Network Administrator’s Guide

Legal Notices
Autodesk®Media and Entertainment Products 2013
©2012 Autodesk, Inc. All Rights Reserved. Except as otherwise permitted by Autodesk, Inc., this publication, or parts thereof, may not
be reproduced in any form, by any method, for any purpose.
Certain materials included in this publication are reprinted with the permission of the copyright holder.
Trademarks
The following are registered trademarks or trademarks of Autodesk, Inc., and/or its subsidiaries and/or affiliates in the USA and other countries:
123D, 3ds Max, Algor, Alias, Alias (swirl design/logo), AliasStudio, ATC, AUGI, AutoCAD, AutoCAD Learning Assistance, AutoCAD LT, AutoCAD
Simulator, AutoCAD SQL Extension, AutoCAD SQL Interface, Autodesk, Autodesk Homestyler, Autodesk Intent, Autodesk Inventor, Autodesk
MapGuide, Autodesk Streamline, AutoLISP, AutoSketch, AutoSnap, AutoTrack, Backburner, Backdraft, Beast, Beast (design/logo) Built with
ObjectARX (design/logo), Burn, Buzzsaw, CAiCE, CFdesign, Civil 3D, Cleaner, Cleaner Central, ClearScale, Colour Warper, Combustion,
Communication Specification, Constructware, Content Explorer, Creative Bridge, Dancing Baby (image), DesignCenter, Design Doctor, Designer's
Toolkit, DesignKids, DesignProf, DesignServer, DesignStudio, Design Web Format, Discreet, DWF, DWG, DWG (design/logo), DWG Extreme,
DWG TrueConvert, DWG TrueView, DWFX, DXF, Ecotect, Evolver, Exposure, Extending the Design Team, Face Robot, FBX, Fempro, Fire, Flame,
Flare, Flint, FMDesktop, Freewheel, GDX Driver, Green Building Studio, Heads-up Design, Heidi, Homestyler, HumanIK, IDEA Server, i-drop,
Illuminate Labs AB (design/logo), ImageModeler, iMOUT, Incinerator, Inferno, Instructables, Instructables (stylized robot design/logo),Inventor,
Inventor LT, Kynapse, Kynogon, LandXplorer, LiquidLight, LiquidLight (design/logo), Lustre, MatchMover, Maya, Mechanical Desktop, Moldflow,
Moldflow Plastics Advisers, Moldflow Plastics Insight, Moldflow Plastics Xpert, Moondust, MotionBuilder, Movimento, MPA, MPA (design/logo),
MPI, MPI (design/logo), MPX, MPX (design/logo), Mudbox, Multi-Master Editing, Navisworks, ObjectARX, ObjectDBX, Opticore, Pipeplus, Pixlr,
Pixlr-o-matic, PolarSnap, PortfolioWall, Powered with Autodesk Technology, Productstream, ProMaterials, RasterDWG, RealDWG, Real-time
Roto, Recognize, Render Queue, Retimer, Reveal, Revit, RiverCAD, Robot, Scaleform, Scaleform GFx, Showcase, Show Me, ShowMotion,
SketchBook, Smoke, Softimage, Softimage|XSI (design/logo), Sparks, SteeringWheels, Stitcher, Stone, StormNET, Tinkerbox, ToolClip, Topobase,
Toxik, TrustedDWG, U-Vis, ViewCube, Visual, Visual LISP, Voice Reality, Volo, Vtour, WaterNetworks, Wire, Wiretap, WiretapCentral, XSI.
All other brand names, product names or trademarks belong to their respective holders.
Disclaimer
THIS PUBLICATION AND THE INFORMATION CONTAINED HEREIN IS MADE AVAILABLE BY AUTODESK, INC. "AS IS." AUTODESK, INC. DISCLAIMS
ALL WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE REGARDING THESE MATERIALS.

Contents
Chapter 1 Network Administration and Deployment . . . . . . . . . . . . . 1
Network Administration and Deployment . . . . . . . . . . . . . . . . . 1
About Deployments . . . . . . . . . . . . . . . . . . . . . . . . . 1
Planning a Deployment . . . . . . . . . . . . . . . . . . . . . . . 2
Check Deployment Readiness . . . . . . . . . . . . . . . . . 2
Determine the Installation Type . . . . . . . . . . . . . . . . 4
Determine the License Server Model . . . . . . . . . . . . . . 5
Configure Individual Products . . . . . . . . . . . . . . . . . 5
Include Service Packs . . . . . . . . . . . . . . . . . . . . . . 6
Create a Network Share . . . . . . . . . . . . . . . . . . . . . 7
Creating a Deployment . . . . . . . . . . . . . . . . . . . . . . . . 8
Create an Original Deployment . . . . . . . . . . . . . . . . 8
Modify a Deployment . . . . . . . . . . . . . . . . . . . . . 10
Direct Users to the Administrative Image . . . . . . . . . . 11
Chapter 2 Alternative Distribution Methods . . . . . . . . . . . . . . . . . 13
Alternative Distribution Methods . . . . . . . . . . . . . . . . . . . . . 13
Overview of Distribution Methods . . . . . . . . . . . . . . . . . 13
Use Batch Files to Deploy the Program . . . . . . . . . . . . . . . 13
Sample Installation Batch Files . . . . . . . . . . . . . . . . 14
Run Batch Files . . . . . . . . . . . . . . . . . . . . . . . . 16
Use Group Policies to Run a Deployment . . . . . . . . . . . . . 16
iii

Use Group Policies to Assign a Deployment to
Computers . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Verify a Group Policy Deployment . . . . . . . . . . . . . . 20
Use Microsoft SCCM to Deploy Products . . . . . . . . . . . . . . 21
Set Up a Source Directory for SCCM . . . . . . . . . . . . . 22
Create the SCCM Software Installation Package . . . . . . . 22
Distribute Products Using Imaging Software . . . . . . . . . . . . 24
Distribute Multi-Seat Stand-Alone Products . . . . . . . . . 25
Distribute Network Licensed Products . . . . . . . . . . . . 26
Restore the Master Image . . . . . . . . . . . . . . . . . . . 26
Clean a Master System and Restore the Operating
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Chapter 3 Installation Troubleshooting . . . . . . . . . . . . . . . . . . . 29
Installation Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Licensing Questions . . . . . . . . . . . . . . . . . . . . . . . . . 29
What is the difference between a stand-alone license and
a network license? . . . . . . . . . . . . . . . . . . . . . . 29
What is the benefit of using a network licensed version
of the software? . . . . . . . . . . . . . . . . . . . . . . . 30
What is SAMreport-Lite? . . . . . . . . . . . . . . . . . . . 30
Deployment and Networking Questions . . . . . . . . . . . . . . 30
Where should deployments be located? . . . . . . . . . . . 30
When should I select all products for the administrative
image, and can I add products later? . . . . . . . . . . . . 31
What are the profiles associated with user computer
settings? . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
What happens if I choose to append or merge service
packs? . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Where can I check if service packs are available for my
software? . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
How do I extract an MSP file? . . . . . . . . . . . . . . . . . 32
How should I configure a network license server for a
firewall? . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Uninstall and Maintenance Questions . . . . . . . . . . . . . . . 33
How can I see what is included in a default
installation? . . . . . . . . . . . . . . . . . . . . . . . . . 33
Is it possible to change the installation folder when adding
or removing features? . . . . . . . . . . . . . . . . . . . . 33
How do I install tools and utilities after installing my
product? . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
When should I reinstall the product instead of repairing
it? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Do I need the original media to reinstall my
product? . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
iv | Contents

When I uninstall my software, what files are left on my
system? . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Chapter 4 Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Contents | v

vi

Network Administration
and Deployment
Network Administration and Deployment
About Deployments
A deployment provides an efficient way to install one or more Autodesk products
with a standard configuration on multiple computers. The files required for the
installation process are stored on the network, in an administrative image, in
a folder to which all users have shared access. To install the products, users
navigate to the deployment folder and double-click an installer shortcut (.LNK
file).
NOTE The installer referenced in this guide applies only to Windows operating
systems. However, some of the concepts and procedures may be useful to
administrators of Autodesk products on Linux or Mac OS X networks.
Some essential facts about deployments:
■Deployments can be created for network licenses or multi-seat stand-alone
licenses.
■Multiple deployments with different configurations can exist in the same
folder, sharing the same administrative image, which is a set of installation
files.
■Each deployment installs products in a single language. If you need to install
products in different languages, each language requires a separate
deployment.
1
1

■An existing deployment can form the basis for creating another deployment
with a different configuration.
■Deployments can be configured to generate a log file for each installation.
Network administrators can use these log files for troubleshooting.
■Each deployment creates a subfolder, <deployment name>\SMS_SCCM scripts,
which contains two documents to help you with the distribution of
deployments using Microsoft Systems Management Server (SMS) and System
Center Configuration Manager (SCCM): SMS_SCCM_ReadMe.txt and
<deployment name>_SCCM.txt.
Deploying Language Packs
AutoCAD-based products, Inventor, and 3ds Max can use separate language
packs to add one or more additional language versions to an installed product.
Each language pack provides user interface strings, message text, and
documentation in a specific language, without duplicating the product
software. To distribute a specific language version to multiple instances of an
Autodesk product, you can use the installer included with each language pack
to create a language pack deployment. If you need to deploy language packs
for multiple languages or multiple products, you can create a batch file to
install a series of language packs on each computer.
Planning a Deployment
Check Deployment Readiness
This checklist identifies preliminary tasks to complete, information to gather,
and decisions to make before creating a network deployment.
TIP To review deployment settings, including details of product configuration,
you can create a test deployment. After the learning process, you can delete the
test deployment.
Deployment Checklist
Review the system requirements by clicking the System Requirements link in the
installer. Confirm that your network, servers, and client computers meet these
system requirements.
2| Chapter 1 Network Administration and Deployment

Deployment Checklist
Understand the general process for installing the type of license you have pur-
chased. For a network license deployment, know the license server name(s), and
the type of license server model that was specified at the time of license purchase.
For more information, see Determine the License Server Model (page 5)
Install and activate any network administrator tools and utilities. For example, if
you are using a network license, install the Network License Manager from the
installer.
Locate your product serial number and product key. These are located on the
outside of the product packaging, or in an email message if you downloaded
your product or upgrade from Autodesk.
Identify a network location for deployments, and create a shared folder to contain
deployments.
If your product has language options, decide which language to use for each
deployment.
NOTE Languages can be included when you initially create a deployment, or
when you create a new deployment configuration, but not when you modify a
deployment.
Determine whether to create log files on individual computers, in the deployment
folder, or both.
Determine whether to run installations in silent mode.
NOTE When products are installed in silent mode, the user's system can automat-
ically reboot without warning when the installation is complete.
Identify other applicable configuration settings such as defined search paths,
locations of support files, and whether to automatically install service packs.
Network Administration and Deployment | 3

Determine the Installation Type
When you set up your deployment, you specify the installation type by target
platform and license type.
Target Platform
Specify either a 32-bit or 64-bit platform, depending on the operating system
of the computers that will use the deployment. For some Autodesk products,
you can install a 32-bit version on a 64-bit operating system. For more
information, consult product-specific documentation.
License Type
Specify one of the following license types in the installer, based on the type
of license you purchased:
Network License With this license type, you install the product to computers
on a network, along with the files and registry entries that allow the product
to communicate with the Network License Manager (NLM) on one or more
servers. You also define the NLM configuration. When an Autodesk product
starts up on a client computer, it requests a license from NLM, then returns
it when the product is stopped. Computers running the product based on a
network installation do not require individual activation. For more
information, see Determine the License Server Model (page 5).
A major advantage of a network license is that you can install the product on
more systems than the number of licenses you have purchased (for example,
purchase 25 licenses, but install on 40 computers). At any one time, the product
runs on the maximum number of computers for which you have licenses, so
you get true floating licenses.
Stand-Alone License This license type is for multi-seat stand-alone installations
where a single serial number and product key are used to install products on
multiple computers. With this license type you do not use NLM to manage
product licensing. Instead, installation, registration, and activation occur on
each computer. After the first activation using the multi-seat stand-alone serial
number and product key, activation occurs automatically for all computers
using this deployment, as long as they are connected to the Internet.
4| Chapter 1 Network Administration and Deployment

Determine the License Server Model
If you choose the Network License option, you need to know which license
server model will be used to distribute the product licenses. This was specified
as one of the following when the license was purchased:
■Single license server model. The Network License Manager (NLM) is
installed on a single server, so license management and activity is restricted
to this server. A single license file records the total number of licenses
available on the server.
■Distributed license server model. Licenses are distributed across more
than one server. A unique license file is required for each server. To create
a distributed license server, you must run NLM on each server that is part
of the distributed server pool.
■Redundant license server model. Three servers are available to
authenticate each license. With this configuration, licenses continue to
be monitored and issued as long as at least two servers are functional. The
license file on all three servers is the same, and you must run NLM on each
server.
Each of these license server models is described in detail in the Licensing Guide.
It is recommended that you also read that guide before you deploy the product.
You can find the Licensing Guide by clicking the Installation Help link in the
installer.
Configure Individual Products
When you create a deployment, you can accept the default settings for any
product you choose to install, or you can configure these settings to create a
custom deployment. Configuration details for each product are usually covered
in a product-specific appendix to this guide. It is recommended that you review
these appendices, and determine the right settings for each product in your
deployment.
To configure product settings, on the Create Deployment page of the installer,
ensure that the product is selected for installation, and then click the product
in the scrolling list. The configuration panel opens.
Network Administration and Deployment | 5

IMPORTANT The configuration settings you choose apply to every instance of
the product installed from the deployment. After the deployment is created, these
settings can be changed only by modifying the deployment. For more information,
see Modify a Deployment (page 10).
Most products allow you to choose an installation type, either Typical to select
the most common options, or Custom to review options in more detail.
Some other common product settings are as follows:
■User preferences for product behavior
■Installation of support files, such as material libraries
■Access to online resources
Click Installation Help for further information specific to your product or
suite.
Include Service Packs
Most products provide the option to include service packs in a deployment.
You can download a service pack from autodesk.com, or use a service pack
stored on a local hard drive or network location. In either case, the service
pack will be applied only after the installation of the main product is
completed.
If you select the Install Service Pack from autodesk.com button, the service pack
will be automatically downloaded and you will not need to extract the MSP
file.
You can add multiple service packs to a deployment only if the service packs
are locally stored, not if you are downloading them from autodesk.com.
NOTE If the deployment process for the main product is canceled or fails, the
service pack installation will automatically be canceled.
Two options are available for including service packs in deployments:
■Append the Service Pack onto the Deployment. When you append
a service pack, the service pack is applied to the current deployment only.
Multiple service packs may be appended to a deployment. The service pack
file is included in the deployment and the service pack is applied after the
product is deployed.
■Merge the Service Pack into the Administrative Image MSI File.
With this option, the service pack is merged into the administrative image.
6| Chapter 1 Network Administration and Deployment

Once merged, a service pack cannot be removed from the administrative
image.
To extract a Microsoft Installer Patch (MSP) file from a service pack
1Download the service pack from the Support site for your product.
2Review the service pack Readme file for information about patch usage.
3Open a Windows command prompt and enter the patch file name
followed by the /e switch and a target file name. Here is the general
command format:
<local_drive:>\<patch_name>.exe /e
<local_drive:>\<patch_name>.msp
Here is an example:
ProductSP1.exe /e ./ProductSP1.msp
where ProductSP1.exe is the name of the downloaded patch and
ProductSP1.msp is the name of the extracted file. Using ‘./’in front of the
extraction file name places the extracted file in the same folder as the
original executable. The “e”command line switch extracts the MSP file
from the executable.
To include a service pack with the deployment
To include a service pack with a deployment, an MSP file must be extracted
from the downloaded service pack executable.
1On the Include Service Packs page, click the Browse button.
2In the Open dialog box, locate the service pack you want to include with
the deployment.
3Select the MSP file and click Open.
4Specify whether you want to append the service pack to the deployment
or merge the service pack into the administrative image.
5Click Next.
Create a Network Share
After you have fully prepared for creating a deployment, you are ready to set
up and distribute Autodesk products from a shared network location. A network
share is an installation folder to which all users' computers have access. You
create deployments in the network share, and point users to this location to
Network Administration and Deployment | 7

install the program. Any subfolders inside a network shared folder are
automatically shared.
If you select the option to create a network log file, then during installation,
the user's computer writes an entry to the log file in the network share.
Therefore, this option requires that users have read-write access to the network
share.
You can create a deployment folder on a network share as part of the process
of creating the deployment. If you plan to create several deployments of the
same product or suite, configured for different user groups, then these
deployments can share the same administrative image, and the shortcuts can
reside in the same folder. However, if you plan to create deployments of
different products or suites, it is recommended that you create separate product
folders on the network share before starting to create deployments.
For more information on how to create a network share, see the documentation
for your operating system.
Creating a Deployment
Create an Original Deployment
Use this procedure to create a new deployment from the installer. In the
process, you can create a default deployment by accepting the default
configuration of each installed product, or you can create a custom
deployment by customizing the configuration settings of one or more
products in the deployment.
To create an original deployment
1Close all running applications on your computer.
2Start the installer.
3On the first page, if language choices are available, select a language for
the deployment instructions, and then click Create Deployment.
4On the Configure <name> page, Administrative Image section, specify
the following data:
aEnter a descriptive name for the deployment that identifies the
user group, platform, or other attribute to differentiate this
deployment from others.
8| Chapter 1 Network Administration and Deployment

bEnter the path or browse to the shared network folder where you
want to create and store your administrative image. Users install
the program from this location.
NOTE For information on how to create a network share, see Create
a Network Share (page 7).
cSelect either 32-bit or 64-bit for the target operating system.
dChoose whether to include only the products required by this
configuration.
■If selected, the deployment cannot be modified in future to
include additional products.
■If unselected, the administrative image will include all possible
products, so the current deployment can be modified in any
way.
5In the Installation Settings section, select one or more of these
options:
■Silent mode runs the installation in background, without prompting
the user for any input.
NOTE Silent mode can automatically restart the user's computer without
warning after installation.
■Log file on each workstation can enable users to review and
troubleshoot their own installations.
■Network log file in a central location supports the network
administrator in reviewing data for all installations.
NOTE The network log file must be in a shared folder where users of the
deployment have read-write access. Otherwise, log data for user
installations cannot be written to the log file.
6Review and accept the Autodesk software license agreement.
7On the Product Information page, select your license type, and enter
your serial number and product key. If this data is valid, green check
marks appear.
8If you are sure that the product information is correct, click Next.
9On the Create Deployment Configuration page, select the products to
include in the deployment.
Network Administration and Deployment | 9

10 If you need to configure settings for a product, click the product name
to open the configuration panel where you can review and change
settings.
IMPORTANT The configuration settings you choose apply to every instance
of the product installed from the deployment. After the deployment is
created, these settings can be changed only by modifying the deployment.
Configuration settings vary widely by product. For more information,
click Installation Help to see the product documentation.
11 Click Create to create the deployment.
After the deployment is created, the Deployment Configuration Complete
page opens, presenting useful paths to the new deployment and a link
for registering products online.
12 After you have finished using this screen, click Finish.
Modify a Deployment
Inside each deployment folder is a Tools folder that contains a shortcut (.LNK
file) named Create & Modify a Deployment. You can use this shortcut to
■Create a new deployment configuration
■Create a new deployment configuration that uses an existing deployment
as a template
■Modify the configuration of an existing deployment
The installer pages guide you through the process, similar to when creating
an original deployment. If your original administrative image was set to include
only products required by the deployment configuration, then your options
for creating or modifying the deployment are limited. In particular, you cannot
add products to the deployment that are not in the original administrative
image. Conversely, if your original administrative image was not set to include
only the required products, then it includes all product files. As a result, you
can add products when you modify this deployment or when you create new
deployment configurations.
To modify a deployment
1Open the shared network folder that contains the deployment.
2In the Tools folder, double-click the Create & Modify a Deployment
shortcut.
10 | Chapter 1 Network Administration and Deployment

The installer opens at the Modify Deployment page.
3Click through the deployment configuration pages, and select the
required options.
4Click Create Deployment.
Direct Users to the Administrative Image
After you have created the deployment, users can install the program using
the shortcut (.LNK file) located in the deployment folder with the
administrative image. The shortcut name matches the deployment name that
you specified when creating the deployment. Notify users of the shortcut
name and location. Instruct them to double-click the shortcut to start the
installation. If the deployment uses silent mode, advise users to keep other
applications closed during the installation, because their computers might
restart automatically after products are installed.
Network Administration and Deployment | 11

12

Alternative Distribution
Methods
Alternative Distribution Methods
Overview of Distribution Methods
In addition to standard deployments, you can use the following alternative
methods of distributing Autodesk programs on Windows platforms:
■Scripting. See Use Batch Files to Deploy the Program (page 13).
■Group Policy Objects (GPOs). See Use Group Policies to Run a Deploy-
ment (page 16).
■Microsoft System Center Configuration Manager (SCCM). See Use
Microsoft SCCM to Deploy Products (page 21).
■Imaging Software. See Distribute Products Using Imaging Software (page
24).
Use Batch Files to Deploy the Program
A batch file executes a set of commands. Installation batch files are useful for
installation of stand-alone or network licensed programs on computers that are
connected to a network. These files are also useful for installing service packs,
extensions, and object enablers on a network.
The batch file consists of one or more commands, as well as command switches
that specify options, and flags that modify the options. An installation script
also contains path names.
2
13

An installation script points to the location of the product's setup.exe file. You
must point to the setup.exe file on your installation media or network location.
In order for your Autodesk product to run properly, you must have
Administrator permissions on the computer where the program is being
installed.
Sample Installation Batch Files
The sample batch files in this section install AutoCAD in typical configurations
for stand-alone or network licensed versions. To make it easy to copy this
sample batch file and substitute your own information, the same names are
used throughout for variables.
Notes
<mediaDriveLetter> is the drive letter where the media is mounted or the
setup.exe file is stored
Install options used here include /t (setup is executed by script) and /qb (display
a basic user interface). Others such as /w (log nonfatal warnings) are defined
for Microsoft Msiexec command line, and documented on the MS TechNet
website.
<SerialPrefix> is the first 3 digits of the serial number
<SerialPostFix> is the last 8 digits of the serial number
<ProdKey> is the Product Key
<lang> is the IETF language tag, for example en-US for English-United States
<eula_lang> is the ISO 3166-1 alpha-2 standard for the country for example
US = United States
Stand-Alone License
<mediaDriveLetter>\setup.exe /t /qb /language <lang> /c
ACAD: INSTALLDIR="%programFiles%\Autodesk\AutoCAD 2013"
ACADSERIALPREFIX=<SerialPrefix>ACADSERIALNUMBER=<SerialPostFix>
ADLM_PRODKEY=<ProdKey> ADLM_EULA_COUNTRY=<eula_lang>
InstallLevel=5
Example:
C:\setup.exe /t /qb /language en-us /c
ACAD: INSTALLDIR="%programFiles%\Autodesk\AutoCAD 2013"
14 | Chapter 2 Alternative Distribution Methods
