100 Litre Direct Drive Air Compressor
AIR100L
SAFETY AND OPERATING MANUAL

AIR100L
TABLE OF CONTENTS
Welcome to Auto
j
ack!
Dear customer, Congratulations on your purchase. Before using the
Product for the first time please be sure to read these instructions for use.
They provide you with all information necessary for using the product safely and to
ensure its long service life.
Closely observe all safety information in these instructions!
General Power Tool Safety Warnings………………………………….…......01
Symbols & Cable Rating Chart ……….…………………………………….………05
Machine Details and Product features……….…………………………….….06
Assembly……………………………………………………………………………………..07
Operation……………………………………...…….……………………………………..08
Maintenance and Service…………………………………………………………….10
Autojack guarantee………………………….………………………………………….12
Declaration of conformity……………………………………………………………14
Parts list……………………………………………………………………………………...15
Parts Diagram………………………………………………………………………………17

AIR100L 01
WARNING Read all safety warnings and
all instructions.
Failure to follow the warnings
and instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for
future reference.
The term "power tool" in
the warnings refers to your electric (corded)
power tool or battery-operated (cordless) power
tool.
1. Work area safety
a) Keep work area clean and well lit. Cluttered
or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or
fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
2. Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do not use
any adapter plugs with grounded power tools.
Unmodified plugs and matching outlets will
reduce risk of electric shock.
b) Avoid body contact with grounded surfaces,
such as pipes, radiators, ranges and
refrigerators
. There is an increased risk of
electric shock if your body is grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords
increase the risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk
of electric shock.
3. Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power
tools may result in serious personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat, or
hearing protection used for appropriate conditions
will reduce personal injuries.
c) Prevent unintentional starting. Ensure the
switch is in the off position before connecting to
power source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your
finger on the switch or energising power tools that
have the switch on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personal injury.
GENERAL POWER TOOL SAFETY WARNINGS

AIR100L 02
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving
parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
4. Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
b) Do not use the power tool if the switch does
not turn it on and off. Any power tool that
cannot be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts and
any other condition that may affect the power
tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused
by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier
g) Use the power tool, accessories and tool bits
etc. in accordance with these instructions, taking
into account the working conditions and the work
to be performed. Use of the power tool for
operations different from those intended could
result in a hazardous situation.
5. Service
a) Have your power tool serviced by a qualified
repair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.
b) If the replacement of the supply cord is
necessary, this has to be done by the
manufacturer or its agent in order to avoid a
safety hazard.
GENERAL POWER TOOL SAFETY WARNINGS

AIR100L 03
6 Additional Safety Instructions for
compressed air and blasting guns
6.1 During operation Compressor pump and
lines can become extremely hot. Touching
these parts is dangerous and will burn you.
6.2 Air which is compressed must be kept free
of any impurities which could cause fires or
explosions in the compressor pump.
6.3 Always secure the hose coupling as you
release it. This prevents injury caused by a
rebounding hose.
6.4 Wear Safety goggles when using the
blowout pistol. Eyes are extremely sensitive
and easily injured by small and large foreign
bodies, which are disturbed when using the
pistol.
6.5 Do not use or point the Blowout pistol on
or at others.
6.6 Do not clean clothes or use on yourself
this can cause injury.
7 Additional Safety Instructions for Paint
Spraying
7.1 Do not use paints or solvents whose flash
points are below 55°C as there is a risk of
explosion.
7.2 Never heat up paints or solvents this can
lead to fires or explosions.
7.3 If using hazardous liquids, wear protective
face guards and adhere to all safety
information for the liquids provided by the
manufacturer.
7.4 Do not smoke while operating and/or in the
work area. Paint vapours and other small
particulates are highly combustible and can
explode.
7.5 Evaluate the situation and wear suitable
clothing and masks if the situation calls for it.
7.6 Never set up or operate the machine while
near to or in the vicinity of a fire place, open
lights, sparking machines or any naked flame.
7.7 keep food and drink away from work area
paint vapours are damaging to your health.
7.8 Use in a well ventilated area.
7.9 Ensure that the work area is at least ૜૙࢓
૜
.
7.10 Do not use materials such as white spirits,
Butyl Alcohol and methylene chloride with the
PVC hose. These materials will destroy the hose
damaging the product and creating an unsafe
work environment.
GENERAL POWER TOOL SAFETY WARNINGS

AIR100L 04
8 Additional Safety Instructions for
operating pressure vessels
8.1 Vessel must be kept in good working
order, any repair or maintenance work
necessary must be carried out immediately.
8.2 Supervisory authority may enforce
essential control measures in individual cases.
8.3 DO NOT US A DEFECIENT OR FAULTY
PRESSURE VESSEL. This can seriously
endanger workers or third parties.
8.4 Always check your pressure vessel for
signs or rust and damage before each use. Do
not use if found to be damaged.
9. Using an Extension Cable .
9.1 If an extension cable is required, use an
approved triple core extension cable suitable
for the power input of the tool.
9.2 Grounded tools always require a three wire
extension cable.
9.3 As the distance from the supply outlet
increases you must use a heavier gauge
extension cable. Using extension cables with
inadequately sized wire causes a serious drop in
voltage, resulting in loss of power and possible
tool damage.
9.4 The smaller the gauge number of the wire
the greater the capacity of the cord.
9.5 When using a cable reel, always unwind the
cable completely.
GENERAL POWER TOOL SAFETY WARNINGS

AIR100L 05
SYMBOLS AND POWER RATING CHART
Danger!
–
Read the operating
instructions to reduce the risk of
injury.
Caution! Wear safety goggles.
Caution! Wear ear defenders. The
impact of noise can cause damage
to hearing.
Amperes 7.5M 15M 25M 30M 45M 60M
0 – 2.0 6 6 6 6 6 6
2.1 – 3.4 6 6 6 6 6 6
3.5 - 5.0 6 6 6 6 10 15
5.1 – 7.1 10 10 10 10 15 15
7.1 – 12.0 15 15 15 15 20 20
12.1 – 20.0 20 20 20 20 25 -
Caution! Risk of Injury! Do
not reach into the running
saw blade .
Caution! Wear a dust mask.

AIR100L 06
MACHINE DETAILS AND PRODUCT FEATURES
Machine Details
Specifications:
Mains Voltage - 230V / 50Hz
Output - 2200W/3HP
Motor speed – 2850rpm
Capacity – 100Litre
Operating pressure – approx. 8 bar
Theoretical intake –approx. 115l/min
Sound power level ܮ௪௔ – 99.5 dB (A)
Gross Weight – 81Kg
Package Contents:
Air Compressor
Air Filter
Oil Breather
Wheels
Mounting Hardware for Wheels
Product Features
Quick coupling valve
100Litre tank
Intended Use
Designed to generate compressed air
Using equipment in ways other than its
intended use the user and not the
manufacture will be liable for any damage or
injuries caused.
Also note that this equipment is not designed
for commercial or industrial use. Warranty will
be voided if used for these purposes.
1. Check-box for oil level
2. Output connector
3. Pressure reducer
4. Air pressure gauge
5. Pressure switch
6. Button ON /OFF Compressor
7. Air filter
8. Piston block
9. Oil filler plug with oil dipstick
11. Belt casing
12. Reset button
13. Electric motor
14. Receiver
15. Wheel
16. Drain valve
17. Support legs

AIR100L 07
Assembly
1. Before starting to assemble the
equipment
1.1 Check equipment for damage which may
have occurred in transit. Report this
immediately to the carrier used for delivery.
1.2 Assemble and install near the area
intended to be used.
1.3 Avoid long electric wires and air lines.
1.4 Avoid Installing in a damp or wet
environment.
1.5 Check the air is dry and dust free.
1.6 You cannot use the compressor in an
area where work is conducted with sprayed
water.
1.7 This compressor can only be used in
rooms with good ventilation and temperature
of +0 to +40°C.
1.8 Ensure there is no dust, acid, vapors,
explosive gasses or inflammable gases in the
room.
2. Product assembly
2.1 Fitting wheels
Install the compressor feet and support
feet.
2.2 Fitting the oil and oil breather
Before you starting the air compressor
please remove the white oil stopper and add
oil into crankcase.
NOTE: Before starting the air compressor
you must verify oil the crankcase and
install the oil breather as described
below:
a) Place compressor on level ground.
b) Remove the plastic oil stopper the oil fill
hole.
c) Verify oil in the crankcase. If the oil down
to the center of the red dot on the oil sight
glass, slowely pour the oil into the oil fill
hole until the oil level rises to the red dot.
d) Insert the oil breather into the oil fill hole.
Firmly hand tighten the oil breather by
turning clockwise.
NOTE: This compressor uses only SAE20 or
SAE30 non-detergent motor oil.
2.3 Fitting the air filter
a) The plastic air filter is installed into the
cylinder head and fixed with hex bolts.
b) Securely tighten the air filter in place.
Note: Do NOT over tighten air filter.
4.Bolt
5.Washer
6.Sucker
7.Nut

AIR100L 08
Operation
Operation
BEFORE OPERATING YOUR NEW AIR
COMPRESSOR
Please check the following points carefully:
- Check that all nuts and bolts are secure.
- Make sure oil has been properly added to
compressor.
Initial start-up
- Open the air tank drain valve to permit air
to escape preventing air from pressure
buildup air tank.
- Run the air compressor for a minimum of
20 minutes in this “up-load” position to
lubricate the piston and bearing.
- Close air tank drain valve. Your
compressor is ready for use. Depending on
the CFM draw of the tools being operated,
your new air compressor can be used for
operating paint sprayers, air tools, grease
guns, air brushed, caulking guns, abrasive
blasters, tire & plastic toy inflation, spraying
weed killer and insecticides, etc. Proper
adjusting the air pressure regulator is
necessary for all of the these operations.
Refer to the air pressure specifications
provided with the tool you are using.
General overview
To compress air, the piston moves up and
down in the cylinder. On the down stroke air
is drawn in through the valve inlet. The
discharge valve remains closed. On the
upstroke of the piston air is compressed; the
inlet valve closes and air is forced out
through the discharge valve, through the
check valve, and into the air tank. Working
air is not available until the compressor has
raised; the tank pressure above that required
in the air service connection. The air inlet
filter openings must be kept clear off
obstructions, which could reduce air delivery
of the compressor.
Installation and location
Locate the compressor in a clean, dry and well
ventilate area. The compressor should be
located 12 to 18 inches against walls or any
other obstruction which would interfere with
airflow. Place the compressor on a firm, level
surface. Keep all of spare parts which collect
dust or dirt clean. A clean compressor runs
cooler and provides longer service. Do not
place rag, containers or other materials on top
of the compressor.
Connecting to power source
This air compressor is designed to operate on
a properly grounded 230V,50HZ,single phase,
alternating current power source. It is
recommended that a qualified electrician verify
the ACTUAL VPLTAGE at the receptacle into
which unit will be plugged and confirm that the
receptacle is properly fused and grounded.
The use of the proper circuit size can eliminate
nuisance circuit breaker tripped while
operating your air compressor.
Extension cords
For optimum air compressor performance and
extension cord should not be used unless
absolutely necessary. If necessary, care must
be taken to select an extension cord
appropriate for use with specific air
compressor. Select a properly grounded
extension cord which will mate directly with the
power source receptacle and the air
compressor power cord without the use of
adapters. Make certain the extension cord is
properly wired and in good electrical condition.
Extension cords must be #14 gauge or 1mm
2
at the smallest. Do not use an extension cord
over 25ft. in length.

AIR100L 09
Operation
Attaching an air hose
Your air compressor is ready to accept air
hoses with (1/4”) male plug or (1/4”)female
hose end . To install an air hose into air cock
or air quick coupler, equipped with proper
connecter. Verify that air hose is securely
connected to air outlet by pulling lightly on air
hose.
NOTE: Use only air hoses rated for use with
115PSI air pressure or higher.
Adjusting the air pressure
Your air compressor is equipped with an air
pressure regulator. This regulator adjust the
air pressure.
To increase air pressure, turn air regulator
clockwise.
To decrease air pressure, turn air trgulator
counterclockwise.
Replace the Transmission belt
A Loosen belt
1. Turn off the power and unplug the socket
to ensure the air compressor is power off.
2. Unscrew the bolts of metal protection, and
remove the metal protection.
3. Pull out the belt from the belt wheel and
turn around the belt wheel to loose the belt
from the motor strap wheel and belt wheel.
4. Replace a new belt, and put the new belt
on the strap wheel and belt wheel, then turn
around the belt wheel to make sure the belt
is secure on the belt wheel and strap wheel
completely.
B Broken belt
1. Replace loose belt step 1 to 2.
2. Pull out the broken belt.
3. Put the new belt, and put he new belt on
the strap wheel and belt wheel, then turn
around the belt wheel to make sure the belt
is secure on the wheel and strap wheel
completely.
NOTE: When you find the air compressor is
getting low, maybe the belt was loose.
Please check the bolts and nuts on motor
and crank case and make sure all the bolts
and nuts are securely tighten. If all the bolts
and nuts are tighten very well, but the belt
still loose, that is mean you need to replace a
new belt for safety concern.

AIR100L 10
MAINTENANCE AND SERVICE
Maintenance and service
Pull out plug before performing any cleaning or
maintenance work.
Wait for the equipment to cool down before
any work to avoid burns.
Always depressurize the equipment before
carrying out cleaning or maintenance.
1. Cleaning
1.1 The equipment must be kept as free of dirt
and dust as possible.
1.2 It is recommended that the equipment is
cleaned immediately after you use it.
1.3 Do not clean the compressor with water,
solvents or the like.
1.4 Clean the filter at least every 80 operating
hours
2. Maintenance work
Warning: Before maintenance operation, stop
the air compressor, disconnect the unit from
the mains supply and discharge all air in the air
tank.
2.1 Daily(or before each use)
- Check oil level before each use.
- Drain the condensation from the air receiver.
- Check for any unusual noise or vibration.
- Be sure all nuts and bolts are tight
2.2 Weekly
- Clean breather hole on oil breather.
2.3 Monthly
- Inspect air system for leaks by applying soapy
water to all joints.
- Tighten these joints if leaks are discovered.
6 Monthly(or after 250hourse of operation-
whichever comes first)
Change air compressor oil.
NOTE:Change oil more often if air compressor is
used near paint spraying operations or in dusty
environments.
3. Checking the air compressor oil
3.1 Place air compressor on level surface. The oil
level should be at the red dot on the oil sight
glass.
3.2 If oil level is low, remove oil breather and add
enough oil to bring the oil level to the red dot on
the oil sight glass.
3.3 Replace oil breather before starting
compressor.
4. Changing the air compressor oil
4.1 Remove the oil sight glass by turning counter
clockwise with wrench.
NOTE: Oil will begin to drain as oil sight glass is
loosened. Place a funnel and oil pan in place
before loosening oil sight glass.
4.2 Once oil sight glass is removed, tilt air
compressor backwards to allow all of the oil to
drain out of the crankcase.
4.3 Once oil is drained, replace oil sight glass and
securely tighten in place with a wrench. Be careful
not to over tighten the oil sight glass, this will
damage the rubber seal.
4.4 Place air compressor on level surface.
4.5 Remove the oil breather.
4.6 Slowly pour the oil into oil fill hole, until the oil
level rises to the center of the red dot on the oil
sight glass.
4.7 Install the oil breather into the oil fill hole.
Firmly hand tight the oil breather by turning
clockwise.
Always inspect the tool before use, and make sure
it is in good working condition. Make sure all air
vents are clear,(use compressed air to clean the
machine if possible). Check the power cable to
make sure it is intact and free from cracks, bare
wires etc. To avoid using solvents when cleaning
plastic parts, most plastic are suspected to damage
from the various types of commercial solvents.

Trouble Probable cause Remedy
Compressor won’t start 1. Blown fuse or circuit breaker
tripped
2. Loose electrical connections
1. Replace or reset fuse/ circuit
breaker
2. Check wiring connections
Low pressure 1. Restricted air filter
2. Defective check valve
3. Air leak in safety valve
4. Check by the belt was loosened
1. Replace air filter
2. Replace check valve
3. Check valve by pulling
upwards on ring. If condition
persists, replace valve
4. Check by the belt was
loosened
Safety valve releasing 1. Defective pressure switch 1. Replace pressure switch
Oil discharge in air 1. Improper oil viscosity
2. Too much oil in crankcase
3. Compressor over heated
4. Restricted oil breather
1. Replace oil with SAE20 or
SAE30 no-detergent oil
2. Drain crankcase and refill to
proper level on oil sight glass
3. Reduce air pressure
regulation
4. Clean or replace oil breather
AIR100L 11
MAINTENANCE AND SERVICE

AIR6V 01AIR6V 01AIR6V 01
AIR100L 12
AUTOJACK GUARANTEE
1. Guarantee
1.1 Autojack guarantees that for a period of 12
months from the date of purchase the
components of qualifying products (see clauses
1.2.1 to 1.2.8) will be free from defects caused
by faulty construction or manufacture
1.2 During this period, Autojack, will repair or
replace free of charge any parts which are
proved to be faulty in accordance with
paragraph 1.1 providing that:
1.2.1 You follow the claims procedure set out in
clause 2.
1.2.2 Autojack and its Authorised Dealers are
given reasonable opportunity after receiving
notice of the claim to examine the product.
1.2.3 If asked to do so by Autojack or its
Authorised Dealer, you return the product at
your own cost to Autojack’s or the supplying
Authorised Dealer’s Premises, For the
examination to take place clearly stating the
Returns Material Authorisation Number given by
Autojack or an Authorised Dealer.
1.2.4 The fault in question is not caused by
industrial use, accidental damage, fair wear and
tear, wilful damage, neglect, incorrect electrical
connection, misuse, alteration or repair of the
product without approval.
1.2.5 The product has been used in a domestic
environment only.
1.2.6 The fault does not relate to consumable
items such as blades, bearings, drive belts or other
wearing parts which can reasonably be expected
to wear at different rates depending on usage.
1.2.7 The product has not been used for hire
purposes.
1.2.8 The product has been purchased by you, as
the guarantee is not transferable from a private
sale.
2. Claims Procedure
2.1 In the first instance please contact the
Authorised Dealer who supplied the product to
you. In our experience many initial problems with
machines that are thought to be fault due to faulty
parts are actually solved by correct setting up or
adjustment of the machine. A good Authorised
Dealer should be able to resolve the majority of
these issues much more quickly than processing a
claim under the guarantee. If a return is requested
by the Authorised Dealer or Autojack, you will be
provided with a Returns Material Authorisation
Number which must be clearly stated on the
returned package, and any accompanying
correspondence. Failure to provide a Returns
Material Authorisation Number may result in item
being refused delivery.

AIR6V 01AIR6V 01AIR6V 01
AIR100L 13
AUTOJACK GUARANTEE
2.2 Any issues with the product resulting in a
potential claim under the guarantee must be
reported to the Authorised Dealer from which it
was purchased within 48 hours of receipt.
2.3 If the authorised Dealer who supplied the
product to you has been unable to satisfy your
query, any claims made under this guarantee
should be made directly to Autojack. The claim
itself should be made in a letter setting out the
date and place of purchase, giving a brief
explanation of the problem which has led to the
claim. This letter should be then sent with proof
of purchase to Autojack. If you include a contact
number with this it will speed your claim up.
2.4 Please note that it is essential that the letter
of claim reaches Autojack on the last day of this
guarantee at the latest. Late claims will not be
considered.
3. Limitation of Liability.
3.1 We only supply products for domestic and
private use. You agree not to use the product for
any commercial, business or resale purposes and
we have no liability to you for any loss of profit,
loss of business, business interruption or loss of
business opportunity.
3.2 This guarantee does not confer any rights
other than these expressly set out above and does
not cover any claims for consequential loss or
damage. This guarantee is offered as an extra
benefit and does not affect your statutory rights as
a consumer.
4. Notice
This guarantee applies to all product purchased
from an Authorised Dealer of Autojack within the
United Kingdom. Terms of guarantee may vary in
other countries.

AIR6V 01AIR6V 01AIR6V 01
AIR100L 14
CE DECLARATION OF CONFORMITY
TOOLSAVE
Unit C, Manders Ind. Est.,
Old Heath Road, Wolverhampton,
WV1 2RP.
Tel: [phone]
Declares that the Direct Drive Air Compressor (AIR100L)
Is in compliance with the regulations included in the Directives:2006/42/EC
EC DECLARATION OF CONFORMITY
Certificate for EC-type examination delivered by Interk Testing Services Shanghai Building
No.86, 1198 Qinzhou Road(North), Shanghai 200233, China
(Verification No.:151001687SHA-V1 )
Person who declares: Bill Evans
01.04.2017
The Director

AIR100L 15
No. Description No. Description
1 Bolt 32 Bolt
2 Cylinder head 33 Elbow
3 Gasket 34 Piston ring
4 Valve plate 35 Piston
5 Gasket 36 Pin
6 Valve 37 Wrist pin
7 Wrist pin 38 Connect rod
8 Gasket 39 Spring washer
9 Cylinder 40 Bolt
10 Gasket 41 Oil seal
11 Crank case 42 Crank case cover
12 Bolt 43 Spring washer
13 Cylinder head cover 44 Bolt
14 Bolt 45 Fly wheel
15 Air filter 46 Bolt
16 Bolt 47 Washer
17 Spring washer 48 Bolt
18 Bracket 49 Washer
19 Gasket 50 Spring washer
20 Bearing 51 Nut
21 Crank shaft 52 Motor
22 Breather 53 Fly wheel for motor
23 Oil sight glass+gasket 54 Key
25 Bolt 55 Nut
26 Plate 56 Spring washer
27 Gasket 57 Support
28 Bolt 58 Washer
29 Nut 59 Bolt
30 Spring washer 60 Bolt
31 Flat washer 61 Cover
Parts List

AIR100L 16
No. Description No. Description
62 Nut 80 Washer
63 Spring washer 81 Spring washer
64 Washer 82 Nut
65 Bolt 83 Drain cock
66 Belt 84 Plate
67 Nut 85 Tank
68 Spring washer 86 Nut
69 Wheel 87 Spring washer
70 Axle 88 Wheel
71 Air cock 89 Washer
72 Regulator 90 Bolt
73 Connect 91 Washer
74 Pressure switch 92 Handle
75 Power plug 93 Connect
76 Saftey valve 94 Check valve
77 Pressure gauge 95 Exhaust pipe
78 Pressure gauge 96 Unloading assembly
79 Bolt
Parts List

AIR100L 17
Parts Diagram
