AVAIR AV-201 User manual

INSTRUCTION
THE AV-201 and AV-601 POWER&SWR meter is the most efficient tool in wide range of semi-professional Measuring And
control instruments. the measured values can be easily read in the large scale instruments.
The AV-201 and AV-601 or is an insertion type RF wattmeter and can be permanently fitted into a transmission System for
continuous monitoring of station working condition .
The unit can be work without external power supply . but with 13.8DC power which permits to light up the Meter and shows
the active led corresponding to the selected RF coaxial line ( for AV-601 )
DESCRIPTION OF CONTROL
1 POWER/SWR reading meter 14 led sensor 1
2 Indicator adjustment 15 led sensor 2 (BANK2 ,BANK3 ,BANK4)
3 Power range switch 16 sensor1/sensor2 switch
4 Function switch
5 FWD /REFLECT POWER/OFF SWITCH REMARK :FIG1/FIG2 FOR AV-200/AV-400/AV-201
6 SWR calibration potential-meter :FIG3/FIG4 FOR AV-601
7 Average pep to pep switch
8 200W/1KW select switch
9-12 Antenna connector(connect to the antenna with 50 ohm coaxial cable)
10-13 TX connector (connect to the radio with 50 ohm coaxial cable)
11 Power jack (13.8VDC) light up the meter and sensor 1 / sensor 2 led
FIG1 FIG2
1 7 6 9 10
8
11
2 3 4 5
1 15 14 7 6 12 16 9
8
2 3 4 5 13 11 10
FIG3 FIG4

INSTALLATION
To install the AV-201 orAV-601 simply connect coaxial cable directed to the antenna connector marked “ANT”,and
The cable coming from the transmitter or from the linear amplifier to the connector marked “TX”
AV-201/orAV-601 is ready to operate.
POWER MEASUREMENTS
1 Select the RANGE (3) switch on the end-scale position value as to the power of the unit
2 Select the FUNCTION (4) switch in the power position
3 Select the POWER switch the FWD position to measure the direct power(from the radio to antenna)
or REF position to measure the reflected power(from antenna to the radio)
4 Select the power value can be read on the corresponding scale.
SWR MEASUREMENTS
1 Select the RANGE (3) switch on the end-scale position value as to the power of the unit.
2 Select the FUNCTION (4) switch in the CALposition .
3 Let the radio transmit and adjust the instrument by turning the CAL knob, position the end-scale index in the
CAL position.
4 Select the FUNCTION (4) switch in the SWR position
5 Read the SWR value in the above scale.
FIG5 (FOR AV-201) FIG6 (FORAV-601 )
TO ANT TO RADIO TO ANT TO RADIO TO RADIO TO ANT
(1.8-160MHZ)OR(140-525 MHZ) (1.8-160MHZ) AV-601 (140-525 MHZ)
REMARK: SWR VS. REFLECT POWER
Pfwd + Prev SWR 1.0 1.1 1.2 1.5 2.0 2.5 3.0
SWR (STANDING WAVE RATIO)=
Pfwd -Prev Prev%0 0.22 0.8 4 11.1 8.4 25.0
SPECIFICATION
FREQUENCE RANGE: ………...1.8~160 MHZ(AV-201,AV-601 ,) , 140~525 MHZ (AV-401,AV-601)
POWER MEASURE RANGE :….0.5~1KW(5W/20W/200W/1KW ) FOR AV-201 AND AV-601 HF BAND
1KW input condition (1KW 10 SECONDS ON 50 SECONDS OFF) if continuous 1KW input will burn the sensor .
POWER MEASURE RANGE :….0.5~400W(5W/20W/200W ) FOR AV-601 UHF BAND
400W input condition (400W 25 SECONDS ON 35 SECONDS OFF) if continuous 400W input will burn the sensor .
MINIMUN POWER INPUT :.…..0.5W Maximum continuous input 200W
PRECISION………………………5W RANGE ±5% , 20W RANGE ±7.5% , 200W RANGE ±10% , 400W RANGE ±12.5%
1KW RANGE ±15%
SWR:……………………..………. 1~INFINITY
IMPDANCE:……………………...50ohm
INPUT LOSS:……………………..0.2db (1.8~160 MHZ) , (140~525MHZ) , 0.3db(430-1300MHZ)
DEMISION:…………………….…15X6.5X10CM
WEIGHT:……………………….…720gr.(AV-601) , 630gr.(AV-201)
