Avanti BCAD680 User manual

BEVERAGE CENTER /ENFRIADOR DE REFRESCOS
INSTRUCTIONMANUAL
MANUAL DE INSTRUCCIONES
Model Number/ No. de Modelo: BCAD680
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS.
Lasección en español empieza en lapágina18.
Avanti Products has a policy of continuous improvement on its products and reserves the right to change materials and
specifications without notice.
Avanti Products, A Division of The Mackle Co., Inc.
P.O. Box 520604 -Miami, Florida 33152
www.avantiproducts.com

2
APPLIANCESAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and onyour appliance. Always
read and obey all safety messages.
This is the Safety Alert Symbol. This symbol alerts you to potential hazards that
can kill or injure you and others. All safety messages will follow the Safety
Alert Symbol and either the words”DANGER”, “WARNING”or“CAUTION”.
Danger means that failure to heed this
safety statement may result in severe
personal injury or death.
Warning means that failure to heed this
safety statement may result in extensive
product damage, serious personal injury, or
death.
Caution means that failure to heed this
safety statement may result in minor or
moderate personalinjury, or property or
equipment damage.
Allsafetymessageswill alert you to know what the potential hazard is, tell you how to reduce the
chance of injury, and let you know what can happen if the instructions are not followed.

3
IMPORTANT SAFEGUIDES
Before theappliance is used, it must be properly positioned and installedas
described in this manual, so read the manual carefully. To reduce the risk of fire,
electrical shock or injury when using the appliance, follow basic precaution,
including the following:
?Plug into a grounded 3 -prong outlet, do not remove grounding prong, do not use an adapter, and
do not use an extension cord.
?Replace all panels before operating.
?It is recommended that a separate circuit, serving only yourappliance be provided. Use
receptacles that cannotbe turned off by a switch or pull chain.
?Never clean appliance parts with flammable fluids. These fumes can create a fire hazard or
explosion. And do not store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance. The fumes can create a fire hazard or explosion.
?Before proceeding with cleaning and maintenance operations, make sure the power line of the
unit is disconnected.
?Do not connect or disconnect the electric plug when your hands are wet.
?Unplug the appliance or disconnect power before cleaning or servicing. Failure to do so can result
in electricalshockordeath.
?Do not attempt to repair or replace any part of your appliance unless it isspecifically
recommended in thismanual. All other servicing should be referred to a qualified technician.
FOLLOW WARNING CALL OUTS BELOW ONLY WHEN APPLICABLE TO YOUR MODEL
?Use two or more people to move and installappliance. Failure to do so can result in back or other
injury.
?To ensure proper ventilation for your appliance, the front of the unit mustbe completely
unobstructed. Choose a well-ventilated area with temperatures above 60°F (16°C) and below
90°F(32°C). This unit must be installed in an area protected from the element, such as wind, rain,
water spray or drips.
?The applianceshould not be located next to ovens, grills or other sources of high heat.
?The appliancemust be installed with all electrical, water and drain connections in accordance with
state and local codes. A standard electrical supply (115 V AC only, 60 Hz), properly grounded in
accordance with the National Electrical Code and local codes and ordinances is required.
?Do not kink or pinch the power supply cord ofappliance.
?The fuse (or circuit breaker) size should be 15 amperes.
?It is important for the appliance to be leveled in order to work properly. You may need to make
several adjustments to level it.
?All installation must be in accordance with local plumbing code requirements.
?Make certain that the pipes are not pinched or kinked or damaged duringinstallations.
?Check for leaks after connection.
?Never allow children to operate, play with or crawl inside theappliance.
?Although the unit has been tested at the factory, due to long-term transit and storage, the first
batch of cubes must be discarded.
?Do not use solvent-based cleaning agents of abrasives on the interior. These cleaners may
damage or discolor the interior.
?Do not use this apparatus forother than its intended purpose.
REGISTRATION INFORMATION

4
Thank you for purchasing this fine Avanti products. Please fill out thisform and return it within 100
days of purchase and receive theseimportant benefits to the following address:
Avanti Products, A Division of The Mackle Co., Inc.
P.O. Box 520604-Miami, Florida 33152 USA
?Protect your product:
We will keep the model number and date of purchase of your new Avanti Products product on
file to help you refer to this information in the event of an insurance claim such as fire or theft.
?Promote better products:
We value your input. Your responses will help us develop products designed to best meet
your future needs.
----------------------------------------------------------(detachhere)----------------------------------------------------------
Avanti Registration Form
__________________________________ _____________________________________
Name Model # Serial #
__________________________________ _____________________________________
Address Date Purchased Store/Dealer Name
__________________________________ ______________________________________
City State Zip Occupation
__________________________________ As Your Primary Residence, Do You:
Area Code Phone Number ?Own ?Rent
Did You Purchase An Additional Warranty: Your Age:
?Extended ?Food Loss ?None ?under 18 ?18-25 ?26-30
Reason For Choosing This Avanti Product: ?31-35 ?36-50 ?over 50
Please indicate the most important factors Marital Status:
that influenced your decision to purchase ?Married ?Single
this product. Is This Product Used In The:
?Price ?Home ?Business
?Product Features How Did You Learn About This Product:
?Avanti Products Reputation ?Advertising
?Product Quality ?In Store Demo ?Personal Demo
?Salesperson Recommendation ?Other_______________________________
?Friend/Relative Recommendation Comments____________________________
?Warranty _____________________________________
?Other_______________________ _____________________________________

5
HELP US HELP YOU...
Read this guide carefully.
It is intended to help you operate and maintain
your newbeverage center properly.
Keep it handy to answer your questions.
If you don't understand something or you
need more assistance, please call:
Avanti Customer Service
800-220-5570
Keep proof of original purchase date (such as
your sales slip) with this guide to establish the
warranty period.
Write down the model and serial numbers.
You'll find them on a plate located on the rear
outside wall of the beveragecenter.
Please write these numbers here:
____________________________________
Date of Purchase
____________________________________
Model Number
____________________________________
Serial Number
Use these numbers in any correspondence or
service calls concerning your beverage center.
If you received a damaged beverage center,
immediately contact the dealer (or builder) that
sold you the beverage center.
Save time and money. Before you call for
service, check the Troubleshooting Guide. It
lists causes of minor operating problems that
you can correct yourself.
IF YOU NEED SERVICE
We're proud of our service and want you to be
pleased. If for some reason you are not happy
with the service you receive, here are some
steps to follow for further assistance.
FIRST, contact the people who serviced your
beverage center. Explain why you are not
pleased. In most cases, this will solve the
problem.
NEXT, if you are still not pleased, write all the
details, including your telephone number, and
send it to:
Customer Service
Avanti Products
10880 NW 30 Street
Miami, FL 33172 USA
CAUTION
:
THIS BEVERAGECENTER IS
NOT DESIGNED FOR THE
STORAGE OF MEDICINE OR
OTHER MEDICAL PRODUCTS.

6
PARTS & FEATURES
1. LIGHT SWITCH
2. DIGITAL CONTROL PANEL
3. GLASS DOOR
4. SHELVES (TOTAL 5)
5. BOTTOMGRILLE
6. SECURITY LOCK
7. REAR CASTERS WITHOUT BRAKES (2)
8. CABINET
9. FRONT CASTERS WITH BRAKES (2)
10. INTEGRATED HANDLE
11. RIGHT UPPER HINGE

7
TABLE OF CONTENTS
Appliance Safety 2
Important Safeguides 3
RegistrationInformation ________________________________________________________ 4
Help Us Help You…_____________________________________________________________ 6
Parts And Features _____________________________________________________________ 7
Important Safety Instructions ____________________________________________________ 9
Installation Instructions _________________________________________________________ 9
Before Using Your Beverage Center ______________________________________________ 9
Installing Your Beverage Center__________________________________________________ 9
Electrical Connection__________________________________________________________10
Extension Cord 10
Reversing The Door Swing Of Your Appliance 10
Operating Your Beverage Center ________________________________________________10
Setting The Temperature Control _______________________________________________11
Interior Light 11
Door Lock 11
Shelves 11
Care And Maintenance 12
Replacing Your Fluorescent Light 12
Cleaning Your Beverage Center 12
Power Failure 13
Vacation Time_________________________________________________________________13
Moving Your Beverage Cooler 13
Energy Saving Tips____________________________________________________________13
Troubleshooting Guide ________________________________________________________14
Service For Your Beverage Center_______________________________________________15
Your Product Warranty_________________________________________________________16
Wiring Diagram _______________________________________________________________17
INSTRUCCIONES EN ESPAÑOL______________________________________________18~20

8
IMPORTANT SAFETY INSTRUCTIONS
?WARNING? To reduce the risk of fire, electrical shock,
or injury when using your appliance, follow
these basic precautions:
?Read all instructions before using the beverage center.
?DANGER or WARNING: Risk of child entrapment.
Child entrapment and suffocation are not problems of the past. Junked or abandoned
appliances are still dangerous . . . even if they will “just sit in the garage a few days”.
?Before you throw away your old beverage center: Take off the door. Leave the
shelves in place so that children may not easily climb inside.
?Never allow children to operate, play with, or crawl inside the appliance.
?Never clean appliance parts with flammable fluids. The fumes can create a fire
hazard or explosion.
?Do not store or use gasoline or any other flammable vapors and liquids in the vicinity
of this or any other appliance. The fumes can create a fire hazard or explosion.
-Save these instructions-
INSTALLATION INSTRUCTIONS
?Before Using Your Beverage Center
?Remove the exterior and interior packing. Read the Installer’s directions.
?Check to be sure you have all of the following parts:
?5Shelves
?2 Keys
?1 Left Upper Door Hinge for Door Opening from the Right Side
?1 Instruction Manual
?4 Casters
?Before connecting the beverage center to the power source, let it stand upright for
approximately 2 hours. This will reduce the possibility of a malfunction in the cooling system
from handling during transportation.
?Clean the interior surface with lukewarm water using a soft cloth.
?Installation of Your Beverage Center
?This appliance is designed to be free standing installation only, and should not be recessed or
built-in.
?Place your beverage center on a floor that is strong enough to support it when it is fully
loaded.
?Locate the beverage center away from direct sunlight and sources of heat (stove, heater,
radiator, etc.). Direct sunlight may affect the acrylic coating and heat sources may increase
electrical consumption. Extreme cold ambient temperatures may also cause the unit not to
perform properly.
?Avoid locating the unit in moist areas.
?Plug the beverage center into an exclusive, properly installed-grounded wall outlet. Do not
under any circumstances cut or remove the third (ground) prong from the power cord. Any
questions concerning power and/or grounding should be directed toward a certified electrician
or an authorized Avanti Products service center.

9
?Electrical Connection
This appliance should be properly grounded for your safety. The power cord of this appliance is
equipped with a three-prong plug which mates with standard three prong wall outlets to minimize the
possibility of electricalshock.
Do not under any circumstances cut or remove the third ground prong from the power cord supplied.
For personal safety, this appliance must be properly grounded.
This appliance requires a standard 115/120 Volt AC ~/60Hz electrical ground outlet with three-prong.
Have the wall outlet and circuit checked by a qualified electrician to make sure the outlet is properly
grounded. When a standard 2-prong wall outlet is encountered, it is your responsibility and obligation
to have it replaced with a properly grounded 3-prong wall outlet.
The cord should be secured behind the appliance and not left exposed or dangling to prevent
accidental injury.
The appliance should always be plugged into its own individual electrical outlet which has a voltage
rating that matches the rating label on the appliance. This provides the best performance and also
prevent overloading house wiring circuits that could cause a fire hazard from overheated. Never
unplug the appliance by pulling the power cord. Always grip the plug firmly and pull straight out from
the receptacle. Repair or replace immediately all power cords that have become frayed or otherwise
damaged. Do not use a cord that shows cracks or abrasion damage along its length or at either end.
When moving the appliance, be careful not to damage the power cord.
?Extension Cord
Because of potential safety hazards under certain conditions, it is strongly recommended that you do
not use an extension cord with this appliance. However, if you must use an extension cord itis
absolutely necessary that it be a UL/CUL-Listed, 3-wire grounding type appliance extension cord
having a grounding type plug and outlet and that the electrical rating of the cord be 115 volts and at
least 10 amperes.
?Reversing the Door Swing of Your Appliance
This appliance has the capability of the door opening from either the left or right side. The unit is
delivered to you with the door opening from the left side. Should you desire to reverse the opening
direction, please call service for reversal instructions.
OPERATING YOUR BEVERAGE CENTER
It is recommended you install the Beverage Center in a place where the ambient temperature is
between 72-78 degrees Fahrenheit. If the ambient temperature is above or below recommended
temperatures, the performance of the unit may be affected. For example, placing your unit in extreme
cold or hot conditions may cause interior temperatures to fluctuate. The range of 34-43 degrees
Fahrenheit may not be reached.
Also, there is temperaturevariancebetweenthe top and bottom shelves of the appliance.
?
Warning
?
Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is
damaged, have it replaced by an authorized Avanti Products service center.

10
?Setting the Temperature Control
?You can set the temperature as you desire by pushing the UP or DOWN button. When you push
the two buttons for the first time, the LED readout will show the original temperature set at
previous time (the temperature preset at the factory is38ºF).
?The temperature that you desire to set will increase 1ºF or 1ºC if you push the UP button once, on
the contrary the temperature will decrease 1ºF or 1ºC if you push the DOWNbuttononce.
?The range of the temperature control is from 34ºF to 43ºF.
?You can select temperature display setting from Fahrenheit to Celsius degree by pushing the UP
and DOWNbutton at the same time for 5 seconds. Fahrenheit and Celsius degrees indicator will
appear in green color in the “SET” window.
?The temperature inside the unit will be appear in red color in the “DISPLAY” window.
NOTE:
?If the unit is unplugged, power lost, or is turned off, you must wait 3 to 5 minutes before restarting
the unit. If you attempt to restart before this time delay, the appliance will not start.
?Interior Light
The light switch is located on the right of control panel. You can turn the interior light ON or OFF by
pressing the light switch.
?Door Lock
Your unit is provided with a lock and key combination.
The keys are located inside the plastic bag that contains the User’s Guide. Insert the key into the lock
and turn it counterclockwise to unlock the door. To lock the door do the reverse operation making
sure metal pin is engaged completely. Remove the key and place it in a secure place for safekeeping.
?Shelves
?To prevent damaging the door gasket, make sure to have the door all the way opened when
pulling shelves out of the rail compartment.
?For easy access to the storage content, you must pull the shelves approximately 1/3 out of the rail
compartment, however this unit was designed with a plastic post on each sides of the shelf tracks
to prevent bottles from falling.
IMPORTANT SAFEGUARDS
Do not store food in Beverage Center, as interior temperature may not get cool enough to prevent
spoilage.
As a natural result of condensation, in summer months or areas of high humidity, the glass door
may build up moisture on the outside. Just wipe it away.

11
?When removing any of these shelves out of the rail compartment, you must first disassemble and
remove both of the plastic posts after removing the Phillips screws that holds each post in place.
See figure "AA"
FIG "AA"
CARE AND MAINTENANCE
?Replacing Your Fluorescent Light
NOTE:
All parts removed must be saved to do the replacement of the fluorescent light.
Before removing the fluorescent light, either turn off the appliance or disconnect the electricity
leading into the appliance at the main power supply. Failure to do so could result in electrical
shock or personal injury.
?Turn off the fluorescentlight switch.
?Pull down to remove the fluorescent light cover (3) softly.
?Rotate the fluorescent light (2) 90°and pull down softlyto remove it from the light holder (1).
?Replace with a T-5 fluorescent light that is the sameshape and size.
?Replace the lightcover (3).
1. Light Holder
2. Fluorescent Light T5 (8 Watts)
3. Light Cover
?Cleaning Your Beverage Center
?Unplug the appliance, and remove all items including shelves.
?Wash the inside surfaces with a warm water and baking soda solution. The solution should be
about 2 tablespoons of baking soda to a quart of water.

12
?Wash the shelves with a mild detergent solution.
?Wring excess water out of the sponge or cloth when cleaning area of the controls, or any
electrical parts.
?Wash the outside cabinet with warm water and mild liquid detergent. Rinse well and wipe dry with
a clean soft cloth.
CAUTION
Failure to unplug the appliance could result in electrical shock or personal injury.
?Power Failure
?Most power failures are corrected within a few hours and should not affect the temperature of
your appliance if you minimize the number of times the door is opened. If the power is going to be
off for a longer period of time, you need to take the proper steps to protect your contents.
?Vacation Time
?Short vacations: Leave the beverage center operating during vacations of less than three
weeks.
?Long vacations: If the appliance will not be used for several months, remove all items and turn
off the appliance. Clean and dry the interior thoroughly. To prevent odor and mold growth, leave
the door open slightly: blocking it open if necessary.
?Moving Your Beverage Center
?Remove all items.
?Securely tape down all loose items (shelves) inside your appliance.
?Tape the door shut.
?Be sure the appliance stays secure in the upright position during transportation. Also protect
outside of appliance with a blanket, or similar item.
?Energy Saving Tips
?The beverage center should be located in the coolest area of the room, away from heat producing
appliances, and out of the direct sunlight.

13
PROBLEMS WITH YOUR BEVERAGE CENTER?
You can solve many common beverage center problems easily, saving you the cost of a possible
service call. Try the suggestions below to see if you can solve the problem before calling the servicer.
TROUBLESHOOTING GUIDE
PROBLEM POSSIBLE CAUSE
Appliance does not operate. Not plugged in.
The circuit breaker tripped or a blown fuse.
Applianceis not cold enough. Check the temperature control setting.
External environment may require a cooler
setting.
The door is opened too often.
The door is not closed completely.
The door gasket does not seal properly.
Turns ON and OFF frequently. The room temperature is hotter than normal.
A large amount of contents has been added to
the appliance.
The door is opened too often.
The door is not closed completely.
The temperature control is not set correctly.
The door gasket does not seal properly.
The light does not work. Not plugged in.
The circuit breaker tripped or a blown fuse.
The fluorescent tube has burned out.
The ballast has burned out.
Light switch is OFF.
Vibrations. Check to assure that the appliance is level.
The appliance seems to make too much noise. The rattling noise may come from the flow of the
refrigerant, which is normal.
As each cycle ends, you may hear gurgling
sounds caused by the flow of refrigerant in your
appliance.
Contraction and expansion of the inside walls
may cause popping and crackling noises.
The appliance is not level.
The door will not close properly. The appliance is not level.
The door was reversed and not properly installed.
The gasket is dirty.
The shelves are out of position.

14
SERVICE FOR YOUR BEVERAGE CENTER
We are proud of our customer service organization and the network of professional service
technicians that provide service on your Avanti appliances. With the purchase of your Avanti
appliance, you can have the confidence that if you ever need additional information or assistance, the
Avanti Products Customer Service team will be here for you. Just call us toll-free.
AVANTI PRODUCTS CUSTOMER SERVICES
Product Information
800-323-5029 Whatever your questions are about our products, help is available.
Part Orders
800-220-5570 You may order parts and accessories that will be delivered directly to your home by personal
check, money order, Master Card, or Visa.
In-Home Repair Service
800-220-5570 An Avanti Products authorized service center will provide expert repair service, scheduled at a time
that is convenient for you. Our trained servicers
know your appliance inside and out.

15
YOUR Avanti Products WARRANTY Staple your sales receipt here. Proof of
original purchase date is needed to obtain
service under warranty.
WHAT IS COVERED
LIMITED ONE-YEAR
WARRANTY
For one year from the date of
purchase by the original owner, Avanti
Products will, at its option, repair or
replace any part of the unit, which
proves to be defective in material or
workmanship under normal use.
During this period Avanti Products will
provide all parts and labor necessary
to correct such defects free of charge,
so long as the unit has been installed
and operated in accordance with the
written instructions in this manual. In
rental or commercial use, the warranty
period is 90 days. All Avanti
Appliances of 3.5 cubic feet capacity
or less must be brought/sent to the
appliance service shop for repair.
?Content losses of food or other, due to
spoilage.
?Incidental or consequential damages.
?Parts and labor costs for the following will
not be considered as warranty:
?Door springs, and/or frames.
?Inner door panels, door rails and/or door
supports.
?Lightbulbsand/or plastic housing.
?Plastic cabinet liners.
?Punctured evaporator that voids the
warranty on the complete sealed system.
LIMITED SECOND THROUGH
FIFTH YEAR WARRANTY
For the second through the fifth year from date
of original purchase, Avanti Products will
provide a replacement compressor free of
charge due to a failure. You are responsible
for the service labor and freight charges. In
rental or commercial use, the limited
compressor warranty is one year and nine
months. Cost to move the appliance to the
servicers’ shop and back to the user's home,
as may be required, are the user's
responsibility.
?Repairs performed by unauthorized
servicers.
?Service calls that do not involve defects in
material or workmanship such as
customer education, door reversal, or
proper installation.
?Service calls that are related to external
problems, such as abuse, misuse,
inadequate electrical power, accidents,
fire, floods, or acts of God.
?Replacement of house fuses or resetting
circuit breakers.
?Failure of the product if it is used for other
than its intended purpose.
?This warranty does not apply outside the
Continental USA.
WHAT IS NOT COVERED

16
WIRING DIAGRAM

17
INSTRUCCIONES DE SEGURIDAD
ATENCION
INSTRUCCIONES PARA
LA CONEXION A TIERRA
Este aparato electrodoméstico debe estar conectado a tierra. En caso de un cortocircuito eléctrico, la
conexión a tierra reduce el riesgo de choque eléctrico proporcionando un cable a tierra con una
enchufe de conexión a tierra. Este enchufe debe estar conectado en un tomacorriente instalado
correctamente y conectado a tierra.
ADVERTENCIA –El uso inadecuado del enchufe de conexión a tierra puede resultar en un riesgo de
choque eléctrico. Consulte con un electricista o persona de reparaciones competente si no
comprenden bien lasinstrucciones de conexión a tierra o si existe alguna duda sobre si el aparato
esta conectado a tierra correctamente.
NO USE CABLES PARA
EXTENDER EL CORDON ELECTRICO DE LA UNIDAD.
Use un tomacorriente de pared exclusivo. No conecte su unidad a cables para extender el cordon
eléctrico o junto a cualquier otro electrodoméstico en el mismo tomacorriente de pared.
ADVERTENCIA IMPORTANTE:
Una unidad vacía es una atracción muy peligrosa para los niños. Saque todas las juntas,
pestillos, tapas o puerta de todo electrodoméstico que no esté en uso, o tome alguna
medida para asegurar que no presente peligro.
INSTRUCCIONES DE INSTALACION
Saque los embalajes exteriores, limpie bien el exterior con un paño suave seco, y el interior con un
paño húmedo y tibio. Evite colocar la unidad cerca de una fuente de calor, luz de sol directa, o lugar
húmedo.
Lea el papel con direcciones para el instalador.
Ubicación
1. Seleccione un lugar con su piso fuerte y nivelado.
2. Evite la luz directa del sol o calor. La luz directa del sol puede afectar la capa de acrílico.
Las fuentes de calor en su proximidad provocarán un consumo mayor de electricidad.
Operación
?El enfriador de vino viene programado de fábrica a 38ºF(3 a 4ºC).
?Cuando Ud presiona los dos botones por primera vez, la pantalla marcada “DISPLAY” enseñará
la temperatura programada la vez anterior. En este caso será 38ºF (3 a 4ºC).
?La temperatura deseada podría aumentarla 1 grado Centígrado o Fahrenheit oprimiendo el botón
marcado “UP” una vez sucesivamente o podría bajarla oprimiendo el botón marcado “DOWN”.
?Al conectar su unidad por primera vez, puede haber una variante de varios grados entre la
temperatura seleccionada y laindicada en la pantalla digital. Esto es normal y es debido al largo
periodo de actividad y desactivación.
?También puede cambiar de gradosCentígrados a Fahrenheit o viceversa, oprimiendo el botón
“UP” y “DOWN” a la misma vez por 5 segundos. F óC gradosaparecerán en la pantalla
marcada “SET” en color verde.
?La temperatura dentro de la unidad aparecerá en la pantalla marcada “DISPLAY” en color rojo.

18
Cerradura de la puerta
Su unidad viene equipada con una combinación de cerradura y llave.
Las llaves (2) están dentro de labolsa plástica junto al manual de instrucciones.
Introduzca la llave en la cerradura y gírela hacia la izquierda para abrir la puerta.
Para cerrarla, gire la llave hacia la derecha.
Quite la llave y colóquela en un lugar seguro para evitar que se pierda.
Descongelación
Su refrigerador para refrescos ha sido diseñado con un sistema de descongelación de “ciclo
automático”.
Las superficies refrigeradas del compartimiento para refrescos se descongela automáticamente,
durante el ciclo “apagado” del control de enfriamiento (termostato). El agua descongelada del
compartimiento es eliminada automáticamente, encauzándola hacia una bandeja de goteo ubicada
sobre el compresor. La transferencia de calor del compresorhacia la bandejaevapora elagua.
CUIDADO Y MANTENIMIENTO
Limpieza
Para limpiar el interior, use un paño suave con una solución de una cucharada de bicarbonato de
sodio por cada cuarto de agua, o una solución de espuma de jabón suave, o un detergente suave.
Para lavar las rejillas, sáquelas deslizándolas con cuidado, y use una solución de detergente suave;
luego séquelas con un paño suave. Limpie el exterior con un paño húmedo suave y un poco de
detergente suave o productos de limpieza para electrodomésticos.
Período de vacaciones
Para períodos cortos de vacaciones, deje los controles en la posición normal. Durante ausencias
más largas;
(a) saque todas las botellas o latas.
(b) desconecte la unidad del tomacorriente.
(c) limpie bien el refrigerador para refrescos.
(d) deje la puerta abierta para evitar la formación de condensación, moho u olores.
Corte de corriente
La mayoría de los cortes de corriente se corrigen en una o dos horas y no afectarán las temperaturas
de su unidad. Sin embargo, Ud. deberá reducir la cantidad de veces que abrala puerta cuando la
corriente esté apagada.
Si Ud. se muda
Saque yasegure todos los artículos de su unidad.
CAMBIO DE LA BOMBILLA
Antes de cambiar la bombilla, apague el electrodoméstico o desconecte el enchufe de la pared.
?Mueva el interruptor de la luz hacia la posición OFF.
?Empuje hacia abajo la cubierta plástica.
?Saque el bombillo.Mire el dibujo en la página 12.
?Reemplace el bombillo con uno, que seadel mismo poder y forma.
?Coloque la cubierta plástica de nuevo. Mire el dibujo en la página 12.

19
Algunas reglas importantes para el uso correcto de la unidad.
?Las bebidas se deben guardar en botellas o latas cerradas.
?No sobrecargue el compartimiento interior.
?No abra la puerta a menos que sea necesario.
?Si la unidad se guardara sin uso por períodos largos, se sugiere que, luego de una limpieza
cuidadosa, se deje la puerta entreabierta para permitir que el aire circule dentro de la unidad y
evitar una posible formación de condensación, moho u olores.
?Nunca cubra los estantes del compartimiento para refrescos con papel de aluminio o cualquier
otro material para cubrir estantes que puedan obstruir la circulación del aire.
PRINTED IN CHINA
