Autel Robotics Live Deck 2 User manual

Live Deck 2
User Guide

1. Disclaimer
2. Tutorial Video
By using this Product, you hereby agree to this disclaimer and signify
that you have read it fully. Please use the Product in strict
accordance with the manual and be sure to pay attention to the
Warnings.
AUTEL ROBOTICS CO., LTD. (hereinafter referred to as "AUTEL
ROBOTICS") assumes no liability for damage(s) or injuries incurred
directly or indirectly from improper use of this Product. Misuse
includes, but is not limited to, short-circuiting, overheating, introduc-
ing foreign materials into the Product.
Please scan QR code or open the website link
https://www.autelrobotics.com/article/136.html
3. Product Information
3.1 Introduction
The Live Deck 2 supports a wireless connection with the UAV and a
real-time image transmission within 12km under interference-free
conditions. The image transmission system and the remote control
system work on three frequencies: 2.4GHz/5.8GHz/900MHz*
(adaptive aircraft band), and can display videos/images in real-time
through HDMI port or Ethernet port.
*900MHz is only supported in countries covered by FCC certification.
3.2 Component

10
9
1
8
2
3
47
5 6
Communicate with the aircraft via RF signal.
Battery level indicators. Please refer to 3.3
for more information.
➀Antenna
➁LED battery
level indicators
Charging port.
➂Ethernet port
Upgrade the Live Deck 2 through TF card.
External interface*
*Exact function will update later on official website.
➃USB Type A 1
➄HDMI port
➅Type-C port
➆Pairing button/
indicator
⑧Power button
⑨TF card port
⑩USB Type A 2
Connects to computer, supports real-time
video streaming via RTMP.
Connects to a monitor that supports video
outputs via HDMI.
Use to pair with aircraft.
Please refer to 4.2 for more information.
Press and hold the power button for 2s to
turn on/off the Live Deck 2.
Connects to Type-C port of Autel Smart
Controller through USB Type-A 1 port of Live
Deck 2 for function settings. Please refer to
4.3 for more information.

4.1 Power On/Off
Power On: When powered off, press and hold the button for 2
seconds to turn on the power.
Power Off: When powered on, press and hold the button for at
least 2 seconds to turn off the power.
4.2 Connect To Aircraft
1)Power on the aircraft and Live Deck 2.
2)Press the paring button on the aircraft body, and the led lights
on the aircraft will flash green quickly.
4. Setting Up The Live Deck
3.3 Battery Level Indicator
Battery Level Indicator Current Power level
Solid Green Flashing Green Light Off
87.5%~100%
75%~87.5%
62.5%~75%
50%~62.5%
37.5%~50%
25%~37.5%
12.5%~25%
0%~12.5%
0%

3)Press the paring button of Live Deck 2 and the indicator light
will flash green quickly.
4)Led lights on aircraft will flash slowly if pairing is successful.
4.3 Live Deck 2 Setting
Connects to Type-C port of Autel Smart Controller through USB
Type-A 1 port of Live Deck 2 for function settings as below.
1)Flight Information
Enable/Disable
2)RTMP Setting
3)Language Setting
4)Software Upgrade
5)Software Version Check
4.4 Connect To A Display Device
HDMI and Ethernet port can output display information. Please
select one or several ports to connect to your devices accordingly.
1)HDMI: connect the HDMI cable to a monitor that can support
HDMI. The video resolution can be up to 1080P.

Note
① Live Deck 2 supports HDMI and Ethernet port connections
simultaneously.
②If we use the Live Deck 2 while charging, it will stop battery
charging because of Over-temperature Protection when
machine temperature is higher than 45℃, and battery charging
will continue if machine temperature drop below 40℃.
2)Ethernet port: make sure Live Deck 2 is on the same network of as the
projecting screen, and connect the Type-C port of Autel Smart Controller
through USB Type-A 1 port of Live Deck 2. Set the RTMP address to rtmp
protocol format (e.g. rtmp://192.168.10.10/live/live stream) on App of
Smart Controller. After completing the settings, enter the address in
the software that supports rtmp protocol parsing on projecting
devices, such as a laptop to display real-time video.

902~928MHz (FCC);
2.4GHz~2.4835GHz;
5.725 GHz~5.850GHz (Non-Japan);
5.650-5.755GHz (Japan)
900MHz: FCC<=33dBm
2.4GHz: FCC/NCC<=33dBm;CE/MIC/SR-
RC/KC<=20dBm
5.8GHz/5.7GHz: FCC/SRRC/NCC<=33dB-
m;KC<=20dBm;CE<=14dBm
12km
5h
1.3A/3.85V
Li-Po
6200mAh
5W
14°F~104°F (-10°C~40°C)
95%RH
RF Receiver
Operating Frequency
Transmission Power
(EIRP)
Max Video
Transmission
Distance
Max Operating Time
Operating
Current/Voltage
Battery Type
Battery Capacity
Power Consumption
Operating
Temperature
Operating Humidity
5. Product Specifications
424.5g (0.94lbs)
152*111*23.2mm (antennas folded)
223.9*152*23.3mm (antennas unfolded)
IP43
Weight (battery
included)
Dimensions
Ingress Protection

FCC and ISED Canada Compliance
This device complies with part 15 of the FCC Rules and ISED Canada
licence-exempt RSS standards. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Le présent appareil est conforme aux CNR dʼISED Canada applicables
aux appareils radio exempts de licence. Lʼexploitation est autorisée
aux deux conditions suivantes : (1) lʼappareil ne doit pas produire de
brouillage, et (2) lʼappareil doit accepter tout brouillage radioélec-
trique subi, même si le brouillage est susceptible dʼen compromettre
le fonctionnement.
Note
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
1080p@60 fps
100M
EVO II Pro V3
EVO II Dual 640T V3
EVO II RTK Series V3
EVO II Enterprise V3
HDMI
Ethernet
Supported Models

1) Reorient or relocate the receiving antenna.
2) Increase the separation between the equipment and receiver.
3) Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
4) Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.
RF Exposure Information
This equipment complies with RF radiation exposure limits set forth
for an uncontrolled environment. This equipment should be operated
with minimum distance 20cm between the radiator and yourbody.
EU/UK Compliance
Autel Robotics Co., Ltd. hereby declares that this wireless device is in
compliance with Directive 2014/53/EU and Radio Equipment
Regulations2017.
