Query Device
5. Enter Super user login. The default is super
6. Enter Super user password. The default is pass
7. Enter the new super user password
8. Re-enter the new password
9. Change the desired IP address / Subnet mask / Gateway, then click Setup Device to confirm the setting to IP KVM
10. The default address is as below:--
■The single IP KVM model, such as IP-1602H
P. 3
USB Hub DB-15 IP KVM

UM-CV-751-USBKVM-KIT-Q215V3 www.austin-hughes.com
< 1.5 > Important Preconfiguration for IP console USB Hub DB-15 IP KVM
P. 4
( 1 ) TARGET SERVER SETUP
Resolution
The IP KVM remote console recognizes several varieties of video display formats with resolutions up to 1600 x
1200 @60Hz. (Refer to the User Manual for a list of supported video formats). Minimize bandwidth by setting the
target server’s video resolution to the minimum setting required for your remote monitoring application.
The following video modes are recommended:
(i) 800 x 600 @ 60Hz
(ii) 1024 x 768 @ 60Hz
(iii) 1280 x 1024 @ 60Hz
On a Windows target server system, select Control Panel > Display > Settings.
Modify the screen resolution value as necessary.
Mouse
Use generic mouse drivers for optimum mouse control during remote sessions. Set the mouse pointer speed to a
middle setting with no acceleration or snap-to effects.
On a Windows target server system, select Control Panel > Mouse > Pointer Options
Set the pointer speed to medium and disable Enhanced pointer precision
For Linux GUIs, set the mouse acceleration to exactly 1 and the threshold to exactly 1.
You must complete the following tasks after the IP console setting is performed.
If your keyboard keeps repeating keys when it is plugged into the KVM. Please follow either one below :
( a. )
Enable key release timeout if you experience duplicated keystrokes during poor network performance.
- login to IP KVM remote console
- go to Interfaces KVM settings > Keyboard / Mouse
- click the Key Release Timeout
- adjust Timeout after if necessary
( b. )
Reduce video bandwidth usage if you experience duplicated keystrokes during poor network
- login to IP KVM remote console
- go to Interfaces KVM Settings > User Console > Transmission Encoding,
- select Manually
- adjust Compression to [ 0-none ] and Color depth to [ 8-bit – 256 col ]
**Servers connected to KVM

UM-CV-751-USBKVM-KIT-Q215V3 www.austin-hughes.com
USB Hub DB-15 IP KVM
< 1.5 > Important Preconfiguration for IP console
P. 5
JAVA Security Issue
Due to the changes from Java security, customer may facing the "JAVA Block" message while
accessing the remote console over IP.
If it said so, here is the workaround solution :
Customer can use the "Exception Site list" feature to run the applications blocked by security setting.
Adding the URL of the blocked application to the Exception Site list allows it to run with some warnings.
Steps to Add URLs to the Exception Site list :
■Go to the Java Control Panel ( On Windows Click Start and then Configure Java )
■Click on the Security tab
■Click on the Edit Site List button
■Click Add in the Exception Site List window
■Click in the empty field under the Location field to enter the URL ( URL should begin with http:// or https:// )
( 2 ) REMOTE CLIENT COMPUTER SETUP
The remote client computer must have a web browser ( such as Microsoft Internet Explorer, Mozilla Firefox,
and Netscape Navigator ) and a Java Virtual Machine ( version 1.4 or higher ) installed. Enable Java on the
web browser.

UM-CV-751-USBKVM-KIT-Q215V3 www.austin-hughes.com
P. 6
< 1.6 > Built-in USB Hub Usage & Connection USB Hub DB-15 IP KVM
2 x USB 2.0 ( USB hub for device connection )
Printer
Scanner
Flash Disk
Keyboard / Mouse
Hard disk storage
Camera

UM-CV-751-USBKVM-KIT-Q215V3 www.austin-hughes.com
< 1.7 > Specifications
P. 7
-IP802H -IP1602H
▀KVM Port
Number of ports: 8 or 16
Connector: DB-15 combo connector
Connectivity: Combo 2-in-1 VGA + USB KVM cable, 6, 10 or 15 feet
▀Local Console LCD console drawer version ( up to 1920 x 1080 / 1920 x 1200 )
▀USB Hub 2 x USB type A for sharing other peripheral devices among the computers
▀IP Remote Console
Connector: RJ45 Ethernet
User management: 15-user login, 1 x active user
Network protocol: DHCP / BOOTP / DNS
Security: SSL v3, RSA, AES, HTTP / HTTPs, CSR
Resolution: Up to 1600 x 1200
Browser: IE, Firefox, Safari, Netscape
▀Compatibility
Multi-platform: Mix PCs, SUN and Mac G3 / G4 Mac / iMac
Support: Windows 7 / Vista / 2003 / XP, Linux, Unix
▀Power
Input: Auto sensing 100 to 240VAC, 50 / 60 Hz
Option DC: 12V / 24V / 48V / 110 ~ 125V DC input
Consumption: Max. 48 Watt, Standby 5 Watt
▀Regulatory
Safety: FCC & CE certified
Environment: RoHS2 & REACH compliant
▀Environmental
Operating: 0 to 55°C
Storage: -5 to 60°C
Relative humidity: 90%, non-condensing
Shock: 50G peak acceleration (11ms, half-sine wave)
Vibration: 58~100Hz / 0.98G (11ms / cycle)
USB Hub DB-15 IP KVM

UM-CV-751-USBKVM-KIT-Q215V3 www.austin-hughes.com
< 2.1 > Package Contents
P. 8
Part 2. USB Hub DB-15 2-console KVM
USB Hub DB-15 2-console KVM
-802H
-1602H
Daisy-chain feature for this model is NOT available.
Remote
2 x USB 2.0
( USB hub for device connection )
12VDC
• Receiver box for remote console x 1
• Power adapter w/ power cord ( for receiver ) x 1
• CE-6 6ft Combo KVM cable for receiver box x 1
back
KVM Rear Kit
The power of the KVM rear kit may be changed to external power design
based on the LCD console drawer series and model.
-802H / -1602H

UM-CV-751-USBKVM-KIT-Q215V3 www.austin-hughes.com
Remote
USB console
Remote
Cat6
Console
CAT 5 / 6 cable
max. 150m
Receiver
Drawer KVM Rear Kit
CB-6 / CB-10 / CB-15
■6 / 10 / 15 ft USB KVM cable
■Support USB server
DB-15 USB KVM port
USB Servers
USB Servers
CB - 6 / 10 / 15 USB KVM cable
support USB server
USB Hub DB-15 2-console KVM
< 2.2 > KVM port connection
P. 9
< 2.3 > Remote console connection
Drawer KVM Rear Kit

UM-CV-751-USBKVM-KIT-Q215V3 www.austin-hughes.com
How to use a receiver to connect a remote console
Receiver
K/B Mouse Local Remote
Local
Computer Monitor
Power
USB
Remote I/O
Monitor
CE-6
Combo
KVM cable
Cat6 cable
up to 150m
12V DC Power
Adapter
Local computer
( Optional setup )
VGA
cable
Remote
Console
Button
to
PC
Button
to
KVM switch
P.10
The receiver provides a hotkey function for remote console. Please refer to P.18
Front
Rear
Front
Rear
USB Hub DB-15 2-console KVM
Drawer KVM Rear Kit

UM-CV-751-USBKVM-KIT-Q215V3 www.austin-hughes.com
2 x USB 2.0 ( USB hub for device connection )
Printer
Scanner
Flash Disk
Keyboard / Mouse
Hard disk storage
Camera
< 2.4 > Built-in USB Hub Usage & Connection USB Hub DB-15 2-console KVM
P. 11

UM-CV-751-USBKVM-KIT-Q215V3 www.austin-hughes.com
-802H -1602H
▀KVM Port
Number of ports: 8 or 16
Connector: DB-15 combo connector
Connectivity: Combo 2-in-1 VGA + USB KVM cable, 6, 10 or 15 feet
▀Local Console LCD console drawer version ( up to 1920 x 1080 / 1920 x 1200 )
▀USB Hub 2 x USB type A for sharing other peripheral devices among the computers
▀Remote Console
Connector: 1 x DB 15-pin, VGA
Resolution: Up to 1600 x 1200
Input device: 2 x USB type A for keyboard & mouse
Remote I/O: RJ45 via Cat5 / Cat5e / Cat6 cable up to 150m
Compensation: Auto adjust for cable length
▀Compatibility
Multi-platform: Mix PCs, SUN and Mac G3 / G4 Mac / iMac
Support: Windows 7 / Vista / 2003 / XP, Linux, Unix
▀Power
Input: Auto sensing 100 to 240VAC, 50 / 60 Hz
Option DC: 12V / 24V / 48V / 110 ~ 125V DC input
Consumption: Max. 48 Watt, Standby 5 Watt
▀Regulatory
Safety: FCC & CE certified
Environment: RoHS2 & REACH compliant
▀Environmental
Operating: 0 to 55°C
Storage: -5 to 60°C
Relative humidity: 90%, non-condensing
Shock: 50G peak acceleration (11ms, half-sine wave)
Vibration: 58~100Hz / 0.98G (11ms / cycle)
< 2.5 > Specifications USB Hub DB-15 2-console KVM
P.12

UM-CV-751-USBKVM-KIT-Q215V3 www.austin-hughes.com
-801H / -1601H
KVM Rear Kit
The power of the KVM rear kit may be changed to external power design
based on the LCD console drawer series and model.
< 3.1 > Package Contents
P.13
Part 3. USB Hub DB-15 KVM
USB Hub DB-15 KVM
-801H
-1601H
Daisy-chain feature for this model is NOT available.
2 x USB 2.0
( USB hub for device connection )
12VDC
back

UM-CV-751-USBKVM-KIT-Q215V3 www.austin-hughes.com
CB-6 / CB-10 / CB-15
■6 / 10 / 15 ft USB KVM cable
■Support USB server
DB-15 USB KVM port
USB Servers
USB Servers
CB - 6 / 10 / 15 USB KVM cable
support USB server
Drawer KVM Rear Kit
< 3.2 > KVM port connection USB Hub DB-15 KVM
P.14

UM-CV-751-USBKVM-KIT-Q215V3 www.austin-hughes.com
2 x USB 2.0 ( USB hub for device connection )
Printer
Scanner
Flash Disk
Keyboard / Mouse
Hard disk storage
Camera
P.15
< 3.3 > Built-in USB Hub Usage & Connection USB Hub DB-15 KVM

UM-CV-751-USBKVM-KIT-Q215V3 www.austin-hughes.com
P.16
< 3.4 > Specifications
-801H -1601H
▀KVM Port
Number of ports: 8 or 16
Connector: DB-15 combo connector
Connectivity: Combo 2-in-1 VGA + USB KVM cable, 6, 10 or 15 feet
▀Local Console LCD console drawer version ( up to 1920 x 1080 / 1920 x 1200 )
▀USB Hub 2 x USB type A for sharing other peripheral devices among the computers
▀Management
Multilingual OSD: English, France, German, Spanish, Italian, Russian, Simplified Chinese,
Japanese
Hotkey combination: Scroll-lock, Cap-lock, Num-lock, Alt, Ctrl & Win
Security: Password enable & disable, up to 8 users profile for port access
PC Selection: Front button, OSD menu & hotkey
▀Compatibility
Multi-platform: Mix PCs, SUN and Mac G3 / G4 Mac / iMac
Support: Windows 7 / Vista / 2003 / XP, Linux, Unix
▀Power
Input: Auto sensing 100 to 240VAC, 50 / 60 Hz
Option DC: 12V / 24V / 48V / 110 ~ 125V DC input
Consumption: Max. 48 Watt, Standby 5 Watt
▀Regulatory
Safety: FCC & CE certified
Environment: RoHS2 & REACH compliant
▀Environmental
Operating: 0 to 55°C
Storage: -5 to 60°C
Relative humidity: 90%, non-condensing
Shock: 50G peak acceleration (11ms, half-sine wave)
Vibration: 58~100Hz / 0.98G (11ms / cycle)
USB Hub DB-15 KVM
