D-force 1500PV User manual

D-FORCE1500PV
GARAGE DOOR OPENER
WARNING: IT IS VITAL FOR THE SAFETY OF ALL PERSONS INSTALLING AND USING THIS OPENER TO
FOLLOW THE INSTALLATION INSTRUCTIONS AND SAFETY WARNINGS. FAILURE TO COMPLY MAY
RESULT IN SERIOUS PERSONAL INJURY AND/OR PROPERTY DAMAGE AND FAILURE OF THE OPENER
SYSTEM。

D-FORCE1500PV
1.Functions
Micro inte ectua contro —— One button to contro open, stop and c ose.
The ight wi be on whi e opening or c osing the door,
three minutes ater the ight wi be off automatica y.
Contro the unit running by computer program. Test
the force of open or c ose the door, the optiona
function is photo beam, auto-c ose, ock door, etc. The
door wi pause momentari y then rebound when it
reaches the hinders on the c osing way. The protecting
functions is over oad, over hot or ow power input, etc.
DC motor —— Low noise, soft start, s ow stopping to protect the unit
and make sure it can be used for a ong time.
LED disp ay —— Working situation can be shown on the LED screen.
Decoding —— Ro ing code.
Manua Disengagement—— Open and c ose the door by hand without
power.
Optiona Functions —— Photo beam, battery backup, wa button and
f ash ight.

2.Technical Specifications
Power input
P
220VAC±10% 50～60Hz Reception
frequency
433.92MHz
Motor 24VDC Decoding Ro ing code
Working temperature -20～50℃Transmitter
power
27A 12V Battery
Re ative Humidity 90%≦G obe 24V 5W
Open and c ose force 1500N Courtesy ight
time
3 minutes
3.Installation
3.1 Recommended Tools
NO. Too s
1 Dri
2 Step adder
3 Ratchet
4 Tape measure, Carpenter’s eve
5 Screwdriver
6 Tongs
7 Neon-e ectroscope, mu timeter
8 Adjustab e wrench
9 Hammer

3.2 Installing the perator and Rail

4.Control panel and Transmitter
Button 1
Button 2
Button 3
Button 4

5. ptional Terminals and Connections
6.Programming the perator
6.1 Preparing
6.1.1 To tighten the chain,turn adjusting nut-M8 in the direction
shown(picture C).Make sure the shutt e is ocked, pu or push the door to
confirm the shutt e connects with the chain.
6.1.2 Turn on the power, the courtesy ight wi be ight for severa
seconds, at the same time, the LED disp ays the number from 99 to
11.Then the operator turns to standby situation.

>> >>
Turn on the power, The LED disp ays from 99 to 11. At ast, it disp ays “- - ”.
6.2 Setting pen and Close Positions
>> >>
Press and ho d SET unti it disp ays “P1”, press SET, it disp ays “ P”. Then press UP, when the
door has reached the open position, press SET.
>> >>
It disp ays “CL”, then press D WN, it disp ays “CL”. When the door has reached the c osed
position, press SET. The door wi now open and c ose automatica y to map the open and c ose
sensitivity force requirements.
>>
It disp ays “- - ” to show setting is comp ete.

6.3 Self Learning Transmitter
6.3.1 when the unit has stored 20 codes, The LED fashes “Fu”, or preventing coding
mistakes, it is necessary to cance a the stored codes.
>> >>
When it disp ays “Fu”, press and ho d C DE more than 8 seconds unti it f ashes “dL” , a the
codes wi be cance ed.
6.3.2 Adding or Changing Transmitters
>> >>
Press C DE, it disp ays “Su” , press a button on the transmitter, then re ease and press the same
button again, “Su” f ashes, then it disp ays “- - ” to show setting is comp ete.
Repeat up steps to code a maximum of 20 different transmitters’ and/or buttons.
6.4 Force Adjustments
The door meets the hinders wi rebound and it stops automatica y when
over oad.

>> >>
Press and ho d SET, it disp ays ”P1”, press UP once, it disp ays”P2”, press SET once again, it wi
show the current situation. Press UP to increase the force one degree and press D WN to
decrease one degree. Maximum degree is “F9” and minimum is “F1”. Press SET to confirm. The
defau t setting is “F5”.
6.5 Photo Beam
>> >>
Press and ho d SET, it disp ays “P1”, press UP twice, it disp ays “P3”. Press SET to show current
situation. Press UP once it disp ays “H1”, the photo beam is enab ed.
Press down once, It disp ays “H0”, the photo beam is disab ed. Press SET to confirm and quit.
Note: If you do not use photo beam device, please make sure it displays “H0”, to
close this function.
6.6 Auto-Close N/ FF
>> >>
Press and ho d SET, it disp ays “P1”, press UP three times, it disp ays “P4”. Press SET to show
current situation. Press UP to increase the Auto-c ose one minute and press D WN to decrease
one minute. Maximum degree is “b9” and minimum is “b0”. Press SET to confirm. The defau t

setting is “b0”. ”bo” shows auto-c ose off.
7. wners’ Guide
7.1 Attention in use
7.1.1 At the first time of using the door, p ease test the driving system to
see if it moves we . (Test method: un ock the shutt e, pu and push the
door by hand.)
7.1.2 Connected with the appropriate power and socket by professiona s,
and connected the ground wire with earth.
7.1.3 Using the transmitters in your sight. Do not stand or wa k under a
moving door. The transmitters shou d be out of reaching of chi dren.
7.1.4 Make sure the door out off fire, moisture, e ectromagnetism and
some other p aces.
7.1.5 Check at east twice a year to make sure the door is proper y
ba anced and that a working parts are in good working condition. Adjust
the tensi e force of chain. Add suitab e amount of ubricant to the active
system.

7.2 Examination Guide
Problem Causes Solution
The chain is noisy The chain is too oose Adjust nut-M8 referring to
6.1.1
The motor does not
work
The socket is we connected,
or the fuse is broken
Check the socket
Rep ace the fuse
After setting open
and c ose positions,
the motor does not
work
The screws of fixing the Ha
components are oose
Program mistakes
Tighten the screws
Resetting open and c ose
positions
The door can’t be
c osed
Photo beam function works Cance the photo beam
function
The wa button works
we , but the
transmitter doesn’t
work
No transmitter earning
Transmitter battery is power off
Code referring to 6.3
Change new transmitter
battery
Too short of
transmitter distance
The transmitter battery is near
power off
Change new transmitter
battery
