NX215/ NO115B/TN115B/NX215B/D115ONB/D115OXB User Manual www.avermedia.com
AVerMedia NX215 Carrier board and
NO115B/ TN115B/ NX215B/ D115ONB/ D115OXB
Box PC
Applies to NVIDIA®Jetson Nano/TX2 NX/Xavier NX/ Orin Nano/ Orin NX module
AVerMedia Technologies, Inc.
No. 135, Jian 1st Rd., Zhonghe Dist., New Taipei City 23585, Taiwan
Tel: [phone]
Fax: [phone]
Sales and Marketing: Contact
Technical Support: Professional User

1
NX215/ NO115B/TN115B/NX215B/D115ONB/D115OXB User Manual www.avermedia.com
Table of Contents
Preface.............................................................................................................. 3
1.0 Introduction............................................................................................. 9
1.1 Product Specifications ________________________________________________ 10
1.2 OPTION ACCESSORY ______________________________________________ 12
2.0 Product Overview .................................................................................. 13
2.1 Block Diagram for Nano/TX2 NX/Xavier NX ______________________ 13
2.2 Front View and Back View of Carrier board _______________________ 16
2.3 Front View and Three-Quarter View of BoxPC ____________________ 17
2.4 Connector Summary__________________________________________________ 21
3.0 Feature Description............................................................................... 23
3.1 Jetson module Connector_____________________________________________ 23
3.2 RTC Battery Connector ______________________________________________ 23
3.3 ATX 4P _________________________________________________________________ 24
3.4 DC POWER JACK ___________________________________________________ 24
3.5 HDMI OUTPUT ______________________________________________________ 25
3.6 Micro SD Card Slot ___________________________________________________ 25
3.7 MIPI CSI-2 DPHY Lanes_____________________________________________ 26
3.8 SerDes (V-by-One® HS)______________________________________________ 27
3.9 USB 3.1 Gen 1 Type-A Connector #1 , #2, #3 _______________________ 28
3.10 Gigabit Ethernet Connector _______________________________________ 28
3.11 Jetson platform/ USB 2.0 Micro B Connector____________________ 29
3.12 RTC Battery Connector____________________________________________ 29
3.13 20-Pin GPIO expansion ____________________________________________ 30
3.14 Optional Function Selection _______________________________________ 35

2
NX215/ NO115B/TN115B/NX215B/D115ONB/D115OXB User Manual www.avermedia.com
3.15 power Recovery Button ____________________________________________ 35
3.16 Recover on Button __________________________________________________ 36
1.1 BSP Setup Instructions _______________________________________________ 37
2.0 Software ................................................................................................. 38
3.0 Force Recovery Mode............................................................................ 47
4.0 Power Consumption .............................................................................. 48
5.0 Accessory Drawings .............................................................................. 49
5.1 Fan Module/ Adapter/ Power Cord__________________________________ 49
6.0 Dimension Drawings and Assembly Drawings .................................... 57
6.1 Dimension Drawings of carrier board_______________________________ 57
6.2 Dimension Drawing of NO115B/ TN115B/ NX215B/D115OXB Box
PC58

3
NX215/ NO115B/TN115B/NX215B/D115ONB/D115OXB User Manual www.avermedia.com
Preface
Disclaimer
The information contained in this user manual, including but not limited to any product
specification is subject to change without notice. AVerMedia assumes no liability for any
damages incurred directly or indirectly from any technical or typographical errors or omissions
contained herein or for discrepancies between the product and the user manual.
Technical Support
If you experience the difficulty after reading this manual and/or using the product, please contact
the reseller from which you purchased the product. In most cases, the reseller can help you with
the product installation and the difficulty you encountered.
In case the reseller is not able to resolve your problem, our highly capable global technical
support team can certainly assist you. Our technical support section is available 24 hours a day
and 7 days a week through our website, with the click here. For more contact information, you
may find it in the section of AVerMedia Global Offices.
Contact Enquiry
For more information of our products, pricing, and order placement, please fill in our inquiry
form here, we will contact you within 24 hours.
Download User Manual
Please click the link here to download the file of this user manual from AVerMedia website.

4
NX215/ NO115B/TN115B/NX215B/D115ONB/D115OXB User Manual www.avermedia.com
Revision History
Revision
Date
Updates
Version 1.0
17 Nov, 2021
1st Released
Version 1.1
24 Nov, 2021
Update 8.0 power consumption
Version 1.2
12 Jan, 2022
Update DC power jack
Version 1.3
24 Jan, 2022
Update P9/P10 DC input range and Can bus
Version 1.4
18 Apr, 2022
Update P24 Gigabit Ethernet Connector
Version 1.5
17 May, 2022
Update P9/10/12/27/28/29/30/31/36 CAN bus
spec update
Version 1.6
31,OCt, 2022
Update Product specification/Safety Precaution
Version 1.7
23,NOV, 2022
Update Carrier Board Interface/ Contact
information
Version 1.8
18, Dec, 2022
Add D115OXB information
Version 1.9
31, March, 2023
Update D115OXB 20pin define
Version 2.0
23, May, 2023
Correct SW3/SW4 information
Version 2.1
6, July, 2023
Add D115ONB information
Version 2.2
31, July, 2023
Add instruction for how to flash BSP

5
NX215/ NO115B/TN115B/NX215B/D115ONB/D115OXB User Manual www.avermedia.com
AVerMedia Global Offices
https://www.avermedia.com/contact-us

6
NX215/ NO115B/TN115B/NX215B/D115ONB/D115OXB User Manual www.avermedia.com
Limited Product Warranty
AVerMedia provides the one-year product warranty. Should this product, in AVerMedia's
opinion, fail to be in the good working order during the warranty period, AVerMedia will, at its
option, repair or replace it at no charge, provided that the product has not been subjected to abuse,
misuse, accident, disaster, or non-AVerMedia authorized modification or repair.
You may obtain the warranty service by delivering this product to an authorized AVerMedia
business partner or to AVerMedia along with the proof of purchase. Product returned to
AVerMedia must be pre-authorized by AVerMedia with an RMA (Return Material Authorization)
number marked on the outside of the package and sent prepaid, insured, and packaged for the safe
shipment. AVerMedia will return the product by prepaid shipment service.
It is not recommended to disassemble the box PC, which will impact the warranty. The limited
product warranty is only valid over the serviceable life of the product. This is defined as the
period during which all components are available. Should the product prove to be irreparable,
AVerMedia reserves the right to substitute an equivalent product if available or to retract the
product warranty if no replacement is available.
The above product warranty is the only warranty authorized by AVerMedia. Under no
circumstances will AVerMedia be liable in any way for any damages, including any lost profits,
lost savings, or other incidental or consequential damages arising out of the use of, or inability to
use, such product.
Copyright Notice
The information contained in this document is subject to change without notice. AVerMedia shall
not be liable for errors contained herein or for incidental consequential damages in connection
with the furnishing, performance, or use of this material. This document contains proprietary
information that is protected by copyright. All rights are reserved. No part of this document may
be photocopied, reproduced, or translated to another language without the prior written consent
by AVerMedia.

7
NX215/ NO115B/TN115B/NX215B/D115ONB/D115OXB User Manual www.avermedia.com
Trademark Acknowledgement
AVerMedia acknowledges all the trademarks, registered trademarks, and/or copyrights referred to
in this document as the property of their respective owners. Not listing all possible trademarks or
copyright acknowledgments does not constitute the lack of acknowledgment to the rightful
owners of the trademarks and copyrights mentioned in this document.
ESD Warning
Electronic components and circuits are sensitive to Electrostatic Discharge (ESD). When
handling any circuit board assemblies including AVerMedia products, it is highly recommended
that ESD safety precautions can be observed. ESD safe best practices can include, but are not
limited to the following ones.
1. Leave the circuit board in the antistatic package until it is ready to be installed.
2. Use a grounded wrist strap when handling the circuit board. At a minimum, you need to touch
a grounded metal object to dissipate any static charge, which may be present on you.
3. Avoid handling the circuit board in the carpeted areas.
4. Handle the board by the edges and avoid the contact with the components.
5. Only handle the circuit boards in ESD safe areas, which may include ESD floor and/or table
mats, wrist strap stations, and ESD safe lab coats.
Safety Precaution:
1. All cautions and warnings on the device should be noted.
2. For safety consideration, do NOT open the device if not a qualified service stuff.
3. Place the device on a solid surface during installation to prevent falls.
4. Keep the device away from humidity.
5. Do NOT leave this device in an un-controlled environment with temperatures beyond the
device’s permitted storage temperature to avoid damage.
6. All adaptors and cables supplied by AVerMedia are verified. Do NOT use any others not
supplied by AVerMedia to avoid any malfunction or fires.
7. Make sure the power source matches the power rating of the device.
8. Place the power cord where people cannot step on it. Do not put anything on the power cord.
9. Always completely disconnect the power while the device is not usage or idle for a long time.
10. Disconnect the device from any AC supply before cleaning. While cleaning, use a damp cloth
instead of liquid or spray detergents.
11. Make sure the device is installed near a power outlet and easy for accessible.
12. Do not cover the openings on the device to ensure optimal heat dissipation.

8
NX215/ NO115B/TN115B/NX215B/D115ONB/D115OXB User Manual www.avermedia.com
13. Watch out the heatsink or heat spreader of the device when the system is running.
14. Never pour any liquid into the openings. This could cause fire or electric shock.
15. The static electricity should be noted while installing any internal components. Consider to
use a grounding wrist strap and put all electronic parts in static-shielded containers.
If the following situations occur, please contact our service personnel:
(1) The device is dropped or damaged
(2) Damaged power cord or plug
(3) Exposure to moisture
(4) Liquid intrusion into the device
(5) Any obvious signs of damage displayed on the device
(6) Device is not working as expected or in a manner as described in this manual

9
NX215/ NO115B/TN115B/NX215B/D115ONB/D115OXB User Manual www.avermedia.com
1.0 Introduction
AVerMedia NX215/ NO115B/ TN115B/ NX215B/ D D1115ONB/1115OXB includes fully
featured carrier board which is all developed for NVIDIA®Jetson Nano(Version B01)/ /TX2 NX/
Xavier NX /Orin Nano/ Orin NX modules. AVerMedia provide not only the access to a great list
of latest interfaces on NVIDIA®Jetson (Version B01)/ TX2 NX/ Xavier NX/Orin Nano/Orin NX
modules but also two RJ-45 interface and one RTC battery as the function enrichment.
NX215/ NO115B/ TN115B/ NX215B/ D1115OXB provide HDMI video output , two USB 3.0
ports, two GbE RJ-45 port, 20-pin GPIO expansion, and one Micro-B USB 2.0 port for recovery.
Operating with NVIDIA®Jetson Nano(Version B01)/TX2 NX/ Xavier NX/Orin Nano/ Orin NX
modules and the rich I/O functions, AVerMedia NX215/ NO115B/ TN115B/ NX215B/
D115ONB/D1115OXB is the perfect choice in building a compact, high performance AI edge
computing platform for the intelligent video analytics applications.

10
NX215/ NO115B/TN115B/NX215B/D115ONB/D115OXB User Manual www.avermedia.com
1.1 Product Specifications
Model
NX215
Type
Carrier board
NVIDIA GPU
SoC Module
Compatibility
NVIDIA® Jetson
Orin NX/Orin
Nano module
NVIDIA® Jetson
Xavier™ NX
module
NVIDIA® Jetson
TX2 NX module
NVIDIA® Jetson
NANO (B01)
module
Networking
2x GbE RJ-45
1xM.2. key E 2230 for wifi
2x GbE RJ-45
Display Output
1x HDMI 7680 x
4320 at 60Hz for
Orin NX/ 30Hz
for Orin Nano
2x HDMI 2.0 (3840 x 2160 at 60Hz)
1x HDMI 2.0
(3840 x 2160 at
60Hz)
Temperature
Operating temperature 0°C~70°C (TBD)
Storage temperature -40°C ~ 85°C
Relative humidity 40 °C @ 95%, Non-Condensing
MIPI Camera
Inputs
2x 2 lane MIPI
CSI-2, 15 pin FPC
1mm Pitch
Connector
2x 2 lane MIPI CSI-2, 15 pin FPC 1mm Pitch Connector
1x 4 lane MIPI CSI-2, 36 pin FPC 0.5mm Pitch Connector
USB
3x USB 3.0 Type-A (1xinternal)
1x USB 2.0 Micro-B for recovery
Storage
1xM.2. key M
2280 for SSD
1x micro-SD card slot
1xM.2. key M 2280 for SSD
Expansion Header
(EU terminal
block)
(PCN20220406-2)
20 pins: 2x I2C, 1x UART, 4x GPIOs, 1xCAN
20 pins: 2x I2C,
1x UART, 4x
GPIOs
Expansion Header
(EU terminal
block)
(original)
20 pins: 2x I2C, 1x UART, 4x GPIOs, 2xCAN
20 pins: 2x I2C,
1x UART, 4x
GPIOs, 1xCAN
Power
requirement
DCINJACK on board & ATX 4pin
12V/5A, 12~24V is recommended.
Power Cord
US/JP/EU/UK/TW/AU/CN
Fan Module
Heat sink with fan (optional)
Buttons
Power and Recovery
RTC Battery
Support RTC battery and Battery Life Monitoring by MCU
PCB/Electronics
Mechanical Info
120mm (W) x 90mm (L) x 26.5mm (H)
Weight: 125 g
Certifications
CE, FCC, KC

11
NX215/ NO115B/TN115B/NX215B/D115ONB/D115OXB User Manual www.avermedia.com
Model
D115OXB/D115ONB
NX215B
TN115B
NO115B
Type
Box PC
NVIDIA GPU
SoC Module
Compatibility
NVIDIA® Jetson
Orin NX/Orin Nano
module
NVIDIA® Jetson
Xavier™ NX
module
NVIDIA®
Jetson TX2
NX module
NVIDIA® Jetson
NANO (B01)
module
Networking
2x GbE RJ-45
1xM.2. key E 2230 for wifi
2x GbE RJ-45
Display Output
1x HDMI 7680 x
4320 at 60Hz for Orin
NX/ 30Hz for Orin
Nano
2x HDMI 2.0 (3840 x 2160 at 60Hz)
1x HDMI 2.0
(3840 x 2160 at
60Hz)
Temperature
Operating temperature(based on module and usage)
0°C~60°C (TBD)
0°C~60°C for 8G
0°C~50°C
0°C~60°C
Storage temperature -40°C ~ 85°C
Relative humidity 40 °C @ 95%, Non-Condensing
MIPI Camera
Inputs (Internal)
2x 2 lane MIPI CSI-2,
15 pin FPC 1mm
Pitch Connector
2x 2 lane MIPI CSI-2, 15 pin FPC 1mm Pitch Connector
1x 4 lane MIPI CSI-2, 36 pin FPC 0.5mm Pitch
Connector
USB
3x USB 3.0 Type-A (1x internal)
1x USB 2.0 Micro-B for recovery
Storage
1xM.2. key M 2280
for SSD
(SSD installed)
1x micro-SD card slot
1xM.2. key M 2280 for SSD
Expansion Header
(EU terminal
block)
(PCN20220406-2)
20 pins: 2x I2C, 1x UART, 4x GPIOs, 1xCAN
20 pins: 2x I2C,
1x UART, 4x
GPIOs
Expansion Header
(EU terminal
block)
(original)
20 pins: 2x I2C, 1x UART, 4x GPIOs, 2xCAN
20 pins: 2x I2C,
1x UART, 4x
GPIOs, 1xCAN
Power
requirement
DCINJACK on board & ATX 4pin
12V/5A, 12V~24V is recommended.
Power Cord
US/JP/EU/UK/TW/AU/CN
Fan Type
Fanless solution
Buttons
Power and Recovery
RTC Battery
Support RTC battery and Battery Life Monitoring by MCU
PCB/Electronics
Mechanical Info
W: 126mm (W) x 96mm (L) x 74mm (H)
Weight: 1kg
Certifications
CE, FCC, KC

12
NX215/ NO115B/TN115B/NX215B/D115ONB/D115OXB User Manual www.avermedia.com
1.2 OPTION ACCESSORY
Item
NX215/ NX215B/ TN115B/ NO115B/D115OXB
NVIDIA®
Jetson
NVIDIA®Jetson Orin NX for D115OXB
NVIDIA®Jetson Orin Nano for D115ONB
NVIDIA®Jetson Xavier NX for NX215B
NVIDIA®Jetson TX2 NX for TN115B
NVIDIA®Jetson Nano(Version B01) for NO115B
Power cord
EU/JP/TW/US/CN/UK/AU
MIPI Camera
(internal I/O)
⚫For 15 pin MIPI connector
1. raspberry pi camera v2/ raspberry pi camera v3
2. Manufacturer: APPRO.PHO
◼B-04: IMX179(8M)MIPI, 1080P(30fps)
◼C-04: IMX290(2M)MIPI, 1080P(30fps)
◼C-05: IMX290(2M)+ISP(YUV), 1080P(30fps)
⚫For 36 pin MIPI connector (D115OXB/D115ONB doesn’t
support)
1. Manufacturer: APPRO.PHO
◼B-03: IMX334(4K) MIPI, 4K(30fps)
◼A-06: IMX334(4K) V-by-One® HS x1,
4K(30fps)

13
NX215/ NO115B/TN115B/NX215B/D115ONB/D115OXB User Manual www.avermedia.com
2.0 Product Overview
2.1 Block Diagram for Nano/TX2 NX/Xavier NX
(PCN20220406-2)

14
NX215/ NO115B/TN115B/NX215B/D115ONB/D115OXB User Manual www.avermedia.com
(Original)
Jetson Nano/
TX2 NX/
Xavier NX

15
NX215/ NO115B/TN115B/NX215B/D115ONB/D115OXB User Manual www.avermedia.com
Block Diagram for Orin NX/Orin Nano

16
NX215/ NO115B/TN115B/NX215B/D115ONB/D115OXB User Manual www.avermedia.com
2.2 Front View and Back View of Carrier board

17
NX215/ NO115B/TN115B/NX215B/D115ONB/D115OXB User Manual www.avermedia.com
2.3 Front View and Three-Quarter View of BoxPC
Left view
Right view

18
NX215/ NO115B/TN115B/NX215B/D115ONB/D115OXB User Manual www.avermedia.com
Top view
Front view

19
NX215/ NO115B/TN115B/NX215B/D115ONB/D115OXB User Manual www.avermedia.com
Rear view
Bottom view
