AUSTRALIAN MONITOR QF6WRC User manual

INSTALLATION AND OPERATION MANUAL
QF6WRC
WATER RESISTANT CEILING SPEAKER

IMPORTANT SAFETY INFORMATION
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Clean only with dry cloth.
6. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
7. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
8. Only use attachments/accessories specified by the manufacturer.
9. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.
PRÉCAUTIONS DURANT UTILISATION
1. Lisez ces instructions.
2. Tenez ces instructions.
3. Notez tous les avertissements.
4. Suivez toutes les avertissements.
5. Nettoyez seulement avec une étoffe sèche.
6. Ne bloquez aucuns troux de ventilation. Installez en accord avec les instructions du manufacturier.
7. N’installez près aucunes sources de chaleur comme radiateurs, registres de chaleur, fours ou les autres équipements (y compris amplificateurs)
qui produisent la chaleur.
8. Seulement utilisez attachements/accessoires spécifiés par le manufacturier.
9. Référez au personnel qualifié de service pour toutes réparations. La réparation est donnée quand le système a été endommagé à n’importe façon,
par exemple un fil ou une fiche endommagé(e) de la source d’alimentation. Avoir été exposé à pluie ou humidité, n’opère pas normalement, ou avoir
été tombé.

QF6WRC
The Australian Monitor QF6WRC ceiling mount speaker is
designed to provide a water resistant option to complement
the outstanding QF quick fit range of Australian Monitor ceiling
speakers.
Being IP55 rated, the QF6WRC is the perfect option for areas that
may be exposed to damp conditions and moisture including bathrooms
and wet areas.
The QF6WRC is rated at 12 Watts at 8 Ohms with 100V power tappings
at 12, 9, 6, 3 and 1 Watts or 70V tappings at 6, 4.5, 3, 1.5 and 0.5
Watts and is perfect for speech or background music applications.
The speaker features a sealed ABS rear enclosure with a glanded
cable tail for easy installation. Mounting is by way of rotating
mounting tabs and the speaker features a 6” full range driver to
ensure water resistance and smooth operation.
The QF6WRC from Australian Monitor offers exceptional
versatility, performance and value for money. Version 2.0: November 2021
INTRODUCTION & CONTENTS
Introduction 3
Front Panel 4
Rear Panel 5
Mounting 6
Dimensions 8
Specifications 9
Frequency Response 10
Notes 11
Rating plate and caution marking are marked on the back enclosure of the apparatus
WARNING
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THE PLUG WITH AN EXTENSION CORD, RECEPTACLE
OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE
TO RAIN OR MOISTURE.
TO PREVENT ELECTRICAL SHOCK, MATCH WIDE BLADE PLUG TO WIDE SLOT & FULLY INSERT.
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT PERFORM ANY SERVICING OTHER THAN THAT
CONTAINED IN THE OPERATING INSTRUCTIONS UNLESS YOU ARE QUALIFIED TO DO SO.
The lightning flash with
arrowhead symbol, within
an equilateral triangle, is
intended to alert the user to
the presence of uninsulated
“dangerous voltage” within the
product’s enclosure that may
be of sufficient magnitude to
constitute a risk of electric
shock to persons.
WARNING
TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS
INSIDE. REFER SERVICING
TO QUALIFIED SERVICE
PERSONNEL.
The exclamation point
within an equilateral triangle
is intended to alert the user
to the presence of important
operating and maintenance
(servicing) instructions in
the literature accompanying
the appliance.
For European Union countries: This symbol on
the product or its packaging indicates that this
product must not be disposed of with other waste.
Instead, it is your responsibility to dispose of your
waste equipment by handing it over to a designated
collection point for the recycling of waste
electrical and electronic equipment.
Please contact your local authority for further details
of your nearest designated collection point.

QF6WRC INSTALLATION AND OPERATION MANUAL
4
6” FULL RANGE DRIVER
FRONT GRILLE PLATE
GRILLE
GRILLE MOUNTING TABS
FRONT PANEL
4
4 4
3
2
1
2
3
4
1

QF6WRC INSTALLATION AND OPERATION MANUAL 5
REAR PANEL
SPEAKER INPUT CABLE
Speaker input is via a 7 core cable. Refer to the attached
table which identifies the various power tappings available
and also the 8 Ohm direct input.
POWER TAPPING CHART FOR EASY REFERENCE
MOUNTING TABS (Refer to Mounting Section)
3
2
1
1
2
3
QF6WRC
IP Rated Splashproof Ceiling Loudspeaker
+
Common
Power
Impedance
Black 70 V 100 V
Line
Low-imp.
3
3
BROWN
RED
BLUE
YELLOW
GREEN
WHITE
BLACK
TAPPING 100 V 70 V IMPEDANCE
Brown 12 W 6 W 833 Ω
Red 9 W 4.5 W 1.11 kΩ
Blue 6 W 3 W 1.67 kΩ
Yellow 3 W 1.5 W 3.33 kΩ
Green 1 W 0.5 W 10 kΩ
White Direct 8 Ω
Black Common
Brown 6 W 12 W 833 Ω
Red 4.5 W 9 W 1.11 Ω
Blue 3 W 6 W 1.67 kΩ
Green 0.5 W 1 W 10 kΩ
Yellow 1.5 W 3 W 3.33 kΩ
White 12 W 12 W 8Ω

QF6WRC INSTALLATION AND OPERATION MANUAL
6
MOUNTING
When mounting QF6WRC speakers the following safety issues must be considered;
The mounting of a permanently installed speaker may be dangerous unless undertaken by a qualified professional
with relevant experience.
Ceilings and mounting surfaces must be capable of supporting the speaker in a safe and secure manner.
INSTALLATION
(Refer to page 8 for dimension details)
Cut a hole with a diameter of 209 mm (8.3”) in the ceiling ensuring that there is sufficient room both above and at the sides
of the hole to comfortably fit the speaker.
To install the speaker, remove the grille by placing a screwdriver into the three grille release tabs (slots) located around the
circumference of the front panel and carefully prying it free. Take care not to scratch the panel with the screwdriver.
Once the grille and front panel have been removed, simply insert the speaker into the ceiling and using a screwdriver, tighten the
three mounting tabs located around the circumference of the speaker to lock it into place. Once the speaker is installed, relocate
the grille and front plate by securely pressing it back into place.
When wiring the speakers, always connect multiple speaker in parallel and ensure the correct polarity of each speaker, with
respect to each other is maintained. Isolate unused wires in the speaker input cable so that they do not contact each other
or any other conductive object.
NOTE that the QF6WRC has a supervisory capacitor inserted across all 100V tappings.

QF6WRC INSTALLATION AND OPERATION MANUAL 7
REMOVING THE GRILLE
To remove the grille, simply unclip the front grille plate from the speaker by pressing the grille release tabs which are identified
from the front by three small indents located around the circumference of the plate.
If the grille is to be removed whilst the speaker is not mounted, we recommend releasing the tabs from the rear of the speaker
so that the front panel is not scratched. If removing from the front, take care not to scratch the front panel.
Once the panel is removed, the grille itself can be removed from the front panel by turning it anticlockwise until the small tabs
that hold it in place are released.
To reassemble, reinsert the grille following the reverse process and the front plate is simply pressed back into the speaker.

QF6WRC INSTALLATION AND OPERATION MANUAL
8
DIMENSIONS
ø 238.4 mm (9.4”)
137.5 mm (5.4”)
10.3 mm (0.4”)
183.3 mm (7.2”)

QF6WRC INSTALLATION AND OPERATION MANUAL 9
SPECIFICATIONS
SPECIFICATION QF6WRC
IMPEDANCE (DIRECT) 8 Ohms
POWER (CONTINUOUS, PROGRAM) 12 W, 24 W
POWER TAPPINGS (100 V) 12, 9, 6, 3, 1 Watts
POWER TAPPINGS (70 V) 6, 4.5, 3, 1.5, 0.5 Watts
SENSITIVITY (1 W / 1 M @ 1 Khz) 92 dB
CALCULATED MAX SPL (CONTINUOUS, PROGRAM) 103 dB, 109 dB
DISPERSION (1 KHZ, 4 KHZ) 110°, 65° Conical
FREQUENCY RESPONSE (-10DB) 150 Hz – 20 kHz
FREQUENCY RESPONSE (-3 DB) 185 Hz - 19 kHz
SPEAKER COMPONENTS 6” Full Range Driver
INGRESS PROTECTION IP 55
OPERATING TEMPERATURE -30°C ~ +60°C
NET DIMENSIONS (DIAMETER X LENGTH) 238.4 X 137.5 mm (9.4” X 5.4”)
NET WEIGHT (NO CARTON) 1.7 kg (3.75 lbs)
SHIPPING DIMENSIONS (W X H X D) (CARTON) 270 X 270 X 215 mm (10.6” X 10.6” X 8.5”)
SHIPPING WEIGHT (CARTON) 2.4 kgs (5.3 lbs)

QF6WRC INSTALLATION AND OPERATION MANUAL
10
FREQUENCY RESPONSE

NOTES

ENGINEERED BY AUSTRALIAN MONITOR
Address: Unit 1, 2 Daydream Street, Warriewood NSW 2102 Australia
Website: www.australianmonitor.com.au
International enquiries email: [e-mail]
ABN 86 003 231 187
