Leuze MSI-SR5B User manual

MSI-SR5B
Safety Relays
SAFE IMPLEMENTATION AND OPERATION
Original operating instructions
EN 2021/05/27 - 50124428
We reserve the right to make technical changes

Leuze electronic GmbH + Co. KG MSI-SR5B 2
© 2021
Leuze electronic GmbH + Co. KG
In der Braike 1
D-73277 Owen / Germany
Phone: [phone]
Fax: [phone]
http://www.leuze.com
[email protected]

Leuze electronic GmbH + Co. KG MSI-SR5B 3
1 About this document. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
1.1 Used symbols and signal words . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.2 Checklists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2.1 Intended use and foreseeable misuse. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.1.1 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.1.2 Using E-Stop buttons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1.3 Using reset buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1.4 Foreseeable misuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2 Competent persons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.3 Responsibility for safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.4 Exemption of liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 Device description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
3.1 System overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.2 Display elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4 Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
5 Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
6 Mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
7 Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
7.1 Terminal assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
7.2 Sensor wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
7.2.1 Selecting the operating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7.2.2 Acceptance of pending sensor signals (S1 and S2), for both channel 1 (Sx1) and
channel 2 (Sx2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7.2.3 Acceptance of the RES manual release signal via the start button at (RES-I) . . . . . . . . . . . . . 19
7.3 Circuit diagram examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
7.4 Connecting to the machine control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
8 Starting up the device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
8.1 Switching on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
8.2 Start/restart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
8.2.1 Unlocking start/restart interlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
9 Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
9.1 Before the initial start-up and following modifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
9.1.1 Checklist – initial start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
9.2 To be performed periodically by a competent person . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
9.3 To be performed daily by the operating personnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
9.3.1 Check list – daily or at change of shift . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
10 Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
11 Disposing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
12 Service and support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
13 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Leuze electronic GmbH + Co. KG MSI-SR5B 4
13.1 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
14 Order guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
15 EC Declaration of Conformity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

About this document
Leuze electronic GmbH + Co. KG MSI-SR5B 5
1 About this document
1.1 Used symbols and signal words
Table 1.1: Warning symbols and signal words
Table 1.2: Other symbols
Table 1.3: Terms and abbreviations
1.2 Checklists
The checklists (see chapter 9 "Testing") serve as a reference for the machine manufacturer or supplier.
They replace neither testing of the complete machine or system prior to the initial start-up nor their periodic
testing by a competent person. The checklists contain minimum testing requirements. Depending on the
application, other tests may be necessary.
Symbol for dangers
NOTE Signal word for property damage
Indicates dangers that may result in property damage if the measures for danger
avoidance are not followed.
CAUTION Signal word for minor injuries
Indicates dangers that may result in minor injury if the measures for danger avoid-
ance are not followed.
WARNING Signal word for serious injury
Indicates dangers that may result in severe or fatal injury if the measures for danger
avoidance are not followed.
DANGER Signal word for life-threatening danger
Indicates dangers with which serious or fatal injury is imminent if the measures for
danger avoidance are not followed.
Symbol for tips
Text passages with this symbol provide you with further information.
Symbol for action steps
Text passages with this symbol instruct you to perform actions.
AOPD Active optoelectronic protective device
OSSD Output safety switching device
ESPE Electro-sensitive protective equipment
EDM External device monitoring
RES Start/restart interlock (reset)
PFHDProbability of a dangerous failure per hour
MTTFdmean time to dangerous failure
PL Performance Level

Safety
Leuze electronic GmbH + Co. KG MSI-SR5B 6
2 Safety
Before using the safety relay, a risk assessment must be performed according to valid standards (e.g.
EN ISO 12100, ISO 13849-1, EN/IEC 61508, EN/IEC 62061). The result of the risk assessment deter-
mines the required safety level of the safety relay (see table 13.1). For mounting, operating and testing,
this document as well as all applicable national and international standards, regulations, rules and direc-
tives must be observed. Relevant and supplied documents must be observed and handed to the affected
personnel.
Before working with the safety relay, completely read and understand the documents applicable to your
task.
In particular, the following national and international legal regulations apply for the start-up, technical
inspections and work with safety relays:
• Machinery directive 2006/42/EC
• Low voltage directive 2014/35/EU
• Electromagnetic compatibility 2014/30/EU
• Use of work equipment directive 2009/104/EC
•OSHA 1910 Subpart 0
• Safety regulations
• Accident-prevention regulations and safety rules
• Ordinance on Industrial Safety and Health and employment protection act
• Product safety law (Produktsicherheitsgesetz)
2.1 Intended use and foreseeable misuse
2.1.1 Intended use
NOTE
For safety-related information you may also contact local authorities (e.g., industrial inspec-
torate, employer's liability insurance association, labor inspectorate, occupational safety and
health authority).
DANGER
Electrically live systems pose a risk of electric shock!
During all conversions, maintenance work and inspections, make certain that the voltage sup-
ply is interrupted and protected against being restarted again.
Only have work on the electrical system and electronics performed by a competent person.
WARNING
A running machine may result in serious injury!
Make certain that the safety relay is correctly connected and that the protective function of the
protective device is ensured.
Make certain that, during all conversions, maintenance work and inspections, the system is
securely shut down and protected against being restarted.

Safety
Leuze electronic GmbH + Co. KG MSI-SR5B 7
Only if the safety relay is correctly connected and correctly started up is the protective function of the
protective device ensured. To prevent misuse and resulting dangers, the following must be observed:
• These operating instructions are included in the documentation of the system on which the protective
device is mounted and are available to the operating personnel at all times.
• The safety relay is used as a safety monitoring device in combination with safety sensors, switches
and command devices for guarding danger zones or points of operation in machines and systems.
• The safety relay must only be used after it has been selected in accordance with the respectively
applicable instructions and relevant standards, rules and regulations regarding labor protection and
safety at work, and after it has been installed, connected, checked and commissioned by a compe-
tent person.
• The safety relay must only be connected and commissioned in accordance with its specifications
(technical data, environmental conditions, etc.).
• The "Reset" acknowledgment button for unlocking the start/restart interlock must be located outside
of the danger zone.
• The entire danger zone must be visible from the installation site of the acknowledgment button.
• The safety relay must be selected so that its safety-related capability meets or exceeds the required
Performance Level PL ascertained in the risk assessment (see table 13.1).
• The machine or system control must be electrically influenceable so that a switch command sent by
the safety relay results in the immediate shutdown of the dangerous movement.
• The construction of the safety relay must not be altered. When manipulating the safety relay, the pro-
tective function is no longer guaranteed. Manipulating the safety relay also voids all warranty claims
against the manufacturer of the safety relay.
• The safety relay must be tested regularly by a competent person (see chapter 9 "Testing").
• The safety relay must be exchanged after a maximum of 20 years. Repairs or the exchange of wear
parts do not extend the mission time.
2.1.2 Using E-Stop buttons
It must be ensured that the EMERGENCY STOP function is always and immediately effective. An example
showing the connection of a two-channel E-Stop button (see chapter 7.2.2 "Acceptance of pending sensor
signals (S1 and S2), for both channel 1 (Sx1) and channel 2 (Sx2)").
E-Stop buttons connected to the safety relay act only on the safety circuit to which the AOPD or the safety
switch is assigned. It can therefore be considered to be an area E-Stop. The limited sphere of action of the
button is to be clearly marked for the operating personnel. E-Stop buttons must only be used for safety-
related STOP signaling.
2.1.3 Using reset buttons
The "Reset" button for unlocking the start/restart interlock (RES)
• must be located outside of the danger zone.
• must be mounted so that the entire danger zone can be viewed from the installation site.
• must not be accessible from within the danger zone.
If, in the case of two danger zones, it is not possible to monitor both zones from just one location, two reset
buttons (e.g. connected to the local socket of the AOPD) are to be used. The assignment of the buttons to
the respective danger zone must be clearly labeled for the operating personnel.
2.1.4 Foreseeable misuse
Any use other than that defined under the “Approved purpose” or which goes beyond that use is consid-
ered improper use.
Alone, the safety relay is not a complete protective device. It is not suitable for use in the following cases:
• in explosive or easily flammable atmospheres.
• on machines or systems with long stopping times.

Safety
Leuze electronic GmbH + Co. KG MSI-SR5B 8
2.2 Competent persons
Prerequisites for competent persons:
• They have a suitable technical education.
• They know the rules and regulations for labor protection, safety at work and safety technology and
can assess the safety of the machine.
• They know the instructions for the safety relay and the machine.
• They have been instructed by the responsible person on the mounting and operation of the machine
and of the safety relay.
2.3 Responsibility for safety
Manufacturer and operating company must ensure that the machine and implemented safety relay func-
tion properly and that all affected persons are adequately informed and trained.
The type and content of all imparted information must not lead to unsafe actions by users.
The manufacturer of the machine is responsible for:
• Safe machine construction.
• Safe implementation of the safety relay.
• Imparting all relevant information to the operating company.
• Adhering to all regulations and directives for the safe starting-up of the machine.
The operator of the machine is responsible for:
• Instructing the operating personnel.
• Maintaining the safe operation of the machine.
• Adhering to all regulations and directives for labor protection and safety at work.
• Regular testing by competent persons.
2.4 Exemption of liability
Leuze electronic GmbH + Co. KG is not liable in the following cases:
• Safety relay is not used as intended.
• Safety notices are not adhered to.
• Reasonably foreseeable misuse is not taken into account.
• Mounting and electrical connection are not properly performed.
• Proper function is not tested (see chapter 9 "Testing").
• Changes (e.g., constructional) are made to the safety relay.

Device description
Leuze electronic GmbH + Co. KG MSI-SR5B 9
3 Device description
The safety relay serves as a link between one or more safety-related sensors and the machine control.
These sensors may be
•type 4, type 3 or type 2 (self-testing) optoelectronic protective devices (AOPD),
• safety switches,
• safety locking devices,
• E-Stop buttons,
• safety rope switches or
• combinations of these sensors.
The safety relay includes a start/restart interlock that can be activated via the connection terminals, a
contactor monitoring function (EDM) and features two safety-related relay outputs (OSSDs) and LED
displays for status control.
The safety switch uses two terminal groups to connect the sensors and to signal their aggregate data via
the OSSDs. Activation is only possible – taking into account RES and EDM – if the sensors on both chan-
nels and on both terminal groups are switched on.
If one of the sensors switches off, this causes the OSSDs of the safety relay to shut down immediately.
With appropriate bridging (see table 7.1), the evaluation can be reduced to just one sensor.
The safety system consists of the safety relay and the safety components connected to it. It enables
machines or systems to assume a safe state before persons can be endangered. Through the flexible
evaluation of two – possibly also different – sensors, the safety relay provides a compact, low-cost solution
which, with performance level PL e in accordance with EN ISO 13849-1:2015 and SIL 3 in accordance
with EN 61508-1:2010, satisfies the highest safety level.
Figure 3.1: MSI-SR5B with screw terminals Figure 3.2: MSI-SR5B with spring-cage terminals

Device description
Leuze electronic GmbH + Co. KG MSI-SR5B 10
Figure 3.3: Internal circuit diagram
3.1 System overview
• Double sensor evaluation at two terminal groups
• 1- or 2-channel E-Stop circuit
• Cross-circuit detection
• Monitoring of external contactors in the reset circuit
• Monitored reset button (cross circuits between the button contacts and earth faults in the button cir-
cuit are detected.)
• Automatic or manual start/restart
• Stop category 0 (EN 60204-1:2006)
• 2 release circuits
• LED displays Power, K1 and K2, Reset
• Operating voltage 24 V AC/DC
• Housing width 22.5 mm
• Removable connection terminal blocks (screw terminals, spring-cage terminals)
3.2 Display elements
Four LEDs indicate the operating state of the safety relay.
N.O.
N.O.
29 31
30 32
14
K2
K1
5
CH1
CH2
~
=
+
24 16 713
MSI- SR5
21
22 23
15 8
&
(+24V)
(+S12)
(+S11)
(-S12)
(-S22)
(+S22)
(+S21)
(IV-O)
(RES-I)
(RES-O)
(0V-O)
(0V)
6

Device description
Leuze electronic GmbH + Co. KG MSI-SR5B 11
1 "Supply" LED
2"K1" LED
3"K2" LED
4 "Reset" LED
Figure 3.4: Display elements of the MSI-SR5B
Table 3.1: LED indicators
1
2
3
4
Designation LED color Meaning
Supply Green Supply voltage
K1 Green Channel 1
K2 Green Channel 2
Reset Orange Start/restart interlock locked

Functions
Leuze electronic GmbH + Co. KG MSI-SR5B 12
4 Functions
Start/restart interlock
The "start interlock function" ensures that when the system is switched on or when the supply voltage
returns, even if the protective field is free, the safety-related output contacts (OSSDs) of the safety switch
do not automatically switch to the ON state, but only after the reset button has been pressed and released.
The "restart interlock function" prevents the OSSDs of the safety relay from automatically switching to the
ON state if the protective fields of one or more of the connected AOPDs are again released following an
interruption or if a safety switch is closed again. Here too, the reset button must be pressed and released
to unlock the system.
If the "start/restart interlock function" operating mode is not selected for the safety relay, this function and
the corresponding safety level must be ensured by other means.
Observe the safety notices (see chapter 2 "Safety").
Automatic start/restart
"Automatic start" ensures that, if the supply voltage is switched on or restored and with a free protective
field or closed safety switch, the safety-relevant output contacts (OSSDs) of the safety relay automatically
switch to the ON state.
"Automatic restart" ensures that the OSSDs automatically switch to the ON state if the protective fields of
one or more of the connected AOPDs are again released following an interruption or if a safety switch is
closed again.
If the "automatic start/restart" operating mode is selected for the safety relay, steps must be taken to
ensure that it is not possible to step or reach behind or the appropriate safety level must be ensured by
other means.
Observe the safety notices (see chapter 2 "Safety").
EDM contactor monitoring
The "contactor monitoring" function monitors the contactors or relays connected downstream of the safety
relay. Before the OSSDs of the safety relay are switched to the ON state, a check is always performed to
determine whether the downstream switching elements have closed and reopened. If they have not, the
OSSDs remain in the OFF state. If functioning correctly, the start/restart interlock can be unlocked.
The "contactor monitoring" operating mode is selected for the safety relay by looping the EDM contacts of
the subsequent switching elements (e.g. relays, contactors) into the remainder of the circuit. Alternatively,
the corresponding safety level must be ensured by other means.
Reset button monitoring
To detect static faults or blocking of the reset button, the button function is monitored for signal changes.
Enabling occurs when the button is released (1/0 signal change).
Cross-circuit detection
Cross-circuits are detected on the basis of the following correlations:
• AOPDs on the basis of the different test pulses of two transistor OSSDs
• AOPDs with relay OSSDs and two-channel safety switches using 24 V and 0 V
• Cross-circuit between the two channels of a terminal group (+S11, +S12, -S12 and +S21, +S22, -
S22) by means of the 30 ms time window of a group.
If it is to be expected that two, single-channel, contact-controlled sensors will be switched on simultane-
ously, these must be connected at a terminal group or a protected cable layout must be selected.

Applications
Leuze electronic GmbH + Co. KG MSI-SR5B 13
5 Applications
• Sequential circuit for type 4 protective sensors with relay or semiconductor outputs
• Sequential circuit for type 3 laser scanners with semiconductor outputs
• Sequential circuit for type 2 photoelectric sensors (two-channel, self-testing)
• Single-channel E-Stop wiring (up to category 2, EN ISO 13849-1:2015, separate testing)
• Two-channel E-Stop wiring (up to category 4, EN ISO 13849-1:2015)
• Single-channel protective door monitoring (up to category 2, EN ISO 13849-1:2015, separate test-
ing)
• Two-channel protective door monitoring (up to category 4, EN ISO 13849-1:2015)
Figure 5.1: For double muting with entry and exit area, the safety relay evaluates e.g. two AOPDs with
integrated muting function and two muting sensors for each AOPD.

Applications
Leuze electronic GmbH + Co. KG MSI-SR5B 14
Figure 5.2: With this type of point of operation guarding with a service door, the safety relay evaluates
the signals of the safety locking device and of the AOPD.

Mounting
Leuze electronic GmbH + Co. KG MSI-SR5B 15
6 Mounting
The safety relay is intended for mounting on a DIN rail in the switch cabinet.
Prerequisites for mounting:
• Switch cabinet with appropriate degree of protection (at least IP54).
• Sufficient space on the DIN rail.
• Arrangement of the protective device acc. to EN ISO 13855-1:2010 and EN 61496-2:2013.
Snap the safety relay onto the DIN rail.
The safety relay can be connected to the safety sensors.
WARNING
Improper mounting may result in serious injury!
The protective function of the safety relay is only ensured if appropriately and professionally
mounted for the respective, intended area of application.
Only allow competent persons to install the safety relay.
Observe the relevant standards, regulations and these instructions.

Electrical connection
Leuze electronic GmbH + Co. KG MSI-SR5B 16
7 Electrical connection
The following must be observed for the current supply of the safety relay:
• Supply voltage 24 V DC ±20 %.
• Safe mains separation acc. to EN/IEC 60742 possible.
• A corresponding power supply unit handles interruptions of the supply voltage up to 10 ms in dura-
tion acc. to EN/IEC 61496-1:2013.
The following conditions apply for the electrical connection:
• Integration of the safety relay in the control circuit acc. to EN ISO 13849-1.
• Laying of the supply voltage cables separately acc. to EN ISO 13849-1.
• Shutdown of the supply voltage for operational purposes is to be made impossible.
• If the simultaneous switching of two single-channel, contact-controlled sensors is planned, these
must be connected to one terminal group.
• If non-simultaneous switching of two single-channel, contact-controlled sensors is planned, these
are to be connected separately to two terminal groups and the lines to the S inputs of the safety relay
are to be laid in a protected manner.
• Connections 29, 30, 31 and 32 have increased isolation with respect to the housing and the other
connections. The mixed connection of protective extra low voltage and low voltage (e.g. 240 V~) at
terminals 29, 30, 31 and 32 is not permissible.
• It is not permissible to connect the sensor lines in parallel with third-party components.
• All available safety inputs must be occupied.
• To prevent welding of the output contacts, an external fuse must be connected upstream according
to the technical specifications (see table 13.2).
• Terminals 14 and 22 are not intended for the operation of external devices, but rather only for supply-
ing potential-free contacts.
• When connecting potential-free contacts at the S inputs (21, 13, 23, 15) of the safety relay, a safety
fuse must be connected upstream acc. to DIN EN 50156-1.
Connecting the signal lines
For reliable and touch-safe contacts, isolate the connection ends as follows:
• Screw terminals: 7 mm
• Spring-cage terminals: 8 mm
DANGER
Risk of death by electric shock!
Depending on external wiring, dangerous voltages may be present at the switching outputs.
During all work at the electrical system or electronics, make certain that each voltage supply
has been interrupted and protected against being restarted.
WARNING
Improper electrical connection may result in serious injury!
Only allow competent persons to perform the electrical connection.
Make certain that supply and signal lines are laid separately from power lines.
Use appropriate spark extinction for contactors in the cabinet.
Observe the installation and operating information for the products that are to be evaluated
via the safety relay (e.g. multiple light beam safety devices, safety switches, etc.).
Observe the installation and operating information for the products that are to be connected
via the safety relay (e.g. drive motors, brakes, etc.).
When using contact-controlled sensors, separately laid supply lines are to be used for
sensor 1 (+S11, +S12, -S12) and sensor 2 (+S21, +S22, -S22). Cross-circuit monitoring
exists within the terminal groups, but not between the groups.

Electrical connection
Leuze electronic GmbH + Co. KG MSI-SR5B 17
7.1 Terminal assignments
Connected to the safety relay are 16 numbered terminals to which the cables for the various functions are
connected.
The connection of the safety relay is divided into two sensor groups, additional functions, OSSDs and
supply voltage.
Table 7.1: Terminal assignments
WARNING
Selecting the wrong functions may result in serious accidents!
Always connect protective sensors to an external safety relay and activate the restart inter-
lock.
For access guarding, make certain that the restart interlock cannot be unlocked from within
the danger zone but that the danger zone can be viewed from the acknowledgment button
(Reset).
Select the functions so that the safety relay is used as intended (see chapter 2.1 "Intended
use and foreseeable misuse").
Terminal Designation Function
5+Ub Voltage supply, 24 V
60V Voltage supply, 0 V
7+S12 24 V input 1, channel 2
21 +S11 24 V input 1, channel 1
13 -S12 0 V input 1, channel 2
8+S22 24 V input 2, channel 2
23 +S21 24 V input 2, channel 1
15 -S22 0 V input 2, channel 2
14 IV-O 24 V voltage supply, contacts
16 RES-I Reset input
24 RES-O Signal for automatic restart interlock
22 0V-O 0 V voltage supply, contacts
29 OSSD1 Relay contact 1
30 OSSD1 Relay contact 1
31 OSSD2 Relay contact 2
32 OSSD2 Relay contact 2

Electrical connection
Leuze electronic GmbH + Co. KG MSI-SR5B 18
7.2 Sensor wiring
The following evaluation combinations can be selected through external wiring of the safety relay:
Table 7.2: Evaluation combinations
SK = safety-related contact
Evaluation Operating
mode
Connection, terminal Bridging, if the adjacent terminal
group is not needed
AOPD 1, self-testing
(OSSD transistor)
Channel 1
Channel 2
p21
p7
Bridge 22 p13
14 p21
22 p13
14 p7
AOPD 2, self-testing
(OSSD transistor)
Channel 1
Channel 2
p23
p8
Bridge 22 p15
14 p23
22 p15
14 p8
AOPD 1, self-testing
(OSSD relay)
Channel 1
Channel 2
24V pSK p21
0V pSK p13
Bridge 14 p7
14 p21
14 p7
22 p13
AOPD 2, self-testing
(OSSD relay)
Channel 1
Channel 2
24V pSK p23
0V pSK p15
Bridge 14 p8
14 p23
14 p8
22 p15
Safety switch 1, two-
channel
Channel 1
Channel 2
24V pSK p21
0V pSK p13
Bridge 14 p7
14 p21
14 p7
22 p13
Safety switch 2, two-
channel
Channel 1
Channel 2
24V pSK p23
0V pSK p15
Bridge 14 p8
14 p23
14 p8
22 p15
Safety switch 1, single-
channel
Channel 1 24V pSK p21
Bridge 21 p7
Bridge 22 p13
14 p21
22 p13
14 p7
Safety switch 2, one-
channel
Channel 2 24V pSK p23
Bridge 23 p8
Bridge 22 p15
14 p23
22 p15
14 p8
E-Stop command
device 1, two-channel
Channel 1
Channel 2
24V pSK p21
0V pSK p13
Bridge 14 p7
14 p21
14p7
22 p13
E-Stop command
device 2, two-channel
Channel 1
Channel 2
24V pSK p23
0V pSK p15
Bridge 14 p8
14 p23
14 p8
22 p15
E-Stop command
device 2, single-channel
Channel 1 24V pSK p21
Bridge 21 p7
Bridge 22 p13
14 p21
22p13
14 p7
E-Stop command
device 2, single-channel
Channel 2 24V pSK p23
Bridge 23 p8
Bridge 22 p15
14 p23
22 p15
14 p8

Electrical connection
Leuze electronic GmbH + Co. KG MSI-SR5B 19
7.2.1 Selecting the operating modes
The following four operating modes can be selected through external wiring of the safety relay:
7.2.2 Acceptance of pending sensor signals (S1 and S2), for both channel 1 (Sx1) and channel 2 (Sx2)
• For the OSSDs to release, both sensors (S1 and S2) must have satisfied the conditions shown
above.
• The time offset between the sensors (S1 and S2) is arbitrary.
7.2.3 Acceptance of the RES manual release signal via the start button at (RES-I)
• At time t1, all four channels (Sx1, Sx2) must have satisfied the release condition (see chapter 7.2.2
"Acceptance of pending sensor signals (S1 and S2), for both channel 1 (Sx1) and channel 2 (Sx2)").
• Release signal RES must be applied for at least u 150 ms.
Automatic start/restart WA 24p16
Start/restart interlock RES 0V pRES p16
Automatic start/restart and contactor monitoring RS + EDM 24 pK3/K4 p16
Start/restart interlock and contactor monitoring RES + EDM 0V pK3/K4 pRES p16
t < 60 s
Sx1
Sx2
t < 60 s
OSSDs
Sx1
Sx2
OSSDs
350 ms 350 ms
RES
150 ms
>
t1 t2
OSSDs
50 ms

Electrical connection
Leuze electronic GmbH + Co. KG MSI-SR5B 20
7.3 Circuit diagram examples
The following examples show possible connection combinations for AOPDs (relay, transistor), safety
switches and E-Stop command devices on the safety relay.
The following circuit shows the connection of two AOPDs with integrated muting function in a double-
muting application, whereby the muting sensors are locally coupled to the AOPDs to reduce wiring.
Figure 7.1: Two type 4 AOPDs each with two safety-relevant transistor outputs, manual restart (RES)
and contactor monitoring (EDM, K3 and K4)
The following circuit shows the connection of an AOPD in a point of operation guarding system. An E-Stop
button is provided in this circuit.
Figure 7.2: One type 4 AOPD with two safety-relevant transistor outputs, two-channel E-Stop button,
RES and contactor monitoring (EDM, K3 and K4)
NOTE
All available safety inputs must be occupied! Bridges are to connect the remaining sensor inputs
where no components are connected (see table 7.2).
0V MSI-SR5
7
21
13
15
23
6
8
+24V 5
16
22
24
AOPD, Type 4
+24V
14
AOPD, Type 4
+24V
K3 K4
(+Ub)
(+S12)
(+S11)
(-S12)
(+S22)
(+S21)
(-S22)
(IV-O)
(RES-I)
(RES-O)
(0V-O)
(0V)
0V MSI-SR5
7
21
13
15
23
6
8
+24V 5
16
22
24
+24V
AOPD, Type 4
+24V
14
(+U b )
(+S12)
(+S11)
(-S12)
(+S22)
(+S21)
(-S22)
(IV-O)
(RES-I)
(RES-O)
(0V-O)
(0V)
K3 K4
