AUSTRALIAN MONITOR F300 User manual

Australian Monitor
F300
FLOOR MONITOR
The F300 is a high power fullrange 2way passive loudspeaker system designed for as a compact, low profile floor
monitor. Ideal for a multitude of critical professional audio applications where compact size, low distortion and
high output capability are the major considerations. The compact size and the two seperete wedge angles of
cabinet construction, allow for differing stage sizes, with well controlled accuracy and predictable dispersion
characteristics.
Avoiding the need for ancillary control electronics, the passive F300 provides high dynamic, high efficiency
output from an ultra compact enclosure. The two way system utilizes a co-axial 380mm (15") low frequency
driver combined with a 25mm (1") compression driver mounted on the driver assembly,
Complex and robust in design and construction, the unique F300 T.{etwork Manager' provides equalization for
both, horn / compression driver resonance and power response. Accurate filtering allows for a smooth transition
between low & high frequency drivers at the critical crossover point. The resulting smooth frequency response
and phase coherence provides well defined clarity and detail.
The F300 is fabricated from high density plywood with internal bracing, it comes supplied as standard with one
heavy duty handle. The steel grille is powder coated for durability and the enclosure is finished in heavy duty
black carpet with steel protective corners.
Frequency
Maximum SPL:
Impedance:
Bass Driver:
Compression Driver:
300 watts continuous program,
500 watts peak music program
lzldBpeak@ 500 watts
99dB lwatt/ I metre.
8 ohms nominal.
385mm (15")
Proprietary 25mm (1") throat.
60 x 40 degree constant directivity.
SPECIFICATIONS
60Hz - 15kHz +/- 3dB. Enclosure Type: Vented, High densrty plywood,
Floor monitorl.
Dual parallel SPEAKON or XLR.
Perforated steel powder coated.
WxHxD,550x450x460mm
32 Kgs
Grille:
Astibuted by
