Avanti RM806W User manual

INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
Model Number / No. de Modelo: RM806W
REFRIGERATOR
(REFRIGERADOR)
CAUTION:
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS.
La sección en español empieza en la págína 19
Avanti has a policy of continuous improvement on its products and reserves the right to change materials and specifications without notice.
Avanti Products, A Division of The Mackle Co., Inc.
P.O. Box 520604-Miami, Florida 33152
www.avantiproducts.com

2

3
REFRIGERATOR SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manualfor your appliance. Always read
and obey all safety messages.
This is the Safety Alert Symbol. This symbol alerts you to potential hazards that
can kill or injure you and others. All safety messages will follow the Safety
Alert Symbol and either the words”DANGER”, “WARNING”or“CAUTION”.
Danger means that failure to heed this
safety statement may result in severe
personal injury or death.
Warning means that failure to heed this
safety statement may result in extensive
product damage, serious personal injury, or
death.
Caution means that failure to heed this
safety statement may result in minor or
moderate personalinjury, property or
equipment damage.
Allsafetymessageswill alert you to know what potential hazard is, tell you how to reduce the chance
of injury, and let you know what can happen if the instructions are not followed.

4
IMPORTANT SAFEGUIDES
Before the refrigerator is used, it must be properly positioned and installed as
describedinthis manual,so read the manual carefully. To reduce the risk of fire,
electrical shock or injury when using the refrigerator, follow basic precaution,
including the following:
?Plug into a grounded 3 -prong outlet, do not remove groundingprong, do not use an adapter, and
do not use an extension cord.
?It is recommended that a separate circuit, serving only your refrigerator be provided. Use
receptacles that cannotbe turned off by a switch or pull chain.
?Never clean refrigerator parts with flammable fluids. These fumes can create a fire hazard or
explosion. And do not store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance. The fumes can create a fire hazard or explosion.
?Before proceeding with cleaningand maintenance operations, make sure the power line of the
unit is disconnected.
?Do not connect or disconnect the electric plug when your hands are wet.
?Unplug the refrigerator or disconnect power before cleaning or servicing. Failure to do so can
resultin electrical shock or death.
?Do not attempt to repair or replace any part of your refrigerator unless it is specifically
recommended in this manual. All other servicing should be referred to a qualified technician.
FOLLOW WARNING CALL OUTS BELOW ONLY WHEN APPLICABLE TO YOUR MODEL
?Use two or more people to move and install refrigerator. Failure to do so can result in back or
other injury.
?To ensure proper ventilation for your refrigerator, the front of the unit must be completely
unobstructed. Choosea well-ventilated area with temperatures above 60°F (16°C) and below
90°F(32°C). This unit must be installed in an area protected from the element, such as wind, rain,
water spray or drips.
?The refrigerator should not be located next to ovens, grills or other sources of high heat.
?The refrigerator must be installed with all electrical, water and drain connections in accordance
with state and local codes. A standard electrical supply (115 V AC only, 60 Hz), properly
grounded in accordance with the National Electrical Code and local codes and ordinances is
required.
?Do not kink or pinch the power supply cord of refrigerator.
?The fuse (or circuit breaker) size should be 15 amperes.
?It is important for the refrigerator to be leveled in order to work properly. You may need to make
several adjustments to level it.
?All installation must be in accordance with local plumbing code requirements.
?Make certain that the pipes are not pinched or kinked or damaged duringinstallations.
?Check for leaks after connection.
?Never allow children to operate, play with or crawl inside the refrigerator.
?Although the unit has been tested at the factory, due to long-term transit and storage, the first
batch of cubes must be discarded.
?Do not use solvent-based cleaning agents of abrasives on the interior. These cleaners may
damage or discolor the interior.
?Do not use this apparatus for other than its intended purpose.

5
RegistrationInformation
?Protect your product:
We will keep the model number and date of purchase of your new Avanti product on file to
help you refer to this information in the event of an insurance claim such as fire or theft.
?Promote better products:
We value your input. Your responses will help us develop products designed to best meet
your future needs.
---------------------------------------------------------(DetachHere)----------------------------------------------------------
Avanti Registration Card
__________________________________ _____________________________________
Name Model # Serial #
__________________________________ _____________________________________
Address Date Purchased Store/Dealer Name
__________________________________ ______________________________________
City State Zip Occupation
__________________________________ As Your Primary Residence, Do You:
Area Code Phone Number ?Own ?Rent
Did You Purchase An Additional Warranty: Your Age:
?Extended ?Food Loss ?None ?under 18 ?18-25 ?26-30
Reason For Choosing This Avanti Product: ?31-35 ?36-50 ?over 50
Please indicate the most important factors Marital Status:
that influenced your decision to purchase ?Married ?Single
this product. Is This Product Used In The:
?Price ?Home ?Business
?Product Features How Did You Learn About This Product:
?Avanti Reputation ?Advertising ?Product Features
?Product Quality ?In Store Demo ?Personal Demo
?Salesperson Recommendation ?Other______________________________
?Friend/Relative Recommendation Comments____________________________
?Warranty _____________________________________
?Other_______________________ _____________________________________

6

7
HELP US HELP YOU...
Read this guide carefully.
It is intended to help you operate and maintain
your new appliance properly.
Keep it handy to answer your questions.
If you don't understand something or your
need more help, please call:
Avanti Customer Service
800-220-5570
Keep proof of original purchase date (such as
your sales slip) with this guide to establish the
warranty period.
Write down the model and serial numbers.
You'll find them on a plate located on the
inside left wall the appliance.
Please write these numbers here:
____________________________________
Date of Purchase
____________________________________
Model Number
____________________________________
SerialNumber
Use these numbers in any correspondence or
service calls concerning your appliance.
If you received a damaged appliance,
immediately contact the dealer (or builder) that
sold you the appliance.
Save time and money. Before you call for
service, check the Troubleshooting Guide. It
lists causes of minor operating problems that
you can correct yourself.
IF YOU NEED SERVICE
We're proud of our service and want you to be
pleased. If for some reason you are not happy
with the service you receive, here are some
steps to follow for further help.
FIRST, contact the people who serviced your
appliance. Explain why you are not pleased. In
most cases, this will solve the problem.
NEXT, if you are still not pleased, write all the
details, including your telephone number, and
send to:
Customer Service
Avanti Products
10880 NW 30 Street
Miami, FL 33172
CAUTION
:
THIS APPLIANCE IS NOT
DESIGNED FOR THE STORAGE
OF MEDICINE OR OTHER
MEDICALPRODUCTS.

8
PARTS & FEATURES
1Freezer Compartment
2Temperature Control and Light
3Refrigerator Glass Shelves (4)
4Glass Crisper Cover
5Vegetable Crisper
6Leveling Legs (2)
7Egg Trays (2)
8Door Bins (4)
9Bottle Retainer
10 Bottle Door Bin
1
3
4
5
6
7
8
9
10
2

9
Table of Contents
Refrigerator Safety 3
Important Safeguides 4
Registration Information and Registration Card 5
Help Us Help You 7
Parts and Features 8
Important Safety Instructions 10
Installation Instructions 10
Before Using Your Appliance 10
Installation of Your Appliance 10
Electrical Connection 11
Reversing the Door Swing of Your Appliance 11
Operating Your Appliance 11
Temperature Control 11
Interior Light 11
Defrosting Your Appliance 12
Using Your Ice Cube Trays 12
The Freezer Compartment 12
Care and Maintenance 13
Cleaning Your Appliance 13
Maintenance of Your Appliance 13
Changing the Light Bulb 13
Moving Your Appliance 13
Energy Saving Tips 14
Troubleshooting Guide 15
Service for Your Appliance 16
Your Avanti Products Warranty17
Wiring Diagram 18
Instrucciones en Español 19 -24

10
Important Safety Instructions
?WARNING? To reduce the risk of fire, electrical shock,
or injury when using your appliance, follow
these basic precautions:
?Read all instructions before using the appliance.
?DANGER or WARNING: Risk of child entrapment.
?Child entrapment and suffocation are not problems of the past. Junked or
abandoned appliances are still dangerous. . . even if they will “just sit in the garage a
few days.”
?Before you throw away your old refrigerator or freezer:
Take off the doors.
Leave the shelves in place so that children may not easily climbinside.
?Never allow children to operate, play with, or crawl inside the appliance.
?Never clean appliance parts with flammable fluids. The fumes can create a fire
hazard or explosion.
?Do not store or use gasoline or any other flammable vapors and liquids in the vicinity
of this or any other appliance. The fumes can create a fire hazard or explosion.
-Save these instructions-
INSTALLATION INSTRUCTIONS
?Before Using Your Appliance
?Remove the exterior and interior packing.
?Check to be sure you have all of the following parts:
?1 Ice Cube Tray
?1 Plastic Scraper
?5 Door Bins
?4 Refrigerator Glassshelves
?1 Crisper
?1 Glass Crisper Cover
?1 Bottle Retainer
?2 Egg Trays
?Instruction Manual
?Before connecting the appliance to the power source, let it stand upright for approximately 2
hours. This will reduce the possibility of a malfunction in the cooling system from handling
during transportation.
?Clean the interior surface with lukewarm water using a soft cloth.
?In case the interior accessories are not correctly placed, rearrange them as described in
chapter “Parts and Features”
?Installation ofYour Appliance
?Place your appliance on a floor that is strong enough to support the appliance when it is fully
loaded. To level your appliance, adjust the legs at the frontof the appliance.
?Allow 5 inches of space between the back and sides of the appliance, which allows the proper
air circulation to cool the compressor.
?Locate the appliance away from direct sunlight and sources of heat (stove, heater, radiator,
etc.). Direct sunlight may affect the acrylic coating and heat sources may increase electrical
consumption. Extreme cold ambient temperatures may also cause the appliance not to
perform properly.
?Avoid locating the appliance in moist areas. Too much moisture in the air will cause frost to
form quickly on the evaporator requiring more frequent defrosting of the appliance.

11
?Electrical Connection
This appliance should be properly grounded for your safety. The power cord of this appliance
is equipped with a three-prong plug which mates with standard three prong wall outlets to
minimize the possibility of electrical shock.
Do not under any circumstances cut or remove the third ground prong from the power cord
supplied.
Plug the appliance into an exclusive properly installed-grounded wall outlet. Do not under any
circumstances cut or remove the third (ground) prong from the power cord. Any questions
concerning power and or grounding should be directed toward a certified electrician or an
authorized Avanti Products service center.
Use of extension cords is not recommended.
This appliance requires a standard 115/120-volt, 60Hz electrical outlet with three-prong
ground.
The cord should be secured behind the appliance and not left exposed or dangling to prevent
accidentalinjury.
?Reversing the Door Swing of Your Appliance
This appliance has the capability of either opening the door from the left or right side.
The unit is delivered to you with the door opening from the left side. Should you desire
to reverse the opening direction, please call customer service for reversal instructions.
OPERATING YOUR APPLIANCE
?Temperature Control
?Your appliance has only one control for regulating the
temperature in the fresh food and the freezer compartment.
The temperature control is located on the upper right hand
side of the fresh food section.
?The range of the temperature control is from position" 0" the
warmest to "5" the coldest.
?The first time you turn the unit on set the temperature control
to “5” or the max-position.
?After 24 to 48 hours, adjust the temperature control to the setting that best suites your needs.
The setting of “3” should be correct for home or office appliance use.
?Changes of the ambient temperature affect temperature in the interior of the appliance
(choose correct setting of the thermostat knob).
?To turn the thermostat off, turn the temperature control to "0".
NOTE:
?Turning the temperature control to "0" position stops the cooling cycle but does not shut
off the power to the appliance.
?If the unit is unplugged, power lost, or turned off; you must wait 3 to 5 minutes before
restarting the unit. If you attempt to restart before this time delay, the appliance will not
start.
?Interior Light
When you open the door the light will be ON automatically. When you close the door the
light will turn OFF automatically.
?
Warning
?
Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is
damaged, have it replaced by an authorized Avanti Products service center.

12
?Defrosting Your Appliance
?When? For the most efficient operation and minimum energy consumption, defrost the
appliance compartment when the frost on the appliance wallsis excessive or ¼ inch thick.
There is no need to defrost the refrigerator, because ice depositing on the inner back wall is
defrosted automatically. Ice is depositing on the inner back wall during the compressor
operation; later on, when the compressor is not operating ice is defrosting and water drops
collect and drain through the outlet in the inner back wall into the drain pan situated above the
compressor, from where it evaporates.
CAUTION
Do not use boiling water because it may damage the plastic parts. In addition, never
use a sharp or metallic instrument to remove frost as it may damage the cooling coils
and will void the warranty. We recommend using the plastic scraper.
?A few hours before defrosting set the thermostat to position 5, so foods are well frozen.
?Reset the thermostat to 0 position and disconnect the power supply.
?Remove the frozen food from the appliance and place it in a cooler to protect the food.
?Leave the door open for a while so that you can easy scrape off the frost.
?Use a plastic scraper but be careful not to damage the inner surfaces of the freezer.
?Wipe up the scraped frost and ice before it is completely defrosted.
?Using Your Ice Cube Trays
?Recommended thermostat setting for ice making is position 5.
?Fill the ice cube tray (two thirds of it) with cold water or with any liquid
suitable for freezing and place the tray on the bottom of the freezer to
freeze properly.
?Dry the tray, otherwise it may stick to the bottom of the freezer.
?The best method to get ice cubes out of the tray is to hold the tray
under cold tap water for a second.
?To eject the ice cubes from the trays, place over the ice bucket and twist slightly
?Freezing Fresh Foods
?Proper use of the appliance, adequately packed food, correct temperature and taking into
account hygienic precautions will substantially influence the quality of freezing the food or
storing of the frozen foods.
?Carefully select food you intend to freeze; it should be of adequate quality and suitable for
freezing.
?Use correct packaging andwrap it right.
?The packaging should be airtight and shouldn’t leak since this could cause substantial vitamin
loss and dehydration of foods.
?Foils and bags should be soft enough to tightly wrap around the foods.
?When preparing foods to be frozen, consider sanitary precautions.
?Mark packages with following data: kind and amount of foods and the date of loading.
?It is most Important that the food is frozen as quickly as possible.
?If the loading amount is too large, the quality of freezing is reduced which affects the quality of
frozen foods.
?The next time you want to freeze fresh foods, repeat the freezing procedure and be careful
that packages with fresh foods do not touch frozen packages.
?For freezing smaller amount of foods (up to 2 lbs.) there is no need to change the thermostat
setting.

13
CARE AND MAINTENANCE
?Cleaning Your Appliance
?Turn the temperature control to "0", unplug the appliance, and remove the food, shelves, and
trays.
?Wash the inside with warm water and baking soda solution. The solution should be about 2
tablespoons of baking soda to a quart of water.
?Wash the shelves and trays with a mild detergent solution. Plastic parts cannot be washed in
a dishwasher.
?Theoutside of the appliance should be cleaned with mild detergent and warm water.
?The condenser coils should be vacuumed when they are dusty or dirty.
?Clean the drain pan on the refrigerator compressor. Do not remove the drain pan.
?After cleaning, connect the appliance to power supply and reload the packages.
?Maintenance of Your Appliance
?Changing the Light Bulb
?Unplug the AC power cord from the wall.
?Remove the screw with a Phillipsscrewdriver.
?Remove the light bulb cover.
?Removethe bulb.
?Replace with a 10 watts bulb that is the same shape
and size.
?Replace the light bulb cover and tighten screw.
?Power Failure
Most power failures are corrected within a few hours and should not affect the
temperature of your appliance if you minimize the number of times the door is opened. If
the power is going to be off for a longer period of time, you need to take the proper steps
to protect your food.
?Vacation Time
During long absences, remove all the food; unplug your appliance, clean your appliance, and
leave the door slightly open to avoid possible formation of condensation, mold, or odors.
?Moving Your Appliance
?Remove all the food.
?Securely tape down all loose items inside your appliance.
?Turn the leveling screws up to the base to avoid damage.
?Tape the doors shut.
?Be sure the appliance stays in the upright position during transportation.

14
?Energy Saving Tips
?The appliance should be located in the coolest area of the room, away from heat producing
appliances or heating ducts, and out of the direct sunlight.
?Let hot foods cool to room temperature before placing in the appliance. Overloading the
appliance forces the compressor to run longer. Foods that freeze too slowly may lose quality, or
spoil.
?Be sure to wrap foods properly, and wipe containers dry before placing them in the appliance.
This cuts down on frost build-up inside the appliance.
?Appliance storage bin should not be lined with aluminum foil, wax paper, or paper toweling.
Liners interfere with cold air circulation, making the appliance less efficient.
?Organize and label food to reduce door openings and extended searches. Remove as many
items as needed at one time, and close the door as soon as possible.
?Try not to open the door too often, especially when the weather is wet and hot.
?Every so often check if the appliance is sufficiently ventilated.
?Ice and frost layer increase energy consumption, so clean the appliance as soon as the layer is
¼” thick.

15
PROBLEMS WITH YOUR APPLIANCE?
You can solve many common appliance problems easily, saving you the costof a possible service
call. Try the suggestions below to see if you can solve the problem before calling the servicer.
TROUBLESHOOTING GUIDE
PROBLEM POSSIBLE CAUSE
Appliance does not operate. Not plugged in.
The circuit breaker tripped or blown fuse.
Compressor turns on and off frequently. Condenser coil at the back of the unit is dirty.
The room temperature is hotter than normal.
A large amount of food has been added to the
appliance.
The door is open too often.
The door is not closed completely.
The temperature control is not set correctly.
The door gasket does not seal properly.
The appliance does not have the correct
clearances. (5” at both side and the back of unit)
The light does not work. The homecircuit breaker or fuse has tripped.
The appliance is unplugged.
The bulb has burned out (see the maintenance
section for the replacement procedure).
Vibrations. Check to assure that the appliance is level.
The appliance seems to make too much noise. The rattling noise may come from the flow of the
refrigerant, which is normal.
As each cycle ends, you may hear gurgling
sounds caused by the flow of refrigerant in your
appliance.
Contraction and expansion of the inside walls
may cause popping and crackling noises.
The appliance is not level.
The door will not close properly. The appliance is not level.
The doors were reversed and not properly
installed.
The gasket is dirty.
The shelves, bins, or baskets are out of position.

16
SERVICE FOR YOUR APPLIANCE
We are proud of our customer service organization and the network of professional service
technicians that provide service on your Avanti appliances. With the purchase of your Avanti
appliance, you can have the confidence that if you ever need additional information or assistance, the
Avanti Products Customer Service team will be here for you. Just call us toll-free.
AVANTI PRODUCTS CUSTOMER SERVICES
Product Information
800-323-5029 Whatever your questions are about our products, help is available.
Part Orders
800-220-5570 You may order parts and accessories that will be
delivered directly to your home.
You may order these items by personal check,
money order, Master Card, or Visa.
In-Home Repair Service
800-220-5570 An Avanti Products authorized service center will provide expert repair service, scheduled at a time
that is convenient for you. Our trained servicers
know your appliance inside and out.

17
YOUR Avanti Products WARRANTY Staple your sales receipt here. Proof of
original purchase date is needed to obtain
service under warranty.
WHAT IS COVERED
LIMITED ONE-YEAR
WARRANTY
For one year from the date of
purchase by the original owner, Avanti
Products will, at its option, repair or
replace any part of the appliance
which proves to be defective in
material or workmanship under normal
use. During this period Avanti
Products will provide all parts and
labor necessary to correct such
defects free of charge, so long as the
appliance has been installed and
operated in accordance with the
written instructions in this manual. In
rental or commercial use, the warranty
period is 90 days. All Avanti
appliances of 3.5 cubic foot capacity
or less must be brought/sent to the
applicableserviceshopforrepair.
?Content losses of food due to spoilage.
?Incidental or consequential damages.
?Parts and labor costs for the following will
not be considered as warranty:
?Evaporator doors, door springs, and/or
frames.
?Inner door panels, door shelves, door
rails, and/or door supports.
?Chest appliance lid liners.
?Vegetable crispers.
?Light bulbs and/or plastic housing.
?Plastic cabinet liners.
?Punctured evaporator that voids the
warranty on the complete sealed system.
LIMITED SECOND THROUGH
FIFTH YEAR WARRANTY
For the second through the fifth year from date
of original purchase, Avanti Products will
provide a replacement compressor free of
charge due to a failure. You are responsible
for the service labor and freight charges. In
rental or commercial use, the limited
compressor warranty is one year and nine
months. Cost to move the appliance to the
servicers’ shop and back to the user's home,
as may be required, are the user's
responsibility.
?Repairs performed by unauthorized
servicers.
?Service calls that do not involve defects in
material or workmanship such as
customer education, door reversal, or
proper installation.
?Service calls that are related to external
problems, such as abuse, misuse,
inadequate electrical power, accidents,
fire, floods, or acts of God.
?Surcharges including, but not limited to,
any after hour, weekend, or holiday
service calls, tolls, ferry trip charges, or
mileage expense for service calls to
remote areas, include the State of Alaska.
?Replacement of house fuses or resetting
circuit breakers.
?Failure of the product if it is used for other
than its intended purpose.
?This warranty does not outside the
Continental USA.
WHAT IS NOT COVERED

18
Wiring Diagram

19
?INSTRUCCIONES DE SEGURIDAD
?El model contiene R134A (el refrigerante isobutano), un gas natural respetuoso con el medio
ambiente pero también inflamable. Al transportar o instalar la unidad se debe tener cuidado de no
dañar ninguno de los componentes del sistema de refrigeración. En caso de daño se debe evitar
la exposición al fuego o fuentes de ignición y se debe ventilar la habitación en la que se
encuentra la unidad durante unos minutos.
?No utilizar aparatos mecánicos o sistemas artificiales para acelerar el proceso de
descongelamiento.
?No utilizar aparatos eléctricos en la parte de almacenaje de comida.
?Si se utiliza este aparato para sustituir a otro que cuenta con cierre se debe romper o quitar dicho
cierre como dedida de seguridad antes de guardarlo, para así evitar que los niños se queden
encerrados dentro del lugar.
?Las neveras y los congeladores viejos contienen gases aislantes y de refrigeración que se deben
eliminar adecuadamente. La eliminación de una unidad debe ser realizada por un servicio
especializado, y cualquier duda debe ser consultada a las autoridades locales o al proveedor. Es
preciso asegurarse de que los conductos de su aparato de refrigeración no resultan dañados
antes de que los recoja el equipo encargado.
AVISO IMPORTANTE:
?Por favor, lea atentamente este manual antes de proceder a la instalación y al encendido de este
aparato. El fabricante no se hará responsable de las instalaciones defectuosas o del uso
incorrecto del aparato, tal como se describe en este manual.
?RECOMENDACIONES
?No utilise adaptadores que puedan provocar el sobrecalentamiento del aparato o inclusive un
incendio.
?No utilise cables de suministro de energía viejos o deformados.
?No retuerza o doble los cables.
?No permita que los niños jueguen con el aparato. Los niños nunca deben sentarse en los
estantes ni colgarse de la puerta.
?No utilise objetos metálicos afilados para extraer el hielo del congelador: podrían perforar el
circuito del refrigerador y, provocar un daño irreparable al aparato. Utilise la espátula de plástico
suministrada.
?No enchufe el tomacorriente con las manos húmedas.
?No coloque recipientes (botellas de cristal o latas) con líquidos en el congelador, sobre todo
líquidos con gas, ya que podrían provovar que el recipiente explote durante le congelación.
?Las botellas que contengan un alto porcentaje de alcohol, deberán estar debidamente cerradas y
deben ser colocadas verticalmente en el refrigerador.
?No toque las superficies congeladas, especialmente si tiene las manos mojadas ya que podría
producir quemaduras o heridas.
?LA INSTALACION Y ENCENDIDO DEL APARATO
?Este refrigerador se conecta a 120v y 60 ciclos.
?Podrá disponer de la ayuda necesaria para instalar y poner en marcha su refrigerador sin ningún
costo adicional.
?Antes de realizar la conexión al suministro de corriente eléctrica, asegúrese de que el voltaje que
aparece en la etiqueta corresponda al voltaje del sistema eléctrico de su hogar.
?Si la clavija no sirve para las base de enchufe de que dispone, cambie la clavija del enchufe del
refrigerador a una correcta (al menos 10A).
?Inserte la clavija en la base de enchufe con una toma a tierra apropiada. Si la base de enchufe
no tiene una toma a tierra, sugerimos que llame a un electricista para que la ayude.
?El fabricante no se hace responsable por los posibles fallos al completar la toma a tierra, tal como
se describe eneste manual.
?No coloque el aparato en un lugar en el que esté expuesto a la luz directa del sol.

20
?No lo use en lugares al aire libre y no permita que se exponga a la lluvia.
?Coloque el refrigerador lejos de toda fuente de calor y en un lugar ventilado. Elrefrigerador debe
estar colocado a una distancia de por lo menos 50 cm de radiadores, estufas de gas o de carbón,
y a una distancia de 5 cm de las estufas eléctricas.
?No ponga nada encima del refrigerador, y si lo hace que sea a una distancia no menor dea 15
cm.
?Si se instala el aparato cerca de otro refrigerador o congelador, deberá comprobar que se
mantiene a una distancia entre ambos de por lo menos 5 cm con el fin de evitar procesos de
condensación.
?No introduzca en el refrigerador grandes cantidades de productos o que sean muy pesados.
?El refrigerador deberá estar colocado de manera que mantenga una posición firme y nivelada con
respecto al suelo. Utilise las dos patas niveladoras frontales para compensar suelo irregular.
?Deberá limpiar tanto la parte externa del aparato como los accesorios que encontrará en el
interior del mismo con una solución compuesta de agua y jabón líquido; para limpiar la parte
interna del aparato utilise bicarbonato de sodio disuelto en agua tibia. Después de secarlos
vuelva a colocar los accesorios en su lugar de origen.
?ANTES DEL ENCENDIDO
?Deberá esperar unas 3 horas antes de enchufar el aparato a la red eléctrica con el fin de
asegurar el correcto funcionamiento del mismo.
?Es posible que se produzca un cierto olor al encender el aparato por primera vez. Este olor
desaparece cuando el aparato haya comenzado a enfriarse.
LAS DISTINTAS FUNCIONES Y POSIBILIDADES
?AJUSTE DEL TERMOSTATO
?El termostato automáticamente regula la temperature interna en el compartimiento del
refrigerador y del congelador. Para obtener temperaturas más frías debe girar el dial del
termostato desde la posición 1 a la posición 5.
?Para la conservación de alimentos en el compartimiento del congelador durante un corto período
de tiempo, puede colocar el dial del termostato entre la posición 1 y 3.
?Para la conservación de alimentos en el compartimiento del congelador durante un período largo
de tiempo, puede colocar el dial del termostato en la posición4-5.
?Tenga en cuenta; que la temperatura ambiente, la temperatura de la comida almacenada y la
frecuencia con que se abra la puerta del aparato, afectan a la temperatura en el compartimiento
del refrigerador. Si fuera necesario, modifique la temperatura seleccionada según sea el caso.
Accesorios
Como hacer cubitos de hielo: (*)
?Jale de la bandeja hacia usted y extraiga el recipiente para cubitos de hielo.
?Rellene el recipiente con agua hast alcanzar el nivel adecuado.
?Sujete el extremo izquierdo de la bandeja y ajuste el recipiente para sacar los cubitos y pasarlos
a la caja del hielo.
No llene la caja del hielo con agua para hacer hielo en ella directamente. La
caja podría romperse.
Recipiente para hielo:
?Rellene el recipiente para hielo con agua y colóquelo en el compartimiento del congelador.
?Cuando el agua se haya transformado en hielo completamente, puede retorcer la bandeja tal
como se indica más abajo, para extraer los cubitos de hielo.
Estante para botellas: (*)
?Con el fin de evitar que botellas resbalen o se caigan, puede hacer uso del estante para botellas.
También podrá evitar el ruido que suelen producir las botellas al abrir o cerrar la puerta.
(*) SOLO EN ALGUNOS MODELOS
