AvaLAN AW58EMVAP User manual

AW58EMVAP AND AW584EMVSU
QUICK START GUIDE
:: Visit us at www.avalan.com :: Technical Support: 866-533-6216 ::
Mounting the Device:
1. WARNING before proceeding power down the dispenser.
2. Attach the plastic mounting plate.
3. Attach the metal mounting bracket to the inside wall using the adhesive pad.
Clean surface before attaching.
4. Hang the radio on the tab of the wall bracket.
5. Write the dispenser number on the In-Dispenser USB Pairing Key.
Connecting the Device:
1. Connect the grounding wire to the grounding screw.
2. Connect the supplied power cable to the dispenser’s power distribution board.
3. Connect network devices to the Ethernet ports.
4. Power on the Dispensers. All In-Dispenser Radios will power up with successful
boot tones within 45 seconds.
IN-DISPENSER RADIO INSTALLATION
WIRELESS NETWORK PAIRING
1. Power on all In-Dispenser Radios and gather all the Pairing Keys.
2. Power on the Access Point wait 45 seconds.
3. Insert the Access Points Pairing Key into the Access Point wait for afrming beeps.
4. Within 15 Seconds, insert an In-Dispenser Radio Pairing Key into the Access Point.
Then allow up to 30 seconds for afrming beeps.
Repeat steps 3-4 for each of the In-Dispenser Radio Pairing Keys.
Troubleshooting Mode:
Whenever the Access Point is silent you can insert In-Dispenser Pairing Key into the
Access Point to enter Troubleshooting mode. The Access Point will chirp how many
Radios are connected and the In-Dispenser Radios will chirp their signal strength.
Store the Access Point Pairing Key in a secure location.
Service fee for replacement key - $100
Radio Pairing Key
Access Point Pairing Key (2)
Mounting Bracket
Adhesive
AW584EMVSU

WU019854-0001
BEST PRACTICES GUIDE
Copyright :: Dover Fueling Solutions :: All rights reserved
IN STORE MOUNTING LOCATIONS
NETWORK CONNECTION DIAGRAM
The included injector powers the Access Point via Ethernet cable.
Back Wall
Front Window
Install Inside
:: Visit us at www.avalan.com :: Technical Support: 866-533-6216 ::
NETWORK CONNECTION DIAGRAM
The included injector powers the Access Point via Ethernet cable.
AW58EMVAP AND AW584EMVSU
QUICK START GUIDE
