Autel MAXITPMS ITS600PRO User manual

i
Trademarks
Autel®, MaxiSys®, MaxiDAS®, MaxiScan®, MaxiTPMS®, MaxiRecorder®, and
MaxiCheck®are trademarks of Autel Intelligent Technology Corp., Ltd.,
registered in China, the United States and other countries. All other marks are
trademarks or registered trademarks of their respective holders.
Copyright Information
No part of this manual may be reproduced, stored in a retrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying,
recording, or otherwise without the prior written permission of Autel.
Disclaimer of Warranties and Limitation of Liabilities
All information, specifications and illustrations in this manual are based on the
latest information available at the time of printing.
Autel reserves the right to make changes at any time without notice. While
information of this manual has been carefully checked for accuracy, no guarantee
is given for the completeness and correctness of the contents, including but not
limited to the product specifications, functions, and illustrations.
Autel will not be liable for any direct, special, incidental, indirect damages or any
economic consequential damages (including the loss of profits).
IMPORTANT
Before operating or maintaining this unit, please read this manual carefully,
paying extra attention to the safety warnings and precautions.
For Services and Support
pro.autel.com
www.autel.com
www.maxitpms.com
1-855-288-3587 (North America)
[phone] (China)
[email protected]

ii
For technical assistance in all other markets, please refer to Technical Support
in this manual.
Safety Information
For your own safety and the safety of others, and to prevent damage to the
device and vehicles upon which it is used, it is important that the safety
instructions presented throughout this manual be read and understood by all
persons operating or coming into contact with the device.
There are various procedures, techniques, tools, and parts for servicing
vehicles, as well as in the skill of the person doing the work. Because of the
vast number of test applications and variations in the products that can be
tested with this equipment, we cannot possibly anticipate or provide advice
or safety messages to cover every circumstance. It is the automotive
technician’s responsibility to be knowledgeable of the system being tested. It
is crucial to use proper service methods and test procedures. It is essential
to perform tests in an appropriate and acceptable manner that does not
endanger your safety, the safety of others in the work area, the device being
used, or the vehicle being tested.
Before using the device, always refer to and follow the safety messages and
applicable test procedures provided by the manufacturer of the vehicle or
equipment being tested. Use the device only as described in this manual.
Read, understand, and follow all safety messages and instructions in this
manual.
Safety Messages
Safety messages are provided to help prevent personal injury and equipment
damage. All safety messages are introduced by a signal word indicating the
hazard level.
DANGER
Indicates an imminently hazardous situation that, if not avoided, will result in
death or serious injury to the operator or to bystanders.

iii
WARNING
Indicates a potentially hazardous situation that, if not avoided, could result in
death or serious injury to the operator or to bystanders.
Safety Instructions
The safety messages herein cover situations Autel is aware of. Autel cannot
know, evaluate or advise you as to all of the possible hazards. You must be
certain that any condition or service procedure encountered does not
jeopardize your personal safety.
DANGER
When an engine is operating, keep the service area WELL VENTILATED or
attach a building exhaust removal system to the engine exhaust system.
Engines produce carbon monoxide, an odorless, poisonous gas that causes
slower reaction time and can lead to serious personal injury or loss of life.
SAFETY WARNINGS
⚫Always perform automotive testing in a safe environment.
⚫Wear safety eye protection that meets ANSI standards.
⚫Keep clothing, hair, hands, tools, test equipment away from all moving or
hot engine parts.
⚫Operate the vehicle in a well-ventilated work area, as exhaust gases are
poisonous.
⚫Put the transmission in PARK (for automatic transmission) or NEUTRAL
(for manual transmission) and make sure the parking brake is engaged.
⚫Put blocks in front of the drive wheels and never leave the vehicle
unattended while testing.
⚫Be extra cautious when working around the ignition coil, distributor cap,
ignition wires, and spark plugs. These components create hazardous
voltages when the engine is running.
⚫Keep a fire extinguisher suitable for gasoline, chemical, and electrical
fires nearby.
⚫Do not connect or disconnect any test equipment while the ignition is on

iv
or the engine is running.
⚫Keep the test equipment dry, clean, free from oil, water or grease. Use a
mild detergent on a clean cloth to clean the outside of the equipment as
necessary.
⚫Do not drive the vehicle and operate the test equipment at the same time.
Any distraction may cause an accident.
⚫Refer to the service manual for the vehicle being serviced and adhere to
all diagnostic procedures and precautions. Failure to do so may result in
personal injury or damage to the test equipment.
⚫To avoid damaging the test equipment or generating false data, make
sure the vehicle battery is fully charged and the connection to the vehicle
DLC is clean and secure.
⚫Do not place the test equipment on the distributor of the vehicle. Strong
electro-magnetic interference can damage the equipment.

v
CONTENTS
1USING THIS MANUAL .................................................................................1
1.1 CONVENTIONS ...................................................................................1
1.1.1 Bold Text ....................................................................................1
1.1.2 Notes and Important Messages..................................................1
1.1.3 Hyperlink.....................................................................................1
1.1.4 Illustrations .................................................................................2
1.1.5 Procedures.................................................................................2
2GENERAL INTRODUCTION ........................................................................3
2.1 MAXITPMS ITS600/ITS600 PRO TABLET...........................................4
2.1.1 Function Description...................................................................4
2.1.2 Power Sources ...........................................................................6
2.1.3 Technical Specifications.............................................................7
2.2 VCI –VEHICLE COMMUNICATION INTERFACE ........................................8
2.2.1 Function Description...................................................................8
2.2.2 Technical Specifications...........................................................10
2.3 OTHER ACCESSORIES.......................................................................11
3GETTING STARTED..................................................................................12
3.1 POWERING UP.................................................................................12
3.1.1 System Status Icons.................................................................13
3.1.2 Application Buttons...................................................................14
3.1.3 Locator......................................................................................16
3.2 POWERING DOWN ............................................................................16
3.2.1 Reboot System.........................................................................16
4TPMS..........................................................................................................17
4.1 GETTING STARTED...........................................................................17
4.1.1 TPMS Service Menu Layout.....................................................17
4.2 VEHICLE IDENTIFICATION...................................................................19

vi
4.2.1 Auto VIN Detect........................................................................20
4.2.2 Scan License............................................................................20
4.2.3 Scan VIN ..................................................................................22
4.2.4 Manual Input.............................................................................23
4.3 TPMS CHECK .................................................................................29
4.4 TPMS DIAGNOSIS............................................................................31
4.4.1 Establish Vehicle Communication ............................................31
4.4.2 Diagnosis Operations ...............................................................33
4.5 SENSOR PROGRAMMING ...................................................................39
4.5.1 Copy by OBD............................................................................40
4.5.2 Auto Create ..............................................................................41
4.6 TPMS RELEARN..............................................................................43
4.6.1 OBD Relearn............................................................................44
4.6.2 Automatic Relearn....................................................................45
4.6.3 Stationary Relearn....................................................................47
4.7 RETROFIT........................................................................................48
4.8 WEAR DETECTION............................................................................48
4.8.1 Function Operations .................................................................49
4.8.2 Check mode .............................................................................52
4.8.3 Details.......................................................................................55
5TPMS RETROFIT.......................................................................................59
5.1 RETROFIT........................................................................................59
6BATTERY TEST.........................................................................................61
6.1 MAXIBAS BT506 TESTER ................................................................61
6.1.1 Function Description.................................................................61
6.1.2 Power Sources .........................................................................62
6.1.3 Technical Specifications...........................................................63
6.2 TEST PREPARATION .........................................................................64
6.2.1 Inspecting the Battery...............................................................64
6.2.2 Establishing Communication ....................................................64

vii
6.2.3 Connecting to a Battery............................................................65
6.3 IN-VEHICLE TEST..............................................................................66
6.3.1 Battery Test ..............................................................................66
6.3.2 Starter Test...............................................................................70
6.3.3 Generator Test .........................................................................72
6.4 OUT-VEHICLE TEST ..........................................................................74
6.4.1 Battery Test ..............................................................................74
7OE ENTRY .................................................................................................76
7.1 TPMS BY OEM PART NO.................................................................76
7.1.1 Application Scenarios...............................................................76
7.1.2 Function Operations .................................................................76
8DIAGNOSTICS...........................................................................................82
8.1 GETTING STARTED...........................................................................82
8.1.1 Vehicle Menu Layout................................................................82
8.2 VEHICLE IDENTIFICATION...................................................................83
8.2.1 Auto VIN Scan..........................................................................83
8.2.2 Manual VIN Input......................................................................87
8.2.3 Automatic Selection..................................................................88
8.2.4 Manual Selection......................................................................88
8.3 NAVIGATION.....................................................................................89
8.3.1 Diagnostics Screen Layout.......................................................89
8.3.2 Screen Messages.....................................................................90
8.3.3 Making Selections ....................................................................90
8.4 DIAGNOSIS ......................................................................................91
8.4.1 Auto Scan.................................................................................91
8.4.2 Control Units.............................................................................93
8.5 GENERIC OBDII OPERATIONS.........................................................100
8.5.1 General Procedure .................................................................100
8.5.2 Function Descriptions.............................................................102
8.6 EXITING DIAGNOSTICS ....................................................................105

viii
9SERVICE..................................................................................................106
9.1 OIL RESET SERVICE .......................................................................106
9.2 ELECTRIC PARKING BRAKE (EPB) SERVICE......................................109
9.2.1 EPB Safety.............................................................................109
9.2.2 EMF Start-up..........................................................................111
9.2.3 Parking Brake: Workshop Mode.............................................113
9.3 BATTERY MANAGEMENT SYSTEM (BMS) SERVICE ............................114
9.3.1 Register Battery Replacement................................................114
9.4 STEERING ANGLE SENSOR (SAS) SERVICE ......................................119
9.4.1 Steering Angle Sensor Calibration..........................................121
10 TIRE DOT.................................................................................................124
11 SETTINGS................................................................................................127
11.1 TPMS MARKET .............................................................................127
11.2 TPMS PROG.SETTING...................................................................127
11.3 TBE MANAGER..............................................................................127
11.4 VCI MANAGER...............................................................................128
11.4.1 Bluetooth Connection .............................................................129
11.4.2 Update via USB......................................................................130
11.4.3 Update via Bluetooth ..............................................................130
11.5 SYSTEM SETTINGS .........................................................................130
11.6 PRINTER MANAGER ........................................................................130
11.7 REPORT UPLOAD TO CLOUD............................................................131
11.8 UNIT .............................................................................................131
11.9 ABOUT ..........................................................................................132
12 TOOLKIT ..................................................................................................133
13 UPDATE...................................................................................................134
13.1 DISPLAY TABLET UPDATE................................................................134
13.2 MAXIVCI V200 UPDATE .................................................................136
13.2.1 Update via Bluetooth ..............................................................136
13.2.2 Update via USB......................................................................136

ix
14 DATA MANAGER.....................................................................................137
14.1 TEST RECORDS .............................................................................138
14.1.1 TPMS Test Report..................................................................139
14.2 WORKSHOP INFORMATION...............................................................141
14.3 IMAGE ...........................................................................................143
14.4 PDF.............................................................................................145
14.5 REPORT ........................................................................................145
14.6 UNINSTALL APPS............................................................................145
14.7 DATA LOGGING ..............................................................................146
15 ACADEMY................................................................................................148
16 REMOTE DESKTOP ................................................................................149
17 MAXITOOLS.............................................................................................150
17.1 SYSTEM TOOLS..............................................................................150
17.2 QUICK LINK ...................................................................................150
17.3 EMAIL ...........................................................................................151
18 ACTIVATE PRO FUNCTION....................................................................152
19 MAINTENANCE AND SERVICE ..............................................................153
19.1 MAINTENANCE INSTRUCTIONS..........................................................153
19.2 TROUBLESHOOTING CHECKLIST.......................................................154
19.3 ABOUT BATTERY USAGE.................................................................154
19.4 SERVICE PROCEDURES...................................................................155
19.4.1 Technical Support...................................................................156
19.4.2 Repair Service........................................................................157
19.4.3 Other Services........................................................................158
20 COMPLIANCE INFORMATION................................................................159
20.1 FCC COMPLIANCE.....................................................................159
20.2 SAR.............................................................................................160
20.3 RF WARNING STATEMENT.......................................................160
20.4 ROHS COMPLIANCE..................................................................160
20.5 CE COMPLIANCE.......................................................................160

x
20.6 KC COMPLIANCE.......................................................................161
21 WARRANTY.............................................................................................162

1
1 Using This Manual
This manual contains device usage instructions.
Some illustrations shown in this manual may contain modules and optional
equipment that are not included in your system. Contact your sales
representative for availability of other modules and optional tools or
accessories.
1.1 Conventions
The following conventions are used.
1.1.1 Bold Text
Bold text is used to highlight selectable items such as buttons and menu
options.
⚫Tap OK.
1.1.2 Notes and Important Messages
Notes
A NOTE provides helpful information such as additional explanations, tips,
and comments.
Important
IMPORTANT indicates a situation that, if not avoided, may result in damage
to the test equipment or vehicle.
1.1.3 Hyperlink
Hyperlinks or links that take you to other related articles, procedures, and
illustrations are active in electronic documents. Blue italic text indicates a

2
selectable hyperlink and blue underlined text indicates a website link or an
email address link.
1.1.4 Illustrations
Illustrations used in this manual are samples; the actual testing screen may
vary for each vehicle being tested. Observe the menu titles and on-screen
instructions to make the correct option selection.
1.1.5 Procedures
An arrow icon indicates a procedure.
Example:
➢To use the camera:
1. Tap the Camera button. The camera screen opens.
2. Focus the image to be captured in the view finder.
3. Tap the camera icon on the right side of the screen. The view finder
now shows the captured picture and auto-saves the taken photo.

3
2 General Introduction
When it comes to ultra-portability, MaxiTPMS ITS600 or MaxiTPMS ITS600
Pro (hereinafter referred to as ITS600/ITS600 Pro) is your perfect companion.
ITS600/ITS600 Pro offers maximum convenience and swift diagnosis. The
intuitive user interface makes using the device effortlessly through a 5.5-inch
LCD touch screen that displays at 1280 x 720 quality. Together with the ability
to quickly read and clear Original Equipment Manufacturers (OEM) enhanced
codes for TPMS module of the majority of the makes and models on the
market, ITS600/ITS600 Pro provides you with superior special functions for
TPMS services with ease.
There are two main components of ITS600/ITS600 Pro system:
⚫MaxiTPMS ITS600/ITS600 Pro Display Tablet –the central processor
and monitor for the system.
⚫MaxiVCI V200 (Vehicle Communication Interface, hereinafter referred to
as V200) –the device for accessing vehicle data.
This manual describes the construction and operation of both the devices and
how they work together to deliver diagnostic solutions.

4
2.1 MaxiTPMS ITS600/ITS600 Pro Tablet
2.1.1 Function Description
Figure 2-1 Display Tablet Front View
①5.5”LCD Capacitive Touchscreen
②Ambient Light Sensor –detects ambient brightness.
③Power LED –indicates battery level & charging or system status.
④TPMS Service Symbol –indicates the position of the embedded TPMS
antenna.
⑤Lock/Power Button –long press the button to turn on/off the tablet.
The power LED displays green or red depending on power level and
operating state:
A. Green
⚫Flashes green when the Display Tablet is charging; lights green
when the Display Tablet is fully charged.
B. Red
⚫Illuminates red when a problem is detected.

5
Figure 2-2 Display Tablet Back View
①Sticker
②Rear Camera
③Camera Flash
④Speaker
Figure 2-3 Display Tablet Top View
①Micro SD Card Slot
②Type-C USB OTG Port
③Microphone

6
2.1.2 Power Sources
The tablet can receive power from any of the following sources:
⚫Internal Battery Pack
⚫AC/DC Power Supply
⚫Vehicle Power Supply
Internal Battery Pack
The tablet can be powered with the internal rechargeable battery, which if
fully charged can provide sufficient power for about 7 hours of continuous
video watching and 5 hours of operations.
AC/DC Power Supply
The tablet can be powered from a wall socket using the AC/DC power adapter
that connects to the Type-C USB. The AC/DC power supply also charges the
internal battery pack.
Vehicle Power
The tablet can be powered from the auxiliary power outlet adapter or other
suitable power port on the test vehicle through a direct cable connection. The
vehicle power cable connects to the USB Type-C port at the bottom of the
tablet for charging.

7
2.1.3 Technical Specifications
Table 2-1 Specifications
Item
Description
Recommended Use
Indoor
Operating System
AndroidTM 9.0
Processor
Quad-core processor (1.5 GHz)
Memory
2 GB RAM DDR4 & 64 GB ROM
Display
5.5-inch LCD capacitive touchscreen with
1280 x 720 resolution
Connectivity
⚫Wi-Fi
⚫Type-C USB
⚫Bluetooth
Sensors
Light sensor for brightness auto adjustment
Audio input/output
⚫Input: Microphone
⚫Output: Speaker
Power and Battery
⚫3.8 V/5000 mAh lithium-polymer battery
⚫Charges via 5 V DC power supply
Battery Charging
Input
5 V/2 A
Power Consumption
700 mA (LCD on with default brightness, Wi-
Fi on) @3.8 V
Operating Temp.
0 to 50°C (32 to 122°F)

8
Item
Description
Storage Temp.
-20 to 60°C (-4 to 140°F)
Dimensions (W x H x D)
183.0 mm (7.2″) x 89.0 mm (3.5″) x 22.0 mm
(0.87″)
Net Weight
368 g (0.8 lb.)
Protocols
ISO9141-2, ISO14230-2, ISO15765, K/L-
Line, Flashing Code, SAE-J1850 VPW,
SAE-J1850PWM, ISO11898 (Highspeed,
Middlespeed, Lowspeed and Singlewire
CAN, fault-tolerant CAN), SAE J2610, GM
UART, UART Echo Byte Protocol, Honda
Diag-H Protocol, TP2.0, TP1.6, ISO13400,
CAN FD
2.2 VCI –Vehicle Communication Interface
The wireless diagnostic interface MaxiVCI V200 is a small vehicle
communication interface (VCI) used to connect to a vehicle’s DLC and
connect wirelessly with the tablet for vehicle data transmission.
2.2.1 Function Description
Figure 2-4 MaxiVCI V200 Views
①Flashlight Button
②Power LED
③Connection LED

9
④Vehicle Data Connector (16-Pin) –connects the MaxiVCI V200 to the
vehicle’s 16-pin DLC directly.
⑤USB Port –provides the easiest connection between the device and the
display tablet via a USB cable.
Table 2-2 Power LED on the Front Panel
LED
Color
Description
Power LED
Yellow
Lights yellow at power up when VCI is self-
testing.
Green
Lights solid green when powered on.
Red
Blinks red when VCI is upgrading.
NOTE
The power LED briefly lights yellow each time the device powers on and
then lights green when the device is ready.
Table 2-3 Connection LED on the Front Panel
LED
Color
Description
Connection
LED
Green
⚫Blinks green when communicating.
⚫Lights green when connected via
USB cable.
Blue
⚫Blinks Blue when communicating.
⚫Lights Blue connected via Bluetooth
cable.

10
2.2.2 Technical Specifications
Table 2-4 Technical Specifications
Item
Description
Communications
⚫BLE + EDR
⚫Type-C USB
Wireless Frequency
2.4 GHz
Input Voltage Range
8 V to 30V DC
Supply Current
150 mA @ 12 V DC
Operating Temp.
0°C to 50°C (32°F to 122°F)
Storage Temp.
-20°C to 60°C (-4°F to 140°F)
Dimensions
(L x W x H)
89.89 mm (3.53″) x 46.78 mm (1.84″) x 21
mm (0.82″)
Weight
70.7 g (0.156 lb.)
Built-in Battery
3.7 V Lithium Battery
Light
White LED
NOTE
The 3.7 V lithium battery is used for LED lighting only.
