BF5 Series Fiber Optic Amplier
Please read “Caution for your safety” in operation
manual before using.
Dual digital display type fiber optic amplifiers
Features
● Dual-display for light incident level and setting value(BF5 -D)
● Minute object sensing available with 1/10,000 high resolution
● Enables to detect with high-speed(20,000 times per sec.) moving objects
● 4 response speeds
: Ultra fast mode(50㎲), high speed mode(150㎲),
standard mode(500㎲), long distance mode(4ms)
● Long lasting amplifier regardless of element’s life degradation
or temperature change
● Multiple sensitivity setting modes available
: auto tuning, 1 point(maximum sensitivity), 2 point, positioning teaching
● Up to 8 units enable to stack with mutual interference prevention function
using side connectors
● Auto channel setting function for multiple installations
● Slim design(W10×H30×L70mm)
Model
Display type Dual Display type Single Display type
NPN open collector output BF5R-D1-N BF5G-D1-N BF5B-D1-N BF5R-S1-N
PNP open collector output
BF5R-D1-P BF5G-D1-P BF5B-D1-P BF5R-S1-P
Light source Red LED
(660nm, modulated)
Green LED
(530nm, modulated)
Blue LED
(470nm, modulated)
Red LED
(660nm, modulated)
Power supply 12-24VDC±10%
Current consumption Max. 50mA
Operation mode Light ON / Dark ON Selectable
Control output NPN or PNP open collector
●Load voltage: Max. 24VDC ●Load current: Max. 100mA ●Residual voltage - NPN:Max. 1V, PNP:Max. 3V
Protection circuit Reverse polarity protection, overcurrent protection, surge absorption
Response time Ultra Fast : 50㎲, Fast : 150㎲,STD : 500㎲, Long : 4ms Fast : 150㎲, STD : 500㎲, Long : 4ms
Display method
●Incident light level: Red, 4digit, 7Segment
●SV : Green, 4digit, 7Segment
●Main output indicator : Red LED
●Incident light level / SV : Red, 4digit, 7Segment
●Main output indicator : Red LED
Display function Incident light level / SV display [4,000/10,000 resolution], Percentage display, High/Low peak value display,
Normal / Reversed display
Sensitivity setting Auto tuning, 1 point teaching,
2 point teaching, Positioning teaching Auto tuning
Mutual interference
prevention Max. 8 unit sets (Automatically set regardless of response time)
Initializing Initializing to factory mode
-
Energy saving Normal / Energy saving 1 / Energy saving 2 -
Timer OFF, OFF Delay, ON Delay, One-shot OFF, 10ms OFF Delay timer, 40ms OFF Delay timer
Insulation resistance Min. 20MΩ(at 500VDC megger)
Dielectric strength 1,000VAC 50/60Hz for 1 min.
Vibration 1.5mm amplitude at frequency of 10 to 55Hz(for 1 min.) in each X, Y, Z directions for 2 hours
Shock 500m/s2(Approx. 50G) in each X, Y, Z directions for 3 times
Environ-
ment
Ambient illumination Incandescent lamp : Max. 3000㏓ Sunlight : Max. 11000㏓
Ambient temperature -10 to 50℃, storage: -20 to 70℃
Ambient humidity 35 to 85%RH, storage: 35 to 85%RH
Protection IP40(IEC standards)
Material Case : PBT, Cover : PC
Fiber cable
Tightening torque Min. 2kgf
Accessory Connector type wire(ø4, 3-wire, 2m) (AWG22, Core diameter: 0.08mm, Number of cores: 60,
Insulator out diameter: ø1.25mm), Side connector
Approval
Unit weight Approx. 20g
Line-up
PNP output model

B-10
BF5 Series
10
9.5
2-ø2.4
6
216 36.5
72
30
6.7
9.9
①
②
①
※ 35mm DIN rail
①
②
③
Dimensions
(unit: mm)
● BF5 -D1- ● Accessories
● BF5R-S1-
● Connector type wire(length: 2m)
● Side connector
[Installation] [Removal]
Installations
Amplifier unit mounting
● Installation: Hang up the backside holder on the DIN rail
and press the unit toward the DIN rail.
● Removal: Slide the back part of the unit as the ① figure
and lift up the unit as the ② figure.
Amplifier unit connection
● Remove the side cover at the connecting side as the
figure ① and connect the side connector as the figure ②.
● After mounting the unit on the DIN rail, push gently
both units to fasten each other.
※Make sure that connections between the unit case
and connectors correctly. Improper connection may
cause malfunction of channel setting and mutual
interference prevention functions.
※Do not supply the power while connecting / disconnecting
amplifier units.
Control output diagram
● NPN open collector output ● PNP open collector output
Fiber optic sensor circuit Connection
+
-
(Brown)+V
(Black)output
(Blue)0V
Over
current
protection
Max.100mA
12-24VDC
±10%
Load
Main circuit
Load
Fiber optic sensor circuit Connection
(Brown)+V
(Black)output
(Blue)0V
Max.100mA
12-24VDC
±10%
Load
Main circuit
Over
current
protection +
-
Load
