Auto openers Roll Master User manual

Instruction Manual
To view our how to install video visit:
www.autoopeners.com.au
1300 42 88 66
Roll Master

Table of Contents
Installation Instructions .................................................................................................................. 4
1. Prepare The Door................................................................................................................................... 4
2. Fixing of Door Weight Bars................................................................................................................... 4
3. Pinning of the Door ................................................................................................................................ 5
4. Proping of the Door ............................................................................................................................... 5
5. Fixing the Operator to the Door......................................................................................................... 6
6. Setting & Operate Diagram ............................................................................................................... 7
Door Travel Limit Setting................................................................................................................. 8
Setting processes：..................................................................................................................................... 8
CODING TRANSMITTER.................................................................................................................. 12
Safety reverse force adjustment................................................................................................. 13
Connecting the photocells (OPTIONAL)*....................................................................................................... 13
Auto close setting (OPTIONAL)...................................................................................................................... 14
Battery backup connection (OPTIONAL) ....................................................................................................... 15
Packing list.................................................................................................................................... 15
TECHNICAL DATA........................................................................................................................... 15
Common Troubleshooting........................................................................................................... 16
Optional & Additional Accessories............................................................................................. 18
Warranty Registration................................................................................................................... 20

Installation Safety Warnings
This automatic garage door opener is designed and tested to offer safe service provided it is
installed and operated in strict accordance with the following safety warnings. Failure to comply with
the following instructions may result in death, serious personal injury or property damage.
GENERAL WARNINGS
•The door may operate unexpectedly, therefore do not allow anything to stay in the path of the door.
•When operating the manual release while the door is open, the door may fall rapidly due to weak or broken
springs or due to being improperly balanced.
•Do not disengage the opener to manual operation with children / persons or any objects including motor
vehicles within the doorway.
•If the door is closing and is unable to re-open when obstructed, discontinue use. Do not use a door with
faulty obstruction sensing.
•When using auto close mode, a Photo Electric beam must be fitted correctly and tested for operation at
regular intervals. Extreme caution is recommended when using auto close mode. All safety rules must be
followed.
•Due to the risk of entrapment under the door, ensure you test the safety auto reverse function monthly.
ELECTROCUTION RISKS
•Place opener in a protected area so it does not get wet.
•Do not spray with water.
•Disconnect the power cord from mains power before making any repairs or removing covers. Only
experienced service personnel should remove covers from the opener.
•If the power supply cod is damaged, it must be replaced by an Auto Openers service agent or suitably
qualified person.
•Connect the opener to a properly earthed general purpose 240V mains power outlet installed by a
qualified electrical contractor.
CAUTIONS
•If garage has no pedestrian entrance door, an emergency access device should be installed. This
accessory allows manual operation of the garage door from outside in case of power failure.
•Practice correct lifting techniques (carton weighs approx. 9kgs).
•Practice correct lifting techniques when required to lift the door as per installation instructions.
•Ensure ladder is the correct type for job.
•Ensure ladder is on flat firm ground that will take the weight without the legs sinking.
•Ensure user has 3 points of contact while on ladder.
•Place a 2 meter exclusion zone around area under the door while it is unsecured.
•Do not move under a door while it is on the door support (or ladder).
•Follow the installation instructions.
•Fit door support (or ladder) snugly under door before removing bracket.
•Ensure door support (or ladder) is on flat ground.
•Examine the door installation, in particular, springs and mountings for signs of wear, damage and imbalance.
•The garage door must be well balanced. Sticking or binding doors must be repaired by a qualified
garage door installer prior to installation of the opener.
•Remove or disengage all garage door locks and mechanisms prior to installation of the opener.
•Never plug in and operate opener prior to installation.
•Keep hands and loose clothing clear of door and guides at all times.
•DO NOT operate the opener unless the garage door is in full view and free from objects such as cars
and children/people. Make sure that the door has finished moving before entering or leaving the
garage.
•Educate children about garage door safety, keeping transmitters and remote controls of out children’s
reach due to the potential risk of injury or death.

Installation Instructions
SAFETY INSTRUCTIONS FOR INSTALLATION
Not following the installation instructions can lead to serious injury or equipment failure. Ensure you
follow the steps carefully to avoid complications.
SETUP REQUIREMENTS
a. The opener must be installed in a dry
location, protected from weather. Moisture
and corrosion damage is not covered by
warranty.
b. The opener requires properly earthed 3 pin
single phase power within an arm’s length
of the door and at a suitable height.
c. As per figure 1, the minimum side room is
40mm. However, 95mm is recommended
for ease of access.
1. Prepare The Door
a. Clean the guides if there is any oil or wax present using a suitable white spirit. The only lubricant
for use on the door guides is silicon spray. DO NOT use WD-40, RP-7, petroleum grease or similar.
b. Remove the locking bars and disable the lock.
c. Install the locking bar covers if there are locking bar holes in the guides. This ensures fingers
cannot be placed in the holes while the door operates.
2. Fixing of Door Weight Bars
a. Position the two weight bars approximately
400mm from each end of your door at the bottom.
b. Once positioned, drill through the bars into the
door whilst being careful of your hands. Use the
provided screws and nuts to affix the weight bars.
c. Check that the door is still balanced and smooth.
If not, then the door may require servicing / tensioning.

Screw into the
low part of
grove
Pin Points
3. Pinning of the Door
Pinning the door’s curtain to it’s drum maintains security when the opener is
closed. If the curtain is not pinned the door can be partially opened manually.
a. Fully close the door.
b. Mark a minimum of two (2) points on the drum to each end of the door.
c. Fit Teck screw (not supplied) to each of the four (4) points. This screw
Should be positioned as low as possible in the groove, but make sure
that it does not alter the curtain’s normal lead in to the guide.
4. Proping of the Door
a. At the end opposite to where the opener will be fitted, check that
the U-Bolt which holds the door axle to the bracket is tightly secured. If this
is not done the stored energy in the spring can be unexpectedly released.
b. Open the door completely and tie the rope around the door roll.
Do not tie the rope too tight as damage to the curtain may ensue. This will
stop the door unrolling when taken off the bracket.
c. At the end where the opener is to be fitted, support the door with
a door stand of suitable prop. Place a towel between the door and the prop
to protect the door from damage. This can be done on a ladder or on your
shoulder if it is safe to do so.
d. At the end where the opener will be fitted use a pencil to mark the
position of the U-Bolt in the door bracket on the wall to assist in reassembling
BALLOONING DOOR
FREE DOOR
PINNED DOOR
Not pinned and
Without locking bars without locking bars
door can be lifted door can be lifted
Door secure and
will not lift
U-bolts
Door stand
or suitable
prop
Door
bracket

5. Fixing the Operator to the Door
Please note: The motor is designed to operate on the right side of the door by default.
To reverse the drive for left hand side installation, press the set
button and hold until the LED displays “5”.
Using the “UP” and “DOWN” buttons select “1” for left installation
or “0” for right side installation. Hit “SET” to confirm the setting.
Installation process (FIG. 3 through FIG. 5)
1. Remove the U-Bolt off the end of the door that you intend
to install the motor on. Ensure that the U-Bolt on the
opposite end is firmly fastened first.
2. Lift the door up and away from the wall until clear of
the door bracket, before lowering the door to rest on
the door stand or prop.
Note: If there is limited ceiling space, the door bracket may
have to be removed. If this is required, use the reference marks
on the wall for correct positioning to ensure that it is both secure
to the wall & able to support the door.
3. Remove the opener from the box.
4. Check that the drive gear rotates freely by hand, by
pulling the disengage handle. Then move the forks
from side to side by hand.
5. Slide the opener over the door axle and into the drum
of the door as shown in Figure 4.
6. Push the opener as far as possible into the roll of the
door (without interfering with the curtain) so one of the
door drum’s wheel spokes is between the opener’s
drive forks. If the forks cannot slide into the drum
wheel, use the supplied extension arms.
7. Raise the door off the door stand or suitable prop.
8. Lift up and over the door bracket and use your
reference marks on the door bracket to position the
door.
9. Refit the U-Bolt and tighten.
10. Remove the safety rope and door stand / prop.
11. Connect the power cord to a suitable power point, but
do not switch on. Secure the power cord away from
any moving object (e.g. the door).
12. With the opener still disengaged, pull the door up and
down to ensure it runs freely.
WARNING! To prevent injury, do not
allow children or other persons near
the door or the prop

6. Setting & Operate Diagram
1. Operate Button
3. Manual Release Lever
5. Programming Panel
H. Hole for Battery
Backup Connection
2. PB/GND/PE/+24V terminal
(For PE Beams / Receivers)
4. Battery Backup Terminal
6. K Button (Same as Operate Button)

8
To view our how to install video visit:
www.autoopeners.com.au
Door Travel Limit Setting
1. Open the door by hand until the door touches the upper door
stop (see fig 7).
2. Close the door by hand until the door touches the ground.
3. Push up the manual release lever and the motor will re-engage.
4. Press the ‘SET’button and hold on LED displays figure ‘1’, then
adjust the final up limit by pressing the ‘UP’button.
TIP: You can fine tune the position of both the up and the down limit
by single pressing the ‘UP’ or ‘DOWN’ button. Press ‘SET’to save
the setting.
5. The display will now show a ‘2’ automatically. Adjust the down
limit by pressing the ‘DOWN’button, then press ‘SET’.
TIP: For the best operation, set the door 20mm from the stop at the
top and just touching the bottom for the best operation.
Setting processes：
Press ‘SET’ button to confirm the setting
Press ‘SET’
button
Display
‘1’
Press ‘UP’ or ‘DOWN’ button to adjust the opening
height
Press ‘SET’
button
Display
‘2’
Press ‘DOWN’ or ‘UP’ button to adjust the closing
height
WARNING! In setting the close limit position, do
not force the door into the floor with excessive
force, as this can interfere with the ease of
operation of the manual release mechanism.

12
6. Press the RED operate button at the bottom of door operator or K button (FIG.9), confirm the up limit and
down limits are correct. If not, please re-set the travel limits according to above processes until the limits
are correct.
CODING TRANSMITTER
The operator should be under standby mode when coding remotes. Press the ‘SET’ button until the coding
light turns on and the operator is under remote learning mode. Press any one button two times on the remote,
the coding light will extinguish. The remote has been coded successfully. Use the same method to code
multiple remotes. Up to 20 can be stored at any one time.
Press ‘CODE’ button Red light turn on Press any one
button 2 times
Light flashes Light turn off
Coding finished
i.Deleting remotes：Press the code button over 8 seconds until display shows C,
then it will be under standby mode.All stores remotes are now deleted.
Press ‘CODE’ button over 8 seconds Display C Under standby mode

13
4.4.2 Recommended force：5-15 kg resistance is recommended. Lightly lift the door while door closing, the
door can be automatic reverse under approximate 5~15 kgresistance.
Press ‘SET’ button
Display from ‘1’ to ‘3’
Press ‘UP’ or ‘DOWN’ button to adjust the force
The force from 1 to 9
Min force is 1, max force is 9
Press ‘SET’ to confirm
Press ‘DOWN’ button
Display ‘11’
Press ‘UP’ button
Display ‘H’
Press ‘SET’ to confirm
Safety reverse force adjustment
Press ‘SET’ button and hold on until the LED displays figure ’3’. Press ‘UP’ button to increase the force,
Press
the DOWN’ button to decrease the force. The maximum force is 9, the minimum force is 1. The default is 3.
You must test the operation of the auto reverse safety function monthly to ensure the safety feature is functioning when the
door is obstructed so it auto reverses, as to avoid entrapment by animals or children.
Your installation is now complete and motor ready for use.
Below are additional instructions on how to install the optional PE Safety Beams or Battery Backup
Connecting the photocells (OPTIONAL)*
*The photo beam is an optional unit available
as a special order & recommended to avoid
entrapment
ii.The GND、PE、+24V connections of the terminal block
(green) at the bottom of the door operator are for photocells,
(Please refer the Fig.10). Please choose switch value style
(NC) photocell.
Notice: Close the photo beam function when not utilizing
the photo beam sensor.
iii. Activating the photocell function:
Press the ‘DOWN’ button and hold on until the ‘LED’
displays’11’, press ‘UP’ button until the LED displays ‘H’;
photocell function is available, press ‘SET’ to confirm.

14
to cancel this function. When setting is finished,
Please confirm the photocells are well connected and programmed and check if the door automatically
reverses when encountering an obstacle during door closing.
iv. Cancelling the photocell function:
Press the ‘DOWN’ button and hold on until the LED displays ‘H’. Press the ‘DOWN’ button until the LED
displays 11’. To cancel this function, press the ‘SET’ buttonto confirm.
WARNING: Close the photo beam function when not utilizing photo beam sensor.
Auto close setting (OPTIONAL)
Press and hold the ‘UP’ button until the LED displays ‘-’. Every time you press the ‘UP’ button, the auto-
close time will increase by 1 minute, the maximum time is 9 minutes. By pressing the ‘down’ button. the auto-
close time will decrease by 1 minute. The auto-close function will be turned off when LED displays 0. Press
‘SET’ button to confirm.
The default setting for this function is 0 (off).
Press ‘UP’ button Display ‘-’Press ‘UP’ or ‘DOWN’ button to choose the close time The minute from 1 to 9
Press ‘SET’ to confirm
NOTE：The auto close is only available when door is at its full open position.
When using auto close mode, a photo electric beam must be fitted correctly
and tested for operation at regular intervals.
Press ‘DOWN’ button
Display ‘H’
Press ‘DOWN’ button
Display ‘11’
Press ‘SET’ to confirm

15
Battery backup connection (OPTIONAL)
It must use 24V DC 3.5Ah sealed lead acid battery. Please open the light cover to connect the wires of
t h e battery with the battery backup terminal in the control board(Fig.12). The ‘H’ of Fig.11 is a hole for
the battery connection wires to through.
Packing list
Item
Quantity
ET-30 Roller Door Operator
1
Remotes & Wall Button
2
U-Clamp and Cast Iron Saddle
1
Extended DriveForks
2
Extended ManualRelease Arm (Optional)
1
Installationmanual
1
Weight bar
2
TECHNICAL DATA
Input voltage: 220 VAC——240 V AC 50 HZ
Controller voltage: 24 V DC
Max power: 235W
Lifting force: 400N(40kgs)
Workingcircumstance:-20℃——+40℃
Operator limits travel: 4 circles of door drum wheel
Receiver type: 433.92 MHZASK rolling code
The Max height of door : 4.5m

16
Common Troubleshooting
Symptom
Possible reason
Solution
The door does not move
The door is locked or motor
jammed
Mains power not switched on
Switch on the main power
The door is obstructed
Remove the barrier
Unlock the door
Check the motor is turning
The door won’t reverse when
obstructed
The force of the motor is set
too high
Decrease the safety reverse force
The door reverses
automatically when closing
The moving force of the motor is set
too low
Increase the safety reverse force
There could be an obstruction under
the door
Removeobstruction
The door stops automatically
when opening
The moving force of the motor is set
too low
Increase the safety reverse force
The operator can be controlled
by O/S/C button but not the
remote
The remote light doesn’t flash
The battery is loose or flat.
Open rear cover and ensure
battery is connected / replace.
The receiving antenna is not pulled
out
Pull out the receiving antenna
Interference
Turn off wireless equipment in
house to test (doorbells, etc)

17
The door can’t fully close
The door is beyond the original up
limit setting after power failure
Reset the limit position as per
instruction
Anoise emits from the motor
during the first manual travel
limit setting
The up/down limit position
confirmation
This is normal, no action required
The door can only open, cannot
close
The photocell function was activated
Close the photocell function
The motor rotates / grinds but the
door doesn’t move
The motor is in manual mode
(out of gear)
Push the manual release lever up
to put the motor into gear
The door closes when pressing
‘UP’ during limit setting
Left / right installation error
Change the installation direction
according to left/right installation
setting in the instruction manual
2 short beeps from buzzer
means 24V DC Motor no
longer operational
A motor connection may have
broken away from the circuit board
Please make sure thereis a
connection between motor
connector and control board.
Motor fault
Contact Auto Openers
3 short beeps from buzzer
means over-load protection
The door has met an obstacle
Remove the obstacle
Door twisted
Fix the door
4 short beeps from buzzer
means potentiometer is no
longer working
A potentiometer connection has
broken away from the circuit board
Please make sure thereis a
connection between
potentiometer and board.
Potentiometer
Please install a new
potentiometer

18
Roller Opener Instruction Manual
18
Optional & Additional Accessories

19
Roller Opener Instruction Manual
19
PLEASE NOTE:
•This Warranty is in addition to any statutory, non-excludable guarantees or warranty rights and
remedies under the law. See section 5.
•This warranty applies to the original purchaser only and may not be transferred.
•This Warranty is to be read in conjunction with the owner’s copy of the installation instruction manual.
•In this warranty, ‘Auto Opener’s Representative’ means an entity authorized by Auto Openers to
service Auto Openers products. Please check the Auto Openers website for details.
It is a condition of the below warranties that
the manual operating (opening and closing)
force of the door by hand does not exceed
20kg.
MODEL
WARRANTY
Max Door Weight
ROLLER OPENER
Up To Five (5) Years
110kg
EXTRAS
ACCESSORIES
1 year
NOTE: CONSUMABLES (eg Batteries in remote control transmitters and light bulbs and fuses) are not covered
by this warranty.
1. MAKING A CLAIM
(a) The product parts in the above table will
operate in accordance with the product
manual for the time period shown,
provided you comply with the
manufacturer’s instructions concerning
installation, operation, maintenance and
testing. Failure to do so may void all or
part of this warranty.
(b) If, during the relevant warranty period,
a product part in the table above
appears to contain a defect, call the
retailer from whom you purchased the
product, or Auto Openers on 1300 42 88
66, and they will instruct you what to do
next.
(c) You are responsible for the cost of making
a claim under this Warranty. Additional
access expenses where the Product is
not readily accessible must be borne by
you.
(d) If Auto Openers or an Auto Opener’s
Representative confirms the Product is
defective and covered by this Warranty,
Auto Openers will repair or replace it (at
Auto Opener’s sole option) at no cost to
you. Goods presented for repair may be
replaced by refurbished goods of the same
type rather than being repaired.
Refurbished parts may be used to repair
the goods.
2. WARRANTY CONDITIONS
It is a condition of this warranty that:
(a) you provide a copy of the receipt of
original purchase of the Product, and the
serial number of the Product which can
be found on the label adhered to the
Product.
(b) the Product has been serviced within 18
months of installation and thereafter
every 2 years.
(c) You must register your warranty online
within 60 days of purchase
3. WARRANTY EXCLUSIONS
This warranty excludes damages resulting from:
(a) Excessive wear and tear that may
cause the product to fail;
(b) Accidental, deliberate or negligent
damage or damage cause by
insects;
(c) Blown fuses, electrical surges,
power surges or power spikes or
faulty or unsuitable electrical
wiring of structures to which the
product is affixed;
(d) Theft, fire, flood, rain, water,
lightning, storms or any other acts
of God;
(e) Salt or other corrosion due to environmental
conditions,
(f) Any installation, configuration or
use of the product contrary to the
instructions supplied with the
product;
(g) Maximum continuous operating
time exceeding 1 minute in10
minutes;
(h) The manual operating (opening
and closing) force of the door by
hand exceeding 20kg;
(i) Door surface area and/or weight
exceeding amounts listed in table
above respectively;
(j) The door used with the product not
being in safe working order and
condition;
(k) Any modification to the product or
acts or omissions of any person in
respect of the product which are
not authorized by Auto Openers;
(l) Installation of a residential garage
door opener in a commercial or
industrial premises or in a dwelling
other than a single-family dwelling;
(m) Radio or electrical interference or
lack of availability of signal.

20
Roller Opener Instruction Manual
20
4. OTHER CONDITIONS
(a) This Warranty is not transferable.
(b) No additional warranty will apply for Products repaired during the relevant warranty period.
(c) Where the Product is sold by any person other than Auto Openers, except for the warranty set out
above, such person has no authority from Auto Openers to give any warranty or guarantee on
Auto Opener’s behalf in addition to the warranty set out above.
5. STATUTORY GUARANTEES OR WARRANTIES IN AUSTRALIA & New Zealand
If you are a consumer under the Australian Consumer Law, our goods come with guarantees that
cannot be excluded under the Australian Consumer Law. You are entitled
to a replacement or refund for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the
goods fail to be of acceptable quality and the failure does not amount to a major failure.
This warranty certificate and other statements contained in this document or other AutoOpener
documents given to you do not exclude, restrict or modify the application of all or any of the
provisions of the Australian Consumer Law.
Subject to your non-excludable rights under the Australian Consumer Law, AutoOpener expressly
excludes any liability for consequential loss, incidental or indirect damages (including but not limited
to damages for loss of business profits, business interruption and loss of business information) due to a
defect of the Product. In particular, any loss or damage caused to other equipment or accessories
used with the product or any loss resulting from a delay in repair is excluded to extent permitted by
law.
Warranty Registration
Register your warranty online with Auto Openers to receive a full replacement warranty. Simply
visit www.autoopeners.com.au/warranty/registration to register. After 60 days of purchase, failure
to register your warranty will result in a Limited 1 Year Warranty.
Name: __________________________________________
Email: __________________________________________
Serial Number: ___________________________________
Phone: _________________________________________
Sold By: ________________________________________
Installed By: _____________________________________
Invoice: _________________________________________
Installation Date: ____/____/____
Failure to Register Within 60 Days = 1 Year Warranty
