Automationdirect.com Productivity2000 P2-08TRS User manual
®
Sales 800-633-0405 www.productivity2000.com 1
Document Name Edition/Revision Date
P2-08TRS-DS 2nd Ed. 9/5/2019
Copyright 2016, AutomationDirect.com Incorporated/All Rights Reserved Worldwide
Output Specifications
Outputs per Module 8
Operating Voltage Range
(Tolerance)
(CE) 6.25 - 24 VDC (-15% / + 20%)
6 - 120 VAC (-15% / + 10%)
(UL) 120VAC / 30VDC, 4A / point
Output type 6 Relays, FORM A (SPST)
2 Relays, FORM C (SPDT)
AC Frequency 47 - 63 Hz
Maximum Output Current
@ Temp
4A / point @ 60°C for both AC and DC
2A / point if used with ZIPLink Cable
Minimum Load Current 5mA @ 5VDC
Maximum Inrush Current 4A for 10ms
OFF to ON Response m10ms
ON to OFF Response m10ms
Status Indicators Logic Side (8 points)
Commons 8 Isolated (1 point / common)
External Fuses (user supplied) 6.3A Max
Output Specifications .....................1
Module Installation .........................2
QR Code ........................................2
Hot Swap Information.....................2
Wiring Options................................3
Wiring Diagram and Schematic......3
Warning ..........................................4
Typical Relay Life ...........................4
Removable Terminal Block
Specifications .................................4
General Specifications ...................4
Warranty: Thirty-day money-back guarantee. Two-year limited replacement.
(See www.productivity2000.com for details).
Terminal Block sold separately, (see wiring options on page 3).
P2-08TRS Relay Output
The P2-08TRS high-current isolated relay output
module provides eight 4A surge-protected
outputs for extended relay life. Module offers
both normally open and normally closed relay
contacts for use with the Productivity2000
system.
www.productivity2000.com Tech Support 770-844-4200
2
Important Hot-Swap Information
The Productivity2000 supports hot-swap! Individual
modules can be taken offline, removed, and replaced
while the rest of the system continues controlling your
process. Before attempting to use the hot-swap feature,
be sure to read the hot-swap topic in the programming
software’s help file or our online documentation at
AutomationDirect.com for details on how to plan your
installation for use of this powerful feature.
QR Code
Use any QR Code reader application to
display the module’s product insert.
1 Align
with slot
2rotate
to seated
position
Module Installation
WARNING: Do not apply field power until
the following steps are completed. See
hot-swapping procedure for
exceptions.
WIRE STRIP
LENGTH
WIRE STRIP
LENGTH
Step One: Align module
catch with base slot and
rotate module into
connector.
Locked Unlocked
Step Two: Pull top locking
tab toward module face. Click
indicates lock is
engaged.
Step Three: Attach field wiring using the removable
terminal block or ZIPLink wiring
system.
Caution: If possible, remove field power prior to
proceeding. If not, then EXTREME care MUST be taken
to prevent damage to the module, or even personal injury
due to a short circuit from the live terminal block.
Wiring Diagram and Schematic
NC1
NO1
C1
C2
NO2
C3
NO3
C4
NO4
NC5
C5
NO5
C6
NO6
C7
NO7
C8
NO8
12345678910 11 12 1813 14 15 16 17
6 - 27 VDC
6 - 120 VAC
50 - 60 Hz
L
L
L
L
L
L
L
L
L
L
6.3 A
MAX
User Supplied
External Fuse
P2-08TRS
Sales 800-633-0405 www.productivity2000.com 3
Wiring Options
1ZIPLink Feed Through Modules and Cables¹
0.5 m (1.6 ft) cable
1.0 m (3.3 ft) cable
2.0 m (6.6 ft) cable
ZL-RTB20
ZL-RTB20-1
ZL-P2-CBL18
ZL-P2-CBL18-1
ZL-P2-CBL18-2
Terminal Block with pigtail cable
1.0 m (3.3 ft) cable
2.0 m (6.6 ft) cable
ZL-P2-CBL18-1P
ZL-P2-CBL18-2P
3Screw Terminal Block only
P2-RTB
(Quantity 1)
4Spring Clamp Terminal Block only
P2-RTB-1
(Quantity 1)
5Accessories²
ZL-RTB-COM
TW-SD-SL-1
TW-SD-MSL-1
ZL-RTB20
ZL-RTB20-1
2
1.Cable + ZIPLink Module = Complete System
2. ZL-RTB-COM provides a common connection point for power or ground
www.productivity2000.com Tech Support 770-844-4200
4
WARNING: To minimize the risk of potential safety problems, you should follow all appli-
cable local and national codes that regulate the installation and operation of your equip-
ment. These codes vary from area to area and it is your responsibility to determine which
codes should be followed, and to verify that the equipment, installation, and operation are
in compliance with the latest revision of these codes.
Equipment damage or serious injury to personnel can result from the failure
to follow all applicable codes and standards. We do not guarantee the products
described in this publication are suitable for your particular application, nor do we
assume any responsibility for your product design, installation, or operation.
If you have any questions concerning the installation or operation of this equipment,
or if you need additional information, please call Technical Support at 770-844-4200.
This publication is based on information that was available at the time it was print-
ed. At AutomationDirect.com® we constantly strive to improve our products and services,
so we reserve the right to make changes to the products and/or publications at any time
without notice and without any obligation. This publication may also discuss features that
may not be available in certain revisions of the product.
Typical Relay Life
Voltage & Type of Load Operations at 4A Load Current
30VDC Resistive
30VDC Solenoid
120VAC Resistive
120VAC Solenoid
100,000
100,000
100,000
100,000
General Specifications
Operating Temperature 0° to 60°C (32° to 140°F),
Storage Temperature -20° to 70°C (-4° to 158°F)
Humidity 5 to 95% (non-condensing)
Environmental Air No corrosive gases permitted
Vibration IEC60068-2-6 (Test Fc)
Shock IEC60068-2-27 (Test Ea)
Field to Logic Side Isolation 1800VAC applied for 1 second
Insulation Resistance >10MΩ@ 500VDC
Heat Dissipation 3W
Enclosure Type Open Equipment
Module Keying to Backplane Electronic
Module Location Any I/O slot in a Productivity2000 System.
Field Wiring
Use ZIPLink Wiring System or removable terminal
block (not included). See “Wiring Options” on
page 3.
EU Directive
See the “EU Directive” topic in the Productivity
Suite Help File. Information can also be obtained
at: www.productivity2000.com
Connector Type (not included) 18 position removable terminal block
Agency Approvals
UL 61010-1 and UL 61010-2-201 File E139594,
Canada and USA
CE (EN 61131-2 EMC, EN 61010-1 and EN 61010-
2-201 Safety)*
*Meets EMC and Safety requirements. See the D.O.C. for details.
Removable Terminal Block Specifications
Part Number P2-RTB P2-RTB-1
Number of
Positions 18 Screw Terminals 18 Spring Clamp Terminals
Wire Range
30–16 AWG (0.051–1.31 mm²)
Solid / Stranded Conductor
3/64 in. (1.2 mm) Insulation Maximum
1/4 in. (6–7 mm) Strip Length
28–16 AWG (0.081–1.31 mm²)
Solid / Stranded Conductor
3/64 in. (1.2 mm) Insulation Maximum
19/64 in. (7–8 mm) Strip Length
Conductors “USE COPPER CONDUCTORS, 75°C” or Equivalent.
Screw Driver
Width 0.1 inch (2.5 mm) Maximum*
Screw Size M2 N/A
Screw Torque 2.5 lb∙in (0.28 N∙m) N/A
*Recommend Screw Driver TW-SD-MSL-1
