AutoLoc AUTKL600 Instruction Manual

GREEN/BLACK (CH3 – 500 mA)
GRAY (STARTER/IGNTION KILL OUTPUT)
GREEN/WHITE (UNLOCK – 500 mA)
BLUE/WHITE (LOCK – 500 mA)
BROWN/BLACK (CH1 – 500 mA)
YELLOW/BLACK (CH2 – 500 mA)
YELLOW (KEY ON ACCESSORY)
PURPLE/BLACK (CH4 – 500 mA)
ORANGE (PARKING LIGHTS)
+
AUTKL600
USER GUIDE
WIRING DIAGRAM
6 channel system
1st channel output
LOCK
UNLOCK
2nd channel output
3rd channel output
4th channel output
Anytime3
Anytime4
Anytime1+3
Anytime2+4
CODE LEARNING
a. Turn key to ON position (yellow ACC wire must be hooked up), press
valet button for 3 seconds. The parking lights will flash once to indicate
code learning mode. Press any button in order to learn the desired
remote. The parking lights will flash once for confirmation, after each
remote transmitter is learned. Up to 4 remote transmitters can be learned
at this time.
b. Turn key to OFF position or wait for 5 seconds and system will exit
code learning.
REMOTE DOOR LOCKING
a. Press button 1. The parking lights will flash once. The starter/ignition
kill circuit will be enabled and the lock output will pulse for 1 second or
until button 1 is released.
b. LED will begin flashing slowly.
REMOTE DOOR UNLOCKING
a. Press button 2. The parking lights will flash twice. The starter/ignition
kill circuit will be disabled and the unlock output will pulse for 1 second
or until button 2 is released.
b. LED will be off.
CH1 OUTPUT
Press button 3 to output channel 1 continuously until button 3 is released.
CH2 OUTPUT
Press button 4 to output channel 2 continuously until button 4 is released.
CH3 OUTPUT
Press button 1+3 to output channel 3 continuously until button 1+3 is
released.
CH4 OUTPUT
Press button 2+4 to output channel 4 continuously until button 2+4 is
released.
VALET SWITCH
KL800
1.
Remote Transmitter
(illustration may very from actual remote)
2A FUSE
KEYLESS ENTRY SYSTEM
TECH SUPPORT: 503.693.1918 WWW.AUTOLOC.COM
©2008 The Hoffman Group International Ltd Co. All rights reserved.
The above instructions are for reference only. THGI is not responsible for any inaccuracies in the above instructions. THGI is also not responsible for any property damage or personal injuries resulting from
the above instructions. Installation by qualified automotive professionals is highly recommended. AUTKL600 1 of 2 Revised 11/05/2013
*ALL OUPUTS ARE NEGATIVE
Ground signals.
Connect to ground side of circuit.
