Avalon 700 B-Vent User manual

TM
TURN UP THE HEAT!
Owner's Manual
- June, 1994 -
¥ Freestanding Stove
¥ Masonry Fireplace Insert
¥ Factory-Built (Z.C.) Fireplace Insert
Listed
WARNING: If the information in this manual is not followed exactly, a fire or explosion may
result causing property damage, personal injury or loss of life.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS
¥ Do not try to light any appliance.
¥ Do not touch any electrical switch; do not use any phone in your building.
¥ Immediately call gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
¥ If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
700 - Gas Room Heater
10850 117th Place N.E. Kirkland, WA 98033

PAGE 2SAFETY PRECAUTIONS
¥ IF YOU SMELL GAS:
* Do not light any appliance
* Extinguish any open flame
* Do not touch any electrical switch or plug or unplug anything
* Open windows and vacate building
* Call gas supplier from neighbor's house, if not reached, call fire department
¥ This unit must be installed by a qualified installer to prevent the possibility of
an explosion. Your dealer will know the requirements in your area and can
inform you of those people considered qualified. The room heater should be
inspected before use and at least annually by a qualified service person. More
frequent cleaning may be required due to excessive lint from carpeting,
bedding material, etc.
¥ The instructions in this manual must be strictly adhered to. Do not use
makeshift methods or compromise in the installation. Improper installation
will void the warranty and safety listing.
CH 4
83 HC
- or -
¥ This stove may be converted to either natural gas (NG) or propane (LP).
Burning the incorrect fuel will void the warranty and safety listing and may
cause an extreme safety hazard. Direct questions about the type of fuel used to
your dealer. Check the label and flame adjust knob on the gas control valve.
THIS CONTROL
HAS BEEN
CONVERTED FOR
NATURAL GAS
THIS CONTROL
HAS BEEN
CONVERTED TO
LP
HI
LO
PILOT ADJ
VENT
T
O
L
P
I
ON
OFF
HI
LO
RED
LP (Propane)
-o r-
NaturalGas
HI
LO
BLUE
Ok
¥ Contact your local
building officials to
obtain a permit and
information on any
installation restrictions or
inspection requirements in
your area. Notify your
insurance company of this
heater as well.
¥ If the flame becomes
sooty, dark orange in
color, or extremely tall,
do not operate the heater.
Call your dealer and
arrange for proper
servicing.
¥ It is imperative that
control compartments,
screens, or circulating air
passageways of the heater
be kept clean and free of
obstructions. These areas
provide the air necessary
for safe operation. ?
¥ Do not operate the heater
if it is not operating
properly in any fashion or
if you are uncertain. Call
your dealer for a full
explanation of your heater
and what to expect.
Gas
¥ Do not store or use
gasoline or other
flammable liquids in the
vicinity of this heater.
¥ Keep all furniture or other
combustible items at least
36" away from the front
of the stove.
¥ Do not operate if any
portion of the heater was
submerged in water or if
any corrosion occurs.

SAFETY PRECAUTIONS (CONTINUED)PAGE 3
¥ Do not place clothing or
other flammable items on
or near the heater.
Because this heater can be
controlled by a thermostat
there is a possibility of the
heater turning on and
igniting any items placed
on or near it.
¥ Light the heater using the
built-in piezo igniter. Do
not use matches or any
other external device to
light your heater.
¥ Never remove, replace,
modify or substitute any
part of the stove unless
¥ The viewing door should
be opened for service only
(see the maintenance
section of this manual).
¥ Any safety screen or
guard removed for
servicing must be
replaced prior to
operating the room heater.
instructions are given in
this manual. All other
work must be done by a
trained technician. Don't
modify or replace orifices.
¥ Allow the stove to cool
before carrying out any
maintenance or cleaning.
¥ Operate the heater
according to the
instructions included in
this manual.
¥ If the main burners do not
start correctly turn the gas
off at the gas control
valve and call your dealer
for service.
¥ The pilot flame must
contact the thermopile,
thermocouple and deflect
off the pilot hood when
turned on. If it does not,
turn the gas control valve
to "OFF" and call your
dealer.
¥ This unit is not for use
with solid fuel
¥ Do not place anything
inside the firebox (except
the included fiber logs).
¥ If the fiber logs become
damaged, replace with
Travis Industries log set.
This
Manual
¥ Do not throw this manual
away. This manual has
important operating and
maintenance instructions
that you will need at a
later time. Always follow
the instructions in this
manual.
¥ Do not touch the hot
surfaces of the heater.
Educate all children of the
danger of a high-
temperature heater.
Young children should be
supervised when they are
in the same room as the
heater.
¥ Plug the stove into a
115 V. grounded
electrical. Do not use an
adapter plug or remove
the grounding plug.
¥ Don't route the electrical
cord in front of or over
the stove
¥ Instruct everyone in the
house how to shut gas off
to the appliance and at the
gas main shutoff valve.
The gas main shutoff
valve is usually next to
the gas meter or propane
tank and requires a
wrench to shut off.
¥Travis Industries, Inc.
grants no warranty,
implied or stated, for the
installation or
maintenance of your
heater, and assumes no
responsibility of any
consequential
damage(s).

PAGE 4TABLE OF CONTENTS
General Information
Introduction & Important Information ................................................................................................... 1
Safety Precautions............................................................................................................................... 2
Features & Specifications.................................................................................................................... 5
Stove Installation
Heater Placement................................................................................................................................ 6
Floor Protection ................................................................................................................................... 7
Vent Requirements.............................................................................................................................. 7
Gas Line Install.................................................................................................................................... 8
Finalizing the Installation ..................................................................................................................... 9
Insert Installation
Heater Placement................................................................................................................................ 10
Fireplace Sizing ................................................................................................................................... 11
Floor Protection ................................................................................................................................... 11
Vent Requirements.............................................................................................................................. 11
Gas Line Install.................................................................................................................................... 12
Finalizing the Installation ..................................................................................................................... 13
Operating Your Heater
Reviewing the Installation.................................................................................................................... 14
Before You Begin................................................................................................................................. 15
Location of Controls............................................................................................................................. 15
Starting The Pilot ................................................................................................................................. 16
Running Your Heater ........................................................................................................................... 17
Starting the Heater for the First Time ........................................................................................... 17
Turning the Heater On and Off ..................................................................................................... 18
Adjusting the Flame Height .......................................................................................................... 19
Adjusting the Blower Speed ......................................................................................................... 19
Normal Operating Sounds ................................................................................................................... 19
Maintaining Your Heater
Inspecting the Firebox ......................................................................................................................... 20
Installing the Logs and Coals............................................................................................................... 21
Inspecting the Door ............................................................................................................................. 22
Replacing the Door Gasket .......................................................................................................... 22
Replacing the Glass or Glass Gasket........................................................................................... 22
Troubleshooting
Troubleshooting Table ......................................................................................................................... 23
How this Heater Works........................................................................................................................ 24
What Turns the Main Burners On and Off.................................................................................... 24
Why Nothing Should Be Placed Against the Heater..................................................................... 24
What Prevents Gas Buildup ......................................................................................................... 25
Wiring Diagram............................................................................................................................. 26
Replacement Parts List ................................................................................................................ 26
Warranty
Warranty .............................................................................................................................................. 27
Listing Information
Listing Information ............................................................................................................................... 28
Optional Equipment
Legs ..................................................................................................................................................... 29
Pedestal............................................................................................................................................... 29
Surround Panels.................................................................................................................................. 30
Telescoping Legs................................................................................................................................. 31
Remote Control ................................................................................................................................... 32
Thermostat........................................................................................................................................... 34
Re-Routing the Power Cord to the Left or Rear of the Heater............................................................. 36
Index
Index.................................................................................................................................................... 38

FEATURES AND SPECIFICATIONS PAGE 5
Installation Options:
¥ Freestanding
¥ Freestanding in an Alcove
¥ Masonry Fireplace Insert
¥ Factory-Built (Z.C.) Fireplace
Insert
Features:
¥ Works During Power Outages
(utilizes millivolt system)
¥ High Efficiency; Up to 80% for Natural
Gas, 82% for LP (Steady State)
¥ Optional Thermostat or Remote Control
¥ Realistic "Wood Fire" Look
¥ Convenient Operating Controls
¥ Variable-Rate Heat Output
¥ Quiet Blower for Effective Heat
Distribution
¥ Low Maintenance
Heating Specifications: 700 Natural
Gas
700 LP
(propane)
Approximate Maximum Heating Capacity (in square feet)* 600 - 1600 600 - 1600
High Burn Input Rate (In BTU's)** 31,000 31,000
Low Burn Input Rate (In BTU's)** 18,000 17,000
AFUE Efficiency 70.0 % 70.0 %
* Heating capacity will vary depending on the home's floor plan, degree of insulation, and the outside temperature. It is also
affected by the natural gas or LP BTU rating.
** To measure the net BTU's, multiply the BTU input by the efficiency percentage (80% for natural gas, 82% for LP).
700 Dimensions
23 5/8"
18 1/2"
HEIGHT*:
Without Legs 20 1/8"
With Pedestal 31 3/8"
With Brass Legs 28"
With Cast Legs 28"
With Black Legs 26 5/8"
* Subtract 1 1/8" to reach
the base of the flue collar
3 1/4"
Vent Opening Diameter = 4" (Both)
Weight = 175 Pounds
Electrical Specifications:
Blower Electrical Rating: 115 Volts, 1.3 Amps, 60 Hz (150 watts on high)
Fuel:
The heater is designed either for natural gas or for propane (but not for both). Check the sticker
on the top of the gas control valve.
Emissions:
This unit has passed the ANSI emission standards for vented room heaters as tested by Warnock
Hersey, LTD.

PAGE 6STOVE INSTALLATION - For qualified installers only!
This appliance must be installed in accordance with all local codes, if any; if not,
follow ANSI Z223.1 and the requirements listed in this manual. Failure to follow all
of the requirements may result in property damage, bodily injury, or even death.
Check with local building officials for any permits required for installation of this gas heater and
notify your insurance company before hooking up this heater. The requirements listed below are
divided into sections. All requirements must be met simultaneously. The order of installation is
not rigid Ð the qualified installer should follow the procedure best suited for the installation.
Heater Placement
The heater must be placed so the following requirements are met:
¥ Stove must be placed so that no combustibles are within, or can swing within (e.g.
drapes, doors), 36" of the front of the heater
¥ The stove must be placed on a set of Travis Industries legs or pedestal
¥ Heater must be installed on a level, secure floor
¥ The stove must not be placed so the vents below the ashlip, above the door, along
the sides of stove, or along the back of the heater can become blocked
Alcove Installations If the ceiling height is under 7 feet, the following requirements must be met:
¥ Minimum height 58"
¥ Maximum depth 48"
¥ Minimum width 43-5/8"
STRAIGHT INSTALLATION (see the illustration below)
¥ 10" clearance from the top of the heater to the sidewall
¥ 3" clearance from the top of the heater to the backwall
CORNER INSTALLATION (see the illustration below)
¥ 4" clearance from the rear top corner of heater to the cornerwall (at a 45°angle)
HINT: REDUCING CLEARANCES - Clearances may be reduced by
methods specified in NFPA 211, listed wall shields, pipe shields, or
other means approved by local building or fire officials.
Corner
Installation
Backwall
Sidewall
When the stove is installed directly on carpeting, vinyl, or other combustible material other than wood flooring,
the stove must be installed on a metal or wood protection panel extending the full width and depth of the stove.
Straight
Installation
Cornerwall
Cornerwall
4" MIn.
(to top of
stove)
10" MIn.
(to top of
stove)
3" MIn.
(to top of
stove)

STOVE INSTALLATION (CONT.) - For qualified installers only! PAGE 7
Floor Protection
When the stove is installed directly on carpeting, vinyl or other combustible material other than
wood flooring, the stove must be installed on a metal or wood protection panel extending the full
width and depth of the stove.
Vent Requirements
The vent must be installed in accordance with all local codes, if any; if not, follow ANSI 223.1
and the requirements listed below. Furthermore, the vent must be installed to meet the
installation requirements of the vent manufacturer.
¥ Minimum 5' vertical rise from top of stove (see the illustration below)
¥ The horizontal run may not exceed 50% of the vertical rise
¥ Use 4" dia. B vent for entire system from one manufacturer (don't mix brands)
- or -
Use high temperature factory built chimney and connector with listed gas
chimney liner running the entire length
¥ The vent must not service another appliance
¥ 1" clearance to all combustibles must be maintained
¥ Must meet all of the vent manufacturer's requirements
¥ Vent termination must be above the roof and not below any eaves or overhangs
Type B Vent
Vent must
terminate a
minimum 1'
above the roof.
Listed Gas
Chimney Liner
Maintain 1"
minimum
clearance
Provide a 1/4" rise
for every 12" run.
Min. 5' Rise High
temperature
factory built
chimney and
connector
Chimney with LinerStandard Installation Exterior Vent
Min. 5' Rise
The total
horizontal
run must
not exceed
50% of the
vertical rise
Do not block gas
vent termination

PAGE 8STOVE INSTALLATION (CONT.) - For qualified installers only!
Vent Requirements (continued)
¥ Vent termination must have an approved cap (to prevent water from entering)
¥ Vent termination must not be located where it will become plugged by snow or
other material
¥ Vent termination must be 1' above the roof and meet the requirements outlined in
ANSI 223.1, section 7.6.2.
1' Minimum
Note: ANSI 223.1, section 7.6.2 outlines
additional requirements for gas vent terminations.
If your installation involves a roof with a slope
greater than 6/12 or if a wall or other verical
obstruction is within 8' of the vent termination, the
vent termination will need to be taller. Refer to
ANSI 223.1 for full details.
NOTE: When installed, the vent must provide suitable draft for the
appliance. Other factors, such as exhaust fans, may create negative
pressure inside the home and cause down drafts. Additional vent
height may be required in these circumstances.
Draft Hood
TO TEST THE DRAFT:
Remove the back panel. Start the heater and
check the perimeter of the draft hood with a
gas detector or smoke. If combustion products
leak out the draft hood, the vent may need to
be taller to improve draft.
Vent Collar
Spill Switch
Gas Line Install
The gas line must be installed in accordance with all local codes, if any; if not, follow ANSI
223.1 and the requirements listed below.
Gas Line Connection:
¥ The gas inlet is a male 3/8" NPT
¥ This appliance requires a shutoff valve upstream of
the appliance. This valve must be accessible and
within 3 feet of the heater.

STOVE INSTALLATION (CONT.) - For qualified installers only! PAGE 9
Gas Inlet Location:
The 3/8" N.P.T. gas
inlet portrudes 1 1/2"
from the back edge of
the stove.
HEIGHT:
From Base of Stove 1 1/2"
With Pedestal 12 3/4"
With Brass Legs 9 3/8"
With Cast Legs 9 3/8"
With Black Legs 8"
LOCATION OF THE
GAS INLET CENTER:
C
L
7 1/2" (from
center of stove)
Manifold Pressure:
¥ Check the pressure of the gas downstream of the valve by removing the manifold
pressure tap with a 3/16" allen wrench (1/8" N.P.T. plug). If the manifold
pressure does not match the pressure listed in the table below, check the inlet gas
pressure and correct the problem.
Manifold Pressure with Regulator on HI
Natural Gas 3.5" W.C.
Propane 11" W.C.
Manifold Pressure Tap
(1/8" N.P.T. fitting)
Use a 3/16" allen wrench to remove.
The heater must be turned off while
connecting or disconnecting the
pressure tap or pressure sensing
device. Gas will ignite through the
pressure tap hole if the heater is on
and the pressure tap hole is open!
WARNING:
HI-LO Regulator
Gas Pressure:
Minimum Input Pressure
Natural Gas 7" W.C.
Propane 11" W.C.
¥ If the pressure is not sufficient, make sure the piping used is large enough, the
supply regulator is adequately adjusted, and the total gas load for the residence
does not exceed the amount supplied.
¥ The supply regulator (the regulator that attaches directly to the residence inlet or
to the propane tank) should supply gas at the suggested input pressure listed
above. Contact the local gas supplier if the regulator is at an improper pressure.
Purging the Gas Line:
The gas line must be properly purged to release all air in the gas line prior to starting the heater.
Finalizing the Installation
¥ Before starting, all gas line joints must be leak tested.
¥ Optional equipment must be installed (instructions are in the rear of this manual).
¥ The ceramic logs must be placed inside the firebox (see the section "Installing the
Logs and Coals" in the maintenance section of this manual).
¥ Start the heater and check for proper performance. Review the operations portion
of this manual to make sure the owner understands the operation of the heater.
Note: See the instructions "Re-Routing the Power Cord to the Left or Rear of the Heater" in the optional
equipment section of this manual to re-route the power cord.

PAGE 10 INSERT INSTALLATION - For qualified installers only!
This appliance must be installed in accordance with all local codes, if any; if not,
follow ANSI Z223.1 and the requirements listed in this manual. Failure to follow all
of the requirements may result in property damage, bodily injury, or even death.
Check with local building officials for any permits required for installation of this gas heater and
notify your insurance company before hooking up this heater. The requirements listed below are
divided into sections. All requirements must be met simultaneously. The order of installation is
not rigid Ð the qualified installer should follow the procedure best suited for the installation.
Heater Placement
The heater may be installed in a masonry or zero-clearance (metal) fireplace with the
following requirements:
¥ The insert must be placed so that no combustibles are within, or can swing within
(e.g. drapes, doors), 36" of the front of the heater
¥ The insert must be installed in a level, undamaged masonry or zero-clearance
(metal) fireplace. Any damage must be repaired prior to installation. The heater
must not extend beyond the hearth.
¥ The insert must maintain a 10" clearance to sidewalls
¥ The non-combustible side facing (e.g. brick, tile, cement board) must extend 8"
from the side of the insert
¥ The non-combustible top facing (e.g. brick, tile, cement board) must extend 8"
above the top of the insert
¥ The combustible mantle must be at least 17" above the top of the insert
HINT: REDUCING CLEARANCES - Clearances may be reduced by
methods specified in NFPA 211, listed wall shields, pipe shields, or
other means approved by local building or fire officials.
17" Min.
Combustible Mantle
Floor protection must
extend underneath
insert to the faceplate
Sidewall
23 5/8" Min.
(Width of Floor Protection)
WIDTH INCLUDING
SIDE PANELS:
40" with 8" Panels
44" with 10" Panels
48" with 12" Panels
HEIGHT INCLUDING
TOP PANEL:
28" with 8" Panels
30" with 10" Panels
32" with 12" Panels
10" Min. 8" Min.
8" Min.
Floor Protection The heater must be installed over a non-combustible 3/8" thick hearth that
extends to both sides and from the rear edge of the heater to the front edge.

INSERT INSTALLATION (CONT.) - For qualified installers only! PAGE 11
Fireplace Sizing
21" Minimum**
21" Minimum
24" Minimum*
24" Minimum
13" Minimum*
5 3/4" Minimum
* The gas inlet may be
located at the rear or on the
left side if the Side Inlet Kit
is used. Allow space for
gas hookup.
** The extra space above
the heater is to allow
connection of the flue.
Vent Requirements
The vent must be installed in accordance with all local codes, if any; if not, follow ANSI 223.1
and the requirements listed below. Furthermore, the vent must be installed to meet the
installation requirements of the vent manufacturer.
¥ Minimum 5' vertical rise from top of stove (see the illustration below)
¥ 4" listed gas chimney liner or B vent from one manufacturer (don't mix brands)
¥ Vent must reline the entire length of the chimney
¥ The vent must not service another appliance
¥ Must meet all of the vent manufacturer's requirements
NOTE: When using flexible gas vent, do not crimp or rupture the liner when
bending it around a chimney offset
4" Listed gas chimney
liner or B Vent
Hearth and/or
hearth pad must
extend at least
to the faceplate
Z.C. (Metal)
firebox
Telescoping
Leg
6"
Min.
A sealed cover plate
is recommended,
but not required.
Surround
Panel
(Do not seal)
17"
Min.
Gas line with
shutoff valve
6"
Min.
17"
Min.
Leveling bolts for step-up hearths
Zero
Clearance
Fireplace
Surround
Panel
(Do not seal)
Approved Cap
Masonry
Fireplace

PAGE 12 INSERT INSTALLATION (CONT.) - For qualified installers only!
Vent Requirements (continued)
The vent termination must meet the following requirements:
¥ Vent termination must have an approved cap (to prevent water from entering)
¥ Vent termination must not be located where it will become plugged by snow or
other material
¥ Vent termination must extend a minimum of 6" above the top of the chimney
NOTE: When installed, the vent must provide suitable draft for the
appliance. Other factors, such as exhaust fans, may create negative
pressure inside the home and cause down drafts. Additional vent
height may be required in these circumstances.
How to tell if you have negative pressure:
The most common indication of a negative pressure situation is the heater (and pilot) turning off
between 10 and 25 minutes from the time the main burner was started (this happens most often on
cold days). The main burner turns on, but instead of warming the flue and creating draft, it vents out
of the draft hood at the rear of the heater. The spill switch then heats up, and in about 5 to 15
minutes shuts off all gas to the heater (shutting off the main burner and pilot). If a thermostat is used
on your heater, and the pilot shuts down sporadically, you may have a negative pressure situation.
Gas Line Install
The gas line must be installed in accordance with all local codes, if any; if not, follow ANSI
223.1 and the requirements listed below.
Gas Line Connection:
¥ The gas inlet is a male 3/8" NPT
¥ This appliance requires a shutoff valve upstream of
the appliance. This valve must be accessible and
within 3 feet of the heater.
Gas Inlet Location:
1 1/2" Above
the base of
the stove
LOCATION OF THE
GAS INLET CENTER:
C
L
7 1/2" (from
center of stove)
The 3/8" N.P.T.
gas inlet
portrudes 1
1/2" from the
back edge of
the stove.
LOCATION OF THE GAS INLET
CENTER WITH THE SIDE INLET KIT:
2 1/8" Behind the
fireplace opening
1 1/2"
Above the
base of
the stove
The 3/8" N.P.T.
gas inlet
portrudes 1
1/2" from the
back edge of
the stove.

INSERT INSTALLATION (CONT.) - For qualified installers only! PAGE 13
Manifold Pressure:
¥ Check the pressure of the gas downstream of the valve by removing the manifold
pressure tap with a 3/16" allen wrench (1/8" N.P.T. plug). If the manifold
pressure does not match the pressure listed in the table below, check the inlet gas
pressure and correct the problem.
Manifold Pressure with Regulator on HI
Natural Gas 3.5" W.C.
Propane 11" W.C.
Manifold Pressure Tap
(1/8" N.P.T. fitting)
Use a 3/16" allen wrench to remove.
The heater must be turned off while
connecting or disconnecting the
pressure tap or pressure sensing
device. Gas will ignite through the
pressure tap hole if the heater is on
and the pressure tap hole is open!
WARNING:
HI-LO Regulator
Gas Pressure:
Minimum Input Pressure
Natural Gas 5.5" W.C.
Propane 11" W.C.
¥ If the pressure is not sufficient, make sure the piping used is large enough, the
supply regulator is adequately adjusted, and the total gas load for the residence
does not exceed the amount supplied.
¥ The supply regulator (the regulator that attaches directly to the residence inlet or
to the propane tank) should supply gas at the suggested input pressure listed
above. Contact the local gas supplier if the regulator is at an improper pressure.
Purging the Gas Line:
The gas line must be properly purged to release all air in the gas line prior to starting the heater.
Finalizing the Installation
¥ Before starting, all gas line joints must be leak tested.
¥ Optional equipment must be installed (instructions are in the rear of this manual).
¥ The ceramic logs must be placed inside the firebox (see the section "Installing the
Logs and Coals" in the maintenance section of this manual).
¥ Start the heater and check for proper performance. Review the operations portion
of this manual to make sure the owner understands the operation of the heater.
Note: See the instructions "Re-Routing the Power Cord to the Left or Rear of the Heater" in the optional
equipment section of this manual to re-route the power cord.

PAGE 14 REVIEWING THE INSTALLATION
The check off list below details the installation concerns that you, the consumer,
should know prior to starting the heater. This information is very important and
must be checked off.
( ) There are no combustible
items placed within 36" of the
front of the heater or swing
within 36" of the front of
heater. This includes
furniture, doors, drapes, etc. Combustible
36" Minimum
( ) No combustibles are within
1" of the exhaust vent. Due
too high temperatures, the
room heater should be located
out of traffic and away from
combustibles. This includes
drywall, drapes, window sills,
etc. If any question exists,
call your dealer for a full
explanation.
CombustibleGas Vent
Min.1"
clearance
( ) The location of the GAS
MAIN SHUTOFF VALVE.
It is usually directly next to
the gas meter or propane tank
and may require a wrench to
shut off. Everyone in the
house should know where the
gas main shutoff valve is and
how to turn it off.
On most valves this is ON On most valves this is OFF
( ) All of the necessary permits
and installation information
have been obtained for your
records. This includes the
permits from building
officials, receipts, and this
manual.
O k
Permits Receipts This Manual
OWNER'S
MANUAL
( ) The operation card included
with the heater slides out
from behind the access panel.
If you can not find it, call
your dealer for details. This
card includes important
operation information that
must be kept with the heater
at all times.

OPERATING YOUR HEATER PAGE 15
Before You Begin
READ THIS ENTIRE MANUAL BEFORE YOU USE YOUR NEW HEATER.
FAILURE TO FOLLOW THE INSTRUCTIONS MAY RESULT IN PROPERTY
DAMAGE, BODILY INJURY, OR EVEN DEATH.
Before starting your heater make sure you have read the section titled Safety Precautions. Any
questions should be referred to your dealer.
Location of Controls - See explanation below
ON
OFF
MAIN BURNER
PILOT
IGNITER
HI
OFF
LO
Flame
Adjust
Knob
With the access panel flipped down
the controls can be accessed.
Gas
Control
Knob
ON/OFF
Switch
PILOT
IGNITER
BLOWER
Dial
BLOWER
Gas Control Knob This knob is used for starting the pilot. There are three positions, ON,
OFF, & PILOT. The pointer directly below the knob indicates the
position this knob is in.
Flame Adjust Knob This knob controls the flame height from low ("LO") to high ("HI"). The
pointer to the upper right of the knob points to the position this knob is in.
ON/OFF Switch This control is used to turn the heater on and off.
PILOT IGNITER The pilot igniter is used only while starting the pilot. When pressed, it
sends an electrical charge to the pilot assembly. This creates a blue spark
directly next to the pilot light, igniting it.
BLOWER Dial This dial controls the speed of the internal convection blower that pushes
the heated air into the room.
NOTE: The ON/OFF Switch must be left "ON" if using the remote control or
thermostat. Turning the ON/OFF Switch to "OFF" will keep the
heater off always.

PAGE 16 OPERATING YOUR HEATER (CONTINUED)
Starting The Pilot
The pilot light is used to ignite the main burners when the stove is turned on and also provides an
important safety role. It will stay lit once it is started. However, the gas flowing to the pilot will
shut off whenever the pilot goes out. If the pilot turns off frequently, call your dealer for
information. To start the pilot follow the directions below:
A. Push the gas control
knob in slightly and
turn it to the "OFF"
position. The knob
will not turn from
"ON" to "OFF"
unless the knob is
depressed slightly.
B. Wait five minutes to
let any gas that may
have accumulated
inside the firebox
escape. If you smell
gas, follow the
directions on the
cover "IF YOU
SMELL GAS".
C. Turn the gas control
knob to the "PILOT"
position and press the
knob in, this will
allow gas to flow to
the pilot light. Press
the red button on the
pilot igniter
repeatedly until you
see the pilot light.
KEEP THE GAS
CONTROL KNOB
DEPRESSED FOR
30 SECONDS
ONCE IT IS LIT.
Note: If the pilot
does not light after
several tries, call
your dealer for
service.
IN
L
O
T
ON
OFF
P
I
IN
L
O
T
ON
OFF
P
I
IN
L
O
T
ON
OFF
P
I
Keep the knob
pressed in for
30 seconds
C
B
IN
L
O
T
ON
OFF
P
I
A

OPERATING YOUR HEATER (CONTINUED)PAGE 17
D. Release the gas
control knob. If the
pilot goes out, repeat
step C. If the pilot
refuses to stay lit,
call your dealer for
service.
E. Turn the gas control
knob counter-
clockwise to "ON".
The pilot is now lit
and the heater can be
turned on and off.
IN
L
O
T
ON
OFF
P
I
IN
L
O
T
ON
OFF
P
I
If the pilot
light goes
out after
releasing
the knob,
repeat step
C above.
D
E
Running Your Heater
Your heater may be turned on and off manually, with the optional remote control, or by the
optional thermostat. The speed of the blower and the height of the flame can also be adjusted
manually.
NOTE: When the heater first comes on, the flames will be blue and
somewhat transparent. After fifteen minutes the flames will turn a
more realistic yellow and orange color.
NOTE: Certain installations use a remote "wall switch" to turn the heater on
and off. If this is the case, leave the ON/OFF switch on "ON".
NOTE: When this switch is turned to the "OFF" position the main burner
will not operate. However, the pilot flame will stay lit.
Starting the Heater for the First Time
Cure the Paint
To cure the paint, start the heater and turn the flame height to low. Leave it on for 20 minutes
then turn it off and let it cool. Repeat this process two more times to fully cure the paint. You
will smell the paint curing Ð this is normal.
Ventilate the Room
You may wish to ventilate the room by opening a window. Furthermore, the glass may become
obscure during the first 10 hours of burning due to the components inside the firebox curing.
Clean the glass with a glass cleaner after the first ten hours of operation.

PAGE 18 OPERATING YOUR HEATER (CONTINUED)
Turning the Heater On and Off
¥ Manual Operation
After the pilot has been
on for approximately one
minute the heater may be
turned on and off by
pressing the ON/OFF
switch located behind the
access panel underneath
the ashlip (see the
illustration to the right).
Use this switch to turn the heater on and off.
ON
OFF
MAIN BURNER
BLOWER
PILOT
IGNITER
HI
OFF
LO
¥ Remote Control Operation (Optional)
The remote control turns the heater on from any location within the room. It utilizes a remote
control and a receiver (usually located in the wall near the heater). Make sure the following has
been done before trying to use the remote control: 1) The pilot is on; 2) The on/off switch is
turned to "ON", and; 3) The switch on the remote control receiver is turned to "REMOTE" (see
the illustration below). This switch can also be used to turn the heater on and off manually. The
remote control requires two batteries, one in the remote and one in the remote control receiver .
Both batteries must be charged for the remote control to work. If the remote control does not
work, try replacing the batteries. If this doesn't work, contact your dealer for service.
REMOTE OFF ON
FIRELYTER
Remote Control
Receiver
(Mounted to Wall)
Remove the screw on the back of the
remote control to access the battery
Remove the upper
and lower screws to
access the battery
Remote Control
Hookup Wire
Turn this switch to
"REMOTE" to use
the remote control
This button
on the remote
control turns
the heater on
and off
¥ Thermostat Operation (Optional)
After the pilot has been started the heater may be controlled by a
thermostat. The on/off switch on the heater must be turned "ON"
for the thermostat to operate. The thermostat will automatically
turn the heater on and off depending on the temperature. If the
thermostat does not turn the heater on, the thermostat may be set
too low or the on/off switch may be turned "OFF". If the
thermostat does not turn the heater off, the thermostat may be
set too high. If the thermostat does not work after making these
adjustments, call your dealer for service.
HINT: If the heater turns on and off frequently, you may want to adjust the
flame height down until it produces just enough heat needed. This
keeps the thermostat from turning the heater on and off repeatedly.
WARNING: Do not place any combustible items on top of the heater, even
temporarily. The thermostat is automatic and may start the heater
causing a combustible item to ignite.

OPERATING YOUR HEATER (CONTINUED)PAGE 19
Adjusting the Flame Height
Your heater has an adjustable flame to tailor the look and heat output to your specific needs. It is
adjusted by turning the middle dial on the valve assembly.
Flame Height
Adjustment Knob
Index Mark
HI
LO
Turn clockwise to
adjust the flame higher.
HI
LO
Turn counter-clockwise
to adjust the flame lower.
The flame height adjustment
knob is located under the
ashlip behind the access panel
Adjusting the Blower Speed
The blower helps transfer the heat from the heater into the room. It will not turn on until the
heater is up to temperature (approximately 10 minutes after starting). See the illustration below
for instructions on adjusting the blower speed.
ON
OFF
MAIN BURNER
BLOWER
HI
OFF
LO
Turn the knob all the way
counter-clockwise to turn the
blower off. One click
clockwise turns the blower to
high speed. Turning the knob
clockwise from the high
position decreases the speed
of the blower.
Normal Operating Sounds
Gas Control Valve
As the gas control valve is
turned on and off you will
hear a dull clicking sound.
This is the valve opening
up and shutting down.
Blower Thermodisk
This part can produce a
clicking sound as it turns
the blower on and off.
Blower
This heater uses a
high tech blower to
push heated air
into the room. It
will make a whirring
sound and will
increase in volume
as the speed is
increased.
Burner Pan
The burner pan is underneath
the logs and is used to mix the
proper amount of air with the
natural gas to produce a clean
and efficient burn. When it is
started you will hear a slight
"whoosh" sound. When the
main burner is running you will
hear the gas flowing through
the burner pan and orifices Ð
this sound will decrease as the
flame height is lowered.
Pilot Flame
The pilot flame, which
remains on, makes a very
slight "whisper" sound.
Stove Body
Due to the heavy steel
construction, occasional
clicks may come from the
heater, especially during
startup.

PAGE 20 MAINTAINING YOUR HEATER
Every year you should inspect the firebox and door to make sure they are clean and functional.
WARNING: Failure to inspect and maintain your heater may lead to improper
burning inside the heater, leading to a dangerous situation.
Inspecting the Firebox
The firebox should be inspected and cleaned of any soot or dust that may have been drawn into
the heater. To do this, follow the directions below.
1. Remove the door (see the illustration below).
1. Unscrew the handle
until it can be removed.
3.
2. Swing the
door open.
Lift the
door off
the hinges
(use both
hands).
4.
When replacing the
handle make sure
the handle is facing
outwards, otherwise
it may burn.
2. Remove the logs and coals (see the instructions on the following page).
3. Use a vacuum cleaner with a soft brush attachment to vacuum any dirt off the
burner pan (see the illustration below). The rear log is fragile and should not be
vacuumed. Inspect the burner pan and firebox for any deterioration. If it shows
signs of deterioration, call your dealer for a full inspection. There should be no
soot in the firebox, except for a small amount on the logs where the flames brush
up against them. If there is additional soot, the heater may need adjustment.
Contact your dealer for information.
Make sure
all the
burner
holes are
clean and
no dirt has
collected Log clips
Rear log
4. To replace the front log and coals follow the directions in the section "Installing
the Logs and Coals".
5. Replace the door. Turn the door handle clockwise until the door seals tight.
Make sure the handle faces outwards and is not in front of the glass.
